Pentair FLECK 5812 XTR User guide

INSTALLER
MANUAL
WATER PURIFICATION
FLECK
5812 XTR

Installer Manual Fleck 5812 - XTR - Table of contents
2 / 132 Ref. MKT-IM-019 / E - 14.10.2019
Table of contents
1. Generalities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1. Scope of the documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
1.2. Release management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3. Manufacturer identifier, product . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.4. Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.5. Abbreviations used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.6. Norms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.6.1. Applicable norms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.6.2. Available certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.7. Procedure for technical support . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.8. Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.9. Limitation of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.10. Scan & Service application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2. Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1. Safety pictograms definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2. Serial label location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3. Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3.1. Personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.3.2. Material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4. Hygiene and sanitization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4.1. Sanitary issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4.2. Hygiene measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3. Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1. Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
3.1.1. Performance flow rate characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.2. Outline drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
3.2.1. Base 2,5" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2.2. Base 4". . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.3. Description and components location . . . . . . . . . . . . . . . . . . . . . . .19
3.4. System regeneration cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.4.1. Downflow regeneration cycle (5-cycles operation) . . . . . . . . . . . . . . . . 20
3.4.2. Upflow regeneration cycle (5-cycles operation). . . . . . . . . . . . . . . . . . . 22
3.4.3. Variable Refill/Brining regeneration cycle (5-cycles operation). . . . . . 24
3.4.4. Filter cycle (3-cycles operation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.5. Configurations for downflow softener, upflow softener and filter 28
3.5.1. Downflow softener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.5.2. Upflow softener. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.5.3. Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.6. Options available on the valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Installer Manual Fleck 5812 - XTR - Table of contents
Ref. MKT-IM-019 / E - 14.10.2019 3 / 132
4. System sizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
4.1. Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.1.1. Injector/DLFC/BLFC-Valve configuration . . . . . . . . . . . . . . . . . . . . . . . 30
4.1.2. Hard water bypass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.1.3. Soft/hard water refill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.2. Sizing a softener (single unit) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.2.1. Parameters to be considered. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.2.2. Determining the required volume of resin . . . . . . . . . . . . . . . . . . . . . . 33
4.2.3. Resin exchange capacity and capacity of the unit . . . . . . . . . . . . . . . . 34
4.2.4. Valve configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.2.5. Cycle time calculation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.3. Salt amount definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.4. 1650 Injector flow rates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
5.1. Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.2. Safety notices for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.3. Installation environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.3.1. General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.3.2. Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.3.3. Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.3.4. Mechanical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.4. Integration constraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.5. Valve connection to piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.5.1. Top-mounted valve installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.6. Block diagram and configuration example . . . . . . . . . . . . . . . . . . 48
5.7. Regeneration types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
5.8. Electrical connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.9. By-passing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5.10. Drain line connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
5.11. Overflow line connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
5.12. Brine line connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Installer Manual Fleck 5812 - XTR - Table of contents
4 / 132 Ref. MKT-IM-019 / E - 14.10.2019
6. Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.1. Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
6.2. Touchscreen controller quick start . . . . . . . . . . . . . . . . . . . . . . . . . 58
6.2.1. Quick start setting reference chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
6.2.2. Format screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
6.2.3. Assistance name screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
6.2.4. Assistance phone screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
6.2.5. Assistance interval screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
6.2.6. Day and time screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
6.2.7. User assistance screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
6.2.8. Settings screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
6.3. Master setting programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
6.3.1. Master setting screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
6.3.2. Master setting reference chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
6.3.3. Format screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
6.3.4. USB connection for field programming . . . . . . . . . . . . . . . . . . . . . . . . . 72
6.3.5. Valve screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
6.3.6. Regeneration screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
6.3.7. Relay output screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
6.3.8. Meter screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
6.3.9. Settings review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
6.3.10. Water Saver Regen screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
6.3.11. Remote Regeneration screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
6.3.12. Chlorine generation screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
6.3.13. Non-factory setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
6.4. Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
6.4.1. Error log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
6.5. Resetting the controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
7. Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
7.1. Water filling, draining and waterproofness inspection . . . . . . . . .95
7.1.1. Activating the softener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
7.2. Sanitization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
7.2.1. Disinfection of water softeners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
7.2.2. Sodium or calcium hypochlorite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
7.2.3. Electro chlorination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Installer Manual Fleck 5812 - XTR - Table of contents
Ref. MKT-IM-019 / E - 14.10.2019 5 / 132
8. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
8.1. Display during operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
8.2. Display during regeneration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
8.3. Controller operation during programming . . . . . . . . . . . . . . . . . . 98
8.4. Manual regeneration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
8.5. Operation during a power failure . . . . . . . . . . . . . . . . . . . . . . . . . . 99
8.6. Remote lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
8.7. Sleep mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
9. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
9.1. General system inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
9.1.1. Water quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
9.1.2. Mechanical Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
9.1.3. Regeneration test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
9.2. Recommended maintenance plan . . . . . . . . . . . . . . . . . . . . . . . . 102
9.2.1. Valve used for softening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
9.2.2. Valve used for filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
9.3. Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
9.3.1. Use original spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
9.3.2. Use original approved lubricants. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
9.3.3. Maintenance instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
9.4. Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
9.4.1. First steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
9.4.2. Controller replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
9.4.3. Power head disassembly/replacement. . . . . . . . . . . . . . . . . . . . . . . . 107
9.4.4. Piston and/or seals & spacers and/or brine valve replacement. . . . 109
9.4.5. Controller motor replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
9.4.6. Injector cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
9.4.7. Optical sensor replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
9.4.8. BLFC cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
9.4.9. Meter replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
9.4.10. Encoding wheel cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
9.4.11. Valve on tank assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
10. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
10.1. Error detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
10.2. Error alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Installer Manual Fleck 5812 - XTR - Table of contents
6 / 132 Ref. MKT-IM-019 / E - 14.10.2019
11. Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
11.1. Valves list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
11.2. Power head parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
11.3. Valve parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
11.4. Safety brine valve 2310 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
11.5. Drain line flow controls list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
11.6. Bypass valve assembly and connectors list . . . . . . . . . . . . . . . . . 129
11.7. CE compliance part list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
12. Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131

Installer Manual Fleck 5812 - XTR - Generalities
Ref. MKT-IM-019 / E - 14.10.2019 7 / 132
1. Generalities
1.1. Scope of the documentation
The documentation provides the necessary information for appropriate use of the product. It informs
the user to ensure efficient execution of the installation, operation or maintenance procedures.
The content of this document is based on the information available at the time of publication. The
original version of the document was written in English.
For safety and environmental protection reasons, the safety instructions given in this documentation
must be strictly followed.
This manual is a reference and will not include every system installation situation. The person
installing this equipment should have:
• training in the Fleck series, XTR controllers and water softener installation;
• knowledge of water conditioning and how to determine proper controller settings;
• basic plumbing skills.
This document is available in other languages on www.pentairaquaeurope.com/product-finder/
product-type/control-valves.
1.2. Release management
1.3. Manufacturer identifier, product
Manufacturer: Pentair International LLC
Avenue de Sevelin 18
1004 Lausanne
Switzerland
Product: Fleck 5812 - XTR
1.4. Intended use
The device is intended to be used for residential, commercial and light industrial applications only and
it is purpose-built for water treatment.
Revision Date Authors Description
A10.11.2017 BRY/ARE First edition.
B09.01.2018 BRY/FLA Corrections on chlorine generation.
C23.02.2018 BRY/ARE Part numbers actualisation.
D13.07.2018 BRY/FIM Address change, Bleam information and valve on
tank assembly.
E14.10.2019 BRY Maintenance plan.

Installer Manual Fleck 5812 - XTR - Generalities
8 / 132 Ref. MKT-IM-019 / E - 14.10.2019
1.5. Abbreviations used
BLFC ..................................................................................Brine Line Flow Controller
BV.......................................................................................Brine Valve
DF.......................................................................................Down Flow
DLFC ..................................................................................Drain Line Flow Controller
Inj .......................................................................................Injector
QC.......................................................................................Quick Connect
Regen.................................................................................Regeneration
S&S ....................................................................................Seals & Spacers
SBV.....................................................................................Safety Brine Valve
TC .......................................................................................Time Clock
UF.......................................................................................Up Flow
1.6. Norms
1.6.1. Applicable norms
Comply with the following guidelines:
• 2006/42/EC: Machinery Directive;
• 2014/35/UE: Low Voltage Directive;
• 2014/30/UE: Electromagnetic compatibility;
• 2011/65/CE: Restriction of use of certain hazardous substances in electrical and electronic
equipment (RoHS);
• UNIEN ISO9001.
Meets the following technical standards:
• EN 55014-1;
• EN 55014-2;
• EN 61000-3-2;
• EN 61000-3-3;
• EN 61000-6-1;
• EN 61000-6-2;
• EN 61000-6-3;
• EN 61000-6-4;
• EN 61010-1.
1.6.2. Available certificates
•CE;
•DM174;
•ACS.
Please find beside the certifications for
some of our product families. Please
note that this list is not an exhaustive list
of all our certifications. In case of need
for more information please contact us.

Installer Manual Fleck 5812 - XTR - Generalities
Ref. MKT-IM-019 / E - 14.10.2019 9 / 132
1.7. Procedure for technical support
Procedure to follow for any technical support request:
ACollect the required information for a technical assistance request.
→ Product identification (see 2.2. Serial label location, page 11 and 9.3. Recommendations,
page 105);
→ Problem description of the device.
BPlease refer to the chapter, 10. Troubleshooting, page 118. If the problem persists contact your
supplier.
1.8. Copyright
© 2019 Pentair International Sàrl All rights reserved.
1.9. Limitation of liability
Pentair Quality System EMEA products benefit, under specific conditions, from a manufacturer
warranty that may be invoked by Pentair’s direct customers. Users should contact the vendor of this
product for applicable conditions and in case of a potential warranty claim.
Any warranty provided by Pentair regarding the product will become invalid in case of:
• improper installation, improper programming, improper use, improper operation and/or
maintenance leading to any kind of product damages;
• improper or unauthorized intervention on the controller or components;
• incorrect, improper or wrong connection/assembly of systems or products with this product and
vice versa;
• use of a non-compatible lubricant, grease or chemicals of any type and not listed by the
manufacturer as compatible for the product;
• failure due to wrong configuration and/or sizing.
Pentair accepts no liability for equipment installed by the user upstream or downstream of Pentair
products, as well as for process/production processes which are installed and connected around or
even related to the installation. Disturbances, failures, direct or indirect damages that are caused by
such equipment or processes are also excluded from the warranty. Pentair shall not accept any
liability for any loss or damage of profits, revenues, use, production, or contracts, or for any indirect,
special or consequential loss or damage whatsoever. Please refer to the Pentair List Price to know
more about terms and conditions applicable to this product.

Installer Manual Fleck 5812 - XTR - Generalities
10 / 132 Ref. MKT-IM-019 / E - 14.10.2019
1.10. Scan & Service application
Scan & Service mobile application is the ideal support for the maintenance person in his daily
business. A simple scan of an identification (ID) label (1) present on the valve with a smartphone gives
an instantaneously access to all updated information related to the product, such as:
• valve’s and tanks detailed configuration;
•manuals;
• spare parts lists;
• troubleshooting recommendations;
• multi-lingual videos, detailing how to best service a part;
• informations about new products, latest technologies, novelties about the Blue Network
program, etc....
No. Operation
ADownload the application "Scan & Service" from or in a
smartphone (4).
BOpen the application "Scan & Service".
CScan the bleam (3) stuck on the valve (2).
DNavigate to find information.

Installer Manual Fleck 5812 - XTR - Safety
Ref. MKT-IM-019 / E - 14.10.2019 11 / 132
2. Safety
2.1. Safety pictograms definition
2.2. Serial label location
Note
Ensure that the serial label and the safety tags on the device are completely legible and
clean. If necessary, replace them with new tags and put them in the same places.
Caution
Warns of a risk of minor injury or major
material damage to the device or
environment.
Warning
Warns against serious personal injury
and damage to health.
Danger
Warns against serious personal injury or
death.
Mandatory
Standard or measure to apply.
Note
Comment
Prohibition
Restriction to be observed.
Model
Electrical rating
Part number
Serial number
Production date
Production order

Installer Manual Fleck 5812 - XTR - Safety
12 / 132 Ref. MKT-IM-019 / E - 14.10.2019
2.3. Hazards
All the safety and protection instructions contained in this document must be observed in order to
avoid temporary or permanent injury, damage to property or environmental pollution.
At the same time, any other legal regulations, accident prevention and environmental protection
measures, as well as any recognized technical regulations relating to appropriate and risk-free
methods of working which apply in the country and place of use of the device must be adhered to.
Any non-observation of the safety and protection rules, as well as any existing legal and technical
regulations, will result in a risk of temporary or permanent injury, damage to property or
environmental pollution.
2.3.1. Personnel
Caution
Only qualified and professional personnel, based on their training, experience and
instruction as well as their knowledge of the regulations, the safety rules and operations
performed, are authorized to carry out necessary work.
2.3.2. Material
The following points must be observed to ensure proper operation of the system and the safety of
user:
• be careful of high voltages present on the transformer (100 - 240 V);
• do not put your fingers in the system (risk of injuries with moving parts and shock due to electric
voltage).
2.4. Hygiene and sanitization
2.4.1. Sanitary issues
Preliminary checks and storage
• Check the integrity of the packaging. Check that there is no damage and no signs of contact with
liquid to make sure that no external contamination occurred;
• the packaging has a protective function and must be removed just before installation. For
transportation and storage appropriate measures should be adopted to prevent the
contamination of materials or objects themselves.

Installer Manual Fleck 5812 - XTR - Safety
Ref. MKT-IM-019 / E - 14.10.2019 13 / 132
Assembly
• Assemble only with components which are in accordance with drinking water standards;
• after installation and before use, perform one or more manual regenerations in order to clean
the media bed. During such operations, do not use the water for human consumption. Perform a
disinfection of the system in the case of installations for treatment of drinking water for human
use.
Note
This operation must be repeated in the case of ordinary and extraordinary maintenance. It
should also be repeated whenever the system remains idle for a significant time.
2.4.2. Hygiene measures
Disinfection
• The materials used for the construction of our products meet the standards for use with potable
water; the manufacturing processes are also geared to preserving these criteria. However, the
process of production, distribution, assembly and installation, may create conditions of bacterial
proliferation, which may lead to odor problems and water contamination;
• it is therefore strongly recommended to sanitize the products. See 7.2. Sanitization, page 96;
• maximum cleanliness is recommended during the assembly and installation;
• for disinfection, use Sodium or Calcium Hypochlorite and perform a manual regeneration.

Installer Manual Fleck 5812 - XTR - Description
14 / 132 Ref. MKT-IM-019 / E - 14.10.2019
3. Description
3.1. Technical specifications
Design specifications/ratings
Valve body ..........................................................................Fiber-reinforced polymer
Rubber components ..........................................................EP/EPDM
Valve material certification ...............................................DM174, ACS, CE
Weight (valve with controller) ...........................................2.3 kg (max)
Recommended operating pressure ..................................1.4 - 8.6 bar
Maximum inlet pressure ...................................................8.6 bar
Hydrostatic test pressure..................................................20 bar
Water temperature............................................................1 - 43°C
Ambient temperature........................................................0 - 52°C
Flow rates base 2.5" (3.5 bar inlet - valve only)
Piston .................................................................................Downflow .........Upflow.............. Filter
Continuous (Δp = 1.03 bar) ................................................9.8 m3/h ...........8.9 m3/h ........... 8.4 m3/h
Peak (Δp = 1.72 bar)...........................................................12.7 m3/h..........11.6 m3/h ......... 10.7 m3/h
Cv*......................................................................................11.2 gpm ..........10.1 gpm ..........9.4 gpm
Kv*......................................................................................9.7 m3/h ...........8.7 m3/h ........... 8.1 m3/h
Maximum backwash (Δp = 1.72 bar) .................................7.5 m3/h ...........8.2 m3/h ........... 10.2 m3/h
Flow rates base 4" (3.5 bar inlet - valve only)
Piston .................................................................................Downflow .........Upflow.............. Filter
Continuous (Δp = 1.03 bar) ................................................10.2 m3/h..........9.1 m3/h ........... 8.m3/h
Peak (Δp = 1.72 bar)...........................................................13.4 m3/h..........11.8 m3/h ......... 11.4 m3/h
Cv*......................................................................................11.7 gpm ..........10.3 gpm ..........9.9 gpm
Kv*......................................................................................10.1 m3/h..........8.9 m3/h ........... 8.6 m3/h
Maximum backwash (Δp = 1.72 bar) .................................7.7 m3/h ...........8.2 m3/h ........... 10.2 m3/h
Valve connections
Tank Thread.......................................................................2½"or 4" - 8NPSM
Inlet/Outlet.........................................................................1" or 1¼", BSP
Riser tube (2.5" tank base) ................................................32 mm (1¼" tube)
Riser tube (4" tank base) ...................................................48.3 mm O.D. (1.9" tube)
Drain line ...........................................................................1¼" straight QC BSP and 1" elbow QC BSP
Brine line (1650).................................................................⅜"

Installer Manual Fleck 5812 - XTR - Description
Ref. MKT-IM-019 / E - 14.10.2019 15 / 132
Electrical
Transformer input voltage ............................................... 100 to 240 VAC
Input supply frequency ..................................................... 50 to 60 Hz
Transformer output voltage ............................................. 12 VDC
Motor input voltage........................................................... 12 VDC
Controller input voltage.................................................... 12 VDC
Controller max. power consumption ............................... 6 W
Protection rating............................................................... IP 22
Power supply .................................................................... 100 to 240 VAC, 50/60 Hz, 0.8 A, Class II
Transient overvoltages ..................................................... Within the limits of category II
Pollution Degree............................................................... 3
Temporary overvoltages must be limited in duration and in frequency.
Environmental conditions
• Indoor use only;
• temperature from 0°C to 52°C;
• maximum relative humidity 80% for temperatures up to 31°C decreasing linearly to 50% relative
humidity at 40°C;
• mains supply voltage fluctuations up to ±10% of the nominal voltage.
3.1.1. Performance flow rate characteristics
The graph shows the pressure drop created by the valve itself at different flow rates. It allows to
predetermine the maximum flow rate going through the valve depending on the system settings (inlet
pressure etc). It also allows to determine the valve pressure drop at a given flow rate, and therefore
to evaluate the system pressure drop vs flow rate.

Installer Manual Fleck 5812 - XTR - Description
16 / 132 Ref. MKT-IM-019 / E - 14.10.2019
BASE 2,5"
Filter
Upflow
Flow rate (m3/h]
Pressure drop (bar)
BASE 4"
Flow rate (m3/h]
Pressure drop (bar)
FLOW RATE VS PRESSURE DROP
Downflow
Filter
Upflow
Downflow

Installer Manual Fleck 5812 - XTR - Description
Ref. MKT-IM-019 / E - 14.10.2019 17 / 132
3.2. Outline drawing
3.2.1. Base 2,5"

Installer Manual Fleck 5812 - XTR - Description
18 / 132 Ref. MKT-IM-019 / E - 14.10.2019
3.2.2. Base 4"

Installer Manual Fleck 5812 - XTR - Description
Ref. MKT-IM-019 / E - 14.10.2019 19 / 132
3.3. Description and components location
LCD screen
Brine line
Injector block
Drain line
Piston
Outlet
Mixing device
Inlet
Meter*
Brine valve
Controller
*Not included in case of timeclock
Plugs for hard or soft
water refill

Installer Manual Fleck 5812 - XTR - Description
20 / 132 Ref. MKT-IM-019 / E - 14.10.2019
3.4. System regeneration cycle
Note
This valve allows to do down flow or up flow regenerations.
3.4.1. Downflow regeneration cycle (5-cycles operation)
Service — normal use
Untreated water is directed down through the resin bed and up through the riser tube. The hardness
ions attach themselves to the resin and are removed from the raw water being exchanged on the resin
beads against sodium ions. The water is conditioned as it passes through the resin bed.
Backwash — cycle C1
The flow of water is reversed by the valve and directed down through the riser tube and up through
the resin bed. During the backwash cycle, the bed is expanded and debris is flushed to the drain, while
the media bed is remixed.
Brine draw & slow rinse — cycle C2
The controller directs water through the brine injector and brine is drawn from the brine tank. The
brine is then directed down through the resin bed and up through the riser tube to the drain. The
hardness ions are replaced by sodium ions and are sent to the drain. The resin is regenerated during
the brine cycle. Afterwards the slow rinse phase starts.
Rapid rinse — cycle C3
The valve directs water down through the resin bed and up through the riser tube to the drain. Any
residual brine is rinsed from the resin bed, while the media bed is recompacted.
Brine tank refill — cycle C4
Water is directed to the brine tank, at a rate controlled by the refill controller [BLFC], to create brine
for the next regeneration. During brine refill, treated water is already available at the valve outlet.
Note
For illustration purpose only. Always verify inlet and outlet marking on the valve.
