P D U 1 6 - 1 0 D J
16A 10 WAY POWER DISTRIBUTION
1.8m POWER CABLES SUPPLIED FOR INTERNATIONAL APPLICATIONS
9-10 Parsons Roa , Parsons In ustrial Estate, Washington Tyne & Wear, NE37 1HB, UK
0191 416 1717 or www.penn-elcom.com
E&OE
ON/OFF
16
A
Tr
i
p
Sw
i
t
c
h
In the event of overload these will
cut power to the 10 output sockets
see Appendix for reset time
RED Neon In icator
on this switch will show there is
AC power to the unit.
Should these Not Be Lit then
1st check the power is connected & none of
the outputs have an
overload or short circuit
These 10 switches will
light when the channel
is selected
USER GUIDE
C20 Inlet
0A 50V Rating
10 x C13 Outlet
Max Combined
Load 16A
TYPE G 13A
UK,Ireland, Malta,
Malaysia & Singapore
LIMITED TO 13A MAX LOAD
REPLACE TYPE G WITH
BLUE C FORM FOR 16A USE
TYPE E/ F 16A
Europe, France,
Belgium, Poland,
Russia, Slovakia
& Czechia
TYPE B 15A
USA, Canada,
Mexico & Japan
TYPE 1 10A
Australia, New Zealand,
China & Argentina
LIMITED TO 10A MAX LOAD
REPLACE TYPE 1 WITH
BLUE C FORM FOR 16A USE

OPERATION & USER GUIDE TO
19 INCH RACK MOUNT POWER
DISTRIBUTION UNITS
Please read the following information before installing or
using your Power Distribution Units
Safety an Groun ing (earth)
•This PDU is intended for indoor use only.
•Do not install this PDU where excessive moisture or heat is present.
•Never install any wiring, equipment, or PDU's during a lightning storm.
•lways connect this PDU into a three-wire, grounded power outlet.
•The power input cable should be connected to appropriate branch circuit/mains protection
(fuse or circuit breaker). Connection to any other type of power outlet may result in a shock hazard.
•Use only the supplied brackets for mounting.
•Never work alone under hazardous conditions.
•Check that the power cord, plug, and socket are in good condition.
•Disconnect the PDU from the power outlet before you install or connect equipment to reduce the
risk of electric shock if you cannot verify grounding. Reconnect the PDU to the power outlet only
after you have made all connections.
•Use a protective earth connector with equipment. This type of connector carries the leakage
current from the load devices (computer equipment). Do not exceed a total leakage current of
3.5m or a risk of electrical shock will result.
•LW YS make sure the equipment that has been connected to the PDU is OFF, before switching on
the PDU, as the Inrush Current can trip the power fuse and activate the protection circuit.
•ll equipment plugged into this unit should have the correct fuses fitted for their current draw.
•Penn Elcom Ltd excepts no responsibility or liability for any equipment connected to this unit
GUARANTEE
YOUR EQUIPMENT IS GUARANTEED FOR A PERIOD OF ONE YEAR FROM THE DATE OF PURCHASE OF THE PRODUCT AGAINST ANY DEFECTS DUE TO FAULTY
MATERIALS OR FAULTY MANUFACTURING. DURING THIS PERIOD, REPLACEMENT OR REPAIR TO THE UNIT WILL BE MADE WITHOUT CHARGE BY ANY
AUTHORISED DEALER OR THE FACTORY SUBJECT TO THE FOLLOWING CONDITIONS.
The faul mus be en irely due o faul y ma erials or faul y manufac ure.
The defec mus NOT have been caused by poor ins alla ion, acciden al damage, misuse or failure o comply wi h he ins ruc ions given in he users guide.
If a any ime during he guaran ee period a par or par s of he equipmen are repaired wi h a par or par s
no supplied or approved by us; or if he equipmen has been disman led or repaired by any person no au horised by he us, hen he guaran ee shall
immedia ely cease and become void.
Evidence of he da e of purchase mus be produced a he service poin o ob ain he benefi of his guaran ee. Any carriage charges rela ing o he
guaran ee
will be he responsibili y of he purchaser.
This guaran ee applies o he original purchaser only and he equipmen mus have been purchased or financed from new, his guaran ee canno be assigned
or ransferred.
The company reserves he righ o replace he equipmen or repair i a heir discre ion, any defec ive par shall become he proper y of he company.
This guaran ee applies o equipmen purchased and used wi hin he E.E.C. The impor ers of equipmen in non E.E.C. coun ries are responsible for he
guaran ee
of his uni . Par s required under guaran ee are free. Shipping charges for componen s will be charged a cos .
The guaran ee shall become void if he equipmen is a any ime used on any supply circui or vol age range o her han ha specified on he equipmen .
12. THIS GUARANTEE DOES NOT IN ANY WAY AFFECT YOUR STATUTORY RIGHTS AS A CONSUMER.

Declaration of Conformity
The Manufacturer of the Products covered by this Declaration is
Made in the UK by Penn Elcom
9-10 Parsons Road, Parsons Industrial Estate,
Washington yne & Wear, NE37 1HB, UK
The Directives covered by this Declaration
89/336/EEC Electromagnetic Compatibility directive, as amended
73/23/EEC Low Voltage E uipment directive, amended by 93/68/EEC
The Products Covered by this Declaration
PDU16-10DJ
16A MAX 1U Rack Mount 1 Ch Switchable A/C Power PDU
Usable Voltages 11 V-25 V ~ AC 47-63Hz - Max Current: 16A
Input Socket = IEC C2 16A Europe - 2 A in USA
Outputs = 1 x C13 Outlets IEC Socket 1 A ~25 Vac
with a Maximum Combined Load 16A through a 16A Breaker Switch
The Basis on which Conformity is being Declared
The manufacturer hereby declares under his sole responsibility that the products identified above comply
with the protection re uirements of the EMC directive and with the principal elements of the safety
objectives of the Low Voltage E uipment directive, and that the following standards have been applied:
All components used in this conform to current RoHS, CE & UL certification
(EMI:EN55022 CISPR22) Class B; EN61000-3-2,3 EMS:EN61000-4-2,3,4,5,6,8,11; Light industry level, criteria A)
The technical documentation re uired to demonstrate that the products meet the re uirements of the Low Voltage
E uipment directive has been compiled and is available for inspection by the relevant enforcement authorities.
The CE mark was first applied in: 2019
Signed:
Authority: Technical Director (M Inst SCE)
Date: 17/07/2019
Attention!
The attention of the specifier, purchaser, installer, or user is drawn to special measures and limitations to use which
must be observed when these products are taken into service to maintain compliance with the above directives.
Details of these special measures and limitations to use are available on request and are also contained in the product manual.
E&OE

TRIP SWITCH APPENDIX
These products are fitted with thermal circuit breaker/power switches with indicator as a fail safe and should not be
used to determine excessive current drawer. These are not an RCD and do not function in the same way.
USERS OF THESE PDU'S SHOULD PRE-DETERMINE THE MAXIMUM SAFE LOAD AS INDICATED ON THE BACK OF THE UNIT.
PLEASE NOTE: An RCD is a safety switch that protects people from electrical shock; a circuit breaker protects the wiring
and electrical components attached to the unit.
In normal operation there will be peaks in the current draw and these switches allow for this, but will switch if the
overload is continuous.
Technical Specification
Calibration: Will continuously carry 100% of rating.
May trip between 101% and 134%,
(they must trip at 135% of rating within one hour at +25°C
See Chart)
Dielectric Strength: 1,500VAC (60 seconds).
Insulation Resistance: 100 megohmsDOD.
Maximum Operating Voltage: 250VAC, 50/60 Hz.
These switches have the following certification approvals:
UL 1077 , VDE 0642/EN60934, CCC & CE compliant.
Penn Elcom Ltd excepts no responsibility or liability for any equipment connected to this unit
