PEERLESS DS334 Guide

ISSUED: 03-05-09 SHEET #: 125-9049-1
1 of 4
Visit the Peerless Web Site at www.peerlessmounts.com For customer service call 1-800-729-0307 or 708-865-8870.
Model: DS334
Installation andAssembly - PlasmaPCMountBracket
Qty. Part #
Description
Amount adapter 1 201-1196
Bmount attachment bracket 1 201-1198
Cclamp bracket 2 201-1199
DM5 x 10 mm socket pin serrated washer head screw 8 510-1126
EM6 x 10 mm socket pin serrated washer head screw 4 510-1066
FM10 x 15 mm penta-pin screw 8 520-9263
G4 mm security allen wrench 1 560-9646
Hpenta-pin tool 1 520-9260
Irubber pad (not shown) 12 590-1159
Parts List
Before you start check the parts list to insure all of the parts shown are included.
Note: Read instruction sheet before you start installation and assembly.
D E F
G
H
AB
C

ISSUED: 03-05-09 SHEET #: 125-9049-12 of 4
Visit the Peerless Web Site at www.peerlessmounts.com For customer service call 1-800-729-0307 or 708-865-8870.
See accompanying adapter plate instruction sheet to attach adapter plate to screen.Attach mount adapter (A) to
adapter plate with four M10 x 15 mm penta-pin screws (F).
1
Attach two clamp brackets (C) to mount attachment bracket (B) using four M5 x 10 mm socket pin serrated washer
head screws (D). Leave M5 x 10 mm socket pin serrated washer head screws (D) loose. Place four rubber pads (I)
on clamp brackets (C) as shown.
2
B
C
D
F
A
GENERIC
ADAPTER
PLATE
I

ISSUED: 03-05-09 SHEET #: 125-9049-1
3 of 4
Visit the Peerless Web Site at www.peerlessmounts.com For customer service call 1-800-729-0307 or 708-865-8870.
Attach eight rubber pads (I) to computer. Each pad should be approximately 5.13 in (130 mm) away from center of
computeras shownbelow.
I
Place computer between clamping brackets (C). Attach mount adapter (A) to mount attachment bracket (B) using
four M6 x 10 mm socket pin serrated washer head screws (E). Tighten all fasteners.
3
4
COMPUTER
COMPUTER
A
E
B
5.13in
(130mm)
C

ISSUED: 03-05-09 SHEET #: 125-9049-14 of 4
Visit the Peerless Web Site at www.peerlessmounts.com For customer service call 1-800-729-0307 or 708-865-8870.
Attach mount to mount attachment bracket (B) using four M10 x 15 mm penta-pin screws (F) or four M5 x 10 mm
socketpin serratedwasher headscrews (D)as shownbelow.
5
©2009PeerlessIndustries,Inc. Allrightsreserved.
PeerlessisaregisteredtrademarkofPeerlessIndustries,Inc.
Allotherbrandandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.
B
F or D
GENERIC
MOUNT
