OWNER’S MANUAL
Shallow Well Water System
Installation/Operation/Parts
For further operating, installation, or maintenance assistance:
Call 1-888-782-7483
© 2014 BE586 (02/28/14)
3869 0101
5PNP15H

Safety 2
INTRODUCTION
Please read our instructions before installing and using
your Shallow Well Water System. This will help you
obtain the full benefits of the quality and convenience
built into this equipment. It will also help you avoid any
needless service expense resulting from causes beyond
our control which are not covered by our warranty.
READ AND FOLLOW
SAFETY INSTRUCTIONS!
Carefully read and follow all safety instructions in this
manual or on pump.
This is the safety alert symbol. When you see this
symbol on your pump or in this manual, look for
one of the following signal words and be alert to the
potential for personal injury!
warns about hazards that will cause serious
personal injury, death or major property
damage if ignored.
warns about hazards that will or can cause
serious personal injury, death or major property damage
if ignored.
warns about hazards that will or can cause
minor personal injury or property damage if ignored.
The word NOTICE indicates special instructions which
are important but not related to hazards.
Never run pump dry. Running pump with-
out water may cause pump to overheat, damaging seal
and possibly causing burns to persons handling pump.
Fill pump with water before starting.
Never run pump against closed discharge.
To do so can boil water inside pump, causing hazardous
pressure in unit, risk of explosion and possibly scalding
persons handling pump.
Motor normally operates at high tempera-
ture and will be too hot to touch. It is protected from
heat damage during operation by an automatic internal
cutoff switch. Before handling pump or motor, stop
motor and allow to cool for 20 minutes.
1. To avoid risk of serious bodily injury and property
damage, read safety instructions carefully before
installing pump.
2. Follow local and/or national plumbing and electrical
codes when installing pump.
3. Keep well covered while installing pump to prevent
leaves and other debris from falling into well, con-
taminating well and possibly damaging pump.
4. Protect pump and piping system from freezing.
Allowing pump or water system to freeze could
severely damage pump and voids warranty.
To avoid serious injury and equipment
damage, limit system pressure to 75 pounds per
square inch (PSI) or below at all times. Over-
pressure can cause tank blowup; install relief valve
capable of passing full pump volume at 75 PSI.
5. With a new well, test well for purity before use. Con-
sult local Health Department for procedure.
Hazardous voltage. Can shock, burn,
cause death, or start fires.
6. Disconnect electrical power source before installing
or working on pump.
7. Ground pump with a ground wire run from ground-
ing lug on motor to a grounded lead in the service
panel.
8. Line voltage and frequency of electrical power supply
must agree with motor nameplate.
9. Use of fuses or wire smaller than size recommended
in owner’s manual can cause overheating, possible
fires, and will void warranty.
BASIC TOOLS AND
MATERIALS NEEDED
Plastic Pipe Installation
Tools
Pipe Wrenches
Screwdriver
Knife or Saw to Cut Plastic Pipe
Tire Pressure Gauge
Materials
Plastic Pipe and Fittings (as required to complete job).
Teflon Tape (DO NOT use joint compound on plastic
fittings).
Galvanized Steel Pipe Installation
Tools
Pipe Wrenches
Screwdriver
Pipe Cutting and Threading Tools
Tire Pressure Gauge
Materials
Galvanized Pipe and Fittings (as required to complete
job).
Pipe Joint Compound or PTFE Pipe Thread Sealant Tape
California Proposition 65 Warning
This product and related accessories contain
chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
Safety 2

Safety 3Table of Contents 3
Page
General Safety .....................................................................................................2
Warranty..............................................................................................................3
Installation........................................................................................................4-6
Electrical...........................................................................................................6-7
Operation ............................................................................................................7
Maintenance ..................................................................................................8-12
Repair Parts .................................................................................................13-14
Troubleshooting.................................................................................................15
ATTACH ORIGINAL RECEIPT HERE FOR WARRANTY CONSIDERATION.
Limited Warranty
BERKELEY warrants to the original consumer purchaser (“Purchaser” or “You”) of the products listed below, that they will be free
from defects in material and workmanship for the Warranty Period shown below.
Product Warranty Period
Water Systems:
Water Systems Products — jet pumps, small centrifugal pumps, submersible pumps and
related accessories
whichever occurs first:
12 months from date of original installation, or
18 months from date of manufacture
Pro-Source™ Composite Tanks 5 years from date of original installation
Pro-Source™ Steel Pressure Tanks 5 years from date of original installation
Pro-Source™ Epoxy-Lined Tanks 3 years from date of original installation
Sump/Sewage/Effluent Products 12 months from date of original installation, or
18 months from date of manufacture
Agricultural/Commercial:
Centrifugals – close-coupled motor drive, frame mount, SAE mount, engine drive, VMS, SSCX,
SSHM, solids handling, submersible solids handling
12 months from date of original installation, or
24 months from date of manufacture
Submersible Turbines, 6” diameter and larger 12 months from date of original installation, or
24 months from date of manufacture
Our limited warranty will not apply to any product that, in our sole judgement, has been subject to negligence, misapplication,
improper installation, or improper maintenance. Without limiting the foregoing, operating a three phase motor with single phase
power through a phase converter will void the warranty. Note also that three phase motors must be protected by three-leg,
ambient compensated, extra-quick trip overload relays of the recommended size or the warranty is void.
Your only remedy, and BERKELEY’s only duty, is that BERKELEY repair or replace defective products (at BERKELEY’s choice). You
must pay all labor and shipping charges associated with this warranty and must request warranty service through the installing
dealer as soon as a problem is discovered. No request for service will be accepted if received after the Warranty Period has
expired. This warranty is not transferable.
BERKELEY SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, OR CONTINGENT DAMAGES WHATSOEVER.
THE FOREGOING LIMITED WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. THE FOREGOING LIMITED WARRANTIES SHALL NOT EXTEND BEYOND THE DURATION PROVIDED HEREIN.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on the duration of an
implied warranty, so the above limitations or exclusions may not apply to You. This warranty gives You specific legal rights and You
may also have other rights which vary from state to state.
This Limited Warranty is effective June 1, 2011 and replaces all undated warranties and warranties dated before June 1, 2011.
In the U.S.: BERKELEY, 293 Wright St., Delavan, WI 53115
In Canada: 269 Trillium Dr., Kitchener, Ontario N2G 4W5

Safety 4Installation 4
MAJOR COMPONENTS
AND WHAT THEY DO
Impeller and Jet
Impeller turns with motor shaft, causing water to fly out
from its rim by centrifugal force. Impeller rotation creates
a vacuum which pulls in more water. Part of the water
is diverted back to the jet where it passes through the
nozzle and venturi. This creates more vacuum to draw in
more water.
In shallow wells (less than 25 feet deep), the vacuum
created at the pump is enough to pull water to the pump.
Therefore, for shallow well use the jet is built into the
pump.
Pre-Charged Tank
The tank serves two functions. It provides a reservoir of
water under pressure and maintains a cushion of air pres-
sure to prevent pipe hammering and possible damage to
plumbing components. When water is drawn off through
the house fixtures, the pressure in the tank is lowered
and the pump starts.
Pressure Switch
The pressure switch provides for automatic operation.
Pump starts when pressure drops to 30 pounds and stops
when pressure reaches 50 pounds.
Check Valve or Foot Valve
Install a check valve as close to well as possible on well
point installations. A foot valve must be installed in the
well on dug or cased wells. See Figures 2A and 2B (Pages
4 and 5). For long horizontal pipe runs, install check valve
as close to well as possible (all types of wells).
INSTALLATION
Piping in the Well
The Shallow Well Water System can be installed on a
dug well, cased well or with a driven point. In a dug or
cased well, a foot valve and strainer should be installed
for easy priming. It should be installed five to ten feet
below the lowest level to which the water will drop
while the pump is operating (pumping water level). To
keep sediment from clogging the strainer, be sure it is
five to ten feet above the bottom of the well. Before
installing the foot valve, make sure that it works freely.
When using a foot valve, a priming tee and plug as
shown in Figure 1, are recommended.
When installed on a driven point well, your Shallow
Well Water System should have a check valve installed
as shown in Figure 2A.
TABLE I – PUMP PERFORMANCE (IN GALLONS PER MINUTE)
NOTE: This system is designed for pumping depths of 25 feet or less.
2485 0696
To Household
Water System
Pump Priming
Plug
From Well
Check Valve
Priming Tee
and Plug
Pressure
Switch
Figure 1 – Connections to water system
Pump Discharge Pumping Depth in Feet
Model Description Suct. Disch. Pressure PSI 5’ 10’ 15’ 20’ 25’
5PNP15H 1/2 HP S.W. Jet 1-1/4” 3/4” 40 5.2 5.0 4.6 4.3 3.2
Figure 2A – Driven point
Check valve
Steel drive pipe
Drive coupling
Drive point
Drive coupling
Drive point
Steel Drive Pipe
Check Valve

Safety 5
For a pump at sea level mounted directly over the well,
be sure the total lift from the pumping water level to the
pump does not exceed 25 feet. This will be less if the
pump is offset from the well.
The maximum lift of any pump decreases at the rate of
about 1’ less lift for every 1,000 feet of elevation above
sea level. For example, at Denver, Colorado (Elev.
5,000’) the pump loses five feet of lift. The maximum
depth from which it would pump water would therefore
be 15 feet.
PUMP/TANK INSTALLATION
Pump
NOTICE: Use Teflon tape supplied with the pump or
Plasto-Joint Stik1for making all pipe-thread connections
to the pump itself. To avoid stress-cracking, do not use
pipe joint compounds on the pump.
1. Wrap male pipe threads being attached to pump with
one or two layers of PTFE pipe thread sealant tape.
Cover entire threaded portion of pipe.
2. Do not overtighten threaded fittings in the plastic
pump. Be sure you do not try to tighten joint past
thread stop in pump port!
3. If leaks occur, remove fittings, clean off old tape,
rewrap with two to three layers of tape and remake
the connection. If joint still leaks, replace the fittings
(fittings may be undersized).
4. Be sure to support all piping connected to the System.
Horizontal Piping from Well to Pump
When the pump is offset more than 25 feet from the
well, horizontal suction pipe size should be increased to
reduce friction losses. Never install a suction pipe that is
smaller than the suction tapping of the pump.
1-1/4” 1-1/2” 2”
Up to 25 Ft. 25 to 50 Ft. 50 to 200 Ft.
Discharge Pipe Sizes
When the pump is some distance from the house or
point of water use, the discharge pipe size should be
increased to reduce pressure losses caused by friction.
1” 1-1/4” 1-1/2”
Up to 25 Ft. 25 to 100 Ft. 100 to 600 Ft.
Tank
Tank is pre-charged with 40 pounds per square inch
(PSI) air pressure at the factory. Your tank requires an air
charge of 28 PSI for proper operation; check tank pres-
sure with tire gauge and adjust air charge as needed.
Tank pre-charge should be checked annually; see
instructions on Page 6.
In areas where the temperature is high for long periods
of time, the tank pre-charge pressure may increase. This
may reduce the tank drawdown (amount of water avail-
able per cycle). If this occurs, reduce the pre-charge
pressure until it is 2 PSI below the pump cut-in setting of
the pressure switch (normally 30 PSI).
It is necessary to flush all air out of the piping system and
water reservoir portion of the pre-charged tank. This is
required on new installations, pumps requiring repriming
and pumps that have been disassembled for service. Do
this as follows:
1. Open faucets furthest from tank and allow pump to
operate.
2. Air in the system will cause a sputtering flow; allow
faucets to run until you have a steady, air free stream.
3. Open and close faucets repeatedly until you are sure
all air has been removed.
4. If stream does not become steady, air may be leaking
into the system; check for leaks in the piping on the
suction side of the pump.
NOTICE: To prevent waterlogging, check tank air charge
annually.
Installation 5
Plastic Pipe
Plastic Pipe
Foot Valve
and Strainer
Coupling
Well Seal
Dug or Cased Well
611 1293
Figure 2B – Dug or cased well

Disconnect power before working on pump, motor,
pressure switch, or wiring.
Your Motor Terminal Board (under the motor end cover)
and Pressure Switch look like one of those shown below.
Convert to 115 Volts as shown. Do not change motor
wiring if line voltage is 230 Volts or if you have a single
voltage motor. Connect power supply as shown for your
type of switch and your supply voltage.
Installation / Electrical 6
To Check Tank Air Charge
If drawdown (amount of water available per cycle)
decreases significantly, check as follows:
1. To check air charge in tank, shut off electric power to
pump, open faucet near tank, and drain completely.
2. At the air valve in top of tank, check air pressure with
standard tire gauge. Air pressure should be the same as
the turn on pressure of the pressure switch (30 PSI).
3. If the air pressure is below 30 PSI, add air to the tank.
Use an air compressor or a portable air storage tank.
4. Use soap or liquid detergent to check for air leaks
around air valve. Continuous bubbling indicates a
leak. If necessary, install new core in air valve. This is
the same as those used for automobile tubeless tires.
H20
H20H20
612 1293
123
45
1. Tank nearly empty – air expands filling area above vinyl
separator.
2. Water begins to enter tank – air is compressed above
separator as it fills with water.
3. Pump-up cycle completed – air now compressed to cut off
setting of pressure switch.
4. Water being drawn from tank – compressed tank air forces
water out of separator.
5. Separator completely empty – new cycle ready to begin.
Figure 3
Water Water
Water
Figure 4: Motor wiring connections through Pressure Switch. Match motor voltage to line voltage.
Move plug to change voltage.
115 V
230 V
Power Supply Wires
L1
L2
230 115
L1
L2
230 115
L1
L2
230 115
Grounding Point
3781 1000
230 Volt to 115 Volt Conversion, Plug-in Type:
230 Volt to 115 Volt Conversion, Plug-in Type:
Pull plug
straight
out from
terminal
board.
1.
1.
2.
2.
Plug in again
with arrow
on plug
pointing to
'115 Volts'.
A
L1
230 Volts
115 Volts
A
L1
230 Volts
115 Volts
Ground
Screw
Clamp the power cable to prevent strain
on the terminal screws.
Connect the green (or bare copper) ground wire
to the green ground screw.
Motor wires connect here.
Clamp the power cable to prevent strain
on the terminal screws.
Connect the green (or bare copper) ground wire
to the green ground screw.
Motor wires connect here.
3187 0398
Power supply wires connect here.
230 Volt: Connect 2 hot wires (black and red)
here and cap the white (neutral) wire. It does
not matter which wire goes to which screw.
115 Volt: Connect one hot wire (black or red)
to one of these screws (it doesn't matter
which one). Connect the white (neutral) wire
to the other screw. Cap any remaining
black or red wires.
Power supply wires connect here.
230 Volt: Connect 2 hot wires (black and red)
here and cap the white (neutral) wire. It does
not matter which wire goes to which screw.
115 Volt: Connect one hot wire (black or red)
to one of these screws (it doesn't matter
which one). Connect the white (neutral) wire
to the other screw. Cap any remaining
black or red wires.
ELECTRICAL

Safety 7
Hazardous voltage. Can shock, burn, or
kill. Connect ground wire before connecting power sup-
ply wires. Use the wire size (including the ground wire)
specified in the wiring chart. If possible, connect the
pump to a separate branch circuit with no other appli-
ances on it.
Explosion hazard. Do not ground to a gas
supply line.
WIRING CONNECTIONS
Fire hazard. Incorrect voltage can cause a
fire or seriously damage the motor and voids the warran-
ty. The supply voltage must be within ±10% of the motor
nameplate voltage.
NOTICE: Dual-voltage motors are factory wired for 230
volts. If necessary, reconnect the motor for 115 volts, as
shown. Do not alter the wiring in single voltage motors.
Install, ground, wire, and maintain your pump in com-
pliance with the National Electrical Code (NEC) or the
Canadian Electrical Code (CEC), as applicable, and with
all local codes and ordinances that apply. Consult your
local building inspector for code information.
Connection Procedure:
1. Connect the ground wire first as shown in Figure 4.
The ground wire must be a solid copper wire at least
as large as the power supply wires.
2. There must be a solid metal connection between the
pressure switch and the motor for motor grounding
protection. If the pressure switch is not connected
to the motor, connect the green ground screw in the
switch to the green ground screw under the motor
end cover. Use a solid copper wire at least as large as
the power supply wires.
3. Connect the ground wire to a grounded lead in a
service panel, to a metal underground water pipe, to
a metal well casing at least ten feet (3M) long, or to a
ground electrode provided by the power company or
the hydro authority.
4. Connect the power supply wires to the pressure
switch as shown in Figure 4.
OPERATION
Priming the Pump
NOTICE: To prevent damage to internal parts, do not
start motor until pump has been filled with water.
To prime pump:
1. Remove priming plug (Figure 1, Page 4).
2. Fill pump with water.
3. Replace priming plug, using PTFE pipe thread sealant
tape on plug threads; tighten plug.
4. Start the pump. Water should be pumped in 1-2
minutes. If not, repeat steps 1, 2 and 3.
On shallow depths to water (10 feet or less), the
pump will probably prime the first time after follow-
ing steps 1 through 4 above.
From 10 to 25 foot depths, you might have to shut off
the pump and repeat steps 1, 2 and 3 several times.
5. If, after priming pump several times, no water is
pumped, check the following:
A. Be sure suction pipe is in the water.
B. Be sure suction pipe does not leak.
C. Be sure that pump is not trying to lift water too
high (see “Piping in the Well”, Page 4).
D. As long as foot valve and check valve function
correctly and suction pipe does not develop leaks,
pump should not need repriming in normal service.
Preparing to Start the Pump – Deep Well 7Electrical / Operation 7
Table II Wiring Chart – Recommended Wire and Fuse Sizes
Distance in Feet from Motor to Meter
Branch 0’ 101’ 201’ 301’ 401’
Max. Fuse* to to to to to
Motor Load Rating 100’ 200’ 300’ 400’ 500’
Horsepower Volts Amps. Amps Wire Size
1/2 115/230 8.8/4.4 15/15 14/14 12/14 10/14 8/14 8/12

Safety 8
Lubrication
It is not necessary to lubricate the pump or its motor. The
motor bearings are lubricated for life. The mechanical shaft
seal in the pump is water lubricated and self-adjusting.
Draining for Winter
Risk of electric shock. Disconnect power
before working on unit.
Pump should be drained whenever it is disconnected
from service or is in danger of freezing.
1. DISCONNECT POWER.
2. Open faucet and relieve all pressure on system before
proceeding.
3. Disconnect pressure switch tube (Key No. 15, Page
13) at barbed elbow on pressure switch (Key No. 26)
and allow tube to drain.
4. Unscrew barbed elbow (Key No. 14) from pump
body and allow pump to drain. If necessary to drain
completely, tilt pump.
5. Remove priming plug to vent pump; disconnect hose
(Key No. 8, Page 14) at tank end and drain pressure
tank and all piping to a point below the frost line.
6. Be sure to drain any piping that may be cut off from
normal system drain due to check valve installation.
Vinyl Bag Replacement
Be sure ALL air pressure has been released
from tank before removing nuts from flange. Failure to
do this may result in serious or fatal injury. Do not
attempt to open tank unless all pressure has been
relieved!
Risk of electric shock. Disconnect power
before working on unit.
1. DISCONNECT POWER TO PUMP.
2. Drain system as follows:
A. Open faucet closest to tank.
B. Remove hose (Key No. 8, Page 14) from tank
elbow.
3. Relieve (expel) ALL air pressure in system by remov-
ing valve core.
4. Disconnect outside piping from tank and pump.
To avoid serious or fatal injury, be sure
all air pressure has been released from tank before
proceeding to step 5.
5. Remove nuts from inlet flange (Key No. 4, Page 14).
Tap inlet flange to break seal. Remove flange.
6. Wherever convenient, hold bag with pliers and cut
with single-edge razor blade or sharp knife. Bag will
not come out in one piece. Continue pulling and cut-
ting until bag is removed.
7. Clean and dry inside of tank.
8. Place replacement bag on a clean surface with open-
ing up. Flatten bag and force air out.
9. Tightly roll bag towards center opening.
10.Before center opening is covered up, force air out of
remaining portion of bag. Finish rolling bag.
11.To make bag easier to insert into tank, sprinkle out-
side of bag with talcum powder.
12.Being careful not to break valve, stand tank on end.
Push tightly rolled bag into tank.
13.Reach into bag and push out sidewalls. You need not
remove all wrinkles.
14.Clean center opening ring on bag and lip on tank.
15.Pull ring on bag through tank opening and fit over
tank lip. BE SURE it seats properly in groove on tank
lip.
16.Clean sealing surface of inlet flange and place on
studs.
17.NOTICE: Tighten nuts as follows:
A. Hand tighten all nuts.
B. Tighten one nut snug.
C. Tighten opposite nut snug.
D. Proceed, tightening opposite pairs to a snug fit.
E. Recheck all nuts, using same pattern. Be sure all
nuts are tight and you have a good seal.
NOTICE: Do not overtighten; you may twist studs off
of tank. If you have a torque wrench, tighten to 85
inch-pounds torque.
18.Stand tank on feet and reconnect piping.
19.Recharge tank to proper air pressure (see Page 6).
20.Reconnect hoses and pressure switch tube; prime
pump (above).
Air Valve Replacement
1. Follow steps 1 through 5 under “Vinyl Bag
Replacement”.
2. Cut valve off as close to tank as possible. Push
remaining portion back into tank.
3. Tip tank on end and BE SURE all water is drained
from bag.
4. Carefully remove bag ring from lip on tank opening
and push bag ring back into tank; reach in around it
and remove cut off portion of valve from tank.
5. Wipe a thin film of soapy solution on replacement
valve and from inside tank insert in hole in top of tank.
Maintenance 8

Maintenance 9
6. Pull valve through hole with pliers or a valve tool
(available at your local filling station or Automotive
Center).
7. Follow steps 14 through 20 under “Vinyl Bag
Replacement”, Page 8, to reinstall bag in tank.
Testing for Bag Leakage
1. Follow steps 1 through 4 under “Vinyl Bag
Replacement”, Page 8.
2. Tip tank on end, valve down. Be careful not to break
valve!
3. If bag leaks, water will run out of valve. If so, replace
bag as instructed above.
DISASSEMBLY AND
ASSEMBLY OF PUMP
Risk of electrical shock. Be sure unit is
grounded and power disconnected before attempting any
work on pump or motor.
Your pump is designed for ease in servicing. Should repair
or replacement of the motor or seal be needed, the pump
and piping do not need to be disconnected or disturbed.
1. Disassemble pump as follows:
A. Disconnect power.
B. Remove pressure switch tube from pump body
and allow pump to drain.
C. Remove four hexnuts and lockwashers (Key Nos.
24 and 23, Page 13) which hold the pump body
to the motor.
D. Remove motor, seal plate, impeller, rubber pad
and diffuser (Key Nos. 1, 3, 7, 8 and 9, Page 13)
as a unit. You may have to pry gently with two
screwdrivers between the motor flange and the
pump body to separate pump and motor.
2. Reassembly of pump:
A. Install O-Ring gasket on seal plate (Key Nos. 5
and 3, Page 13).
B. Pick up a small amount of petroleum jelly on one
finger and spread evenly over seal plate and ven-
turi O-Ring gasket for lubrication during reassem-
bly. Be careful not to nick or tear O-Ring.
C. Replace motor onto pump body; be sure rubber
pad (Key No. 8, Page 13) stays in place on top of
diffuser. Remount base on lower studs. Tighten
four hexnuts and lockwashers snugly (35-45 inch-
lbs. torque). Do not overtighten.
D. Replace pressure switch tubing and motor wiring.
E. Prime pump according to instructions above.
F. Check for leaks.
Removing Motor for Service and
Replacing Shaft Seal
If it is necessary to separate motor and seal plate, always
replace the shaft seal. We suggest you purchase this
item, U109-6A, and have it on hand for future use.
NOTICE: The seal consists of two parts, a rotating mem-
ber and a ceramic seat. The surfaces of the seal are eas-
ily damaged. Read instructions carefully.
Remove motor as follows:
1. Disassemble pump per instructions above.
2. Remove diffuser and impeller as follows (Key Nos. 9
and 7, Page 13).
A. Remove screws holding diffuser.
B. Loosen two screws and remove motor canopy
from motor (Key No. 1, Page 13).
C. Place 7/16” open end wrench on motor shaft flat.
D. Turn impeller counterclockwise when facing it.
3. Remove seal plate from motor by inserting two
screwdrivers between the seal plate and the motor
flange. Pry seal plate off motor flange. This will force
rotating portion of seal off of shaft.
NOTE: Be sure you do not scratch shaft!
See Figures 5 & 6.
Figure 5
Figure 6

Maintenance 10
4. Place seal plate face down on flat surface and tap out
ceramic seat.
NOTICE: Do not force out copper insert. If it has moved,
leakage will occur. See section on installing copper
insert on Page 11.
5. Clean seal cavity.
6. Install new seal.
A. Clean polished surface of ceramic seat with clean
cloth.
B. Wet outer edge of cup seal with petroleum jelly
or detergent solution.
C. With finger pressure, press firmly and squarely
into cavity. Polished face of seat faces inside of
pump. If seat will not locate properly, place card-
board washer over polished face and use piece
of 3/4” standard pipe for pressing purposes. See
Figure 7.
D. Dispose of cardboard washer and clean surface of
seat.
E. Clean motor shaft.
F. Reassemble seal plate to motor flange. BE SURE it
is right side up: index pins should be down; seal
plate is marked at top. See Figures 8A and 8B.
G. Apply detergent solution to inside diameter of
rotating seal member.
H. Slide rotating member on shaft until rubber drive
ring hits shaft shoulder.
NOTE: Be sure you do not chip or scratch seal
face on shaft shoulder or seal will leak!
I. Screw impeller on shaft (clockwise) while holding
shaft with 7/16” open end wrench on shaft flats.
This will automatically locate seal in place. See
Figure 9.
J. Remount diffuser on seal plate. Be sure diffuser is
right side up as follows (see Figures 10 and 11).
a. Rib next to priming hole should be at six
o’clock position;
b. Part number (N1-28P) should be between nine
o’clock and ten o’clock.
Figure 7
Figure 8A
Figure 8B
Figure 9

Maintenance 11
c. Both mounting screws must engage screw
holes in seal plate. See Figure 10.
d. Be sure rubber pad (Figure 10; Key No. 8, Page
13) stays in place on top of diffuser.
Installing Copper Insert
NOTE: If the copper insert (Key No. 4, Page 13) moves
or shifts during seal removal, it should be removed and
reinstalled.
1. Remove copper insert as shown in Figure 12. do not
deform.
2. Replace copper insert:
A. Clean off surplus Permatex* from around insert
cavity. Be careful not to scratch or mark the
machined bore. It is important that this area be
clean so no old Permatex lodges behind the new
insert and causes improper seating.
B. Place a small amount of No. 2 non-hardening
Permatex on surface of insert as shown. Smooth
out with finger. See Figure 13.
C. Pull insert into cavity as shown in Figure 14.
D. Clean out any surplus Permatex from insert cavity
where new seal will be located. See Figure 15.
Figure 10
Figure 11
Figure 12
Figure 13
Wipe on small amount of
non-hardening Permatex
on this surface
756 0993
Figure 14
7/8" Socket
Bolt
1-3/8" O.D.
Washer
038 0893
Figure 15
Remove
Surplus
Permatex
Properly
Seated
039 0893

Maintenance 12
Cleaning Impeller
1. Follow steps 1A through 1D under “Disassembly
and Assembly of Pump” on Page 9.
2. Remove diffuser and impeller from pump per
instructions under “Removing Motor for Service
and Replacing Shaft Seal” on Page 9.
3. Clean impeller and reassemble impeller and dif-
fuser per instructions under “Removing Motor for
Service and Replacing Shaft Seal” on Page 9.
Cleaning Shallow Well Jet
To remove debris from venturi or nozzle, proceed as fol-
lows:
1. Disassemble pump per instructions on Page 9.
2. Turn venturi counterclockwise and remove it. The
nozzle is now exposed. Remove it using a 5/8” hex
socket wrench with extension. Turn counterclock-
wise. If socket wrench is not available, insert an ice
pick or similar pointed tool carefully into the nozzle.
This will dislodge debris.
3. Flush out the debris by running water through the
nozzle in the same direction as the dislodging tool
was inserted.
4. Replace nozzle and venturi. Do not overtighten!
5. Reassemble per pump instructions on Page 9.
HELPFUL HINTS
How to Handle a Gaseous Well
In some areas well water contains gases which must be
allowed to escape before the water is used. This can be
done as shown in Figure 16.
A good way of delivering gas-free water is to suspend a
pipe, closed at the bottom and open at the top, surround-
ing the suction pipe. Since the gases rise in the well cas-
ing, the water sucked down through the pipe and into
the suction pipe is free of gas. This type of well must be
vented to the outside of any enclosure.
Not
to
Scale
Pipe strap or
wire to hold
pipe sleeve
Pipe
sleeve
Pipe
cap
Tail
pipe
Foot
valve
2369 0396
Gases
rise to
surface
Figure 16

Repair Parts 13
Repair Parts
1
2305 0296 BE
AVC
Port
2
34
56
78
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Key
No. Description Qty. Part Number
1# Motor - 115/230V 1 A100CLL
2 Water Slinger 1 C69-2
3* Seal Plate Assembly 1 N103-12PSS
4 Seal Plate Insert 1 J3-2SS
5 O-Ring 1 U9-390
6 Shaft Seal 1 U109-6A
7 Impeller 1 J105-40PF
8 Rubber Pad 1 C35-41
9 Diffuser 1 N1-28P
10 Capscrew #10-16 Hex Head 2 U30-738SS
11** Pump Body Assembly 1 N176-35P
12 Pump Body 1 N76-35P
13 Pipe Plug 1/8” NPT 1 WC78-41T
14 90° Hose Barb 1 U111-86T
15 Pressure Switch Tube 1 U37-670P
16 Gasket 1 J20-18
17 Pump Body Jet Insert 1 N76-29P
18 Capscrew #10-16 4 U30-742SS
19 Nozzle #45 1 N34P-19
20 Venturi 1 N32P-66
21 O-Ring 1 U9-201
22 Base Assembly Painted 1 J104-9F
23 Lock Washer 3/8” 4 U43-12ZP
24 Nut 3/8” - 16 4 U36-38ZP
25 Rubber Pad 1 C35-5
26 Pressure Switch 1 U217-1216
27 Locknut 1/2” 1 U36-112ZP
28 Connector 1/2” 1 L43-5C
# For repair or service to motors, always give the motor model
number and any other data found on the motor model plate.
* Includes Key No. 4.
** Includes Key Nos. 12, and 16 through 21.

Repair Parts 14
Repair Parts - Tank Only
1
3
2
7
5
9
10
11
4
2433 0596 BE
6
7
8
Key
No. Description Qty. Part Number
1 Air Valve Cover 1 U31-380P
2 Air Valve and Cap 1 U212-160
3 Replacement Tank 1 PS15H-S05
4 Inlet Flange 1 U31-442P
5 Nut, 5/16-18 Hex 6 U36-202BT
6 Elbow, 3/4” MPT x 1” Insert 1 U78-770P
7 Clamp 2 U19-55SS
8 Hose - 1” x 23” 1 U74-37X
9 Discharge Tee with Barb 1 U78-972P
10 1/2” x 1/8” NPT Reducer Bushing 1 U78-107PT
11 1/8” NPT Pipe Plug 1 WC78-41T
 • Diaphragm 1 U20-7
 • Notillustrated.
† Standard hardware item, may be purchased locally.

Troubleshooting 15Troubleshooting 15
TROUBLE POSSIBLE CAUSES REMEDIES
Motor will not run 1. Disconnect switch is off 1. Be sure switch is on
2. Fuse is blown 2. Replace fuse
3. Starting switch is defective 3. Replace starting switch
4. Wires at motor are loose, 4. Refer to instructions on wiring
disconnected, or wired incorrectly
5. Motor is wired incorrectly 5. Refer to instructions on wiring
6. Pressure switch contacts are dirty 6. Clean by sliding piece of plain paper between contacts
Motor runs hot and *1. Motor is wired incorrectly 1. Refer to instructions on wiring
overload kicks off 2. Voltage is too low 2. Check with power company. Install heavier wiring
if wire size is too small. See wiring instructions
3. Pump cycles too frequently 3. See section below on too frequent cycling
Motor runs but no *1. Pump in a new installation did 1. In new installation:
water is delivered not pick up prime through:
a. Improper priming a. Re-prime according to instructions
b. Air leaks b. Check all connections on suction line and jet
c. Leaking foot valve c. Replace foot valve
*2. Pump has lost its prime through: 2. In installation already in use:
a. Air leaks a. Check all connections on suction line, jet and shaft seal
b. Water level below suction of pump b. Lower suction line into water and re-prime. If
receding water level in a shallow well operation
exceeds suction lift, a deep well pump is needed
3. Jet or impeller is plugged 3. Clean jet or impeller according to instructions
4. Check valve or foot valve is stuck 4. Replace check valve or foot valve
in closed position
5. Pipes are frozen 5. Thaw pipes. Bury pipes below frost line. Heat pit or
pump house
6. Foot valve and/or strainer are 6. Raise foot valve and/or strainer above well bottom
buried in sand or mud
Pump does not 1. Water level in well is lower than 1. A deep well jet pump may be needed (over 25 ft.
deliver water to full estimated to water)
capacity (also check 2. Steel piping (if used) is corroded or 2. Replace with Plastic Pipe where possible, otherwise
point 3 immediately limed, causing excess friction with new steel pipe
above) 3. Offset piping is too small in size 3. Use larger offset piping
Pump pumps water 1. Pressure switch is out of adjustment 1. Adjust or replace pressure switch
but does not shut off or contacts are “frozen”
2. Faucets have been left open 2. Close faucets
3. Jet or impeller is clogged 3. Clean jet or impeller
4. Motor is wired incorrectly 4. Refer to instructions on wiring
5. Water level in well is lower than 5. Check possibility of using a deep well jet pump
estimated
Pump cycles too 1. Pipes leak 1. Check connections, replace pipe fittings
frequently 2. Faucets or valves are open 2. Close faucets or valves
3. Foot valve leaks 3. Replace foot valve
4. Pressure switch is out of adjustment 4. Adjust or replace pressure switch
5. Air charge too low in 5. Disconnect electrical power and open faucets until all
pre-charged tank pressure is relieved. Using automobile tire pressure
gauge, check air pressure in tank at the valve stem
located at top of tank. If less than 30 pounds, pump air
into tank from outside source, until 30 pounds pressure
is reached. Check air valve for leaks, using soapy
solution, and replace core if necessary
Air spurts from 1. Pump is picking up prime 1. As soon as pump picks up prime, all air will be ejected
faucets 2. Leak in suction side of pump 2. Check suction piping, make sure joints are not sucking air
3. Well is gaseous 3. Change installation as described in manual
4. Intermittent over-pumping of well 4. Lower foot valve if possible, otherwise restrict discharge
side of pump
(*Note: Check
prime before look-
ing for other causes.
Unscrew priming
plug and see if there
is water in priming
hole)

16
