Philco PHS69C User manual

GLASS-CERAMIC HOB
OWNER’S MANUAL
PHS 69C

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all
the instructions in this user’s manual.
Copyright © 2019, Fast ČR, a. s. Revision 08/2019

Copyright © 2019, Fast ČR, a. s. Revision 08/2019
EN - 1
CONTENTS
PART 1: SAFETY INFORMATION......................................................................................................................2
PART 2: DESCRIPTION OF THE APPLIANCE...................................................................................................7
Technical characteristics..................................................................................................................................................................7
Control panel.......................................................................................................................................................................................8
PART 3: USE OF THE APPLIANCE ....................................................................................................................8
Sensitive touch.................................................................................................................................................................................... 8
Display.................................................................................................................................................................................................... 8
PART 4: STARTINGUP AND APPLIANCE MANAGEMENT ............................................................................9
Before the rst use.............................................................................................................................................................................9
Starting-up ........................................................................................................................................................................................... 9
Residual heat indication.................................................................................................................................................................. 9
Automatic cooking..........................................................................................................................................................................10
Control panel locking.....................................................................................................................................................................10
PART 5: COOKING ADVICES ..........................................................................................................................11
Examples of cooking power setting..........................................................................................................................................11
PART 6: WHAT TO DO IN CASE OF A PROBLEM ...........................................................................................11
PART 7: MAINTENANCE AND CLEANING.....................................................................................................12
PART 8: INSTALLATION INSTRUCTIONS ......................................................................................................13
PART 9: ELECTRICAL CONNECTION .............................................................................................................14
Connection of the hob...................................................................................................................................................................14
This appliance has been tested in accordance with the directives in force in the European Union.
This appliance conforms to the relevant safety provisions for electrical appliances in force in the
European Union.
Dear customer,
Thank you for having chosen a hob.
In order to install properly your appliance and to make the best use of it, please read this entire instruction
manual carefully.

Copyright © 2019, Fast ČR, a. s. Revision 08/2019
EN - 2
PART 1: SAFETY INFORMATION
PRECAUTIONS BEFORE USING
 UNPACK ALL THE MATERIALS.
 THE INSTALLATION AND CONNECTING OF THE APPLIANCE
HAVE TO BE DONE BY APPROVED SPECIALISTS. THE
MANUFACTURER CANNOT BE RESPONSIBLE FOR DAMAGE
CAUSED BY BUILDINGIN OR CONNECTING ERRORS.
 TO BE USED, THE APPLIANCE MUST BE WELLEQUIPPED
AND INSTALLED IN A KITCHEN UNIT AND AN ADAPTED AND
APPROVED WORK SURFACE.
 THIS DOMESTIC APPLIANCE IS EXCLUSIVELY FOR THE COOKING
OF FOOD, TO THE EXCLUSION OF ANY OTHER DOMESTIC,
COMMERCIAL OR INDUSTRIAL USE.
 REMOVE ALL LABELS AND SELFADHESIVES FROM THE
CERAMIC GLASS.
 DO NOT CHANGE OR ALTER THE APPLIANCE.
 THE COOKING PLATE CANNOT BE USED AS FREESTANDING OR
AS WORKING SURFACE.
 THE APPLIANCE MUST BE GROUNDED AND CONNECTED
CONFORMING TO LOCAL STANDARDS.
 DO NOT USE ANY EXTENSION CABLE TO CONNECT IT.
 THE APPLIANCE CANNOT BE USED ABOVE A DISHWASHER OR A
TUMBLEDRYER:
STEAM MAY DAMAGE THE ELECTRONIC APPLIANCES.

Copyright © 2019, Fast ČR, a. s. Revision 08/2019
EN - 3
 THE APPLIANCE IS NOT INTENDED TO BE OPERATED BY MEANS
OF EXTERNAL TIMER OR SEPARATE REMOTE CONTROL SYSTEM.
 CAUTION : THE COOKING PROCESS HAS TO BE SUPERVISED.
A SHORT TERM COOKING PROCESS HAS TO BE SUPERVISED
CONTINUOUSLY.
USING THE APPLIANCE
 SWITCH THE HEATING ZONES OFF AFTER USING.
 KEEP AN EYE ON THE COOKING USING GREASE OR OILS: THAT
MAY QUICKLY IGNITE.
 BE CAREFUL NOT TO BURN YOURSELF WHILE OR AFTER USING
THE APPLIANCE.
 MAKE SURE NO CABLE OF ANY FIXED OR MOVING APPLIANCE
CONTACTS WITH THE GLASS OR THE HOT SAUCEPAN.
 MAGNETICALLY OBJECTS CREDIT CARDS, FLOPPY DISKS,
CALCULATORS SHOULD NOT BE PLACED NEAR TO THE
ENGAGED APPLIANCE.
 METALLIC OBJECTS SUCH AS KNIVES, FORKS, SPOONS AND
LIDS SHOULD NOT BE PLACED ON THE HOB SURFACE SINCE
THEY CAN GET HOT.
 IN GENERAL DO NOT PLACE ANY METALLIC OBJECT EXCEPT
HEATING CONTAINERS ON THE GLASS SURFACE. IN CASE OF
UNTIMELY ENGAGING OR RESIDUAL HEAT, THIS ONE MAY HEAT,
MELT OR EVEN BURN.
 NEVER COVER THE APPLIANCE WITH A CLOTH OR A
PROTECTION SHEET. THIS IS SUPPOSED TO BECOME VERY HOT
AND CATCH FIRE.

Copyright © 2019, Fast ČR, a. s. Revision 08/2019
EN - 4
 THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8
YEARS AND ABOVE AND PERSONS WITH REDUCED PHYSICAL,
SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE
AND KNOWLEDGE IF THEY HAVE BEEN GIVEN SUPERVISION OR
INSTRUCTION CONCERNING USE OF THE APPLIANCE IN A SAFE
WAY AND UNDERSTAND THE HAZARDS INVOLVED.
 CHILDREN SHALL NOT PLAY WITH THE APPLIANCE.
 CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY
CHILDREN WITHOUT SUPERVISION.
PRECAUTIONS NOT TO DAMAGE THE APPLIANCE
 RAW PAN BOTTOMS OR DAMAGED SAUCEPANS NOT
ENAMELLED CAST IRON POTS, MAY DAMAGE THE CERAMIC
GLASS.
 SAND OR OTHER ABRASIVE MATERIALS MAY DAMAGE CERAMIC
GLASS.
 AVOID DROPPING OBJECTS, EVEN LITTLE ONES, ON THE
VITROCERAMIC.
 DO NOT HIT THE EDGES OF THE GLASS WITH SAUCEPANS.
 MAKE SURE THAT THE VENTILATION OF THE APPLIANCE WORKS
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.
 DO NOT PUT OR LEAVE EMPTY SAUCEPANS ON THE
VITROCERAMIC HOBS.
 SUGAR, SYNTHETIC MATERIALS OR ALUMINIUM SHEETS MUST
NOT CONTACT WITH THE HEATING ZONES. THESE MAY CAUSE
BREAKS OR OTHER ALTERATIONS OF THE VITROCERAMIC GLASS
BY COOLING: SWITCH ON THE APPLIANCE AND TAKE THEM
IMMEDIATELY OUT OF THE HOT HEATING ZONE BE CAREFUL:
DO NOT BURN YOURSELF.

Copyright © 2019, Fast ČR, a. s. Revision 08/2019
EN - 5
 WARNING: DANGER OF FIRE: DO NOT STORE ITEMS ON THE
COOKING SURFACE.
 NEVER PLACE ANY HOT CONTAINER OVER THE CONTROL
PANEL.
 IF A DRAWER IS SITUATED UNDER THE EMBEDDED APPLIANCE,
MAKE SURE THE SPACE BETWEEN THE CONTENT OF THE
DRAWER AND THE INFERIOR PART OF THE APPLIANCE IS LARGE
ENOUGH 2 CM. THIS IS ESSENTIAL TO GUARANTYA CORRECT
VENTILATION.
 NEVER PUT ANY INFLAMMABLE OBJECT EX. SPRAYS INTO
THE DRAWER SITUATED UNDER THE VITROCERAMIC HOB. THE
EVENTUAL CUTLERY DRAWERS MUST BE RESISTANT TO HEAT.
PRECAUTIONS IN CASE OF APPLIANCE FAILURE
 IF A DEFECT IS NOTICED, SWITCH OFF THE APPLIANCE AND
TURN OFF THE ELECTRICAL SUPPLYING.
 IF THE CERAMIC GLASS IS CRACKED OR FISSURED, YOU MUST
UNPLUG THE APPLIANCE AND CONTACT THE AFTER SALES
SERVICE.
 REPAIRING HAS TO BE DONE BY SPECIALISTS. DO NOT OPEN
THE APPLIANCE BY YOURSELF.
 WARNING: IF THE SURFACE IS CRACKED, SWITCH OFF THE
APPLIANCE TO AVOID THE POSSIBILITY OF ELECTRIC SHOCK.
OTHER PROTECTIONS

Copyright © 2019, Fast ČR, a. s. Revision 08/2019
EN - 6
OTHER PROTECTIONS
 NOTE SURE THAT THE CONTAINER PAN IS ALWAYS CENTRED ON
THE COOKING ZONE. THE BOTTOM OF THE PAN MUST HAVE TO
COVER AS MUCH AS POSSIBLE THE COOKING ZONE.
 FOR THE USERS OF PACEMAKER, THE MAGNETIC FIELD COULD
INFLUENCE ITS OPERATING. WE RECOMMEND GETTING
INFORMATION TO THE RETAILER OR OF THE DOCTOR.
 DO NOT TO USE ALUMINIUM OR SYNTHETIC MATERIAL
CONTAINERS: THEY COULD MELT ON STILL HOT COOKING
ZONES.
 NEVER TRY TO EXTINGUISH A FIRE WITH WATER, BUT SWITCH
OFF THE APPLIANCE AND THEN COVER FLAME E.G. WITH A LID
OR A FIRE BLANKET.

Copyright © 2019, Fast ČR, a. s. Revision 08/2019
EN - 7
PART 2: DESCRIPTION OF THE APPLIANCE
Technical characteristics
Type PHS69C
Total power
Energy consumption for the hob EChob*
6000 W
180.7 Wh/kg
Front left heating zone
Nominal power
Standardised cookware category*
Energy consumption ECcw*
Ø 190 mm
1800 W
C
183.9 Wh/kg
Rear left heating zone
Nominal power
Standardised cookware category*
Energy consumption ECcw
Ø 155 mm
1200 W
A
173.8 Wh/kg
Rear right heating zone
Nominal power
Standardised cookware category*
Energy consumption ECcw*
Ø 190 mm
1800 W
B
191.3 Wh/kg
Front right heating zone
Nominal power
Standardised cookware category*
Energy consumption ECcw*
Ø 155 mm
1200 W
A
173.8 Wh/kg
* Calculated according to the method of measuring performance (EN 60350-2).

Copyright © 2019, Fast ČR, a. s. Revision 08/2019
EN - 8
Control panel
Power display
[ + ] key On/o key
[ - ] key for all
heating zones
PART 3: USE OF THE APPLIANCE
Sensitive touch
Your ceramic hob is equipped with electronic controls with sensitive touch keys. When your nger presses
the key, the corresponding command is activated. This activation is validated by a control light, a letter or a
number in the display and/or a“beep”sound.
Touch only one key on the same time.
Display
Display Designation Function
0Zero The heating zone is activated.
1…9 Power level Selection of the cooking level.
A Heat accelerator No pan or inadequate pan.
E Error message Electronic failure.
H Residual heat The heating zone is hot.
L Locking Control panel locking.
