RTD50CS
RTD TEMPERATURE SENSOR FOR TEMPERATURE MEASUREMENT TO 400°F (204°C)
INSTALLATION INSTRUCTIONS
THERMAL MANAGEMENT SOLUTIONS EN-DigiTraceRTD50CS-IM-H5885601/13
DESCRIPTION
The RTD50CS is a 50-foot three-wire platinum RTD (resistance
temperature detector) used with monitoring and control systems,
such as our DigiTrace C910 or ACCS-30 controllers.
The RTD50CS can be installed directly to the controller using the
supplied 1/2-inch conduit fitting or to an RTD junction box where
RTD extension wire is used.
TOOLS REQUIRED
ǩ PPIODWEODGHVFUHZGULYHU
ADDITIONAL MATERIALS REQUIRED
ǩ $7DOXPLQXPWDSH
KIT CONTENTS
Qty Description
1 RTD temperature sensor
This component is an electrical device. It must be installed
correctly to ensure proper operation and to prevent shock or
fire. Read these important warnings and carefully follow all the
installation instructions. Component approvals and performance
are based on the use of specified parts only. Do not use substitute
parts or vinyl electrical tape to make connections.
WARNING:
Extension Wires
Wire size
(each of 3)
20 AWG, stranded tinned copper
Wire insulation
rating
YROWV
Length IHHWPIOH[LEOHDUPRULQPP
lead wire
Outer shield Stainless steel flexible armor
Maximum exposure
temperature
r)r&
Conduit bushing ½ in NPT
APPROVALS
$SSURYDOVDVVRFLDWHGZLWKWKHFRQWUROGHYLFH
SPECIFICATIONS
Sensor
Housing 316 stainless steel
Dimensions LQPPOHQJWKLQPPGLDPHWHU
Sensing area 1½LQPP
Accuracy sr)r&DWr)r&
Range Ǟr)WRr)Ǟr&WRr&
Resistance RKPVDWr&α RKPVRKPr&

2 / 2THERMAL MANAGEMENT SOLUTIONS EN-DigiTraceRTD50CS-IM-H5885601/13
WWW.THERMAL.PENTAIR.COM
© 2012-2013 Pentair. PN P000001512
NORTH AMERICA
Tel: [phone]
Fax: [phone]
Tel: [phone]
Fax: [phone]
[e-mail]
EUROPE, MIDDLE EAST, AFRICA
Tel: [phone]
Fax: [phone]
[e-mail]
ASIA PACIFIC
Tel: [phone]
Fax: [phone]
[e-mail]
LATIN AMERICA
Tel: [phone]
Fax: [phone]
[e-mail]
Pentair and DigiTrace are owned by Pentair or its global affiliates. All other trademarks are the property of their respective owners. Pentair reserves the
right to change specifications without prior notice.
POSITIONING THE SENSOR
Position the RTD sensor in the lower quadrant of the pipe as shown
in the diagram. Place the RTD sensor at least 3 feet (1 m) from
pipe supports, valves, or other heat sinks. Tape the sensor firmly
WRWKHSLSHZLWK$7DOXPLQXPWDSHPDNLQJVXUHWKHUHLVQRDLU
space between the sensor and the pipe. Do not use the same piece
of AT-180 tape to overlap the RTD and heat-trace cable.
90 Heating cable
Control sensor
AT-180 tape AT-180 tape
Heating cable
Control
thermostat bulb
Double traced
Single traced
ROUTING THE RTD
Electrical Wiring Guidelines:
0RVWHOHFWULFDOFRGHVVXFKDV1(&SHUPLW&ODVVFLUFXLWV
to occupy the same cable, enclosure, or raceway without regard
WRZKHWKHUWKHLQGLYLGXDOFLUFXLWVDUHDOWHUQDWLQJFXUUHQWRUGLUHFW
FXUUHQWSURYLGLQJDOOFRQGXFWRUVDUHLQVXODWHGIRUWKHPD[LPXP
YROWDJHRIDQ\FRQGXFWRUVLQWKHFDEOHHQFORVXUHRUUDFHZD\
RTD Direct Connection to Controller
The RTD50CS can be terminated directly at the controller using
the supplied 1/2-inch NPT fitting. In this configuration, no addi-
tional extension wire is required.
RTD50CS WIRING
Connect the wires as shown.
Note: Ground RTD extension wire shield at one end only,
preferably at DigiTrace electronics end.
Red (Source)
White
Red
Red Red (Compensate)
Field Wiring (if required)
White (Common return)
Ambient sensing
RTD50CS
RTD50CS
DigiTrace C910
or ACCS-30
electronic
controller
XL-Trace
Typical Fire Sprinkler Freeze Protection System End Seal
DigiTrace C910
or ACCS-30
electronic
controller
RTD50CS
Typical Freezer Frost Heave Prevention System
