Pepperl+Fuchs R-SP-E12 User manual
Segment Protector for Cabinet
Installation
R-SP-E12
<12 increased safety outputs (Ex e)
<Short circuit current limitation per output
<Segment Protector in Zone 1/Div. 2
<Instruments in Zone 1/Div. 1
<For FOUNDATION Fieldbus H1 and PROFIBUS PA
<High power on trunk and spurs
Foundation
Fieldbus
®
Segment Protector for Cabinet Installation
®
Function
The R SP E12 Segment Protector is a device coupler that connects field instruments to the segment.
Flameproof (Ex d) field devices are connected to the trunk line via one output each. Trunk and spurs are certified increased safety (Ex e).
Short-circuit protection ensures proper operation of the segment in case of unwanted faults at the spur. Work on devices always requires a hot
work permit. The integrated fieldbus terminator features high-availability design and is selectable.
Connectors are fixed screw terminals. Any grounding and shielding concept is possible based on FieldConnex enclosure solutions.
Customizable housings host one or more Segment Protectors for different output counts.
Connection
Zone 1/Div. 2
Spur 1 Spur 2
I I
Spur 3
I
Spur 12
I
T
...
...
-
+
-
+-
+-
+-
+
Trunk
IN
Technical Data
General specifications
Design / Mounting Cabinet installation
Fieldbus interface
Power dissipation 250 mW
Main cable (Trunk)
Rated voltage 9 ... 32 V DC
Outputs
Number of outputs 12
Rated voltage max. 32 V
Rated current max. 40 mA
1
Release
date:
2021-01--
12 Date of
Release date: 2021-01-12 Date of issue: 2021-01-12 Filename: 130713_eng.pdf
Germany: +49 621 776 2222Pepperl+Fuchs Group
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
USA: +1 330 486 0002 Singapore: +65 6779 9091
Technical Data
Short-circuit current max. 52 mA
Self current consumption max. 9 mA
Voltage drop main cable/outputs max. 1.3 V
Terminating resistor selectable 100 Ω integrated
Surge protection trunk, spurs overvoltage protected if voltage exceeds typ. 39 V, max. 41 V
Indicators/operating means
LED PWR green: Fieldbus voltage > 10 V
LED CHANNEL ERROR red flashing: short-circuit
LED COM yellow: bus activity
LED TERM ON yellow: termination activated
Directive conformity
Electromagnetic compatibility
Directive 2004/108/EC EN 61326-1:2006
Standard conformity
Electromagnetic compatibility NE 21:2006
Degree of protection IEC 60529
Fieldbus standard IEC 61158-2
Shock resistance EN 60068-2-27
Vibration resistance EN 60068-2-6
Ambient conditions
Ambient temperature -40 ... 70 °C (-40 ... 158 °F)
Storage temperature -40 ... 85 °C (-40 ... 185 °F)
Relative humidity 95 % non-condensing
Shock resistance 15 g , 11 ms
Vibration resistance 5 g , 10 ... 150 Hz
Mechanical specifications
Connection type screw fixing
Core cross-section max. 2.5 mm2 / AWG 12-24
Housing material Polycarbonate
Housing width 216 mm
Housing height 100 mm
Housing depth 50 mm
Degree of protection IP20
Mass 800 g
Mounting DIN rail mounting
Coating resin filled
Data for application in connection with hazardous areas
EU-Type Examination Certificate PTB 04 ATEX 2100 X
Marking 1 II 2 G Ex e mb IIC T4 Gb
Maximum values
Rated voltage ≤ 35 V
Prospective short-circuit current 100 A
Directive conformity
Directive 94/9/EC EN 60079-0:2012 , EN 60079-7:2007 , EN 60079-18:2009
International approvals
IECEx approval IECEx PTB 05.0010X
Approved for Ex me II T4
Certificates and approvals
Marine approval DNV A-14038
General information
Supplementary information EC-Type Examination Certificate, Statement of Conformity, Declaration of Conformity,
Attestation of Conformity and instructions have to be observed where applicable. For
information see www.pepperl-fuchs.com.
Segment Protector for Cabinet Installation R-SP-E12
Release date: 2021-01-12 Date of issue: 2021-01-12 Filename: 130713_eng.pdf
2
Germany: +49 621 776 2222Pepperl+Fuchs Group
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
USA: +1 330 486 0002 Singapore: +65 6779 9091
Assembly
Matching System Components
F.SPE.P**.A**.1.0.***.***.
****
F.SPE.S**.A**.1.0.***.***.
****
Segment Protector for Cabinet Installation R-SP-E12
Release date: 2021-01-12 Date of issue: 2021-01-12 Filename: 130713_eng.pdf
3
Germany: +49 621 776 2222Pepperl+Fuchs Group
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
USA: +1 330 486 0002 Singapore: +65 6779 9091
Release date: 2021-01-12 Date of issue: 2021-01-12 Filename: 130713_eng.pdf
R-SP-E12
4
Germany: +49 621 776 2222Pepperl+Fuchs Group
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
USA: +1 330 486 0002 Singapore: +65 6779 9091
Segment Protector for Cabinet Installation
Additional Information
Release date: 2021-01-12 Date of issue: 2021-01-12 Filename: 130713_eng.pdf
R-SP-E12
5
Germany: +49 621 776 2222Pepperl+Fuchs Group
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
USA: +1 330 486 0002 Singapore: +65 6779 9091
Segment Protector for Cabinet Installation
Note:
For the connection of the cable shields earth bars are to be used in the enclosure. With metallic enclosures the appropriate
insulation has to be ensured.
see manual
Dimensions
Installation
Spur terminals
Trunk
terminals
Mounting on
DIN rail
DIN mounting rail
Terminals for
terminator bridge
LEDs
channel state
LED
fieldbus status
LED
fieldbus power
LED
terminator on
100
50
213
1 2 3 4 5 6 7 8 9 10 11
Tr u n k
In
12
Channel
On
