Pfeiffer LAZY JACK SYSTEM II User manual

ASSEMBLY INSTRUCTIONS
PFEIFFER LAZY JACK SYSTEM II

Production and distribution:
Pfeiffer Marine GmbH
Gewerbestraße 15
D-78345 Moos
www. feiffer-
marine.de
info@ feiffer-marine.de
Tel.: [phone]-
0
Fax: [phone]
ASSEMBLY INSTRUCTIONS
PFEIFFER LAZY JACK SYSTEM II
Dear customer,
t ank you very muc for your purc ase of one of our Pfeiffer Marine products!
Your dealer or shi yard will surely install the system rofessionally for you. If you are a skilled ski er and wish
to install the unit yourself, the following installation and o erating instructions will hel you to install the unit and
use it for the first time. Therefore, lease read these assembly and o erating instructions com letely first and act
according to our recommendations in order to be able to ensure o timum functionality. If you have any technical
queries, lease contact the dealer from whom you urchased the roduct or we as the manufacturer will be
ha y to answer them ourselves.
I. COMPLETENESS CHECK
The urchased Lazy-Jack System II for sailboats u to a rox. 40 feet with Pfeiffer order number 76.881.01
includes the following arts included in the set as standard:
Two single blocks, twelve eyebolts with 24 self-ta ing screws (and two s are screws), two ro es each 4 metres
long, two ro es each 7 metres long and single block fixed at the end with Ro eClam , two ro es each 9 metres
long and single block fixed at the end with Ro eClam , two ro es each 20 metres long and single block fixed at
the end with Ro eClam , two mast cleats and associated fixing set with screws.
In addition, we ask you to have the following tools ready for assembly: Metre stick, screwdriver (cross-slot, size 2
for Philli s cross-slot ty e H), centre unch, hammer, drill, twist drill Ø 4 mm for the su lied self-ta ing metal-
sheet screws Ø 4.8 mm X 25 mm and the su lied self-ta ing metal-sheet screws Ø 4.8 mm X 9.5 mm and
some oil and a encil.
IMPORTANT TIP:
To avoid drilling errors, we recommend that you first drill a hole for all arts to be screwed on, then screw the art
already in it, align it and then drill the other fixing holes. This way you avoid inaccurate drill holes! The core drill
holes for the self-ta ing screws can be found in the assembly drawing.

II. INSTALLATION
The illustrated drawings show an exem lary assembly of the lazy-jack-system. We ask you to adhere to this, as
this will ensure o timal functionality. In addition, the lengths of the su lied ro es are matched.
Once the o timal oints have been found, the eyebolts on the mast and main boom are to be drilled and screwed
on (make sure beforehand that there are no i es with cables in the mast at this oint, or that no running ro es
are obstructed inside the main boom by the screws!).
III. FUNCTIONAL TESTING AND HANDLING
The lazy-jack-system is designed to hel you lower (recover) the sail in a controlled manner. For this ur ose, it
falls into the ocket formed by ro es. When sailing, we recommend that you re-tie the illustrated ro e unit
towards the mast. Always make sure that the lazy-jack-system has sufficient clearance, i.e. that it does not block
or constrict a tight haul of the mainsheet or cause breakage during sailing manoeuvres.
IMPORTANT!
Check all fasteners (screws) again for correct tightening!
IV. CONCLUDING REMARKS
We wish you great enjoyment using your new roduct. If you have any technical questions, lease do not
hesitate to contact your dealer or us. Please note that we cannot acce t any warranty if the installation is not
carried out ro erly according to our s ecifications.
We wish you safe sailing and once again we would like to ex ress our thanks for the urchase of one of our
roducts.
Kind regards
Your Pfeiffer Marine Team
P.S. If you have any suggestions or requests, lease let us know!
If you would like our catalogue,
you can request it free of charge by calling 07732 - 99500 or faxing 995050.
You can find us at www. feiffer-rnarine.de
or email your requests to: [e-mail]
Ti : The screws are easier to screw in with a little
oil or grease and the thread is cut more
cleanly.
Dimension X
2
a rox. 1.8 x main boom length
