Pfeuffer Contador 2 User manual

Artikelnummer / Article no. 1410 0101
Pfeuffer GmbH
Flugplatzstraße 70
97318 Kitzingen
GERMANY
Phone: [phone]
Fax: [phone]
[email protected] Revision 7/25.04.2019
www.pfeuffer.com Translation of the Original Operating Instructions
Operating Instructions
Seed counter
Contador 2
Inclusive semi-automatic filling station
Contafill 2

Contador 2 Operating Instructions
Translation
In the event of delivery of subsequent sale to the countries of the European Economic Area (EEA), the operating
instructions must be translated into the corresponding language of the country of use.
In the event of discrepancies in the translated text, the original operating instructions (German) must be used for
clarification, or the manufacturer must be contacted.
Operating instructions in electronic format
The original operating instructions (German) and translations of the original operating instructions can be
requested as PDF files by e-mail: [e-mail]
Specifying the correct type designation and serial number is important for further processing!
Copyright
This document is not allowed to be communicated or duplicated, utilised without express permission, which also
applies to communicating its content. Offenders are liable to the payment of damages. All rights reserved with
regard to patent claims or submission of design or utility patent.
(DIN ISO 16016)
Page 2 of 46 Revision 7 © 2019 – Pfeuffer GmbH
These Operating Instructions are a constituent part of the machine and must be available to all
operating personnel at all times. They are intended for the operating company of the system, the
operating personnel and the specialists who are responsible for the transport, assembly,
installation, operation, maintenance, cleaning, disassembly and disposal.
The Pfeuffer
GmbH has prepared and reviewed these Operating Instructions with the greatest
care. However, no guarantee is made for its completeness or accuracy.
Subject to technical modifications.

Contador 2 Operating Instructions
© 2019 – Pfeuffer GmbH Revision 7 Page 3 of 46
Table of contents
1Introduction ............................................................................................................................ 5
1.1 Intended use ............................................................................................................................ 5
1.2 Declaration of conformity CONTADOR 2 ................................................................................. 6
1.3 Declaration of incorporation CONTAFILL 2.............................................................................. 7
1.4 Structural features of the danger notes .................................................................................. 8
1.5 Pictograms in the operating instructions ................................................................................ 8
1.6 Identification............................................................................................................................ 9
2Safety ......................................................................................................................................9
2.1 Installed safety systems........................................................................................................... 9
2.1.1 Mains switch (plug/socket combination).................................................................... 9
2.1.2 Protective coverings.................................................................................................. 10
2.2 Operating and danger areas on the CONTADOR 2 ................................................................ 10
2.3 Operating and maintenance personnel................................................................................. 10
2.4 Safety measures (to be carried out by the operating company)........................................... 10
2.5 General safety instructions.................................................................................................... 11
2.6 Safety tests............................................................................................................................. 12
2.7 Residual dangers in connection with the CONTADOR 2........................................................ 12
2.8 Switch-off procedure ............................................................................................................. 12
3Technical data ....................................................................................................................... 13
3.1 CONTADOR 2.......................................................................................................................... 13
3.2 CONTAFILL 2 (accessories)..................................................................................................... 13
3.3 Marina 200 air pump ............................................................................................................. 13
3.4 General data .......................................................................................................................... 13
4Delivery, transport and storage .............................................................................................. 14
4.1 Standard equipment supplied ............................................................................................... 14
4.2 Transport and packaging ....................................................................................................... 14
4.3 Temporary storage ................................................................................................................ 16
5Function ................................................................................................................................ 17
5.1 Overview................................................................................................................................ 17
5.2 Functional sequence.............................................................................................................. 18
5.3 Checked and countable products .......................................................................................... 18
5.4 Additions and accessories...................................................................................................... 19
5.4.1 CONTAFILL 2.............................................................................................................. 19
5.4.2 External »START« key ............................................................................................... 20
5.4.3 Remote control – PC »SeedCount« software ........................................................... 20

Contador 2 Operating Instructions
Page 4 of 46 Revision 7 © 2019 – Pfeuffer GmbH
6Installation and operation...................................................................................................... 21
6.1 Assembling the CONTADOR 2................................................................................................ 21
6.2 Connections and installation of the external air pump ......................................................... 21
6.3 Connection to a compressed air system................................................................................ 22
6.4 Assembling the filling station CONTAFILL 2 (optional) .......................................................... 23
6.4.1 Assembly and loading the carousel........................................................................... 24
6.4.2 Inserting the carousel................................................................................................ 26
6.5 Operating the CONTADOR 2 .................................................................................................. 26
7Operation.............................................................................................................................. 27
7.1 The function keys ................................................................................................................... 27
7.2 Structure of the function menu ............................................................................................. 27
7.3 Selecting the feed container.................................................................................................. 30
7.4 Counting the seed/grain ........................................................................................................ 31
7.4.1 Interrupting the count .............................................................................................. 33
7.4.2 Setting the gate height.............................................................................................. 34
7.5 Counting the seed/grain with CONTAFILL 2........................................................................... 35
7.5.1 »Bag« counting mode - CONTAFILL 2........................................................................ 36
7.5.2 CONTAFILL 2 – manually rotating the filling position ............................................... 37
7.6 Switching on/off the acoustic warning signal ........................................................................ 37
7.7 The hidden settings................................................................................................................ 37
7.7.1 Setting the display (illumination, brightness and contrast)...................................... 38
7.7.2 Selecting the language .............................................................................................. 38
7.7.3 Container parameter menu ...................................................................................... 38
8Maintenance and cleaning ..................................................................................................... 39
8.1 Cleaning.................................................................................................................................. 39
8.2 Cleaning in the case of a dust warning .................................................................................. 39
8.3 Inspection intervals and functional check ............................................................................. 40
8.4 General maintenance information ........................................................................................ 40
8.5 Check the positioning of the lasers by means of a laser test................................................. 41
8.6 Renewing the equipment fuse............................................................................................... 42
8.7 Checks .................................................................................................................................... 42
9Faults – causes and remedy ................................................................................................... 43
10 Spare parts and accessories ................................................................................................... 44
11 Emergency ............................................................................................................................ 45
12 Disassembly and disposal....................................................................................................... 45

Contador 2 Operating Instructions
© 2019 – Pfeuffer GmbH Revision 7 Page 5 of 46
1Introduction
1.1 Intended use
The CONTADOR 2 seed counter is used to count cleaned seeds such as grain, oil seeds, corn legumes and
similar, dust-free products in order to establish, for example, the thousand seed weight. The maximum
counting rate is 5.000 seeds/min.
It is controlled by the three function keys which are fitted to the machine and also the RS232 interface,
e. g. using the PC software »Seed Count« which is available as an accessory.
The filling station, CONTAFILL 2, is required as an accessory for automatically filling the counted seeds
into bags or bottles.
The CONTADOR 2 is designed as a portable machine with a power plug for interiors.
A private use of the CONTADOR 2 seed counter is not permitted.
NOTE The machine cannot be used to count dressed seeds, items made of static plastic parts
and dusty products. This can cause the light barriers to become soiled.
NOTE The CONTADOR 2 is designed to be used exclusively for the purpose described.
Any use or modification that does not have the prior written approval of the
manufa
cturer shall be considered as improper use. The manufacturer assumes no
liability for damage caused by improper use. The operating company is solely
responsible for any damage resulting from this.
The CONTADOR 2 may be put into operation only once it has been established that all
the safety equipment is functioning.
The samples that are used for the intended use must be procured by the CONTADOR 2
operating company.
The operating company is solely responsible for the proper handling of these materials
and the associated hazards.
The operating company must provide hazard and disposal information.
Intended use includes also the compliance with the Instruction Manual and User´s Guide as well as the
maintenance and servicing conditions, as specified in these Operating Instructions.
These Operating Instructions do not relieve the operating company of the obligation to develop and to
apply independent health and/or safety regulations or safe working processes which are aimed at the
requirements of the overall machine, as well as the obligation to monitor their compliance.
