PEERLESS PLA1-UN7 Guide

This product is UL Listed. It must be
installed by a qualified professional
installer.
R
Max Load Capacity: 150 lb (68 kg)
3215 W. North Ave. • Melrose Park, IL 60160 • [phone] or [phone] • Fax: [phone] • www.peerlessmounts.com
ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
Installation and Assembly:
Articulating Swivel Arm for 32" - 60" Large Flat Panel Screens
Model: PLA1-UN7, PLA1-UN7S
Features:
•Universal design supports most 32" to 63" plasma and LCD screens
• One-touch adjustable tilt (5° back and 15° forward)
• Complete integrated security from the wall to the screen
• Up to 6" of horizontal adjustment when the screen is up
• Sleek, airy design complements today’s flat panel technologies

2 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
Note: Read entire instruction sheet before you start installation and assembly.
Tools Needed for Assembly
• Phillips screwdriver
• 5/32" or 4 mm drill bit (for installation to wood stud wall)
• 1/4" or 6 mm drill bit (for installation to concrete wall)
• 10 mm wrench
• Hammer
• Tape
• 3/4" open end wrench (optional: for roll adjustment)
• 6 mm allen wrench (included)
•stud finder ("edge to edge" stud finder is recommended)
Table of Contents
Parts List..........................................................................................................................................................................3, 4
Installation to Double Wood Stud Wall..................................................................................................................................5
Installation to Solid Concrete or Cinder Block .......................................................................................................................6
Installing Swing Arm to Wall Bracket and Assembling Components to Arm .........................................................................7
Assembling Adapter Bracket ...........................................................................................................................................8-10
InstallingAdapter Bracketto Screen...................................................................................................................................11
Installing Pitch Roll Assembly to Adapter Bracket..............................................................................................................12
Optional: Placing Screen in Vertical Position .....................................................................................................................12
InstallingScreentoArticulating SwivelMount.....................................................................................................................13
Final Adjustment to Screen ................................................................................................................................................14
Forcustomer carecall [phone] or(708) 865-8870.
• Do not begin to install your Peerless product until you have read and understood the instructions and warnings
contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please
call Peerless customer service at 1-800-729-0307.
• Thisproduct shouldonly beinstalled bya qualifiedprofessional.
• Do not attach directly to a metal stud wall. Use of a triple stud WSP wall plate is required for attachment to metal
studs (contact customer care). Metal stud installation is not UL evaluated.
• Makesure that thesupporting surfacewill safelysupport the combinedload ofthe equipmentand all attachedhard-
wareand components.
• Neverexceed theMaximum ULLoad Capacityof 150lb (68kg).
• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of an
"edgeto edge"stud finderis highlyrecommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tightenscrews firmly,butdo notovertighten. Overtighteningcandamage theitems, greatlyreducing theirholding
power.
WARNING

3 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
C
D
A
LNE
GMIHFJ
KRPT
U
Y
VX
ZAA OQSW
PLA1-UN7 PLA1-UN7S
Description Qty Part # Part #
Ac-channel spacer 2 200-1388 200-4388
Bvertical bracket 2 200-1446 200-4446
Cadapter plate 1 200-1300 200-4300
Dc-channel 2 200-1331 200-4331
E.34" x .75" x .25" spacer 4 540-1002 540-1002
FM4 x 10 mm serrated head socket pin screw 8 520-1156 520-1156
G10-32 x 1/2" socket pin screw 4 520-1055 520-1055
HM5 x 12 mm socket pin screw 8 520-1064 520-1064
IM6 x 12 mm socket pin screw 8 520-1050 520-1050
JM8 x 15 mm socket pin screw 6 520-1068 520-1068
KM8 x 25 mm socket pin screw 4 520-1101 520-1101
L1/4" SAE washer 8 540-9440 540-9440
M10-32 x 3/8" serrated head socket pin screw 4 520-1151 520-1151
N.38" x .625" x .5" spacer 6 540-1015 540-1015
O#10 SAE washer 8 540-9400 540-9400
PM5 x 30 mm socket pin screw 4 520-1112 520-1112
Q.219" x .5" x .5" nylon spacer 4 590-1096 590-1096
RM4 x 30 mm serrated head socket pin screw 4 510-1090 510-1090
S.25" x .5" x .625" nylon spacer 4 590-1106 590-1106
TM8 x 40 mm socket pin screw 6 520-1152 520-1152
UM5 x 8 mm socket pin screw 4 520-1062 520-1062
VM5 x 16 mm socket pin screw 8 520-1161 520-1161
W.281" x .5" x .375" spacer 4 540-9416 540-9416
XM6 x 20 mm serrated head socket pin screw 4 510-9554 510-9554
Y4 mm security allen wrench 1 560-9646 560-9646
ZM5 x 40 mm serrated head socket pin screw 6 510-1001 510-1001
AA .25" x .5" x 1.25" H aluminum spacer 6 580-1067 580-1067
Before you begin, make sure all parts shown are included with your product.
Parts List
B

4 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
PP
BB
CC
FF
EE
DD
HH
II
QQ
GG
PLA1-UN7 PLA1-UN7S
Description Qty. Part # Part #
BB wall bracket 1 200-1472 200-4472
CC rotation box 1 200-1434 200-4434
DD wall support arm axle 1 200-1052 200-1052
EE tilt pivot retainer assembly 1 200-1877 200-4877
FF swing arm assembly 1 200-0878 200-0879
GG pitch roll assembly 1 200-0288 200-0277
HH #14 phillips wood screw 8 5S1-015-C03 5S1-015-C03
II carriage bolt 3/8"-16 x 3" 1 520-1001 520-1001
JJ M10 x 1.5 x 15 mm screw bolt 8 520-9262 520-9262
KK 10-32 x 1/2" phillips screw 2 520-9509 520-9509
LL knob 1 590-1087 590-1087
MM cable clips 4 590-1166 590-1166
NN snap ring 1 560-9641 560-9641
OO holding pin 1 5M9-025-X02 5M9-025-X02
PP 3/4" x 3/16" x 14" bumper strip 1 570-1030 570-1030
QQ 3/4" x 3/16" x 10" bumper strip 2 570-1029 570-1029
RR cable ties 4 560-9711 560-9711
Parts List
JJ
OO
NN
LL
KK
RR
MM

5 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
Installation to Double Wood Stud Wall
Attach adhesive bumper strip (PP) to wall bracket (BB). Next attach one adhesive bumper strip (QQ) to each side of
swing arm (FF).
Note: Be sure swing arm is in correct position as shown with plastic cap at top.
1
Using wall bracket (BB) as a template, drill eight
5/32" (4 mm) diameter holes to a minimum depth of
2-1/2" (64 mm) into stud centers. Attach wall
bracket using #14 phillips wood screws (HH) and
phillips screwdriver (not provided).
Skip to step 3, page 7.
1
2
• Tighten wood screws so that wall bracket is firmly
attached, but do not overtighten. Overtightening can
damage the screws, greatly reducing their holding
power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
• Make sure that mounting screws are anchored into
the center of the studs. The use of an "edge to edge"
stud finder is highly recommended.
WARNING HH
BB
FF
PP BB
QQ
QQ
• Never mount this product to metal studs without the
requiredaccessory.
WARNING

6 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
Use wall bracket (BB), making sure that it is level,
as a template to mark holes. Drill 1/4" (6 mm)
diameter holes to a minimum depth of 2.5" (64 mm).
Insert anchors in holes flush with wall as shown
(right). Place wall bracket over anchors and secure
with #14 x 2.5" (6 mm x 65 mm) wood screws (HH).
Tighten all fasteners.
Installation to Solid Concrete or Cinder Block
2
• When installing Peerless wall mounts on cinder block, verify that you have a minimum of 1-3/8" of actual concrete
thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount in a solid
part of the block, generally 1" minimum from the side of the block. Cinder block must meet ASTM C-90 specifica-
tions. It is suggested that a standard electric drill on slow setting is used to drill the hole instead of a hammer drill to
avoid breaking out the back of the hole when entering a void or cavity.
• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.
• Makesure that thesupporting surfacewill safelysupport the combinedload ofthe equipmentand all attachedhard-
wareand components.
WARNING
• Tighten screws so that wall bracket is firmly attached,
but do not overtighten. Overtightening can damage
the screws, greatly reducing their holding power.
• Never tighten in excess of 80 in. • lb (9 N.M.).
• Make sure that mounting screws are anchored into
the center of the studs. The use of an "edge to edge"
stud finder is highly recommended.
WARNING
CUTAWAY VIEW
INCORRECT
concrete
plaster/
drywall
BB
CORRECT
concrete
plaster/
drywall
BB
Note: Fasteners for concrete not included, order TWO #ACC 204 accessory kits.
ACC204
HH
CONCRETE
WALL
1
3
2
ACC204
ACC204
ACC204
Drill holes and insert anchors.
Place wall bracket (BB) over anchors and secure with screws.
Tighten all fasteners.
BB
BB
• Always attach concrete expansion anchors directly to
load-bearingconcrete.
• Neverattach concreteexpansion anchorstoconcrete
coveredwith plaster,drywall, orother finishingmate-
rial.
WARNING

7 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
Note: There are five mounting positions. The center position is shown below.
Insert holding pin (OO) into wall support arm axle (DD). Insert axle through wall bracket (BB) and lower swing arm
(FF). Lock axle in place with holding pin.
FF
groove
1
3
2
groove
NN
DD
Note: Fit of axle into
wall bracket and lower
swing arm will be tight.
Gently tap into place
with a hammer if
necessary.
BB
FF
OO
DD
NN
DETAIL 4
plastic cap
3-1
Installing Swing Arm to Wall Bracket and Assembling Components to Arm
Place rotation box (CC) with threaded holes up over swing arm (FF).
Insert tilt pivot retainer assembly (EE) through rotation box (CC) and swing arm (FF). Align holes in tilt pivot retainer
assembly with holes in rotation box and secure with two phillips screws (KK) as shown.
Snap four cable management clips(MM)into swing arms(FF)as shown. Cable ties (RR) are used with clips (MM) for
cordmanagement.
EE
CC
THREADED
HOLES
FF
Note: Fit of rotation box
into tube will be tight.
Gently tap into place with
a hammer if necessary.
EE
KK
FF
CC
3
3-1
4-1
4-2
4-1
4
Next thread snap ring (NN) into groove at bottom of axle (DD)
protruding wall bracket (BB) as shown.
SNAP RING INSTALLATION: Pull snap ring apart. Wind it around
the tube while feeding it into the groove. Finish by snapping the end
of the snap ring into groove.
OO
NN
FF
• Failure to correctly mount swing arm with plastic cap at top as shown in detail 4 will result in product failure.
• Improperlyinstalled snapring willresult inproduct failure.
• If you are uncertain that product is properly installed, call customer service.
WARNING
MM
RR
4-2

8 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
Assembling Adapter Bracket
5Attach c-channels (D) to adapter plate (C).
Note: Make sure that the holes in the c-channels are facing the proper direction. See figures 1 and 2.
fig. 1
fig. 2
TOP C-CHANNEL (D) HOLES
FACING UPWARD
TOP C-CHANNEL (D) HOLES
FACING DOWNWARD
C
D
D
D
D
G
Fasten c-channels (D) to adapter plate (C) using four 10-32 x 1/2" socket pin screws (G).
C
Use the tables on accompanying screen compatibility chart to assemble the adapter bracket. First, find your screen brand
and model in the tables on accompanying screen compatibility chart. Find the configuration letter which corresponds to
your screen. This letter will be used to determine the proper method of assembly for the adapter bracket. Continue to the
table on the last page of accompanying screen compatibility chart.
Example:For a Sony model KDL-42XBR950 42" screen, use configuration C.

9 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
Slide vertical brackets (B) onto c-channels (D) as shown below. Refer to the table on accompanying screen
compatibility chart to determine the proper assembly of the adapter bracket. For standard bracket mounting, see
figure3. Forreverse bracket mounting,see figure4.
Example: For a Sony model KDL-42XBR950 42" screen, assemble the bracket as shown in figure 4 below (reverse
bracket mounting).
D
B
fig. 4
Bracket Mounting: Reverse
D
B
fig. 3
Bracket Mounting: Standard
6

10 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
B
D
C
B
M
Place the screen on the floor face down. Set a cloth on the floor to prevent scratching the screen. If the screen
has knobs on the back, remove them. Place adapter bracket on the center of the screen. Slide the vertical
brackets (B) along the c-channels (D) of the adapter bracket until the slots on the back of the vertical brackets
are aligned to the holes on the back of the screen. Fasten vertical brackets to c-channels using four 10-32 x 3/8"
serrated head socket pin screws (M).
Note: Do not fully tighten the screws to allow the adapter bracket to slide along the vertical brackets freely.
7

11 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
Slide the vertical brackets (B) along the c-channels (D) of the adapter bracket until the slots on the back of the
vertical brackets are aligned to the holes on the back of the screen. Fully tighten the four 10-32 x 3/8" screws (M)
which hold the vertical brackets to the c-channels. Refer to the table on the last page of accompanying screen
compatibility chart to determine the proper fasteners to use. Attach the assembled adapter bracket to the back of
the screen using screws, upper and lower spacers as pictured. Verify that all holes are properly aligned, then use a
phillips screwdriver to tighten the screws.
Note: See figure 5 below for slot sizes.
Example: For a Sony model KDL-42XBR950 42" screen, attach the plate to the screen using screws (F or H) and
upper spacers (O) through the small slots on the vertical brackets. Lower spacers are not required for this
configuration.
SCREWS
UPPER
SPACERS
LOWER
SPACERS
fig. 5
Mounting Slots
SMALL SLOTS ARE USED
FOR M4 AND M5 SCREWS.
LARGE SLOTS ARE USED
FOR M6 AND M8 SCREWS.
MOUNTING SLOTS: SMALL
MOUNTING SLOTS: LARGE
B
D
M
Installing Adapter Bracket to Screen
8

12 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
TILT BRACKET
CENTER
BOLT
GENERIC ADAPTER BRACKET
WASHER
SLOT
M5 SCREW
BRACKET
CARRIAGE BOLT
RETAINING
SPACER
M5 SCREW
SLOT
RETAINING
SPACER
BRACKET
VERTICAL
POSITION
OPTIONAL:
Placing Screen in Vertical Position
HORIZONTAL
POSITION
TILT BRACKET
CENTER
BOLT
Insert and tape carriage bolt (II) into top hole of pitch
roll assembly (GG). Attach pitch roll assembly to
adapter plate (C) with four M10 socket screws (JJ).
Tighten M10 socket screws with 6 mm allen
wrench (Y).
GG
Fig. 16A
DO NOT REMOVE M5 SCREWS. For vertical orientation,
unscrew two M5 screws until screw is able to move freely
in slot of tilt bracket as shown in figures 16A & 16B. Hold
adapter bracket stationary and rotate tilt bracket 90° by
hand or using a lever (example: wood 2" x 4"). Align M5
screws with threaded holes on bracket and tighten two M5
screws back into bracket.
II
Fig. 16B
JJ
C
THREADED
HOLE
WASHER M5 SCREW
Installing Pitch Roll Assembly to Adapter Bracket
M5 SCREWS
BRACKET
ADAPTER
BRACKET
• Do not overtighten screws. Overtightening may
hinder roll option.
CAUTION
9

13 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
Install remaining two M10 screws (JJ). HAND
TIGHTEN all four M10 screws to allow for tilt
adjustment. Remove tape from carriage bolt (II).
For tilt adjustment, gently push back on the top of
screen to relieve pressure on knob. Adjust tilt to
desired position and tighten tilt adjustment knob
(LL), then securely tighten all four M10 screws
using 6 mm allen wrench (Y).
As a final precaution, check all fasteners and
tightensecurely.
Insert two M10 screws (JJ) into rotation box (CC)
as shown. Leave approximately 1/4" of exposed
thread.
Hook pitch roll assembly (GG) onto M10 screws
(JJ). Insert carriage bolt (II) into slot of tilt pivot
retainer assembly (EE) as shown. Install tilt
adjustment knob (LL). GG
JJ
II
EE
GG
JJ
II LL
LL
• Always use an assistant or mechanical lifting equip-
ment to safely lift and position the plasma television.
B
CC
.25" JJ
WARNING
Installing Screen to Articulating Swivel Mount
1/4"
10-1
10-2
10
10-1
10-2

14 of 14 ISSUED: 09-21-04 SHEET #: 201-9269-6 11-29-05
Depending on the specific size and weight of the screen, the articulating swing arm may be angled at
different positions, causing the screen to appear to lean sideways at different articulating positions. The
pitch roll assembly (GG) allows the screen to be manually adjusted to appear horizontal at all times. To
adjust, gently rotate the screen by hand to the desired position.
Note: Center bolt is factory torqued for optimal performance to adjust for range of screen sizes.
If it is too difficult to adjust roll of screen, torque may be adjusted by following the procedures below.
Adjust tilt adjustment knob (LL) to allow maximum tilt.
Insert 3/4" open-end wrench (not provided) into side of pitch roll assembly (GG) and rotate center bolt
counterclockwise to loosen torque.
Note: Do not loosen or tighten more than 1/8 turn.
CENTER
BOLT
ARTICULATINGARM
SCREEN
CC
GG
SCREEN
GG
CENTER
BOLT
WRENCH
LL
11
11-1
11-2
11-1 11-2
Final Adjustments to Screen
©2005PeerlessIndustries,Inc.Allrightsreserved.
Peerless is a registered trademark of Peerless Industries, Inc.
All other brand and product names are trademarks or registered trademarks of their respective owners.
