LEG INSTALLATION KIT
Operation/Installation Manual
PURPOSE:
The purpose of this guide is to provide a
step-by-step process for our leg attachment
method. Legs will be shipped with all
free-standing equipment.
TOOLS NEEDED:
• Level
• Phillips screw driver
NOTE:
Phillips screw driver is
needed for leg mounting
style B only.

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. 3
Form No. Z2386
Rev. 10.04.22
LEG INSTALLATION KIT
Operation/Installation Manual
PREPARING FOR USE:
Step 1
Identify parts to be assembled you might have either Mounting Style, A, B or C. Unpack the legs that
were shipped with your equipment, and grab the level you will use to level the equipment.
Step 2
Position the equipment so the leg
mount is visible and accessible.
MOUNTING STYLE A
Traditional Pedestal Style
MOUNTING STYLE B
Traditional Cabinet Style
MOUNTING STYLE C
NEW Quick Clamp Style

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice
4
LEG INSTALLATION KIT
Operation/Installation Manual
Step 3
Mounting Style A & C
Screw the leg into the leg mount by hand
until snug, then turn 1/4 turn more to secure
the leg. Repeat the process with all legs on
the equipment.
Mounting Style B
Screw the leg flange into the equipment using
a Phillips head screw driver and the screws
provided in the pack with the legs.
NOTE: Be sure not to over tighten the screws,
DO NOT USE A DRILL.
Step 4
Stand the unit back up on the legs
before leveling.
Step 5
Level the unit by turning the adjustable billet
feet by hand clockwise or counter clockwise
to lengthen or shorten the leg.
NOTE: Check for level on both sides, the front
ledge, and the top of the backsplash using the
level. Adjust each foot and check again until
the unit is level.
Mounting Style A Mounting Style B

PURPOSE:
The purpose of this section is to provide a step-
by-step process for our Perlick Flex Mount Leg
Relocation Kit, a leg relocation may be needed to
move the rear legs forward or the front legs back to
avoid leg interference with something in your bar.
NOTE: The Leg
relocation kit can
only be installed on
the leg mounting
style C.
Form No. Z2386
Rev. 10.04.22
PERLICK CORPORATION 8300 W. Good Hope Road, Milwaukee, WI 53223 • 800.558.5592 • perlick.com
PERLICK FLEX MOUNT LEG KIT
INSTALLATION GUIDE
Leg moves
inward.
0”-7”
2” original
position

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice
6
LEG INSTALLATION KIT
Operation/Installation Manual
KIT CONTAINS:
Kit uses the existing
legs on the unit
TOOLS NEEDED:
• Level
1 bolt with plastic nut
1 bracket

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. 7
Form No. Z2386
Rev. 10.04.22
LEG INSTALLATION KIT
Operation/Installation Manual
PREPARING FOR USE
Step 1
If possible, position equipment
so the bottom of the unit is
visible and accessible.
Step 2
Unscrew the existing legs from the equipment
by hand and set legs aside for later use.
NOTE: if your legs are not attached to the
equipment yet, locate the legs that came
with the unit and set aside.
Step 3
Position bracket front to back on equipment
over the existing leg mounting holes.
NOTE: Relocation kit can only be installed
on leg Mounting Style C.
NOTE: Use a team lift
when necessary.

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice
8
LEG INSTALLATION KIT
Operation/Installation Manual
Step 4
Thread one leg into the original leg
mounting hole sandwiching the
relocation bracket into place.
Screw the bolt with plastic nut into
the other original mounting hole.
NOTE: Which ever leg is staying in place
will mount into the original mounting hole.
Step 5
Thread remaining leg into
the relocation bracket
mounting hole.
NOTE: Do not use tools
to install the relocation
bracket bolt or legs.
Step 6
Repeat steps 2 thru 5 for other
side of equipment.
Step 7
Stand the unit back
up on the legs
before leveling.
Step 8
Level the unit by
turning the adjustable
billet feet by hand
clockwise or
counterclockwise
to lengthen or
shorten the leg.
NOTE: Check for level on both sides, the front ledge,
and the top of the backsplash using the level. Adjust
each foot and check again until the unit is level.
NOTE: Equipment
does not need to
be installed in final
position to level.
