peerless-AV SC550GL Guide

2300 White Oak Circle • Aurora, Il 60502 • [phone] • Fax: [phone] • www.peerlessmounts.com
ISSUED: 02-25-11 SHEET #: 009-9049-2 05-14-11
Installation and Assembly: 32" - 50" Flat Panel Display Cart
Models: SC550GL Max Load Capacity:
125 lb (56.7 kg) display
25 lb (11.3 kg) per shelf

2 of 35 ISSUED: 02-25-11 SHEET #: 009-9049-2 05-14-11
NOTE: Read entire instruction sheet before you start installation and assembly.
Table of Contents
Parts List............................................................................................................................................................................ 3, 4
Attaching Glass Base .............................................................................................................................................................5
Attaching Glass Shelf .............................................................................................................................................................6
Installing Universal Adapter Plate to Display..........................................................................................................................8
Mounting Flat Panel Display................................................................................................................................................ 10
Tools Needed for Assembly
•level
•phillips screwdriver
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US
customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact
your local distributor.
• This product should only be installed by someone of good mechanical aptitude, and fully understands
these instructions.
• Never exceed the Maximum UL Load Capacity on page 1.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tighten screws firmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding
power.
• The cart is not affixed or secured to the floor, and may therefore tip over and/or fall if display and/or stand is shaken
or hit. Always monitor children and do not let children play alone around stand as they could get hurt by a falling
display. Not recommended for use in areas with heavy traffic.
• This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal
injury.
WARNING

3 of 35 ISSUED: 02-25-11 SHEET #: 009-9049-2 05-14-11
Description Qty.
A
column assembly 1
Buniversal adapter plate 1
Cglass base 1
Dglass shelf 1
Eshelf bracket 1
Ffront caster 2
Grear caster 2
Hrear caster plate 1
Icolumn cover 1
K
flat head cap screw 4
LM6 x 15mm socket screw 4
MM8 x 30mm socket screw 2
NM6 x 8mm socket screw 16
OM5 x 12mm phillips screw 2
Pfront caster plate 2
QM6 washer 20
RM8 washer 2
A
A
M5 x 15mm philips screw 4
BB M5 x 35mm phillips screw 4
CC M6 x 15mm phillips screw 4
DD M6 x 35mm phillips screw 4
EE M8 x 15mm phillips screw 4
FF M8 x 35mm phillips screw 4
GG multiwasher 4
HH spacer 4
II M4 allen wrench (not shown) 1
JJ M5 allen wrench (not shown) 1
KK spanner wrench (not shown) 1
Parts List
C
D
E
A
B
HIK
Before you begin, make sure all parts shown are included with your product.
Parts may appear slightly different than illustrated. FG
P

4 of 35 ISSUED: 02-25-11 SHEET #: 009-9049-2 05-14-11
Before you begin, make sure all parts shown are included with your product.
Parts may appear slightly different than illustrated.
AA
BB
ROQNLM
GG
HH
CC
DD
EE
FF

5 of 35 ISSUED: 02-25-11 SHEET #: 009-9049-2 05-14-11
Attach front casters (F) to front caster plates (P) with four M6 x 8mm screws (N) and four M6 washers (Q) as
shown in figure 1.1.
Attach front casters (F) to front of glass base (C) with two M6 x 15mm screws (L), two M6 washers (Q), and two
flat head cap screws (K) as shown in figure 1.2.
Attach rear casters (G) to caster plate (H) with four M6 x 8mm screws (N) and four M6 washers (Q) as shown in
figure 1.3.
1
L
H
G
Q
Q
P
N
N
F
F
Q
C
K
Attach column assembly (A) to glass base (C) with two M8 x 30mm screws (M), two M8 washers (R) and caster
plate (H).
2
fig. 1.3
fig. 1.2
Attaching Glass Base
fig. 1.1
A
M
R
C
H

6 of 35 ISSUED: 02-25-11 SHEET #: 009-9049-2 05-14-11
Attach column cover (I) onto rear of column until it snaps into place.
Attach shelf bracket (E) to glass shelf (D) with two M5 x 12mm screws (O).
3
4
Attaching Glass Shelf
O
E
D
I

7 of 35 ISSUED: 02-25-11 SHEET #: 009-9049-2 05-14-11
Remove two M4 x 8mm screws and two M4 washers from column assembly.
Hook shelf bracket onto column assembly as shown in detail 3. Secure shelf bracket to column assembly with two
M4 x 8mm screws and two M4 washers as shown in detail 4. Glass shelf may be adjusted vertically by loosening
knobs on rear of column assembly.
NOTE: Do not adjust shelf while components are on the shelf.
DETAIL 3 DETAIL 4
KNOBS
M4 WASHER
M4 x 8mm SCREW
5

8 of 35 ISSUED: 02-25-11 SHEET #: 009-9049-2 05-14-11
To prevent scratching the display, set a cloth on a flat, level surface that will support the weight of the display.
Place display face side down and refer to display manufacturer's instructions for removing obstructions from the
back of the display. Adjust display brackets of universal adapter plate (B) to align with display mounting holes.
Select the screws from the baffled fastener pack that best fit your display and secure to display following step 6-1
or 6-2 on page 9.
NOTE: Top and bottom mounting holes must be used for attaching display brackets.
Verify that all holes are properly aligned, then tighten screws using a phillips screwdriver.
6
Installing Universal Adapter Plate to Display
CENTER DISPLAY BRACKETS VERTICALLY ON BACK OF DISPLAY
DISPLAY
DISPLAY BRACKETS
NOTE: "X" dimensions should be equal.
X
X
• Tighten screws so display brackets are firmly attached to display. Do not tighten with excessive force.
Overtightening can cause stress damage to screws, greatly reducing their holding power and possibly causing
screw heads to become detached. Tighten to 40 in. • lb (4.5 N.M.) maximum torque.
• If screws don't get three complete turns in the display inserts or if screws bottom out and bracket is still not tightly
secured, damage may occur to display or product may fail.
WARNING
B

9 of 35 ISSUED: 02-25-11 SHEET #: 009-9049-2 05-14-11
Begin with the shortest length screw, hand thread screw through multi-washer and display brackets (B) into
display as shown. Screw must make at least three full turns into the mounting hole and fit snug into place. Do not
over tighten. If screw cannot make three full turns into the display, select a longer length screw from the baffled
fastener pack. Repeat for remaining mounting holes, level display brackets and tighten screws.
NOTE: Spacers may not be used, depending upon the type of display.
Begin with the longest length screw, hand thread screw through multi-washer, display brackets (B) and spacer
in that order into display as shown. Screw must make at least three full turns into the mounting hole and fit snug
into place. Do not over tighten. If screw cannot make three full turns into the display, select a shorter length screw
from the baffled fastener pack. Repeat for remaining mounting holes, level display brackets and tighten screws.
For Flat Back Display
For Bump-out or Recessed Back Display
6-1
6-2
DISPLAY
DISPLAY
MULTI-WASHER (GG)
MULTI-WASHER (GG)
SCREW
SCREW
(AA,CC,EE)
(BB,DD,FF)
B
B
SPACER (HH)

10 of 35 ISSUED: 02-25-11 SHEET #: 009-9049-2 05-14-11
Mounting Flat Panel Display
Tilt Adjustment
Remove M8 nut and M8 washer from universal adapter
plate. Hook universal adapter plate (B) onto column
assembly.
Secure universal adapter plate to column assembly by
reinstalling M8 nut and M8 washer as shown in detail 3.
7
Adjust tension knobs on sides of mount to desired
tension to enable tilt adjustment and balance your
screen size and weight. Push or pull from top or
bottom of screen to adjust tilt as shown. The tilt
can be adjusted to a maximum of 15°.
Retighten tension knob.
8
• Always use an assistant or mechanical lifting equipment to safely lift and position the display.
WARNING
TENSION KNOB
B
A
DETAIL 3
M8 NUT M8 WASHER
