PEERLESS PLCM-UNL Instruction Manual

ISSUED: 07-31-06 SHEET NO: 200-9831-3 07-08-09
Peerless Industries, Inc.
3215 W. North Ave. Melrose Park, IL 60160
708-865-8870 800-865-2112 Fax [phone]
www.peerlessmounts.com
page 1 of 3
©2008,PeerlessIndustries,Inc.Allrightsreserved.
Allotherbrandandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.
TheStraight ColumnCeiling Mount offersastraight columnfrom the
ceiling attachment point to the flat panel screen. The straight column
ceiling mount is ideal for sports facilities, airports, lobbies or retail
environments.
Features:
•PLCM-UNLmodelsincludeaPLP-UNLadapterplate(landscape
only)
• 0° to 20° adjustable tilt and 360° swivel
• Screenmountshorizontally
• Uses standard 1 1/2" – 11.5 NPT schedule 40 pipe
• Additionallengthcanbeaddedforlowering
• Theft-resistant security fasteners secure the screen to the mount
• Sold without ceiling plate
• Completedetailedinstallationinstructionsforwoodandconcrete
structures
Accessories:
•CeilingPlaterequired(soldseparately).Variousoptionsavailable.
Other ceiling accessories can be ordered separately to allow
mounting to I-beams, cathedral ceilings, trusses, etc.
Dimensions:
Weight:
23.1 lb (10.5 kg)
Shipping weight:
30.3 lb (13.7 kg)
Maximum Load Capacity:
200lb (90.7 kg)
ShippingCartondimensions:
L=38.0625"(967mm)
W=12"(305mm)
H= 8.125"(206mm)
MODEL:PLCM-UNL
A R C H I T E C T S S P E C I F I CA T I O N S
TheStraightColumnFlatPanelCeilingMountshallbeaPeerlessmodelPLCM-UNLandshallbemountedwhereindicatedontheplans.Itshallbe
constructedofheavygaugecoldrolledsteel,steeltubingandfinishedwithscratchresistantBlackFusedEpoxy.Itshallfeature360°swiveland0°
to20°rangeoftilt.Assemblyandinstallationshallbedoneaccordingtoinstructionsprovidedbythemanufacturer.
TECHNICAL DATA SHEET - Straight Column Flat Panel Ceiling Mount
for 32" to 60" LCD And Flat Panel Screens
R

TECHNICAL DATA SHEET MODEL:PLCM-UNL
page 2 of 3
ISSUED: 07-31-06 SHEET NO: 200-9831-3 07-08-09
Peerless Industries, Inc.
3215 W. North Ave. Melrose Park, IL 60160
708-865-8870 800-865-2112 Fax [phone]
www.peerlessmounts.com ©2008,PeerlessIndustries,Inc.Allrightsreserved.
Allotherbrandandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.
(UNLESS OTHERWISE SPECIFIED)
ALLDIMENSION= INCH
(MM)
FRONT VIEW
SIDE VIEW
0° to 20°
TILT
5.25
(133)
RANGE
3.75
(95)
RTO
Landscape: X = A - (1/2 ( height of screen)) - 2.68" (68 mm))
A = 34.26" (870 mm) when used with 33" (838 mm) extension
column Landscape: X = A - (1/2 ( height of screen)) - 2.68" (68 mm)
TOP VIEW
10.24
(260)
1.79
(46)
X
A
R

TECHNICAL DATA SHEET MODEL:PLCM-UNL
page 3 of 3
ISSUED: 07-31-06 SHEET NO: 200-9831-3 07-08-09
Peerless Industries, Inc.
3215 W. North Ave. Melrose Park, IL 60160
708-865-8870 800-865-2112 Fax [phone]
www.peerlessmounts.com ©2008,PeerlessIndustries,Inc.Allrightsreserved.
Allotherbrandandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.
(UNLESS OTHERWISE SPECIFIED)
ALLDIMENSION= INCH
(MM)
SIDE VIEW
WITH SHALLOW
BRACKET
ADAPTER BRACKET DETAIL
SIDE VIEW
WITH DEEP
BRACKET
3.26
(83)
1.25
(32)
4
(100)
30.75
(781)
3.25
(83) 2.63
(67)
28.7
(729)
max.
7.45
(189)
17.05
(433)
max.
18
(457)
.7
(18)
1.18
(30) 1.68
(43)
.7
(18)
18
(457) 18
(457)
