Pentair SPEEDEO SB-PF-SPO-003C User manual

SPEEDEO®
VARIABLE SPEED PUMP
VALID
ESC
VS
SB-PF-SPO-003C
PENTAIR WATER SOLUTIONS SB-CU-IMP-051F (this version 03/2019)
* SPEEDEO optimises the speed variation of the IntelliFlo pump and is
compatible with variable speed pumps with an external connection
which permits them to be externally controlled. The list of
compatible pumps is constantly changing in accordance
with releases of new models.
01:03 Water:+24.3°C
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C
SPEEDEO®
EN
3 assignable outlets
4 controllable speeds
2 assignable inputs
1 Intelli BUS
IMPORTANT SAFETY INSTRUCTIONS,
READ AND FOLLOW ALL OF THE INSTRUCTIONS,
KEEP THESE INSTRUCTIONS
INSTALLATION AND USER GUIDE

Pentair International S.a.r.l
Avenue de Sévelin 18
1004 Lausanne - Switzerland
Authorised person for technical documentation
Guillaume Goussé
Lausanne, 01/04/2019
European Vice President of Operations
SAFETY EN 61010-1:2010
EM EN 61326-1: EN 301 489-3
EMF EN 62311
RADIO EN 300 220-2
SPEEDEO (+ PARTS)
SB-PF-SPO-003C
PART NUMBERS:
SB-SE-TEC-006A
Pentair thanks you for placing your trust in the company and purchasing a SPEEDEO®, the variable speed pump control automaton, with 3
assignable pieces of equipment. SPEEDEO® will start up the correct speed of the connected variable speed pump according to the hydraulic
requirements linked to the event.
Please carefully read this user manual to fully benet from all of the functions of SPEEDEO®. Store it carefully so that it can be consulted at any
time.
Product specications: SB-PF-SPO-003C model
Operating temperature: 0° to 40° C Operating hygrometry: 40% at 75° C Power supply: 230 V ~, 50 Hz
Maximum operating altitude: 2000 m Weight (excluding probes): 1.2 kg
Main box (internal use): IP 64
Customer Support: PISA, ITALY (8:30 A.M. to 4:30 P.M.) CET website: www.pentairpooleurope.com
- Warranty (excluding probes and consumables): 2 years
© 2019 Pentair International LLC, All rights reserved - The document is subject to change without notice
Trademarks and disclaimers: Speedeo®, Soleo® and Pentair® are trademarks and/or registered trademarks of Pentair and/or its aliated
companies. Unless indicated otherwise, names and brands of others that may be used in this document are not used to indicate an aliation or
endorsement between the owners of these names and brands and Pentair. Those names and brands may be the trademarks or the registered
trademarks of these parties, or others.
Waste treatment of electronic devices at the end of their service life:
The crossed-out bin placed on the main parts which make up the product indicates that it must not be disposed of with household
waste. It must be returned to an appropriate collection point for electronic device recycling (information available from the local
household waste collection service). This product contains potentially dangerous substances which may have adverse effects on the
environment and human health.
Declaration of conformity
Directives – Harmonised standards
Pentair International Sarl - Avenue de Sévelin 18 - 1004 Lausanne - Switzerland
We declare, under our own responsibility, that the product meets the directives
Other normative documents

p 07
p 09
p 10
p 11
p 13
p 14
p 15
p 16
p 17
p 27
p 28
p 18
p 19
p 20
p 22
p 23
p 24
p 25
p 04
p 06
p 06
PRESENTATION
> Possibilities for a pump with variable speeds
> Packaging contents / Functions of the device
> Description
INSTALLATION - SPECIFIC POINTS
> Fixing connections / hygiene
> Examples of installation types
> Water and air temperature probes
> Connection of IntelliFlo to IntelliBUS and other pumps with variable speeds
> Invertek convertor connection
MENUS
> Main menu / Radio menu
> Install / Heating pump / Information menu
> Filtration Length
> Filtration Speed / Set Time
CONNECTIONS Inlets / Outlets
> Inlet: connection for the end of a cover line / switch or remote control
> Outlet: connections for a controller and an IntelliChlor
> Outlet: connections for heating pump and solar heating
> Outlet: connections for lighting and a 3-way motorised valve
> Outlet: connections and automatic washing for a pneumatic valve
> Washing assisted by 6-way valve
> Navigating the menus
OTHERS
> Updating internal rmware / History menu
> pH / RedOx / chlorine ratio
Summary
01

GENERAL POINTS
- DANGER - INSTALLERS, POOL SPECIALISTS AND OWNERS MUST CAREFULLY READ THESE WARNINGS AND ALL
INSTRUCTIONS BEFORE USING THIS PRODUCT.
- WARNING - Most countries regulate the construction, installation and operation of public swimming pools and spas, and the construction of
residential pools and spas. It is important to comply with these regulations, many of which directly regulate the installation and use of this product.
Consult your local building and health codes for more information.
- ATTENTION - This installation and user guide contains important information on the installation, operation and safety of this product. This guide
should be provided to the owner and/or user of this product.
INSTALLATION
- DANGER - RISK OF ELECTRIC SHOCK or electrocution
BEFORE WORKING ON THIS DEVICE - Always cut the supply to the device at the circuit breaker before maintenance. Failure to do this may lead to
death or serious injury to service staff, pool users or others, due to an electric shock.
- DANGER - SERIOUS BODILY INJURY OR DEATH CAN RESULT IF THIS PRODUCT IS NOT INSTALLED AND USED CORRECTLY.
- WARNING - Before installing this product, read and follow the warnings and instructions of this guide. Failing to follow these warnings and
instructions may lead to serious injuries, death or material damage. Refer to www.pentairpooleurope.com for more information linked to this
product.
- WARNING - Connect the device to a differential interrupter. If this system is used to control the underwater lighting devices, a differential
interrupter must be installed upstream of these devices. Conductors downstream of the differential interrupter shall not occupy conduits, junction
boxes or enclosures containing other conductors, except if the conductors are also protected by a differential interrupter. Refer to valid local codes
for more details.
- WARNING - This product must be installed by an authorised or certied electrician or a qualied swimming pool professional. All of the applicable
installation codes and local regulations must also be respected. Poor installation will create an electrical hazard which could result in serious injury
or the death of pool users, installers or others due to electric shocks, and may also cause damage to property.
- DANGER - DISCONNECT THE SUPPLY CONNECTIONS BEFORE WORKING ON THIS DEVICE; ELECTRICAL POWER MAY BE SUPPLIED TO THE RELAY
TERMINALS FROM OTHER SOURCES.
- WARNING – CHEMICAL BURN HAZARD: Make sure all pumps are switched off at the main circuit breakers at the domestic distribution board before
drilling into any pipes. Set rules for all handling related to electrical aspects, water and chemical products. Group the supply pumps and chemical
product tanks in a safe and secured area.
- WARNING - Do not use this product to control an automatic swimming pool cover. There is a risk that swimmers could become trapped under the
cover.
- WARNING – Devices which are not intended for use in single-family dwellings may require additional safety equipment to comply with local
regulations.
- DANGER – Except for remote controls, install components at a minimum of at least 1.5 m (5 feet) from the inside wall of the pool or spa.
- DANGER - This product is intended for use in swimming pool applications only.
- ATTENTION - A sucient equipotential connection (min. 4.5 mm2 recommended), in accordance with local regulations, is obligatory for all metal
components of the swimming pool, including the pool pump. This is necessary for the electrical safety as well as reduction of the corrosion risk.
IMPORTANT SAFETY GUIDELINES, READ AND FOLLOW ALL OF THE INSTRUCTIONS, KEEP THESE INSTRUCTIONS
02

USE
- DANGER - DO NOT LET CHILDREN OPERATE THIS EQUIPMENT.
- WARNING – Strictly respect the safety and handling procedures from the acid manufacturers, including protective measures for hands, body and
eyes during transferring and using acid. Follow the prescribed safety precautions for handling muriatic acid intended for checking the water pH.
Muriatic acid may cause serious physical harm and may damage the swimming pool equipment. Extra care must be taken when installing,
maintaining and operating the acid pump feed systems. Acid is dangerous to handle and should be properly contained, transported, poured, stored
and dispensed.
- WARNING – Check the pH and sanitizer levels of the water before using the pool and make sure the ltration device is not obstructed.
- WARNING – Periodically use an independent pH and chlorine testing kit to ensure that the pH and chlorine is at a safe level. If the pH and Oxidation
Reduction Potential (ORP) or conductivity probes are broken, depleted or dirty with oils, lotions, or other contaminants, they can report inaccurate
results to the system causing incorrect water chemistry, which could harm people or equipment.
- WARNING – Consult the device display daily to ensure there are no alarm messages.
- DANGER – Water temperatures greater than 37.7° C (100° F) are a health hazard. Prolonged immersion in hot water may induce hyperthermia.
Hyperthermia occurs when the internal body temperature exceeds the normal temperature of 37° C (98.6 °F) by several degrees. Hyperthermia may
produce the following effects: (1) Unawareness of impending danger. (2) Failure to perceive heat. (3) Failure to recognise the need to leave the spa.
(4) Physical inability to leave the spa. (5) Harm to the foetus in pregnant women. (6) Unconsciousness leading to the risk of drowning. The use of
alcohol, drugs or medicine is a factor which increases the risk of hyperthermia in hot tubs and spas.
- WARNING - When mixing acid with water, ALWAYS ADD THE ACID TO THE WATER. Never add water to the acid. When adding a chemical product to
the swimming pool, carefully follow the manufacturer instructions.
- DANGER - DO NOT MIX SODIUM HYPOCHLORITE AND MURIATIC ACID.
- DANGER - Keep standard solutions away from children, ensure that the bottles are securely closed, store them in a dry and ventilated location and
do not let them freeze. The pH 4 calibration solution is acidic.
03

- Speed 1: Permits minimal circulation. Speed V1 is used for frost protection and is selected when the cover is
placed over the pool (if applicable). V1 will function 24h/day if the water T° > +28.0 °C. This speed is therefore
used when there are no bathers in the pool.
- Speed 2: Permits circulation of a larger amount of water when the cover is stowed (if relevant). This speed
is used when there are no bathers in the pool.
- Speed 3: Permits a strong ow of water when an accessory requires it. It is often chosen for a counter-cur-
rent jet, heating, cascade, etc. It is triggered in accordance with the parameters, either by a timer or a wired
remote control.
- Speed 4: Only used for backwashing of the lter. On some pumps, V4 cannot be adjusted and automatically
represents the maximum power.
SPEEDEO is intended to optimally control (via dry contacts [of which one is shared and one is a controllable
speed contact, a maximum of four]) the different rotation speeds of a variable speed ltration pump. There
are usually 4 speeds: V1, V2, V3, V4. SPEEDEO makes it possible to launch up to 3 pieces of equipment, whose
operation is linked to a speed. The rotation speeds at different speeds are directly pre-set on the control unit
(drive) of the pump. SPEEDEO will therefore select the most appropriate power according to the requirements
to save as much electricity as possibility without impairing the ltration quality.
Consumption is roughly speed squared, so when the rotation regime is divided by 2, the electricity consumption
of a pump is divided by 4! The average prot of SPEEDEO running a VS pump alongside a classic ltration of 1.5 cv
is €450 per year (ERDF base rate in 2015).
Foreword: management possibilities for a pump with variable speed control
Max. flow
pump
0
Min. pump
pump S1 S2 S3 S4
0 h 24 h12 h 15 h6 h 9 h 18 h
Example: typical day for a pool at 25.0°C in June in Europe
Consumption of a classic ltration pump S1 S2 S3 S4
At night, the curtain is closed.
Filtration runs at the minimum
speed V1 at night. V1 is very
quiet.
At 9:00 am, the curtain
is manually opened; the
speed automatically
changes to V2.
At midday, ltration goes up to V3 for one
hour to ensure the surface is well-skimmed.
In the afternoon, the NAC command and
cascade timer launch the pump at V3.
Backwashing of the
lter (taking a few
minutes) triggers V4.
One 1.5 cv pump
costs on average €600 per year
for electricity.
04

Filtration control:
- By calculating the time according to the pool temperature (automatic mode).
- By programming a 24 hour cycle (makes it possible to benet from off hours).
- By integrating the frost protection function (activation of the ltration below 3°C, modiable
value).
- By giving priority to the heating (if the value of this reference exceeds the set value, and if the
ltration is cut, ltration starts in the next 15 minutes).
- Possibility to select the start time and end time of the ltration in automatic mode (to prevent
noise at night). If SPEEDEO is connected to a SOLEO, this function is found on SOLEO.
- Possibility to increase or reduce the ltration time according to the use of the swimming pool
(economical mode = pool with a low number of visitors, turbo mode = pool with a high number of
visitors) or by default + or - 30% (value can be adjusted).
- Possibility to change into “SHOCK” mode (forcing of the ltration and electrolyser for 24 hours).
- Possibility to change the speed according to the position of the pool cover (motorised cover) if
there is a position contact connection on the dedicated inlet.
- Possibility to change the speed according to the position of a command (interrupter, end
position sensor of the motorised cover).
Control of 3 devices:
- By synchronisation with operation of the pump (each connected device will only be authorised
to operate if the ltration runs at a sucient rate).
SPEEDEO also makes it possible to visualise, on its screen (in the technical room):
- time
- water temperature
- operating speed (S1 to S4)
- status of the 3 outlets (S1 S2 S3, ON or OFF)
- air temperature (if second sensor present)
THEREFORE IN SUMMER AND WINTER, YOU NO LONGER NEED TO WORRY ABOUT YOUR
FILTRATION AND YOU LIMIT THE INTERVENTIONS IN THE TECHNICAL ROOM TO A BARE
MINIMUM.
Functions
05

SPEEDEO®
VARIABLE SPEED PUMP
VALID
ESC
Connector cover
(Removable with a at screwdriver)
01:03 Water:+24.3°C
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C
SB-PF-SPO-003C SB-SE-TEC-006A
S/N 1234ABCD1234ABCD1234ABCD01
QC Passed
Pentair International Sarl
Avenuede Sévelin 18
CH-1004 Lausanne, Switzerland
Mfg Year
Apr-2019
MADE IN ITALY
SCAN
ME
230 V 50 Hz~/IP64/3.2 W
433.4 MHz
Description
Screw cover
(Insulator of acidic vapours
and humidity circulating
via the screw hole)
Fuse holder (1 A 250 VAC)
Status light
(for updates)
Elastomer cover
(Insulator of acidic vapours
and humidity)
SPEEDEO automatically controls the pump rotation speed with variable speed, enabling the function of
programmed or activated events.
FRONT VIEW
Water or air
temperature sensor
(see p06)
USB / mini USB
Update of the software
Replace the soft
cover after each
opening.
Clamp band
For mounting the water temperature probe
Backlit screen
(4 x 20 characters)
Menu navigation buttons
(Esc/Bottom/Top/Valid.)
Manufacturer’s plate
Serial number
06

1
8
5
mm
15
0
m
m
1
2
3
1
2
4
3
Pierce three holes in accordance with the below dimensions then place 3 suitable plugs.
1 - Tighten the screw at the top, leaving 2 mm under the screw head, then hang the device on this.
2 - Place the 2 lower screws.
3 - Add the 2 lower screw covers to ensure a full seal.
Wall xing
- This device is intended to be used inside, installed in a technical room which cannot be accessed by
children.
- Set the device at a height lower than 2 m using three screws (4 to 5 mm diameter) in appropriate plugs
for the type of support and x the device vertically on a clean support which is able to bear a minimum
vertical load of 5 kg.
A safety cover which cannot be unclipped without a tool is positioned above the connectors which provide
the voltage. > Place a at screwdriver on the at part of clips 2 and 3, while keeping pressure on to unclip it.
After each intervention, replace the
orange safety cover then the exible
grey cover.
07

OUT 1 OUT 2
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
BUS IN 1 IN 2
OUT 3
N L
230 V ~
185 mm
150 mm
Ø 8/8.8 mm
30 mm max.5 mm Ø 8/8.8 mm
30 mm max.5 mm
= RO2V (3 x 1.5 mm2min.) = RO2V (2 x 1.5 mm2min.)
POWER SUPPLY 230 V / 50 Hz +- 10%
OUT 1 - 230 V 10A max.
OUT 2 - 230 V 10A max.
OUT 3 - 230 V 10A max.
Compatible power supply cables 230 V Compatible dry contact cables
Cable ducts
- must be installed if an outlet is in use,
(to stop any humidity or acidic vapour entering)
Caps
- must be installed if an outlet is not in use
(to stop any humidity or acidic vapour entering)
- The device must be installed by a qualied technician according to valid local regulation
- This device is permanently connected.
- The power supply to the device is cut by its interrupter, which must be close and must remain
accessible at all times.
- The device needs to be connected to the earth and its power supply needs to be protected by 16A 30
mA differential protection. This protection must be cut before any intervention on the device.
- Overvoltage category II (2,500 V peak) electrical device. If necessary, place overvoltage protection
equipment before the device.
- The device must be placed close to the electrical cabinet to aid connections (3 m max.).
Electrical connections regulation
Interchangeable fuse
FST 5x20 250 V AC 1A 5x20 fast
Screw terminals
Slotted screwdriver 2.5 mm/0.5-0.6 Nm
REAR VIEW
The supply cable as well as the cables of the
dry power contacts must be placed in a plated
and closed channel under the device.
08

O.R.P.
pH
pH
Water
Flow switch
Air T.
SPEEDEO®
VARIABLE SPEED PUMP
VALID
ESC
SPEEDEO®
VARIABLE SPEED PUMP
VALID
ESC
16:03 Water:+26.3°C
Filtration: ON
RedOx: 736mV
Air:+25.0°C pH: 7.2
SOLEO®
FILTRATION, PH & ORP
VALID
ESC
Indicative connections
Indicative connections
- Inlet connections: Water temperature, cover presence sensor
- Outlet connections: Heating, electro-pneumatic valve, solenoid valve
- Inlet connections: Cover presence sensor
- Outlet connections: Heating, solenoid valve
Examples of installation types
Controlling a solenoid valve with SPEEDEO makes it
possible to benet from full power for activities using V3.
Opening the solenoid valve will stop the ows in the main
circuit and cut the ow-switch of the devices with this
safety device (electrolyser, heating).
Controlling a solenoid valve
with SPEEDEO makes it
possible to benet from full
power for activities using V3.
Opening the solenoid valve
will stop the ows in the main
circuit and cut the ow-switch
of the devices with this
safety device (electrolyser,
heating).
01:03 Water:+24.3°C
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C
01:03 Water:+24.3°C
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C
09

Ø 10 mm
12
1 2
3
NO OK
Ø 50/70 mm
- Once SPEEDEO is linked to a SOLEO, the temperature values saved and displayed by SPEEDEO are
picked up by the SOLEO.
The temperature sensor provided can also be used as an air temperature sensor.
SPEEDEO is supplied with a temperature probe which is suitable for water. It is possible to mount a second temperature
probe for the air temperature used to manage the frost protection process of heated technical rooms.
The probe time can be staggered via the Temperature Menu > Calibration: (see p09)
1 - Connect the cables to Inlet 2 in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for
3 secs. A star appears in the top right corner of the home screen).
3 - In the Inlets / E1-E2 sub-menu (in accordance with chosen terminal), select T° Air to
indicate that a temperature sensor is connected to the corresponding inlet.
INSTALLATION OF THE AIR TEMPERATURE PROBE (OPTION)
- If the air temperature probe is connected, it automatically becomes the reference value for freeze protec-
tion management (unless SPEEDO is connected to a SOLEO). The air temperature probe is placed outdoors,
away from direct sunlight so that the measurement is not distorted. It can be easily moved due to its 6 m long
cable.
1 – Mount it on a wall with screws. 2 – Mount it on a horizontal bar of a grate with a cable tie.
INSTALLATION OF THE WATER TEMPERATURE PROBE
The temperature probe can be installed outside the bypass in front of the lter of the pump or in
front of the lter inlet in order to improve the reading precision.
1 - Pierce the PVC pipe (diam. 50-70 mm) to a diameter of 10 mm (3/8 inch).
2 - Remove the burrs and check the O-ring under the probe.
3 - Place the sensor in the hole, then place the clamp band in the groove and tighten.
Water and air temperature probes.
10

Unconnected
VARIABLE SPEED PUMP
01:03 Water:+24.3°C
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C IntFlo
STEP 1
+12
A
B
COM
STEP 2
STEP 3
OVRD
ICOM
ON
12345
BUS
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
230 V
EARTH
NEUTRAL (N)
PHASE (L)
PENTAIR VS2 (Supero, SuperMax, Ultraow, S5P2R, Challenger and
Whispero): Connections and functions
Connect the pump to the 230 V, connect to the 10-m long IntelliFlo cable (ref 350122), the green/yellow to the
'BUS', adhering to the colours.
PENTAIR IntelliFlo: Connections and functions
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select 4 speeds and hold down Valid.
PENTAIR VS1 (Supero, Ultraow, SuperMax and S5P2R): Connections
and functions
Control the speeds S1 < S2 < S3 < S4 and S4 at 100% on the pump drive.
Set the DIP switches 1, 2, 3, 4 on the pump drive to ON.
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select 4 speeds and hold down Valid.
Control the speeds S1 < S2 < S3 < S4 and S4 at 100% on the pump drive.
11

INPUT 1
INPUT 2
INPUT 3
INPUT 4
COMMON
Control the appropriate speeds for the HAYWARD pump, 1 (Eco), 2 (Normal) and 3 (Max).
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
Control the appropriate speeds for the pump, 1 (Eco), 2 (Normal) and 3 (Max).
- The SPECK Eco Touch pump functions for 5 minutes at maximum speed after starting.
SPECK Eco Touch: Connections and functions
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select 3 speeds and hold down Valid.
HAYWARD VSTD: Connections and functions
ZODIAC FloPro VS: Connections and functions
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select 4 speeds and hold down Valid.
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select Invertek and hold down Valid.
Control speeds 1 < 2 < 3 < 4 on the pump drive
- Control all operation lengths at '0'
!! Terminal under the user interface!!
12

4321 5 6 7 8 9 10 11
Terminal mode:
P12 = 0
P15 = 2
Common = 50
Speed 1 = 51
Speed 2 = 52
Speed 3 = 53
Speed 4 = 54
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
On the pump, control the speeds N1 < N2 < N3 < N4 and N4 at 100% / 'EXTERNAL = FIX SPEED'
and 'SIGNAL = CONTINUED'. - The pump functions for 5 minutes at maximum speed after starting.
SPECK 90 Eco Motion: Connections and functions
1 - Connect a 5 x 0.75 mm2 cable in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select 4 speeds and hold down Valid.
This assembly allows a standard filtration pump with a fixed speed to be transformed into a pump with
variable speeds, and also benefits from a strong energy gain.
Invertek Drives / Optidrive E2 variator: Connections
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (on the main menu, press Esc and Valid at the same time for 3 secs. A star
appears in the top right corner of the home screen).
3 - On the Filtration Speed / Type sub-menu, select Invertek and hold down Valid.
13

-Radio Channel : 01
VALID VALID VALID
01:22 Water:+26.6°C '
Filtration : S3
S1:OFF S2:ON S3:OFF
Air:+26.8°C WASHING
Main menu
Water temperature
Pairing with a SOLEO
Filter clean required
(not displayed for
automatic washing on pneumatic valve)
Time
Air temperature
(if 2nd sensor connected, see p06)
Operating speed
Status of outlets S1, S2, S3
Home menu > Radio menu :
This symbol (antenna) indicates that SPEEDEO is connected to a SOLEO.
Radio menu (radio pairing between SOLEO and SPEEDEO)
The default radio channel is Channel 01 (same for SPEEDEO). The devices have a range of 30 m. A
SOLEO and a SPEEDEO set on the same radio channel and at a distance maximum 30 m will
automatically be paired. If several different Combi installations are close to each other, it is possible to
shift the radio channel of one of the installations to one of the other 9 channels (2 to 10) to prevent
interference. It is therefore important to choose the same channel number on the 2 devices to be
paired.
If SPEEDEO is linked to a SOLEO, the SOLEO filtration outlet is only supplied with power when
SPEEDEO starts the VS pump (whatever the speed). This SOLEO filtration outlet can for
example be used to supply a UV light.
- Once SPEEDEO is linked to a SOLEO, the temperature values saved and displayed by SPEEDEO
are picked up by the SOLEO.
Information
Language
Update
-Radio
-Radio Channel: 01
16:03 Water:+26.3°C '
Filtration: ON
RedOx: 736mV
Air:+25.0°C pH: 7.2
14

SPEEDEO®
VARIABLE SPEED PUMP
VALID
ESC
*
16:03 Water:+26.3°C *
Filtration: ON
RedOx: 061mV
Air:+25.0°C pH: 7.2
Information about the
OS version
Choice between French
and English
Choice between the 14
lighting modes
See p12-13 (this menu is not available if a SOLEO is linked)
See p11
See p17-18
See 13 (this menu is not available if a SOLEO is linked)
See p14 (accessible via Install)
See p15 (accessible via Install)
See p19 (accessible via Install)
See p10
The Install menu menu is active.
It automatically deactivates after 15 mins of inactivity.
-Filtration length
Filtration speed
Filter washing
Inputs
Outputs
-Setting the time
Temperatures
Information
Languages
Update
Radio
Lighting
SPEEDEO v2
Version : 2.0
pentairpooleurope.com
SPEEDEO controls the equipment in the technical room, and the wrong settings may have serious
consequences for the safety of the pool. Because of this, access to certain initial configuration
functions is reserved for professionals, or people whose experience enables them to modify these
parameters while being fully aware of the consequences. In
order to limit accidental access, the Install menu menu has
secured access. (from the main menu, simultaneously hold
down Esc and Valid for 3 secs. A star appears in the top right
corner of the home screen).
Access to restricted access mode 'Install'
Menu organisation / Heating menu / Information menu
-Heating pump
Calibration
Antifreeze : +3°C
-LANGUAGE : French-Mode : Californian
-Heating pump: AUTO
Set point : 30°C
Priority : NO
CALIBRATION
-Temp. Water : +23.2°C
-Temp. Air : +23.3°C
Below this temperature, the filtration runs 24/7 to prevent the pool from freezing (active wintering).
- If the air temperature probe is connected: it becomes the reference value for freeze protection management. Place it
outdoors, out of direct sunlight so that the measurements are not distorted (see p06). - If the air temperature probe is not
connected: the water temperature becomes the reference value for freeze protection management. Please check that the
technical room is not heated or has a significantly different temperature in comparison with the temperature outside. If this is
the case, the difference must be compensated by Calibration.
This setting makes it possible to deliberately correct any
difference with another reference thermometer.
AUTO Activate the heating pump until the set point value has
been reached. Priority: NO Make sure the heating pump
does not start until the filtration is already running. Priority:
YES Start filtration so that the heating can function.
01:03 Water:+24.3°C *
Filtration: V2
S1:OFF S2:ON S3:OFF
AIR:+25.9°C
15

5°0°
0 hrs
5 hrs
3 hrs
10 hrs
15 hrs
20 hrs
24 hrs
10° 15° 20° 25° 30° 35°
VS
t=T
VS
Blue Class.
Blue
t=T/2
Class.
t=T VS (the daily filtration time is equal to the temperature value in ° Celsius): At 10 °C, filtration will function 10 hrs/day,
at 20 °C 20h/day... Aimed at pumps with variable speed control, this mode filters the most.
BlueVS Aimed at pumps with variable speed control, this mode filters less, particularly at temperatures below 15 °C,
where bacteria do not easily develop.
t=T/2Classic (the daily filtration time is equal to half the temperature value in ° Celsius): At 10 °C, filtration will function
5 hrs/day, at 20 °C 10 hrs/day ...Aimed at pumps with fixed speeds, this mode filters the most.
Blue Classic Aimed at pumps with fixed speeds, this mode filters less, particularly at temperatures below 15 °C, where
bacteria do not easily develop.
ltration [hrs/day]
- Once the SPEEDEO is linked to a SOLEO, this menu Filtration Length disappears. The
SOLEO will manage the filtration length.
SPEEDEO proposes 4 different algorithms to suit different preferences concerning the ratio of the
number of hours for filtration according to the water temperature.
Menu: Filtration Length (daily) / Algorithm
This control increases or decreases the filtration time.
- TURBO increases the filtration time (modifiable factory setting: +30%) to compensate for a pump
which is undersized with respect to the height of the pool, or to compensate for intensive pool use with
more bathers than normal.
- ECO decreases the filtration time (modifiable factory setting: -30%) to compensate for a pump which
is undersized with respect to the height of the pool, or to compensate for underactivity (e.g. a pool at a
secondary residence which has not been used for a long period).
Menu: Filtration Length (daily) / Eco-Normal-Turbo Mode
1 - Start the secured Install menu (from the main menu, simultaneously hold down
Esc and Valid for 3 secs. A star appears in the top right corner of the home screen).
2 - On the Mode sub-menu, choose between Eco / Normal / Turbo.
3 - If necessary, modify the coefficient Eco or Turbo.
Home menu > Filtration Length menu:
-Mode : Normal
Algorithm : VSClass
Eco mode : -30%
Turbo mode: +30%
1 - Start the secured Install menu (from the main menu, simultaneously hold down Esc and Valid for 3 secs. A star appears
in the top right corner of the home screen).
2 - On the Filtration Length / Algorithmsub-menu, select your chosen mode.
Water temperature [°C]
16

-Hour : 16 h
Minute : 03 min.
- Once the SPEEDEO is linked to a SOLEO, this menu Setting the time disappears. The SOLEO
will manage the time settings.
- Once the SPEEDEO is linked to a SOLEO, this menu Filtration Length disappears. The
SOLEO will manage the filtration length.
-Filtration : ON
Start : 05:00
Stop : AUTO
mode : TURBO
Menu: Filtration Length / Auto/On/Off/Timer/Shock Mode
Filtration speed menu
Time set menu
-Mode: AUTO
Events
-Mode : MANUAL
Speed : S2
S2 timer : YES
Start : 11:00
End : 16:00
S3 timer : YES
Start : 17:00
End : 18:00
Cover open : NO
Heating : NO
S3 inlet 1 : YES
Event creation:
S2 timer = If YES the pump is running at S2 from the Start time to End.
S3 timer = If YES the pump is running at S3 from the Start time to End.
Cover open = Opening the cover (if connected) changes the speed from
S1 to S2.
Heating = Starting the heating pump (see p13) activates S2.
Inlet 1 S3 = Closing a contact at Inlet 1 starts S3 (e.g. connecting a switch
for activating a waterfall, an animation, swimming against the current...).
Select current mode:
AUTO = Automatically calculates the filtration length according to the water
temperature.
ON = Filtration runs 24/7.
OFF = Filtration stops (note - anti freeze mode becomes inactive).
TIMER = Filtration runs during the selected time period (see below)
CHOC = Activates 24-hour filtration. This function can be useful after the pool
has been used by many visitors and when the pool temperature is high. At the
end of the mode CHOC, SPEEDEO returns to normal AUTO.
This menu gives you control of the filtration start and end time, to control the level of noise linked to your pool (filtration noise),
for the sake of the neighbourhood. By default, leave End on AUTO.
In AUTO, SPEEDEO calculates the filtration end time.
MANUAL displays the field Speed which enables
manual selection of the rotation speed for the pumps
with variable speeds.
In AUTO, these events which adjust the different rotation
speeds for the pumps with variable speeds. The field for
Events will appear.
Home menu > Filtration Length menu:
Home menu > Filtration Length menu:
Makes it possible to set the time of the device. If the power supply is interrupted for more
than 30 min., reinstalling the time is necessary.
17

OUT 1 OUT 2
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
BUS IN 1 IN 2
OUT 3
N L
230 V ~
OUT 1 OUT 2
COMM. SPEED 1 SPEED 2 SPEED 3 SPEED 4
BUS IN 1 IN 2
OUT 3
N L
230 V ~
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (from the main menu, simultaneously hold down Esc and Valid for 3 secs. A star appears
in the top right corner of the home screen).
3 - On the Inlets / E1-E2 sub-menu (in accordance with chosen terminal), select COVER CONTACT to indicate that a limit
contact has been connected to the corresponding inlet.
4 - On the Filtration Length / Cover Open sub-menu, select YES so that filtration is carried out while the cover is open (the
cover does not cover the pool). This is the primary function of the Filtration Length / Start setting (despite the setting of an
hour from the start and/or end of filtration, if the cover does not cover the pool all day, filtration will run all day).
5 - On the Filtration Speed / Events / Cover Open sub-menu, select YES so that the filtration speed changes from S1 to S2.
Inlet: connection for the end of a cover line
The contact is closed when the cover is covering the pool
1 - Connect the cables in accordance with the diagram.
2 - Start the secured Install menu (from the main menu, simultaneously hold down Esc and Valid for 3 secs. A star appears
in the top right corner of the home screen).
3 - On the Inlets / E1-E2 sub-menu (in accordance with chosen terminal), select OTHER to indicate that a dry contact has been
connected to the corresponding inlet.
Inlet: connection for a switch, a remote control...
Inlet: connection for an air temperature probe (see p06)
It is possible to connect any type of dry contact inlet (switch, remote control, relay) which activates an
outlet.
18
