Combined Motor Start and Braking Device
VBMS ...
Assembly- and Commissioning Instructions

VBMS ... 1
as per 10/20 1C000.10001
Table of Contents Page
1. Safety notes 3
2. Conformity 3
3. General description 4
4. Usage to the intended purpose 4
5. EC Declaration of Conformity 5
6. Block diagram 6
7. Functional description 7
8. LED indicators 8
9. Control inputs 9
10. Potentiometers 9
11. Technical data 10
11.1 Environmental conditions 10
12. Commissioning 11
12.1 Mounting instructions 11
12.2 Connection 11
12.3 Parameter settings 12
12.4 Possible fault indications during commissioning 13
13. Dimensioning rules 14
13.1 Dimensioning of braking device 14
13.2 Dimensioning of pre-fuses 15
13.3 Permissible braking frequency 17
14. Dimensional drawings 18
15. Typical connections 19
15.1 Connection diagram 19

2 VBMS ...
Notes and symbols used in these instructions
Note: Notes explain the advantages of certain adjustments or settings and help
you to make use of the device in the best possible way.
Warning notices: Read them carefully and follow them strictly!
Warning notices are indicated in order to protect you against danger or to
help you to prevent the device from being damaged.
Caution: Danger to life through electric shock!
When you see this sign, always make sure that the device is de-energized
and secured against unintentional energizing.
These commissioning instructions were prepared with great care. Nevertheless, PETER
electronic GmbH & Co. KG does not assume liability for damage resulting from mistakes
possibly contained in this manual. Technical changes that serve to improve the product are
subject to change without notice.
Disposal Instructions
Equipment containing electrical components may not be disposed of
together with domestic waste. It must be collected separately as electrical
and electronic waste according to local and currently valid legislation.

VBMS .... 3
1. Safety notes
The described devices are electrical equipment for use in industrial electrical power
installations. An impermissible removal of the covers during operation can cause
serious damage to your health, since these devices contain live parts with high
voltages.
Adjustment work may only be performed by trained staff observing the safety regulations.
Assembly and mounting work may only be carried out with the equipment deenergized.
Make sure that all drive components are properly earthed.
Please read these commissioning instructions carefully before putting the device into operation.
Besides, the user must ensure that the devices and associated components are fitted and
connected in accordance with the appliable local, legal and technical regulations. The VDE-
regulations VDE 0100, VDE 0110 (EN 60664), VDE 0160 (EN 50178) , VDE 0113 (EN 60204,
EN 61310),VDE 0660 (EN 50274) plus the appropriate regulations of the TÜV (Technical Control
Association) and the trade associations apply in Germany.
The user must ensure that the drive turns into a safe operating state following a device failure, in
the event of maloperation, or if the control unit has failed etc..
Caution: Even if the motor is at rest, it is not physically separated from the mains.
2. Conformity
In industrial linguistic usage the electronic brakes with motor contactor of the type series VBMS...
are called "devices", however, in the sense of the "device-safety-law", the "EMC-law" or the "EC
machinery directive" they are not devices or machines ready for use or connection but they are
components. It is only possible to define their final function, when these components are
integrated into the design and construction of the user.
To be able to use the devices to their intended purpose, it requires power supply networks
according to DIN EN 50160 (IEC38).
The user takes the responsibility that the user’s design and construction comply with the appli-
cable legal provision.
The commissioning is strictly forbidden as long as the conformity of the final product with the
guidelines 2006/42/EC (Machinery directive) and 2006/95/EC (Low voltage directive) is not
proved.

4 VBMS ....
3. General description
The type VBMS ... is a compact motor control unit which includes both a motor contactor with a
contact gap ≥ 3mm and an electronic braking device.
Because of the integrated motor contactor it is with a modest amount of wiring work possible to
implement the functions „Motor On“ and „Motor Braking“.
The braking current is controlled and can be adjusted within a range of 10-100% of the rated
device current. An integrated standstill detection function switches the braking current off after the
motor has come to a standstill. The control inputs are metallically separated from the load (24V
extral-low voltage).
Various fault conditions are indicated via LED „on“. .
Special features:
• simple motor control with only a few elements
• motor contactor and DC-brake in a single device
• suitable for all asynchronous motors
• controlled bei microcontroller
• easy mounting, also for retrofitting into existing plants
• motor contactor with contact gap ≥3mm, utilization category AC-3
• operator’s controls physically separated from load (24V extra-low voltage)
• connection of several „OFF“-buttons possible (e.g., motor temperature switch)
• for snap-on mounting on 35mm DIN rail
• degree of protection IP 20
• meets trade assoc. requirements for category 2 acc. to EN 954-1 according to the test
principies of GS-HO-01
• intermateable with BRMS
4. Usage to the intended purpose
The devices of the VBMS series are electrical equipment that is used in industrial power installa-
tions. They are designed for an application in machines, in order to switch on and to decelerate
drives with three-phase a.c. motors.
Typical applications:
• sawing machines
• centrifuges
• vibrators

VBMS .... 5
5. EC Declaration of Conformity
EC Declaration of Conformity
The manufacturer / company placing the product on the market
(authorized representatives of the manufacturer / companies placing the product on the market
that are established within the Community)
Name / Address: PETER electronic GmbH & Co. KG
Bruckäcker 9
92348 Berg
hereby declares that the following product (device, component, unit) in the version as supplied
Product designation: Combined Motor Start and Braking Device
Series / type designation: VBMS 230-1,5/20; VBMS 400-2,2/20
Article number: 2C0...
Year of manufacture: 2007
complies with the provisions of the following EU-directives:
2014/30/EU
2014/35/EU
2011/65/EU
This EC Declaration of Conformity is no longer valid, if the product is modified or changed
without our agreement.
This declaration is issued under the sole responsibility of the signatory.
Berg, 15.04.2016 Dr. Thomas Stiller, Managing director
(place, date) (signatory and function of the signatory) (signature)
Electromagnetic compatibility
Electrical equipment designed for use within certain voltage limits
The restriction of the use of certain hazardous substances in
electrical and electronic equipment
The following harmonized standards have been applied:
EN 60947-1:2007+A1:2012
EN 60947-4-2:2012
Low-voltage switchgear and controlgear General rules
Low-voltage switchgear and controlgear
Contactors and motor-starters - AC semiconductor motor
controllers and starters

6 VBMS ....
6. Block diagram
24VR
24V
5V
230/400V
Power supply unit
Braking relay
OFF
Motor contactor
ON
Controller
Pulse
stage I
n0
Motor
contactor
Braking
relay
24VR
Motor
contactor
Braking
relay
Remanence
voltage
X8
X7
X6
X5
X4
X3
Current
detection
X1
X2
1L1 3L2 5L3 5L3'
2T1 4T2 6T3
STOP 1
STOP 2
STOP 3
START

VBMS .... 7
7. Functional description
The terminals for the „ON“ or „OFF“-buttons are connected to a 24V extra-low voltage that is
physically separated from the mains potential.
When actuating the „ON“-button connected with the terminals X1-X2, the integrated motor
contactor switches the motor on.
If one of the contacts on the terminals X3-X4, X5-X6 or X7-X8 is opened, the integrated motor
contactor switches off and initiates braking. During braking, the integrated motor contactor is
interlocked against switching-on. After a delay time which, dependent on the amount of the
remanent voltage of the motor, optimizes itself, the integrated braking relay pulls in. After the
contact bounce time has been waited out, a controlled d.c. current is fed into the motor winding.
The magnetic field resulting from this has a braking effect on the still rotating rotor. The d.c.
current is generated by a thyristor phase control. Special suppressor circuits protect the power
semiconductors against overvoltage.
With the potentiometer I, the braking current (and thus the braking torque) can be adjusted within
a range of 10 … 100% of the rated device current. The integrated motor standstill detection,
which functions via the amount of the remanent voltage, switches the braking current off approx.
1,5s after a motor standstill has been detected. To be able to adapt the device to a variety of
motors, it is possible to adjust the standstill threshold via the potentiometer n0).
Faults that occur during operation of the device are indicated via the „ON“ LED.
A motor protecting switch may additionally be wired in series before VBMS... device.
For this purpose, the wire jumper between 5L3 and 5L3’ has to be removed. The wiring is then to
be effected as illustrated in the connection diagram.
Warning notices:
To ensure a reliable standstill detection function, it is necessary to comply
with the following:The braking current must not exceed (3) three times the
amount of the rated motor current. If the VB-L is operated without the 6T3
(T3)-terminal beeing connected, which always applies in the case of single-
phase applications, it is to be ensured that braking current flows at least for a
period of 1.5 s before the motor comes to a standstill, as no motor standstill
is detected within this period of 1.5s and the braking current would then flow
over the total maximum braking time. This could cause destruction of the
motor and fault indications of the braking device.
Note: If the braking time at rated device current is too short, due to the fact that the
centrifugal masses to be slowed down are too large, either a device with a
longer braking time can be inquired of the producer or a device featuring a
higher rated current has to be used.

8 VBMS ....
8. LED indicators
LED - on Operational status Fault correction
Illuminated Motor runs
Flashing 1x repeatedly
with a short pause
no motor stillstand
detected
Fault will be reset by motor restart
(voltage on T1, T2, T3).
Flashing 2x repeatedly
with a short pause
Adjusted braking current
was not reached
Flashing 3x repeatedly
with a short pause
Braking frequency too
high
Fault can only be reset by discon-
necting the device for 5s from the
mains voltage (motor contactor is inter-
locked).
Flashing 4x repeatedly
with a short pause
Contacts of the motor
contactor are charred/
short-circuited.
Flashing 5x repeatedly
with a short pause
3x in succession no motor
stillstand detected
Flashing 6x repeatedly
with a short pause
Program error
LED - braking Operational status
Illuminated Braking current is flowing

VBMS .... 9
9. Control inputs
Warning
Please note, the total contact resistance on terminals X3 - X8 of the
connected contacts must not exceed 50 Ohm. If the limit of the total contact
resistance is exceeded, a reliable operation of the motor relays at 90% of the
mains supply (230V or 400V depending on device model) is no longer
ensured. In this case the motor could start on 2 phases.
10. Potentiometers
With the potentiometers it is possible to adjust the following parameters.
Note! If the potentiometer is adjusted to a position too far in clockwise or counter-
clockwise direction (e.g., end stop position), it may happen that no standstills
are detected. In this case, braking current flows until the end of the max.
braking time. The LED indicates „no standstill during the max. braking time“.
Control termi-
nals
Designation Description
X1, X2 Starting contact Connection of an „ON“-button (normally open contact)
X3, X4; X5, X6;
X7,X8
Braking contact Connection of an „OFF“-button (normally closed
contact)
„I“ Adjusting the braking current:
The braking current can be adjusted in the range from approx. 10% - 100% of the rated
device current. The adjustment is roughly linear.
„t“ Adapting the standstill threshold and braking behavior at motor standstill.
With this potentiometer it is possible to adapt the motor standstill threshold to various
motor types and applications and to influence the behavior of the braking current at
motor standstill.
In „left stop“ (full counter-clockwise) position, the standstill detection function is most
sensitive, and the braking behavior, upon reaching the motor standstill, is most soft.
Possibly, the braking current is switched off even before the motor has come to a
standstill. The potentiometer has to be adjusted so that the braking current is switched
off approx. 1-1.5s after the motor has come to a standstill.
Factory-setting: approx. 40%.

10 VBMS ....
11. Technical data
11.1 Environmental conditions
Note: Please pay attention and consider for the operation of IE3 motors while
dimensioning of combined motor start and braking devices the resulting
higher starting and braking currents.
For the use of IE3 motors we highly recommend to dimension and design
the needed combined motor start and braking devices one size higher.
Type designation VBMS 400-2,2/20 230-1,5/20
Ratetd operational voltage 50/60Hz
according to DIN EN 50160 (IEC 38)
3x 380/415V
±10%
3x 200/240V
±10%
AC-3 Rated operational power 2.2kW 1.5kW
AC-3 Rated operational power on IE3 Motor 1.5kW 1.1kW
Conventional Thermal current Ith = Ie16A
Braking current 2...20A
max. braking time 10s
max. braking frequency at
braking current 10A
braking current 20A
at 5s braking time: 1 in 25s
at 10s braking time: 1 in 50s
at 5s braking time: 1 in 60s
at 10s braking time: 1 in 120s
Delay time during switch-off and braking 500ms
Braking voltage 0...220V DC 0...110V DC
max. Cross-sectional area 2.5mm² per terminal
Weightt 0.6kg
Storage temperature -25 ... 75°C
Operating temperature 0 ... 45°C
Degree of protection IP 20
Environment Overvoltage category III, pollution degree 2

VBMS .... 11
12. Commissioning
The device is to be put into operation in 3 steps:
1. Mounting
2. Connection and
3. Parameter setting
12.1 Mounting instructions
Caution: Danger to life through electric shock!
The following conditions are to be complied with in order to ensure a safe
and reliable operation of the VersiBrake…-L (LP).
1. The device series VersiBrake…-L (LP) is to be used under overvoltage
conditions of the category III.
2. Make sure that pollution degree 2 or better, in accordance with IEC664, is
complied with.
3. The device is to be installed into a housing (min. degree of protection: IP54).
4. The device must be operated without being exposed to contamination by
water, oil, carbon deposits, dust, etc..
Warning:
Make sure that a minimum distance to adjoining devices is kept. Above and
underneath the housing a minimum distance of 50mm is to be kept.
Please note, the total contact resistance on terminals X3 - X8 of the
connected contacts must not exceed 50 Ohm.
12.2 Connection
The braking device (with integrated motor contactor) is to be installed according to the attached
connection diagram. For other connections please consult PETER electronic GmbH & Co. KG.
Note: Further connection proposals for special circuit arrangements are available
via our homepage at www.peter-electronic.com.
Note: Prior to putting the motor brake into operation the wiring is to be checked.
Warning:
In the case of high-inertia starting, it may happen that the fuses blow.

12 VBMS ....
12.3 Parameter settings
Sequence of steps during commissioning:
(the designations/details indicated in brackets refer to the circuit-board version)
1. Disconnect the plant/system from the supply mains.
2. Adjust the requested braking current with the potentiometer „I“, „(P2)“.
Since the potentiometer reacts roughly linear, it is possible to infer the braking current from
the potentiometer setting.
Left stop (counter-clockwise direction) roughly equals 10% of the rated device current
(20A).
Mid-position roughly equals 50% of the rated device current.
Right stop (clockwise direction) equals 100% of the rated device current.
3. Adjust potentiometer „n0“, „(P1)“ to approx. 40%.
4. Switch on the plant.
5. Initiate braking by switching the motor ON/OFF.
Note: When putting the device into operation for the first time, the braking current
can be checked with a true r.m.s. measuring instrument.
Adjusting the braking current
The braking current is to be adjusted to a value as small as possible, in order to avoid
unnecessary heating of the power semiconductors and motor. This is especially important in the
case of high switching frequencies. We recommend to limit the max. braking current to 2.5 times
the rated motor current.
The requested braking torque can be adjusted with the potentiometer „I“, „(P2)".
Adjusting the braking time
No adjustments are required, since the braking current is automatically switched off approx. 1.5s
after a motor standstill has been detected.
If no standstill is detected during the max. braking time (10s in the case of standard devices), the
braking current is switched off when this time is over. This case is indicated by the LED „ready“,
„(V9)“ (flashing 1x).
Adjusting the standstill threshold
In most applications, the factory-setting (40%) produces good results.
If the braking current is switched off before the motor has come to a rest, or if the braking current
is not switched off approx. 1.5s after the motor has come to a rest, it is possible to make an
adjustment with this potentiometer. The optimum setting has to be found by carrying out several
braking operations. The potentiometer should be changed only in little steps (10%). For a more
detailed functional description please refer to page 9.

VBMS .... 13
12.4 Possible fault indications during commissioning
During commissioning, and in normal operation too, fault indications can occur. The following
explanation is to give you assistance in the localization and correction of faults.
Fault
indication on
LED „Ready“,
„(V9)“
Fault Possible cause Fault correction
Flashing 1x No motor standstill
during max. braking
time
Braking current adjusted to a
too small value.
Adjust braking current to a
higher value.
Too large centrifugal mass. Use VBMS with longer max.
braking time.
Terminal „6T3“ „(T3)“ is not
connected and the motor is not
suplied with current for a period
of 1,5s prior to the standstill.
If possible, connect 6T3 (T3) or
adjust the braking current to a
slightly lower value.
Standstill threshold is not
adapted.
Adapt standstill threshold with
„n0“.
Flashing 2x Adjusted braking
current was not
reached.
Interruption in the braking
circuit. Possibly the motor is
started with star-delta
connection.
Check circuit. Possibly the star
contactor has to be closed
during braking.
The resistance of the motor
winding is too high for the
adjusted braking current.
Turn braking current back so
that the fault does not occur
any more.
Flashing 3x VBMS is
overloaded.
Braking frequency is
too high.
The specified max. braking
frequency is exceeded.
Reduce braking current or
braking frequency.
During commissioning,
4 braking operations in
succession can be initiated
without an overload being
indicated.
Flashing 4x Contacts of motor
contactor are
charred/short-
circuited.
Starting current of the motor is
too high (high-inertia starting,
blocked motor).
Send device for repair.
Motor with too high power
rating was connected.
Send device for repair.
Flashing 5x 3x in succession no
standstill detected
Braking current adjusted to a
too small value.
Adjust braking current to higher
value.
Centrifugal mass is too large. Use braking device with longer
max. braking time or higher
rated device current.
Standstill threshold is not
adapted.
Adapt standstill threshold with
„n0“.
Flashing 6x Program error Program crash Send device for repair.

14 VBMS ....
13. Dimensioning rules
Note! All data sheets and commissioning instructions are avaialble on our
homepage at www.peter-electronic.com.
13.1 Dimensioning of braking device
For most applications, it is relatively easy to select a suitable braking device.
In most cases, an acceptable braking torque is achieved, if. during braking, the motor is
connected in Y (star) and the braking current is 2 times as high as the rated motor current. If,
during braking, the motor winding can only be connected in Δ (delta), the braking current has to
be at least 2.5 times as high as the rated motor current in order to achieve a sufficiently high
braking torque.
If special applications require more precise calculations, the following formula can be used.
Calculating the braking current (IB))
Table 1
IB = Braking current in A
fB = Braking factor acc. to table 1
tB = Braking time required (in s)
IN = Nominal/rated motor current (in A)
tA = Time until nominal speed is reached
(in the case of motors with star-delta start - approx.
switch-over time)
Values usual for tA:
Conveyor belt::20s, Pump: 8s, Power crusher: 30s,
Compressor: 10s, Fan: 20s, Circular saw: 10s
N
B
A
BB
I
t
t
fI
⋅⋅⋅
= 2.6
Connection of motor winding
at nominal operation during braking
b
a
f
B
b
a
f
B
= 3
b
a
f
B
= 1.7

VBMS .... 15
Calculating the cyclic duration factor (ED):
If the required cyclic duration factor (c.d.f.) exceeds the permissible values indicated on the data
sheet, the permissible maximum braking current is to be accordingly reduced. The data required
in this connection can be found in the device-specific commissioning instructions.
If it is not possible to reduce the braking current, a braking device with a higher braking current
has to be used.
Example: If the required c.d.f. is twice as high as the value indicated on the data sheet, a
braking device of twice the nominal/rated device durrent has to be used.
13.2 Dimensioning of pre-fuses
Basically, two types of fuse protection are available for the user:
1. Fusing according to allocation type „1“, DIN EN 60947-4-2.
After a short circuit, the braking device is allowed to be inoperative.
2. Fusing according to allocation type „2“, DIN EN 60947-4-2.
After a short circuit, the braking device must be suitable for further use. However, there is
the danger that the contacts of the braking relay (braking contactor) weld. Therefore, if
possible, these contacts are to be checked prior to applying again mains voltage to the
device. If this check cannot be carried out by the user, the device has to be returned to the
producer in order to have it checked.
The following dimensioning information refers to the below operating conditions:
• Use of standard asynchronous motors
• Braking time not exceeding 20s, for braking devices up to 36A
• Braking time not exceeding 40s, for braking devices from 40A up
• Braking current not exceeding 2.5x INOM of the motor.
• Cyclic duration factor (c.d.f.) not exceeding the value indicated in the data sheet.
tB = Braking time
tZ = Cycle time (Running-Braking)
100
t
t
ED
Z
B
⋅⋅

16 VBMS ....
Fusing according to allocation type „1“:
As pre-fuses, we recommend to use line protection fuses (utilization category gL) or automatic
circuit breakers with tripping characteristic B, C, D or K.
Taking into account the maximum braking currents that occur (normally the rated device current),
we recommend fuses according to table 2, column 3.
Note: Wiring cross-sectional area according to DIN VDE 0100-430,
DIN EN 57100-430.
Fusing according to allocation type „2“:
The power semiconductors are to be protected by fuses of the utilization category gR (semicon-
ductor fuses, high-speed fuses). However, since these fuses do not ensure line protection, it is
necessary to use additionally line protection fuses (utilization category gL).
As for the dimensioning of the line protection fuse (gL), please refer to table 2, column 3.
To protect the semiconductors it is necessary to select gR-fuses featuring cutoff-I²t-values of the
ranges indicated in table 2, column 4. In this connection, the fuse rating of the selected fuse
should not be smaller than the braking current to be expected (rated device current).
Note 1: On the basis of the recommended I²t-value, braking current, and possibly the
c.d.f., the fuse supplier is able to select a suitable type. Due to the great
variety of producers, sizes, and types, PETER electronic does not
recommend any particular fuses.
Note 2: If the fuse or cutoff-I²t-value is selected too small, it may happen that the
semiconductor fuse reacts during braking.
Table 2
Column 1 Column 2 Column 3 Column 4
max. Braking
current / Rated
device current
Device type Fuse value
in the case of
allocation type 1
Recommended range for
cutoff-I²t-value of semiconductor
protection fuses in the case of
allocation type „2“
20A VBMS 16A 300… 650 A²s

VBMS .... 17
13.3 Permissible braking frequency
The braking frequency depends on the adjusted braking current:
Warning:
When setting up a machine or during commissioning, it is possible to carry
out 5 braking operations in succession, i.e., with rated device current and at
a braking time of 10s. After such operating conditions, however, the device
needs a recovery time of 15 minutes.
cyclicduration factor (r.c.d.f.) = tB / cycletime x 100
tB = Braking time, Cycle time = Braking time + Non-braking time
Braking current Braking time Braking frequency
20A 5s
10s
1 Braking per 63s
1 Braking per 125s
15A 5s
10s
1 Braking per 34s
1 Braking per 67s
10A 5s
10s
1 Braking per 22s
1 Braking per 44s
Load curve for VBMS
0
10
20
30
40
50
60
70
80
90
100
0 102030405060708090100
Cyclic duration factor in %
Permissible max. braking current in % of the rated device
current

18 VBMS ....
14. Dimensional drawings
All dimensions in mm.
100 120
73

VBMS .... 19
15. Typical connections
15.1 Connection diagram
START
(e.g., "Start" button)
STOP 2
(e.g., temperature monitoring)
If you connect only one "Stop"
button, this button has to be
connected between the
terminals X3 and X8.
STOP 3
(e.g., door interlocking)
Connection "START/STOP" button with 3 conductors
VBMS ...
4T2
3L2
2T1
1L1
M
6T3
5L3
M 3
V
Connection for single-phase motor
F1
N
PE
L
UW
~
X8
X2X1
STOP 1
(e.g., "Stop" button)
X54T2
3L2
2T1
1L1
X46T3 X3
VBMS ...
5L3
PE
Control with push-button
L1
L2
L3
F1
Standstil adjustment
Braking current
X6 X7 X8
X1 X2
~
UVW
M 3
VB M S ...
2T1 4T2 6T3
1L1 3L2 5L3
Control with switch
PE
L1
L2
L3
F1
X8X3 X4 X5 X6 X7
X2X1
Switch
closed = operation
open = braking -OFF
Braking current
Standstil adjustment
5L3' 5L3'
5L3'
3L21L1 5L3
Connection with motor protection relay
L1
L2
L3
F1
5L3'
VBMS ...
F2
The limit values for emitted interference according to the applicable device standards do not rule out the possibility that the limit values according
to the basic standard EN 61000-6-3:2007 are exceeded. If it is necessary to comply with the limit values of the basic standard EN 61000-6-3:2007,
PETER electronic will offer appropriate solutions for the VBMS device series. In this case, please contact us.
We point out that the creator of the plant / machine shall be responsible to ensure compliance with the EMC law.
EMC
