peerless-AV DS-C555-4X2 User manual

12014-06-20 #:009-9085-2.1 (2014-07-28)
ENG
DS-C555-4X2
46" - 55"
(117 - 140cm)
800 lb
(363 kg)
MAX

22014-06-20 #:009-9085-2.1 (2014-07-28)
This page intentionally left blank.

32014-06-20 #:009-9085-2.1 (2014-07-28)
Heavy
(13mm)
Do not begin to install product until you have read and understood the instructions and warnings contained in
this user guide. Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
This product must be installed onto at, hard, level surface to prevent tipping. The cart or stand is not afxed or
secured to the oor, and may therefore tip over and/or fall if screen and/or stand is shaken or hit. Displays must
be removed before moving cart. Not recommended for use in areas with heavy trafc. This product is intended
for indoor use only. Use of this product outdoors could lead to product failure or personal injury. Screws must
be tightly secured. Do not overtighten screws or damage can occur and product may fail. Never exceed the
Maximum Load Capacity. Be careful not to pinch ngers when operating the mount. For support please call
customer care at 1-800-865-2112.
WARNING
To properly tighten screws: Tighten until screw
head makes contact, then tighten another 1/2
turn. Do not overtighten screws.
1
2
+1/2
4
3
Symbols
ENG
WARNING
ENG
Display center.
ENG
x3
Screws must get at
least three full turns
and t snug.
ENG
Do not overtighten screws.
ENG
Tools Needed for Assembly.
ENG

42014-06-20 #:009-9085-2.1 (2014-07-28)
Parts (Before beginning, make sure you have all parts shown below).
Parts List
Part #Description Qty
Acaster, 5" swivel 6 600-0026
Bcaster support 6 145-T1799
Ccover 9 145-T1809
Dbase leg 3 145-T1767
Ehorizontal leg support 2 145-T1785
Fbase support tube 3 145-T1812
Gbase support 12 560-T1261
Hvertical leg support 3 145-T1777
Iadaptor bracket 16 145-T1792
Jside support bracket 2 145-T1807
Kvertical support bracket 4 145-T1806
Lcomputer cover 1 145-T1930
Mcomputer shelf 1 145-T1931
Ndual cross support 4 145-T1924
Olocking tab 6 145-T1936
Pcord bracket 6 145-T1929
Qbracket, 4x2 conguration 2 145-T1858
RM8 x 16mm socket button screw 180 520-9527
SM8 square nut 108 530-1066
Tcover clip 36 590-0317
UM5 x 10mm type-f, socket pin screw 18 520-1164
VM5 x 12mm socket pin screw 6 520-1064
W1/4" power bit 1 560-0263
X5mm allen wrench 1 560-9640
Ynylon shoulder washer 32 590-2233
ZM6 x 12mm socket pin screw 32 520-1050
AA 4mm allen wrench 1 560-9646
A (6)
caster
B (6)
caster support C (9)
cover
D (3)
base leg
E (2)
horizontal leg
support
F (3)
base support
tube
H (3)
vertical leg
support
K (4)
vertical support
bracket
J (2)
side support
bracket
G (12)
base support I (16)
adaptor bracket

52014-06-20 #:009-9085-2.1 (2014-07-28)
AA (1)
4mm allen
wrench
L (1)
computer cover
P (6)
cord bracket
N (4)
dual cross
support
R (180)
M8 x 16mm S (108)
M8 square nut
T (36)
cover clip
U (18)
M5 x 10mm
W (1)
1/4" power
bit
X (1)
5mm allen
wrench
V (6)
M5 x 12mm
Y (32)
nylon shoulder
washer
Z (32)
M6 x 12mm
O (6)
locking tab
M (1)
computer shelf
Q (2)
bracket, 4x2
conguration

62014-06-20 #:009-9085-2.1 (2014-07-28)
1
R (4)
A
B
X
R (2)
S (2)
Do not fully tighten hardware
Repeat for each caster assembly.
(5mm)
SIDE VIEW

72014-06-20 #:009-9085-2.1 (2014-07-28)
2
R (4)
R (4)
F
F
S (2)
S (2)
D
S (2)
S (2)
Repeat for each base leg
assembly.
(5mm)
X

82014-06-20 #:009-9085-2.1 (2014-07-28)
3
4
Repeat for each base leg assembly.
Repeat for each base support (x12).
S (4)
G
R (4)
TIGHTEN
CONNECTING
HARDWARE
Do not fully tighten hardware
SIDE VIEW

92014-06-20 #:009-9085-2.1 (2014-07-28)
5
Repeat for each side (x2).
H
6
Assemble middle support bracket.
H
TIGHTEN
CONNECTING
HARDWARE
TIGHTEN
CONNECTING
HARDWARE

10 2014-06-20 #:009-9085-2.1 (2014-07-28)
7
E
E
8
Repeat for each vertical support bracket (x4).
R (6)
S (4)
K
TIGHTEN
CONNECTING
HARDWARE
1/8"
(3mm)
1/8"
(3mm)
LOCK WHEELS

11 2014-06-20 #:009-9085-2.1 (2014-07-28)
9
Use metric formula below and diagram to
right to determine hole pattern required for
center vertical support bracket. Repeat (x2).
All dimensions are metric.
Use the outside mounting holes when…
a x 4 > 4368mm and a x 3 + b < 4318mm
Use the inside mounting holes when…
a x 4 > 4098mm and a x 3 + b < 4064mm
R (12)
S (8)
Q
S (8)
Q
R (12)
BACK
SIDE
1/8"
(3mm)
b
a
BACK OF DISPLAY

12 2014-06-20 #:009-9085-2.1 (2014-07-28)
DISPLAY HEIGHT
10
11
N
N
TIGHTEN
CONNECTING
HARDWARE

13 2014-06-20 #:009-9085-2.1 (2014-07-28)
12
N
N
TIGHTEN
CONNECTING
HARDWARE
13
J
R (2)
S (2)

14 2014-06-20 #:009-9085-2.1 (2014-07-28)
14
P
O
V
TIGHTEN
CONNECTING
HARDWARE
TOP VIEW
OPTIONAL: Unlock wheels to move cart to
desired location; Lock wheels before hanging
screens.
LOCK WHEELS
P
O
V

15 2014-06-20 #:009-9085-2.1 (2014-07-28)
15
x3
YZR
OR
.98"
(25mm)
2.50"
(63mm)
15.75"
(400mm)
7.87"
(200mm)
0.91"
(23mm)
3.94"
(100mm)
2.50"
(63mm)
X
X
Center adaptor brackets vertically on back of screen.
(4mm)
AA

16 2014-06-20 #:009-9085-2.1 (2014-07-28)
16-1
16-2
Must hang displays to bottom row rst; Secure pin
in "locked" position.
Must hang displays on top row last; Secure pin
in "locked" position.
"LOCKED"
POSITION
"LOCKED"
POSITION

17 2014-06-20 #:009-9085-2.1 (2014-07-28)
16-3
OPTIONAL: Insert M5 x 10mm type-F socket pin screws to lock latches. AA
U

18 2014-06-20 #:009-9085-2.1 (2014-07-28)
Display Adjustment
IN
TILT BACKWARD
OUT
TILT RIGHT
TILT FORWARD
TILT LEFT
SIDE
SIDE
SIDE
TOP
SIDE
TOP
UP DOWN
ROTATE LEFT ROTATE RIGHT

19 2014-06-20 #:009-9085-2.1 (2014-07-28)
17
M
U (2)
M
L
1/8"
(3mm)
TIGHTEN
CONNECTING
HARDWARE
18
M

20 2014-06-20 #:009-9085-2.1 (2014-07-28)
19
T (4)
C
