Peltor Protac II User manual

Tactical
Protac II, Tactical XP

Two-way communication
Three alternatives are available for two-way communication via com
radio, mobile or DECT telephone:
Headset
The ProTac and the Tactical XP come in a standard headset model with
a separate adapter. The PTT button is located on the separate adapter.
Flex headset
The ProTac and the Tactical XP in a Flex headset model is a solution
without an external adapter. The PTT button is on the shell. Jackable
cables enhance flexibility, since you can connect many kinds of
equipment using a range of cords. Flex cords are available for most
devices on the market.
Wireless Bluetooth headset
The ProTac WS headset uses the Bluetooth worldwide standard for
wireless communication. The headset can communicate wirelessly with
another unit that has the Bluetooth standard. The headset and the
other unit can be 10 metres apart without losing contact.
A PTT button and a Bluetooth configuration button are positioned on
the left shell. If a connected mobile phone has voice dialling, you can
use the headset microphone for this.
If your communication radio does not have Bluetooth, Peltor has
developed Bluetooth adapters, the FL6000 series, which can be used
for many of the most common devices on the market.
Bands/Attachments
Peltor hearing protectors are available with a range of attachments
and bands: Headband, neckband, helmet attachment and collapsible
headband.
Attenuation
Peltor hearing protectors can be divided into five different categories,
depending on their attenuation.
The attenuation level of the ProTac and the Tactical XP fall under
category four, which is symbolized by a die with four dots. This means
that the protectors are suitable for high and medium high-frequency
noise in the range of RNR* 94-105dB.
Active-volume function
Both the ProTac II and the Tactical XP are equipped with an active-
volume function that lets you hear ambient noises: conversations,
machine sounds, warning signals, etc. Soft sounds are amplified, so
you hear them even better than you would without hearing protectors.
Two microphones pick up ambient noises and reproduce them in full
stereo, so you can tell what direction they come from. Sudden impulse
noises at harmful levels are immediately attenuated.
An electronic valve detects the noise and attenuates it to a harmless
level. When the noise fades, the electronics automatically go back to
the listening function. A summing function ensures that the combined
sound level from the active-volume function and from connected exter-
nal equipment does not exceed a given level.
Reliable long and short-distance
communication
* (* RNR = Recommended Noise Rating)

FL5000 Headset adapters
Adapters are available for most communication radios, DECT and
mobile phones on the market.
Contact your Peltor dealer for information on which adapter is suited for
your communication radio, DECT or mobile phone.
See below for examples of the most common models:
Prod code Communication radio
FL5001 Peltor Standard
FL5003 Dancall 6000, Tateco CTS900
FL5005 Ericsson Freeset
FL5010 Alinco. ICOM. Yaesu. Zodiac
FL5013 Ascom SE-140
FL5017 Motorola Visar
FL5019 Maxon Slim line. Motorola Expo
FL5030 Motorola GP340, GP320
FL5034 ICOM IC angled connector
FL5035 Kenwood TK3101 Funkey
FL5044 ICOM IC-F31, 41,51, 61
FL6000 WS adapters
Adapters in the Peltor Wireless Solutions™ product range for connecting
Peltor wireless headsets to a com radio or other communication
equipment with no Bluetooth® capacity.
The connector cord to the headset is replaced by a Bluetooth® link
with a range of up to 10 metres.
See below for examples of the most common models:
Prod code Communication radio
FL6005-WS Ericsson Freeset, Tateco CTS900 (2.5 mm plug)
FL6010-WS ICOM IC, Alan, Zodiac (straight connector)
FL6014-WS Motorola GP300. Radius P110
FL6030-WS Motorola GP320/340
FL6034-WS ICOM IC-F3GS, IC-F3GT, IC-F4GS, IC-F4GT (angled co)
FL6035-WS Kenwood TK3101 Funkey
FL6018 Motorola HT1000, MT2000, GP900

Key functions like effective attenuation, comfort and better sound
reproduction have come a step closer to perfection with the Peltor
ProTac II. The ProTac II is now also available as a Bluetooth headset.
Active-volume function
With the ProTac, you are not shut off from the environment, which can
be both dangerous and inconvenient. You always hear what is going on
around you, and you know that your hearing is protected.
Easy and logical to use
The control panel is on the right shell. The buttons are easily accessible
and logically positioned. They make it easy to adjust ambient noise.
Another feature is the power-saver function. If no buttons are pressed,
the hearing protector switches off automatically after two hours, which
eliminates the risk of wearing out the batteries due to forgetfulness.
A warning signal is emitted when the battery is low.
You can also connect the hearing protector to a telephone or
communication radio, so you can always be reached while you work.
The ProTac with speech microphone and a flex cord, separate adapter
or Bluetooth provides complete two-way communication.
WS ProTac headset with Bluetooth
The ProTac WS uses the Bluetooth worldwide standard for wireless
communication. The headset can communicate wirelessly with another
unit that has the Bluetooth standard.
The headset and the other unit can be 10 metres apart without losing
contact. A PTT button and a Bluetooth configuration button are
positioned on the left shell. If a connected mobile phone has voice
dialling, you can use the headset microphone for this.
If your communication radio does not have Bluetooth, Peltor has
developed a Bluetooth adapter, the FL6000 series, which can be used
for many of the most common devices on the market.
ProTac headset with cord connection
The ProTac also comes in a standard headset model with a separate
adapter. In this case, the PTT button is located on the separate adapter.
The Flex headset model of the ProTac has the PTT button on the shell.
A flex headset lets you easily switch between a com radio, DECT or
mobile phone just by switching cords.
A step closer
to perfection with the
ProTac II

ProTac II versions
Standard Headset Flex Headset WS headset, Bluetooth
With neckband/Black MT15H7B2 SV
With helmet attachment/Black MT15H7P3E2 SV MT15H7P3E2-07 SV MT15H7P3E2-77 SV MT15H7P3E2WS3
With headband/Black MT15H7A2 SV MT15H7A2-07 SV MT15H7A2-77 SV MT15H7A2WS3
With headband/Red MT15H7A2 RD
With headband/Green MT15H7A2 GN
SNR
31 dB
H
29 dB
M
24 dB 32dB
L
400 g/14.1 Oz.
1
19.7 25.4 31.0 34.6 32.2 38.7 42.1
3.4 2.5 3.4 1.8 3.6 3.8 3.6
16.3 22.9 27.6 32.8 28.6 34.9 38.5
Frequency 2
Mean att. 3
Stand. dev. 4
MT15H7A2
MT15H7B2
MT15H7F2 APV
Model 125 250 500 1000 2000 4000 8000
SNR
32 dB
H
29 dB
M
23 dB 31dB
L
330 g/11.6 Oz.
1
Frequency 2
Mean att. 3
Stand. dev. 4
ProTac
MT15H7P3*2
APV
Model 125 250 500 1000 2000 4000 8000
20.7 24.7 31.0 35.1 32.6 40.4 42.1
5.4 3.9 3.4 2.9 3.1 3.1 2,7
15,3 20,8 27,6 32,2 29,5 37,3 39,4
Technical data:
Weight: 370 g (headband)
Operating time: About 1000 hours (standard)
Battery type: AA (2x 1.5V)
Attenuation values:

Active-volume function with new possibilities
As with other Peltor active-volume hearing protectors, users can hear ambient
noise: conversations, machine noises etc. Soft sounds are amplified, so you hear
them even better than you would without hearing protectors. At the same time,
sudden impulse noises at harmful levels are immediately attenuated.
But the Tactical XP isn’t like other active-volume hearing protectors. Different
kinds of noise differ in character, direction, impulse, frequency and volume.
The Tactical XP uses a new, revolutionary digital circuit that lets the user control
and monitor the active-volume function, adapting the qualities of the protector
to the situation and environment. The active-volume function on the Tactical XP
also amplifies weak sounds better than any other Peltor protector.
The Tactical XP is equipped with many functions that further improve your
opportunities to hear what you want to hear while remaining protected from
harmful noise. Each function and its settings are indicted by a voice message.
Volume
As with the precursor to the Tactical XP, the user can adjust the volume of the
active-volume function.
Balance
Adjust the balance of the active-volume function. Especially beneficial for users
with hearing loss in one ear.
Reset time
The user can adjust the length of time it takes for the active-volume function to
return to normal, to two different levels. Normally, you want the reset time to be
as fast as possible, but in some situations – with an echo effect or frequently
recurring impulse noises, you may want to extend the time.
Equalizer
The equalizer function lets the user filter the ambient noise, improving or cutting
out the noise on a certain frequency. This lets you hear the sounds you want to
hear more clearly.
Volume on externally connected equipment
In extremely noisy environments, limiting the sound level from external
communication equipment to 82 dB can make it hard to understand, or in
some cases even hear, important information. The Tactical XP allows the user
to increase that limit from 82 dB to 89 dB, in order to improve the sometimes
vital communication in extremely noisy environments.
Since 89 dB is somewhat higher than the maximum permitted exposure over 8
hours according to the European standard, 85 dB, this mode must not be used
continuously. External communication coming in from a com radio or phone
over the course of a working day is usually well below the maximum permitted
exposure.
See the instruction manual for more detailed information on exposure time at
various input signal levels. A warning message is played when the higher level
is set. The electronics return automatically to standard mode when the product
is switched off.
The Tactical XP.
The most adaptable hearing
protector on the market
Maximises communication
and minimises noise of any
character

Tactical XP headset with cord connection
The Tactical XP comes in a headset and a Flex headset model for connection to
a com radio, DECT or mobile phone:
The Tactical XP headset model lets you connect communication equipment with
a separate adapter. The PTT button is located on the separate adapter.
The Tactical XP in the Flex headset model is a solution without an external
adapter. The PTT button is on the shell. Flex cords are available for most devices
on the market.
Tactical XP versions:
Standard Headset Flex Headset
With neckband MT1H7B2 MT1H7B2-07 MT1H7B2-77
With helmet attachment MT1H7P3*2 MT1H7P3*2-07 MT1H7P3*2-77
With collapsible headband MT1H7F2 MT1H7F2-07 MT1H7F2-77
MT1H7A2
MT1H7B2
MT1H7F2
MT1H7P3*2
Attenuation values:
Technical Data:
Weight: 400g
Operating time: about 1000 hours (standard)
Battery type: AA (2x 1.5V)

Accessories and spare parts
HY79 Hygiene kit. Easy-to-replace hygiene kit consisting of two
attenuation cushions and snap-in ear cushions. Replace at
least twice a year to ensure constant attenuation, hygiene and
comfort.
HY100A Clean single-use protectors. A single-use protector that is
easy to apply to the ear cushions. Packages of 100 pairs.
HYM1000 Mike Protector. Moisture and wind-tight. Hygienic,
effective protector that increases the life span of the speech
microphone. Packages of 5 metres, approx. 50 replacements.
Wind protection for ambient microphones
Effective protection from wind hiss.
One pair per package.
M60/2 ProTac
M41/2 Tactical XP
Flex headset cords
Available in several versions, for example the FL6U-32, which fits
the Motorola GP340. The one for your particular communication
radio, DECT or mobile phone is listed on the cord’s package.
Make sure you have chosen the right cord for your communication
equipment.
Cord Communication radio
FL6U-31 Alan 441
FL6U-31 Albecom 1221/1331/PD1000
FL6U-35 Albrecht Tectalk Contact 446 PMR
FL6U-31 Aliinco-LPD01
FL6U-31 Cobra
FL6U-31 ComMaster 1550/3130
FL6U-31 Genzo
FL6U-21 Handy Pro, Radius P110
FL6U-31 Hunter MK16, MK24
TAA13-T0299 ICOM F31/F41
FL6U-35 ICOM IC-F3GS, GT F4GS, GT etc with angled connector
FL6U-31 ICOM IC-F3S, F4S, IC-E90, LPD06,PMR06 (with straight connector)
FL6U-36 Kenwood 260/270, 360/370 LPD, TH22E PMR etc
FL6U-31 Lafayette, DC31 Micro-3, DC155 Micro-3
FL6U-31 Maxon SL25
FL6U-21 Motorola GP300 etc
FL6U-32 Motorola GP640, 680,1280, 320, 340, 360,380
FL6U-61 Motorola Visar 3,5 mm, GP344/388 via Motorola adapter plug
FL6U-31 TEKK
FL6U-31 Yeasu
FL6U-31 Zodiac PA2099/PA1599/PA5499/ PA5500/P2400 + various LPD/PMR radios
TAA20-T0299 Motorola GP344
TAA22-T0299 Vertex VX160/400
Cord DECT- or mobile phone Extra Phone adapter
FL6U-28A Ascom DECT 9d23/Offi ce 155 Pro -
FL6U-28 Ericsson 628/688/788/868/888/T10/T18/R5250s Pro and DT570 TAH10
FL6U-28A Ericsson DT400/DT410/DT420/DT590 -
FL6U-28 Ericsson GSM other models -
FL6U-28 Ericsson T20/T28/T29/T39/T65/T66/T68/ R310/R320/R380/R520/R600/T200/T300/T600 TAH11
FL6U-28 Motorola GSM – most models have a jack on the side -
FL6U-28 Nokia 3210/3310/3330/3410/3510/3510i/3650/5210/5510/6510/7650/8210/8310/8850/8890/8910
TAH02
FL6U-28 Nokia 5100/6100/6610/6650/6800/7210/7250 TAH03
FL6U-48 Nokia 5110/5130/6110/6150/6210/6310/6310i/7110 TAH01
FL6U-28 Siemens C25/S25 TAH20
FL6U-28 SonyEricsson K310i, K610i, K750i, W800i, W550i, W900i, P990 and more TAH12
Peltor AB
Box 2341, 331 02 Värnamo, Tel. [phone]. Fax [phone]
[e-mail] www.peltor.se
Member of the Aearo group
If you are unsure which Flex cord to choose, ask your Peltor
dealer.
See below for examples of the most common models:
Connector cords
FL6H 3.5 mm mono connector
FL6M 2.5 mm mono connector
FL6N 3.5 mm stereo connector for Micman com radio
Connector cords of cold and wear-resistant polyurethane for
connection to a com radio etc. Length 110 cm.
ACK03
Rechargeable battery
FR03EU
Battery charger for the ACK03. European-standard connector
cord.
FR03GB
Battery charger for the ACK03. UK-standard connector cord.
