peerless-AV DS-S560-1X3 User manual

12015-07-01 #:009-9120-3 (2016-05-16)
ENG
DS-S560-1X3
46" - 60"
(117 - 152 cm) 500 lb (227 kg)
MAX

22015-07-01 #:009-9120-3 (2016-05-16)
This page intentionally left blank.

32015-07-01 #:009-9120-3 (2016-05-16)
Heavy
Do not begin to install product until you have read and understood the instructions and warnings contained in
this user guide. Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
This product must be installed onto flat, hard, level surface to prevent tipping. The cart or stand is not affixed or
secured to the floor, and may therefore tip over and/or fall if screen and/or stand is shaken or hit. Displays must
be removed before moving cart. Not recommended for use in areas with heavy traffic. This product is intended
for indoor use only. Use of this product outdoors could lead to product failure or personal injury. Screws must
be tightly secured. Do not overtighten screws or damage can occur and product may fail. Never exceed the
Maximum Load Capacity. Be careful not to pinch fingers when operating the mount. For support please call
customer care at 1-800-865-2112.
WARNING
To properly tighten screws: Tighten until screw
head makes contact, then tighten another 1/2
turn. Do not overtighten screws.
1
2
+1/2
4
3
Symbols
ENG
WARNING
ENG
Display center.
ENG
x3
Screws must get at
least three full turns
and fit snug.
ENG
Do not overtighten screws.
ENG
Tools Needed for Assembly.
ENG
3/8"
(10mm)
3/8"
(10mm)

42015-07-01 #:009-9120-3 (2016-05-16)
Parts List
Part #Description Qty
Apedestal 2 146-T1132
Bcover 2 145-T1809
Cvertical leg support 6 145-T1777
Dcolumn 2 146-T1131
Eextension 2 145-T1778
Fleft adaptor bracket 3 146-1609
Gright adaptor bracket 3 146-1608
Hcross support 3 145-T1816
Icomputer cover 1 145-T1930
Jcomputer shelf 1 145-T1931
Kextension adaptor 2 145-T1935
Lcord bracket 4 146-T1321
Mknurled knob 4 560-1160
NM8 x 16mm socket button screw 56 520-9527
OM8 square nut 24 530-1066
Pcover clip 8 590-0317
QM5 x 10mm type-f, socket pin screw 8 520-1164
Rbar nut 4 146-1319
Snylon shoulder washer 12 590-2233
TM6 x 12mm socket pin screw 12 520-1050
U1/4" power bit 1 560-0263
V5mm allen wrench 1 560-9640
W4mm allen wrench 1 560-9646
XM6 x 35mm screw 8 520-0717
Yrawl bolt #6913 8 5M9-381-H03
Parts (Before beginning, make sure you have all parts shown below).
E (2)
extension
B (2)
cover
D (2)
column
C (6)
vertical support
bracket
A (2)
pedestal G (3)
right adaptor
bracket
F (3)
left adaptor
bracket

52015-07-01 #:009-9120-3 (2016-05-16)
I (1)
computer cover
N (56)
M8 x 16mm O (24)
M8 square nut P (8)
cover clip Q (8)
M5 x 10mm
U (1)
1/4" power
bit
V (1)
5mm allen
wrench
nylon shoulder
washer
S (12)M6 x 12mm T (12)
4mm allen
wrench
W (1)
J (1)
computer shelf
L (4)
cord
bracket
M (4)
knurled
knob
bar nut
R (4)
K (2)
extension
adaptor
H (3)
cross support
rawl bolt
Y (8)
M6 x 35mm
X (8)

62015-07-01 #:009-9120-3 (2016-05-16)
1
x2
X (4)
AD

72015-07-01 #:009-9120-3 (2016-05-16)
2-2
E
K
TIGHTEN
CONNECTING
HARDWARE
2-1
N (4)
R (2)
K
x2
x2
Do not fully tighten hardware

82015-07-01 #:009-9120-3 (2016-05-16)
4
3"
(76mm)
3/8"
(10mm)
Y (8)
3-1
Align base. Mark mounting holes.
ENG
3-2
Drill mounting holes into
supporting surface
(3" (76 mm) minimum
depth required).
ENG
3/8"
(10mm)
3-3
Align base. Install using concrete anchors
provided.
ENG
3/8"
(10mm)
25.50"
(648mm)
Tighten.
ENG
ENG Maximum 35 ft • lb (47 N.M.).
55.00"
(1397mm)

92015-07-01 #:009-9120-3 (2016-05-16)
4-1
4-2
O (4)
N (2)
N (4)
C
C (3)
C (3)
1/8"
(3mm) 1/8" (3mm)
DISPLAY HEIGHT
DISPLAY HEIGHT
TIGHTEN
CONNECTING
HARDWARE
x6

10 2015-07-01 #:009-9120-3 (2016-05-16)
5P (4)
B

11 2015-07-01 #:009-9120-3 (2016-05-16)
6
TIGHTEN
HARDWARE
(X2)
TIGHTEN
HARDWARE
(X2)
Cross supports must center on vertical leg supports.
TIGHTEN
CONNECTING
HARDWARE
H (3)

12 2015-07-01 #:009-9120-3 (2016-05-16)
X
X
7-1
G
F
7-2
Center adapter brackets
vertically on back of screen.
ENG
G
F
x3
STN
OR
OPTIONAL: Use (N) to lock
mechanism on adaptor bracket
x3

13 2015-07-01 #:009-9120-3 (2016-05-16)
8-1
Must hang displays on bottom row first;
Secure pin in "locked" position.
8-2
OPTIONAL: Insert M5 x 10mm type-F socket pin screws
(Q) to lock latches. W
Q
"LOCKED"
POSITION

14 2015-07-01 #:009-9120-3 (2016-05-16)
IN
TILT BACKWARD
OUT
TILT RIGHT
TILT FORWARD
TILT LEFT
SIDE
SIDE
SIDE
TOP
SIDE
TOP
Display Adjustment
UP DOWN
ROTATE LEFT ROTATE RIGHT

15 2015-07-01 #:009-9120-3 (2016-05-16)
9
LM
TIGHTEN
CONNECTING
HARDWARE
TOP VIEW
L
M

16 2015-07-01 #:009-9120-3 (2016-05-16)
10-1
J
Q (2)
J
I
1/8"
(3mm)
TIGHTEN
CONNECTING
HARDWARE
10-2
J

17 2015-07-01 #:009-9120-3 (2016-05-16)
11
Route cables through cord brackets.
L
L

18 2015-07-01 #:009-9120-3 (2016-05-16)
This page intentionally left blank.

19 2015-07-01 #:009-9120-3 (2016-05-16)
This page intentionally left blank.

Peerless Industries, Inc. (“Peerless”) warrants to original end-users of Peerless®products will be free from defects in material and
workmanship, under normal use, for a period of five years from the date of purchase by the original end-user (but in no case longer than
six years after the date of the product's manufacture). At its option, Peerless will repair or replace, or refund the purchase price of, any
product which fails to conform with this warranty.
In no event shall the duration of any implied warranty of merchantability or fitness for a particular purpose be longer than the
period of the applicable express warranty set forth above. Some states do not allow limitations on how long a implied warranty lasts,
so the above limitation may not apply to you.
This warranty does not cover damage caused by (a) service or repairs by the customer or a person who is not authorized for such service
or repairs by Peerless, (b) the failure to utilize proper packing when returning the product, (c) incorrect installation or the failure to follow
Peerless' instructions or warnings when installing, using or storing the product, or (d) misuse or accident, in transit or otherwise, including
in cases of third party actions and force majeure.
In no event shall Peerless be liable for incidental or consequential damages or damages arising from the theft of any product,
whether or not secured by a security device which may be included with the Peerless® product. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
This warranty is in lieu of all other warranties, expressed or implied, and is the sole remedy with respect to product defects. No dealer,
distributor, installer or other person is authorized to modify or extend this Limited Warranty or impose any obligation on Peerless in
connection with the sale of any Peerless®product.
This warranty gives specific legal rights, and you may also have other rights which vary from state to state.
LIMITED FIVE-YEAR WARRANTY
