INDUCTION HOB
OWNER’S MANUAL
PHD 60 IP

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all
the instructions in this user’s manual.
Copyright © 2020, Fast ČR, a. s. Revision 05/2020

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 1
CONTENTS
1. SAFETY..........................................................................................................................................................2
2. PRODUCT INTRODUCTION .........................................................................................................................5
2.2 Control Panel ................................................................................................................................................................................5
2.3 Working Theory............................................................................................................................................................................ 6
2.4 Before using your New Induction Hob................................................................................................................................ 6
2.5 Technical Specication..............................................................................................................................................................6
3. OPERATION OF PRODUCT...........................................................................................................................7
3.1 Touch Controls .............................................................................................................................................................................7
3.2 Choosing the right Cookware.................................................................................................................................................7
3.3 How to use.....................................................................................................................................................................................9
4. COOKING GUIDELINES ..............................................................................................................................13
4.1 Cooking Tips................................................................................................................................................................................13
4.2 Detection of Small Articles ....................................................................................................................................................14
5. HEAT SETTINGS..........................................................................................................................................14
6. CARE AND CLEANING................................................................................................................................15
7. HINTS AND TIPS .........................................................................................................................................16
8. FAILURE DISPLAY AND INSPECTION........................................................................................................17
Troubleshooting...............................................................................................................................................................................17
9. INSTALLATION............................................................................................................................................19
9.1 Selection of installation equipment...................................................................................................................................19
9.2 Before installing the hob, make sure that ........................................................................................................................21
9.3 After installing the hob, make sure that ...........................................................................................................................22
9.4 Before locating the xing brackets.....................................................................................................................................22
9.5 Adjusting the bracket position.............................................................................................................................................22
9.6 Cautions........................................................................................................................................................................................23
9.7 Connecting the hob to the mains power supply...........................................................................................................23

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 2
1. SAFETY
THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8
YEARS AND ABOVE AND BY PERSONS WITH REDUCED PHYSICAL,
SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE
AND KNOWLEDGE IF THEY HAVE BEEN GIVEN SUPERVISION OR
INSTRUCTIONS CONCERNING USE OF THE APPLIANCE IN A SAFE
WAY AND IF THEY UNDERSTAND THE HAZARDS INVOLVED.
CHILDREN MUST NOT PLAY WITH THE APPLIANCE.
CLEANING AND USER MAINTENANCE CANNOT BE PERFORMED
BY CHILDREN WITHOUT SUPERVISION.
IF THE SUPPLY CABLE GETS DAMAGED, HAVE IT REPLACED BY A
SPECIALIZED SERVICE CENTRE IN ORDER TO AVOID DANGEROUS
SITUATION.
IT IS PROHIBITED TO USE THE APPLIANCE WHEN THE SUPPLY
CABLE IS DAMAGED

CAUTION, HOT SURFACE
CAUTION: IF THE SURFACE IS CRACKED, TURN THE APPLIANCE
OFF TO PREVENT RISK OF ELECTRIC SHOCK.
CAUTION: THE APPLIANCE AND ITS ACCESSIBLE PARTS GET HOT
DURING USE.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 3
PLEASE MAKE SURE TO REFRAIN FROM TOUCHING THE HEATING
ELEMENTS.
KEEP CHILDREN BELOW 8 YEARS OF AGE AWAY FROM THE
APPLIANCE IF THEY ARE NOT UNDER CONSTANT SUPERVISION.
WHEN CLEANING THE OVEN DOOR GLASS / COOKING HOB GLASS
HINGED COVERS, DO NOT USE HARSH ABRASIVE CLEANING
AGENTS OR SHARP METAL SCRAPERS AS THE SURFACE MIGHT
BECOME SCRATCHED WHICH COULD RESULT IN THE GLASS
BREAKING.
STEAM CLEANERS MUST NOT BE USED TO CLEAN COOKING HOBS.
METAL OBJECTS SUCH AS KNIVES, FORKS, SPOONS AND POT LIDS
MUST NOT BE PLACED ON THE COOKING HOB AS THEY MIGHT GET
HOT.
THIS APPLIANCE IS NOT INTENDED TO BE USED WITH EXTERNAL
TIME SWITCH OR SEPARATE REMOTE CONTROL SYSTEM.
CAUTION: COOKING ON THE COOKING HOB USING FAT OR OIL
WITHOUT SUPERVISION CAN BE DANGEROUS AND CAN CAUSE
FIRE.
NEVER TRY TO EXTINGUISH FIRE USING WATER; YOU SHOULD
RATHER TURN THE APPLIANCE OFF AND THEN COVER THE FLAMES
E.G. USING A LID OR A FIRE-STOPPING COVER.
NOTICE: COOKING PROCESS MUST BE UNDER SUPERVISION.
SHORT-TIME COOKING PROCESS MUST BE UNDER SUPERVISION
CONSTANTLY.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 4
CAUTION: FIRE HAZARD: DO NOT PLACE ANY OBJECTS ON THE
COOKING SURFACE.
CAUTION: USE ONLY COOKING HOB PROTECTIVE COVERS MADE
BY THE MANUFACTURER OF THE COOKING APPLIANCE OR STATED
BY THE MANUFACTURER OF THE APPLIANCE AS SUITABLE IN THE
RESPECTIVE USER’S MANUAL OR COOKING HOB PROTECTIVE
COVERS BUILT-IN IN THE APPLIANCE. USING INCORRECT
PROTECTIVE COVERS CAN CAUSE ACCIDENTS.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 5
2. PRODUCT INTRODUCTION
2.1 Top View
1. Max. 1500 W zone
2. Max. 2000 W zone
3. Max. 2000 W zone
4. Max. 1500 W zone
5. Glass plate
6. Control panel
7. ON/OFF control
1. Heating zone selection controls
2. Power / Timer regulating key
3. Keylock control
4. ON/OFF control
5. Timer control
2.2 Control Panel

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 6
2.3 Working Theory
Induction cooking is a safe, advanced, ecient, and economical cooking technology. It works by
electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the
glass surface. The glass becomes hot only because the pan eventually warms it up.
iron pot
magnetic circuit
ceramic glass plate
induction coil
induced currents
2.4 Before using your New Induction Hob
• Readthisguide,takingspecialnoteofthe‘SafetyWarnings’section.
• RemoveanyprotectivelmthatmaystillbeonyourInductionhob.
2.5 Technical Specication
Cooking Hob PHD 60 IP
Cooking Zones 4 Zones
Supply Voltage 220-240V~ 50Hz or 60Hz
Installed Electric Power 3000W
Product Size L×W×H(mm) 590X520X60
Building-in Dimensions A×B (mm) 560X490
Weight and Dimensions are approximate. Because we continually strive to improve our products we may
change specications and designs without prior notice.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 7
3. OPERATION OF PRODUCT
3.1 Touch Controls
• Thecontrolsrespondtotouch,soyoudon’tneedtoapplyanypressure.
• Usetheballofyournger,notitstip.
• Youwillhearabeepeachtimeatouchisregistered.
• Makesurethecontrolsarealwaysclean,dry,andthatthereisnoobject(e.g.autensiloracloth)covering
them. Even a thin lm of water may make the controls dicult to operate.
3.2 Choosing the right Cookware
• Onlyusecookwarewithabasesuitableforinductioncooking.
Look for the induction symbol on the packaging or on the bottom of the
• Youcancheckwhetheryourcookwareissuitablebycarryingoutamagnet
test.
Move a magnet towards the base of the pan. If it is attracted, the pan is
suitable for induction.
• Ifyoudonothaveamagnet:
1. Put some water in the pan you want to check.
2. If

does not ash in the display and the water is heating, the pan is suitable.
• Cookwaremadefromthefollowingmaterialsisnotsuitable:purestainlesssteel,aluminiumorcopper
without a magnetic base, glass, wood, porcelain, ceramic, and earthenware.
strana 9

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 8
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits at against the glass, and is the same size as the cooking
zone. Use pans whose diameter is as large as the graphic of the zone selected. Using a pot a slightly wider
energy will be used at its maximum eciency. If you use smaller pot eciency could be less than expected.
Pot less than 140 mm could be undetected by the hob. Always centre your pan on the cooking zone.
Always lift pans o the Induction hob – do not slide, or they may scratch the glass.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 9
3.3 How to use
3.3.1 Start cooking
Touch the ON/OFF control for three seconds. After power on,
the buzzer beeps once, all displays show“–” or“– –”, indicating
that the induction hob has entered the state of standby mode.
Place a suitable pan on the cooking zone that you wish to use.
• Makesurethebottomofthepanandthesurfaceofthe
cooking zone are clean and dry.
Touching the heating zone selection control ,and a indicator
next to the key will ash
Select a heat setting by touching the“-” or“+” control.
• Ifyoudon’tchooseaheatsettingwithin1minute,the
Induction hob will automatically switch o. You will need to
start again at step 1.
• Youcanmodifytheheatsettingatanytimeduringcooking.
Warning:
The whole hob can take in charge a maximum power of 3000W. Consequently, the hob automatically
reduces the maximum output power by allowing a maximum sum of the all power levels of 12.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 10
If the display ashes

alternately with the heat setting
This means that:
• youhavenotplacedapanonthecorrectcookingzoneor,
• thepanyou’reusingisnotsuitableforinductioncookingor,
• thepanistoosmallornotproperlycenteredonthecookingzone.
No heating takes place unless there is a suitable pan on the cooking zone.
The display“U”will automatically disappear after 1 minute if no suitable pan is placed on it.
3.3.2 Finish cooking
Touching the heating zone selection control that you
wish to switch o
Turn the cooking zone o by scrolling down to“0”or
touching“-” and“+”control together. Make sure the
display shows“0”.
OR
Turn the whole cooktop o by touching the ON/OFF
control.
Beware of hot surfaces
• Hwillshowwhichcookingzoneishottotouch.It
will disappear when the surface has cooled down to
a safe temperature. It can also be used as an energy
saving function if you want to heat further pans, use
the hotplate that is still hot.
3.3.3 Locking the Controls
• Youcanlockthecontrolstopreventunintendeduse(forexamplechildrenaccidentallyturningthe
cooking zones on).
• Whenthecontrolsarelocked,allthecontrolsexcepttheON/OFFcontrolaredisabled.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 11
To lock the controls
Touch the lock control The timer indicator will show“Lo”
To unlock the controls
Touch and hold the lock control for a while.
When the hob is in the lock mode, all the controls are disable except the ON/OFF

, you can always
turn the induction hob o with the ON/OFF

control in an emergency, but you shall unlock the hob
rst in the next operation.
3.3.4 Timer control
You can use the timer in two dierent ways:
• Youcanuseitasaminuteminder.Inthiscase,thetimerwillnotturnanycookingzoneowhentheset
time is up.
• Youcansetittoturnoneormorecookingzonesoafterthesettimeisup.
The timer of maximum is 99 min.
a) Using the Timer as a Minute Minder
If you are not selecting any cooking zone
Make sure the cooktop is turned on.
Note: you can use the minute minder even if you’re not
selecting any cooking zone.
Touch“+”the controls of the timer. The minder indicator
will start ashing and “10”will show in the timer display.
Set the time by touching the“-” or“+”control of the
timer
Hint: Touch the “-”or “+”control of the timer to decrease
or increase by 1 minute once.
Touch and hold the“-”or“+” control of the timer to
decrease or increase by 10 minutes.
Touching the“-”and“+” together, the timer is cancelled,
and the“00” will show in the minute display.
When the time is set, it will begin to count down
immediately. The display will show the remaining time
and the timer indicator will ash for 5 seconds.
Buzzer will beep for 30 seconds and the timer indicator
shows“- -” when the setting time nished.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 12
b) Setting the timer to turn one cooking zone o
Set one zone
Touching the heating zone selection control that you
want to set the timer for. (e.g. zone 3#)
Touch timer control, the minder indicator will start
ashing and“10” will show in the timer display.
Set the time by touching the“-” or“+”control of the
timer
Hint: Touch the “-”or “+”control of the timer once will
decrease or increase by 1 minute.
Touch and hold the“-”or“+” control of the timer will
decrease or increase by 10 minutes.
Touching the“-”and“+” together, the timer is cancelled,
and the“00” will show in the minute display.
When the time is set, it will begin to count down
immediately. The display will show the remaining time
and the timer indicator ash for 5 seconds.
NOTE: The red dot next to power level indicator will
illuminate indicating that zone is selected.
When cooking timer expires, the corresponding
cooking zone will be switched o automatically.
Other cooking zone will keep operating if they are turned on previously.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 13
3.3.5 Default working times
Auto shut down is a safety protection function for your induction hob. It shut down automatically if ever you
forget to turn o your cooking. The default working times for various power levels are shown in the below
table:
Power level 1 2 3 4 5 6 7 8 9
Default working timer (hour) 8 8 8 4 4 4 2 2 2
When the pot is removed, the induction hob can stop heating immediately and the hob automatically switch
o after 2 minutes.
People with a heart pace maker should consult with their doctor before using this unit.
4. COOKING GUIDELINES
Take care when frying as the oil and fat heat up very quickly, particularly if you’re using PowerBoost. At
extremely high temperatures oil and fat will ignite spontaneously and this presents a serious re risk.
4.1 Cooking Tips
• Whenfoodcomestotheboil,reducethetemperaturesetting.
• Usingalidwillreducecookingtimesandsaveenergybyretainingtheheat.
• Minimizetheamountofliquidorfattoreducecookingtimes.
• Startcookingonahighsettingandreducethesettingwhenthefoodhasheatedthrough.
4.1.1 Simmering, cooking rice
• Simmeringoccursbelowboilingpoint,ataround85°C,whenbubblesarejustrisingoccasionallyto
the surface of the cooking liquid. It is the key to delicious soups and tender stews because the avours
develop without overcooking the food. You should also cook egg-based and our thickened sauces below
boiling point.
• Sometasks,includingcookingricebytheabsorptionmethod,mayrequireasettinghigherthanthelowest
setting to ensure the food is cooked properly in the time recommended.
4.1.2 Searing steak
To cook juicy avorsome steaks:
1. Stand the meat at room temperature for about 20 minutes before cooking.
2. Heat up a heavy-based frying pan.
3. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and then lower the
meat onto the hot pan.
4. Turn the steak only once during cooking. The exact cooking time will depend on the thickness of the
steak and how cooked you want it. Times may vary from about 2 – 8 minutes per side. Press the steak to
gaugehowcookeditis–thermeritfeelsthemore‘welldone’itwillbe.
5. Leave the steak to rest on a warm plate for a few minutes to allow it to relax and become tender before
serving.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 14
4.1.3 For stir-frying
1. Choose an induction compatible at-based wok or a large frying pan.
2. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large quantities,
cook the food in several smaller batches.
3. Preheat the pan briey and add two tablespoons of oil.
4. Cook any meat rst, put it aside and keep warm.
5. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower setting, return
the meat to the pan and add your sauce.
6. Stir the ingredients gently to make sure they are heated through.
7. Serve immediately.
4.2 Detection of Small Articles
When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other small item (e.g. knife, fork,
key) has been left on the hob, the hob automatically go on to standby in 1 minute. The fan will keep cooking
down the induction hob for a further 1 minute.
5. HEAT SETTINGS
The settings below are guidelines only. The exact setting will depend on several factors, including your
cookware and the amount you are cooking. Experiment with the induction hob to nd the settings that best
suit you.
Heat setting Suitability
1 - 2 • delicatewarmingforsmallamountsoffood
• meltingchocolate,butter,andfoodsthatburnquickly
• gentlesimmering
• slowwarming
3 - 4 • reheating
• rapidsimmering
• cookingrice
5 - 6 • pancakes
7 - 8 • sautéing
• cookingpasta
9• stir-frying
• searing
• bringingsouptotheboil
• boilingwater

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 15
6. CARE AND CLEANING
What? How? Important!
Everyday soiling on
glass (ngerprints,
marks, stains left by
food or non-sugary
spillovers on the
glass)
1. Switch the power to the cooktop
o.
2. Apply a cooktop cleaner while the
glass is still warm (but not hot!)
3. Rinse and wipe dry with a clean
cloth or paper towel.
4. Switch the power to the cooktop
back on.
• Whenthepowertothecooktopis
switchedo,therewillbeno‘hot
surface’indication but the cooking
zone may still be hot! Take extreme
care.
• Heavy-dutyscourers,somenylon
scourers and harsh/abrasive cleaning
agents may scratch the glass. Always
read the label to check if your cleaner
or scourer is suitable.
• Neverleavecleaningresidueon
the cooktop: the glass may become
stained.
Boilovers, melts, and
hot sugary spills on
the glass
Remove these immediately with a
sh slice, palette knife or razor blade
scraper suitable for Induction glass
cooktops, but beware of hot cooking
zone surfaces:
1. Switch the power to the cooktop
o at the wall.
2. Holdthebladeorutensilata30°
angle and scrape the soiling or
spill to a cool area of the cooktop.
3. Clean the soiling or spill up with a
dish cloth or paper towel.
4. Followsteps2to4for‘Everyday
soiling on glass’above.
• Removestainsleftbymeltsand
sugary food or spillovers as soon as
possible. If left to cool on the glass,
they may be dicult to remove or
even permanently damage the glass
surface.
• Cuthazard:whenthesafetycover
is retracted, the blade in a scraper is
razor-sharp. Use with extreme care
and always store safely and out of
reach of children.
Spillovers on the
touch controls
1. Switch the power to the cooktop
o.
2. Soak up the spill
3. Wipe the touch control area with a
clean damp sponge or cloth.
4. Wipe the area completely dry with
a paper towel.
5. Switch the power to the cooktop
back on.
• Thecooktopmaybeepandturn
itself o, and the touch controls may
not function while there is liquid on
them. Make sure you wipe the touch
control area dry before turning the
cooktop back on.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 16
7. HINTS AND TIPS
Problem Possible causes What to do
The induction hob
cannot be turned on.
No power. Make sure the induction hob is
connected to the power supply and
that it is switched on.
Check whether there is a power
outage in your home or area. If you’ve
checked everything and the problem
persists, call a qualied technician.
The touch controls are
unresponsive.
The controls are locked. Unlock the controls. See section
‘Usingyourinductioncooktop’for
instructions.
The touch controls are
dicult to operate.
There may be a slight lm of water
over the controls or you may be using
the tip of your nger when touching
the controls.
Make sure the touch control area is dry
and use the ball of your nger when
touching the controls.
The glass is being
scratched.
Rough-edged cookware.
Unsuitable, abrasive scourer or
cleaning products being used.
Use cookware with at and smooth
bases. See“Choosing the right
cookware”
See“Care and cleaning”.
Some pans make
crackling or clicking
noises.
This may be caused by the
construction of your cookware
(layers of dierent metals vibrating
dierently).
This is normal for cookware and does
not indicate a fault.
The induction hob
makes a low humming
noise when used on a
high heat setting.
This is caused by the technology of
induction cooking.
This is normal, but the noise should
quieten down or disappear completely
when you decrease the heat setting.
Fan noise coming from
the induction hob.
A cooling fan built into your induction
hob has come on to prevent the
electronics from overheating. It may
continue to run even after you’ve
turned the induction hob o.
This is normal and needs no action. Do
not switch the power to the induction
hob o at the wall while the fan is
running.
Pans do not become
hot and appears in the
display.
The induction hob cannot detect
the pan because it is not suitable for
induction cooking.
The induction hob cannot detect the
pan because it is too small for the
cooking zone or not properly centred
on it.
Use cookware suitable for induction
cooking. See section “Choosing the
right cookware”.
Centre the pan and make sure that its
base matches the size of the cooking
zone.

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 17
Problem Possible causes What to do
The induction hob
or a cooking zone
has turned itself o
unexpectedly, a tone
sounds and an error
code is displayed
(typically alternating
with one or two digits
in the cooking timer
display).
Technical fault. Please note down the error letters
and numbers, switch the power to
the induction hob o at the wall, and
contact a qualied technician.
8. FAILURE DISPLAY AND INSPECTION
The induction hob is equipped with a self diagnostic function. With this test the technician is able to check
the function of several components without disassembling or dismounting the hob from the working
surface.
Troubleshooting
1) Failure code occur during customer using & Solution;
Failure code Problem Solution
Auto-Recovery
E1 Supply voltage is above the rated voltage. Please inspect whether power supply is
normal.
Power on after the power supply is normal.
E2 Supply voltage is below the rated voltage.
E3 High temperature of ceramic plate sensor.
(1#) Wait for the temperature of ceramic plate
return to normal.
Touch“ON/OFF”button to restart unit.
E4 High temperature of ceramic plate sensor.
(2#)
E5 High temperature of IGBT. (1#) Wait for the temperature of IGBT return to
normal.
Touch“ON/OFF”button to restart unit.
Check whether the fan runs smoothly; if
not , replace the fan.
E6 High temperature of IGBT. (2#)

Copyright © 2020, Fast ČR, a. s. Revision 05/2020
EN - 18
Failure code Problem Solution
No Auto-Recovery
F3/F6 Ceramic plate temperature sensor failure-
short circuit. (F3 for 1#,F6 for 2#)
Check the connection or replace the
ceramic plate temperature sensor.
F4/F7 Ceramic plate temperature sensor failure-
open circuit. (F4 for 1#,F7 for 2#)
F5/F8 Ceramic plate temperature sensor failure-
invalid . (F5 for 1#,F8 for 2#)
F9/FA Temperature sensor of the IGBT failure.
(short circuit/open circuit for 1#) Replace the power board.
FC/FD Temperature sensor of the IGBT failure.
(short circuit/open circuit for 2#)
2) Specic Failure & Solution
Failure Problem Solution A Solution B
The LED does not come on
when unit is plugged in.
No power supplied. Check to see if plug
is secured tightly in
outlet and that outlet is
working.
The accessorial power
board and the display
board connected failure.
Check the connection.
The accessorial power
board is damaged.
Replace the accessorial
power board.
The display board is
damaged.
Replace the display
board.
Some buttons can’t work, or
the LED display is not normal.
The display board is
damaged.
Replace the display
board.
The Cooking Mode Indicator
comes on, but heating does
not start.
High temperature of
the hob.
Ambient temperature
may be too high. Air
Intake or Air Vent may
be blocked.
There is something
wrong with the fan.
Check whether the fan
runs smoothly;
if not, replace the fan.
The power board is
damaged.
Replace the power
board.
