Perlick TOBIN ELLIS SIGNATURE Series User manual

PERLICK RESIDENTIAL MOBILE BARS
To prevent appliance damage or injury, read these instructions thoroughly prior to use.
TOBIN ELLIS
SIGNATURE SERIES
RESIDENTIAL MOBILE BARS
INSTALLATION & OPERATION MANUAL
RMB-001 70”Tobin Ellis Signature Series Limited Edition Mobile Bar
RMB-002 70”Tobin Ellis Signature Series Mobile Bar - Includes 12” Hand Sink
RMB-003 70”Tobin Ellis Signature Series Mobile Bar - Includes (2) 12” Drainboards
RMB-004 46”Tobin Ellis Signature Series Mobile Bar

INSTALLATION & OPERATION INSTRUCTIONS
PERLICK SIGNATURE SERIES MOBILE BARS
Form No. Z2849
Rev. 06.27.22
PERLICK CORPORATION 8300 W. Good Hope Road, Milwaukee, WI 53223 • 800.558.5592 • perlick.com
Warranty
To register your product, visit our web site at www.perlick.com.
Click on“Commercial”, then“Service”. Click on the link“Warranty
Registration Form”. You must complete and submit this form or
the installation date will revert back to the ship date.
Please record the purchase date and the dealer’s name, address
and telephone number below.
Model Number: _____________________________________
Order Number: ______________________________________
Purchase Date: ______________________________________
Dealer Name & Address _______________________________
___________________________________________________
___________________________________________________
___________________________________________________
Phone Number ______________________________________
Introduction
Congratulations on your purchase of a Perlick commercial
Mobile Bar product. This manual has been prepared to assist
you in the setup of your mobile bar and to acquaint you with its
operation and maintenance.
We dedicate considerable time to ensure that our products
provide the highest level of customer satisfaction. If service is
required, your dealer can provide you with a list of qualied
service agents. For your own protection, never return
merchandise for credit without our approval.
We thank you for selecting a Perlick product and assure you of
our continuing interest in your satisfaction.
GENERAL INFORMATION
MODELS
RMB-001
RMB-002
RMB-003
RMB-004
RMB-001
Tobin Ellis Signature Series
Limited Edition Mobile Bar
RMB-004RMB-003RMB-002

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice
3Form No. Z2849
Rev. 06.27.22
PERLICK SIGNATURE SERIES MOBILE BARS
Installation & Operation Manual
TABLE OF CONTENTS
IMPORTANT!
Read and understand all information in this manual before attempting the installation.
All plumbing and electrical work must be performed by a qualied technician and
conform to all applicable state and local codes.
General Information................................................................................................................................................................................1
Safety ............................................................................................................................................................................................................2
Cabinet Specications............................................................................................................................................................................4
Preparing the Cabinet for Use
Uncrating and Inspection ..............................................................................................................................................................6
Electrical...............................................................................................................................................................................................7
Maintenance ..............................................................................................................................................................................................8
Cleaning.......................................................................................................................................................................................................9
Cabinet Drawings.................................................................................................................................................................................. 11
RMB-001............................................................................................................................................................................................ 11
RMB-002............................................................................................................................................................................................ 12
RMB-003............................................................................................................................................................................................ 13
RMB-004............................................................................................................................................................................................ 14
Replacement Parts................................................................................................................................................................................ 15
SAFETY
PLEASE READ all instructions completely before attempting to
install or operate the unit. Take particular note of the DAN-
GER, WARNING and CAUTION information in the manual. The
information is important for the safe and ecient installation,
operation and care of your Perlick unit.
DANGER
Indicates a hazard that WILL result
in serious injury or death if pre-
cautions are not followed.
WARNING
Indicates a hazard MAY cause
serious injury or death if precau-
tions are not followed.
CAUTION
Indicates a hazard where minor
or moderate injury may occur if
precautions are not followed.
NOTICE
Indicates that property damage
may occur if warnings or instruc-
tions are not followed.

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice
4
PERLICK SIGNATURE SERIES MOBILE BARS
Installation & Operation Manual
RMB-001
MODEL NOS. RMB-001
DIMENSIONS:
EXTERIOR mm
Length 70" (1778)
Width 34-1/2" (877)
Height 43-3/4" (1112)
Weight (lbs) 351 lbs. (159 kg)
DIMENSIONS:
SHIPPING mm
Length 75” (1905)
Width 40” (1016)
Height 70” (1778)
Weight (lbs) 451 lbs. (205 kg)
PERLICK BAR EQUIPMENT Ice Chest TS30IC with Sliding Cover
Insulated Bottle Well TSC12IBW
Drainboard TSCS12 (2 ea.)
Hand Sink N/A
Speed Rail
SRC-CL left curved (1 ea.)
SRC-CR right curved (1 ea.)
SRC-S18 18” straight (1 ea.)
ELECTRICAL Voltage 120V AC
Frequency 60 Hz
Phase Single
Amperage 0.4 A
Connection NEMA 5-15P
Cord Length 12ft
LED BARTENDER
TASK LIGHTING
Color Temperature 4000K
Lumen Output 1200 LM
WATER HEATER Temperature Range N/A
Tank Volume N/A
Recovery time @ 60°^ N/A
WATER PUMP Max Flow N/A
Switch O Pressure N/A
GRAY WATER/ICE MELT TANK
PREPLUMBED Capacity (2) 2.5gal
POTABLE WATER TANK
PREPLUMBED Capacity N/A
Toee Crocodile Vanilla Sugar
Tobin Ellis Signature Series Limited Edition Residential
Mobile Bars feature Toee Crocodile exterior with
Vanilla Sugar engineered solid surface top.
Tobin Ellis Limited Edition Signature Series Residential Mobile Bar

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice
5Form No. Z2849
Rev. 06.27.22
PERLICK SIGNATURE SERIES MOBILE BARS
Installation & Operation Manual
RMB-004RMB-003RMB-002
MODEL NOS. RMB-002 RMB-003 RMB-004
DIMENSIONS:
EXTERIOR mm
Length 70-1/8" (1785) 70-1/8" (1785) 46-1/4" ( 1175)
Width 35-9/16" (903) 35-9/16" (903) 35-9/16" (903)
Height 46-5/16" (1176) 46-5/16" (1176) 46-5/16" (1176)
Weight (lbs) 380 lbs. (172 kg) 351 lbs. (159 kg) 239 lbs. (108 kg)
DIMENSIONS:
SHIPPING mm
Length 75” (1905) 75” (1905) 60” (1524)
Width 40” (1016) 40” (1016) 40” (1016)
Height 70” (1778) 70” (1778) 70” (1778)
Weight (lbs) 480 lbs. (218 kg) 451 lbs. (205 kg) 319 lbs. (145 kg)
PERLICK BAR EQUIPMENT Ice Chest TS30IC with Sliding Cover TS30IC with Sliding Cover TS30IC with Sliding Cover
Insulated Bottle Well TSC12IBW TSC12IBW TSC12IBW
Drainboard TSCS12 (1 ea.) TSCS12 (2 ea.) N/A
Hand Sink TS12HSN with side splash N/A N/A
Speed Rail
SRC-CL left curved (1 ea.)
SRC-CR right curved (1 ea.)
SRC-S18 18” straight (1 ea.)
SRC-CL left curved (1 ea.)
SRC-CR right curved (1 ea.)
SRC-S18 18” straight (1 ea.)
SRC-CL left curved (1 ea.)
SRC-CR right curved (1 ea.)
SRC-S18 18” straight (1 ea.)
ELECTRICAL Voltage 120V AC 120V AC 120V AC
Frequency 60 Hz 60 Hz 60 Hz
Phase Single Single Single
Amperage 13.3 A 0.4 A 0.3 A
Connection NEMA 5-15P NEMA 5-15P NEMA 5-15P
Cord Length 12ft 12ft 12ft
LED BARTENDER
TASK LIGHTING
Color Temperature 4000K 4000K 4000K
Lumen Output 1200 LM 1200 LM 800 LM
WATER HEATER Temperature Range 50°F - 140°F (10°C - 60°C) N/A N/A
Tank Volume 1.5 gal (5.7 L) N/A N/A
Recovery time @ 60°^ 8 minutes N/A N/A
WATER PUMP Max Flow 3 GPM (11.3 LPM) N/A N/A
Switch O Pressure 45 PSI (3.1 bar) N/A N/A
GRAY WATER/ICE MELT TANK
PREPLUMBED Capacity (1) 2.5gal & (1) 6gal (2) 2.5gal (1) 2.5gal
POTABLE WATER TANK
PREPLUMBED Capacity 5 gal (18.9 L) N/A N/A
Black White Quartz
Tobin Ellis Signature Series Residential Mobile
Bars feature Black laminate exterior with
White Quartz engineered solid surface top.
Tobin Ellis Signature Series Residential Mobile Bar
