OWNER’S MANUAL
PLEASE READ AND SAVE THESE INSTRUCTIONS
Model HC-0113
Tower Ceramic
Heater
IMPORTANT INSTRUCTIONS
PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to
reduce the risk of fire, electric shock, and injury to persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
If provided, use handles when moving this heater. Keep combustible materials, such
as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from
the front of the heater and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near children or invalids
and whenever the heater is left operating and unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after the heater
malfunctions, has been dropped or damaged in any manner. Return heater to
authorized service facility for examination, electrical or mechanical adjustment, or
repair.
6. Do not use outdoors.
7. This heater is not intended for use in bathrooms, laundry areas and similar indoor
locations. Never locate heater where it may fall into bathtub or other water container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Arrange cord away from traffic area and where it will not be tripped over.
9. To disconnect heater, first turn controls to off, then remove plug from outlet.
10. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater.
11. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not
use on soft surfaces, like a bed, where openings may become blocked.
12. A heater has hot and arcing or sparking parts inside. Do not use it in the areas where
gasoline, paint, or flammable liquids are used or stored.
13. Use this heater only as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, or injury to persons.
14. Avoid the use of an extension cord because the extension cord may overheat and
cause a risk of fire. However, if you have to use an extension cord, the cord shall be
No. 14 AWG minimum size and rated not less than 1875 watts.
15. This heater draws 12.5 amps during operation. To prevent overloading a circuit, do
not plug the heater into a circuit that already has other appliances working.
16. It is normal for the plug to feel warm to the touch; however, a loose fit between the AC
outlet (receptacle) and plug may cause overheating and distortion of the plug. Contact
a qualified electrician to replace loose or worn outlet.
17. The output of this heater may vary and its temperature may become intense enough to
burn exposed skin. Use of this heater is not recommended for persons with reduced
sensitivity to heat or an inability to react to avoid burns.
18.“SAVE THESE INSTRUCTIONS”

OPERATING INSTRUCTIONS
Place the heater on a firm level surface free from obstructions, and at least 3 ft.
away from any wall and any other objects such as furniture, curtains, plants or
combustible material.
With the Power and Setting Control “A” in the ”OFF” position, plug the heater
into a grounded 120V outlet.
Turn the heater ”ON” by turning the Power and Setting Control “A” clockwise to
your desired power setting (LOW, HIGH , LOW&OSC or HIGH&OSC ). The Power
Indicator Light “D”will illuminate. The power settings operate as follows:
LOW: The Fan and heating elements operate at 900 Watts.
HIGH: The Fan and heating elements operate at 1500 Watts.
LOW&OSC: The Fan and heating elements operate at 900 Watts.
HIGH&OSC: The Fan and heating elements operate at 1500 Watts.
Turn the Thermostat Control “C” to your desired setting from “MIN” to “MAX”.
Turning the thermostat clockwise will increase the “set” temperature; turning the
thermostat counterclockwise will decrease the “set” temperature.
CAUTION: This heater includes a Thermal Cut-Off Overheat Protection System that
shuts the heater off if it overheats due to abnormal conditions. If this occurs, turn the
heater ”OFF”, unplug it, and inspect and remove any objects on or adjacent to the
heater. Allow it to cool for a few minutes, plug it back in, and resume normal
operation.
Parts and Name
Power switch Air Outlet
Thermostat Power Indicator Light
A
B
C
D
UNPACKING AND SET-UP
Unpack your heater and remove the wheel assemblies from the package.
1. Make sure the heater is unplugged and in the ”OFF” position.
2. TURN THE HEATER UPSIDE DOWN. Un-fasten the four screws.
3. Position the two holes assemblies of the two half bases and fix them as shown.
4. Insert each U-shape screw into the holes of base.
5. Insert the butterfly nuts and screw them tightly.
6. Turn the heater upright.
C
A
B
D
IMPORTANT!
Your heater is equipped with a polarized alternating current line plug (a plug having one
blade wider than the other). This plug will fit into the power outlet only one way. This is
a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace your outlet. DO
NOT defeat the safety purpose of the polarized plug.

ADDITIONAL FEATURES
This heater has additional features:
Washable Dust Filter
Convenient Carry Handle –allows for easy transport from room to room.
TROUBLESHOOTING
If your heater fails to operate, please follow these instructions:
Ensure that your circuit breaker or fuse is working properly.
Be sure the heater is plugged in and that the electrical outlet is working properly.
Check for any obstruction. If you find any obstruction, turn the heater “OFF”. Unplug
the heater and wait a few minutes for it to cool down. Carefully remove the
obstruction. Plug the heater in and turn it on again by referring to the OPERATING
INSTRUCTIONS.
NOTE: IF YOU EXPERIENCE A PROBLEM WITH YOUR HEATER, PLEASE SEE THE
WARRANTY INFORMATION FOR INSTRUCTIONS. PLEASE DO NOT ATTEMPT TO OPEN
OR REPAIR THE HEATER YOURSELF. DOING SO MAY VOID THE WARRANTY AND
COULD CAUSE DAMAGE OR PERSONAL INJURY. IF THE PROBLEM STILL PERSISTS,
PLEASE CONTACT US BY REFERRING TO THE SERVICE & SUPPORT INFORMATION ON
THE FOLLOWING PAGE.
CLEANING AND STORAGE
It is recommended that the heater be cleaned at least one time during the operating season in
order to provide the optimum level of performance. ALWAYS TURN THE POWER SWITCH
OFF AND UNPLUG THE HEATER BEFORE CLEANING. Be sure to save the box for off-
season storage.
Turn the heater “OFF”, unplug it and wait for the heater to cool down.
Use a dry cloth to clean only external surfaces of the heater.
Do not use any cleaning agents or detergents.
Never immerse the heater in water.
Pack the heater in the original carton and store it in a cool and dry place.
SPECIFICATIONS
Model No.: HC-0113
Voltage: 120V, 60Hz
Current: Maximum continuous draw: 12.5 Amps.
Output: 5200 BTUs
Power: LOW =900 Watts, HIGH = 1500 Watts
Tolerances on all specifications: Approximately +5%, -10%.
SERVICE & SUPPORT
In the event of a warranty claim or if service is required for this heater, please contact us at
the following:
Toll Free: 866-876-4332
Email us at: [e-mail]
For questions or comments, please write to:
2617 North Great Southwest Parkway
Grand Prairie, TX 75050, USA
For your records, staple your sales receipt to this manual and record the following:
DATE OF PURCHASE: _________________________________________________________________
PLACE OF PURCHASE: ________________________________________________________________
SERIAL NUMBER: _____________________________________________________________________
(STAPLE SALES RECEIPT HERE)
NOTE: PROOF OF PURCHASE IS REQUIRED FOR
ALL WARRANTY CLAIMS

ONE (1) YEAR LIMITED WARRANTY
Please read all instructions before attempting to use this product.
Please return the Warranty Registration card within fifteen (15) days from the date of
purchasing this product.
PELONIS warrants as limited herein to the original purchaser of retail that each new
Pelonis Tower ceramic heater, shall be free of defects in material and workmanship for a
period of one (1) year from the date of original purchase. This one (1) year warranty is
limited to the heating elements, motor, and electric control circuit board.
In the event of malfunctions or failure of your Pelonis Tower ceramic heater, simply deliver
or send the heater, postage prepaid along with PROOF OF PURCHASE, within the
warranty period of one (1) year, to PELONIS. PELONIS reserves the right to inspect the
claimed defective part or parts to determine if the defect or malfunction complaint is
covered by this warranty. PELONIS shall, within sixty (60) days after receipt of the product,
at its option, repair and/or replace the defective part or parts free of charge. This warranty
shall only cover defects arising from normal usage. PELONIS assumes no responsibility
whatsoever if the Tower ceramic heater should fail during the warranty period by reason of:
Misuse, negligence, physical damage or accidents.
Lack of maintenance (see instructions for proper maintenance).
Repair by any unauthorized party during the warranty period.
Damage caused by connection to an improper input voltage (see specification
label on your heater).
PELONIS makes no further warranties or representations, express or implied except those
contained herein. No representative or dealer is authorized to assume any other liability
regarding the Tower ceramic heater. The duration of the implied warranty granted under
State law, including warranties of merchantability and fitness for particular purpose are
limited in duration should the duration of the express warranty grant it hereunder. Pelonis
USA shall in no event be liable for direct, indirect, special or consequential damages.
Some states do not allow limitations on how long an implied warranty lasts, and/or the
above limitations or exclusion may not apply to you. This warranty gives you specific legal
rights and you may have other rights which vary from state to state.
