Philips HF3650 User manual

HF3650, HF3651,
HF3653, HF3654

2
1
11
10
1
9
7543 6
8

English 6
Dansk 21
Norsk 36
Suomi 51
Svenska 66

English
Contents
Introduction ___________________________________________________________________________________________ 6
General description____________________________________________________________________________________ 6
Intended use___________________________________________________________________________________________ 7
The effects of the Sleep & Wake-Up Light____________________________________________________________ 7
Important safety information__________________________________________________________________________ 7
Safety and compliance________________________________________________________________________________ 9
Electromagnetic fields (EMF)__________________________________________________________________________ 9
Display icons___________________________________________________________________________________________ 9
Navigating the menu___________________________________________________________________________________ 10
Setting wake-up profiles______________________________________________________________________________ 10
PowerBackUp+________________________________________________________________________________________ 11
Snoozing_______________________________________________________________________________________________ 11
Turning the alarm off__________________________________________________________________________________ 11
Using the Sleep & Wake-Up Light as a bedside lamp________________________________________________ 11
Midnight light__________________________________________________________________________________________ 12
Settings_________________________________________________________________________________________________ 12
Listening to radio* or your own music_________________________________________________________________ 13
Wind-down programs_________________________________________________________________________________ 14
Sunset Simulation______________________________________________________________________________________ 15
RelaxBreathe___________________________________________________________________________________________ 15
Charging your mobile phone__________________________________________________________________________ 16
Cleaning and storage__________________________________________________________________________________ 16
Recycling_______________________________________________________________________________________________ 17
Accessories and spare parts___________________________________________________________________________ 17
Warranty and support_________________________________________________________________________________ 17
Troubleshooting_______________________________________________________________________________________ 17
Specifications__________________________________________________________________________________________ 19
Introduction
The Philips Sleep & Wake-Up Light helps you wake up more pleasantly. If
the Sunrise Simulation is active (default is 30 minutes), the light intensity of
the lamp gradually increases to the set level and the light color changes
from deep morning red to bright daylight. The light gently prepares your
body for waking up at the set time. To make waking up an even more
pleasant experience, you can use natural wake-up sounds or the FM radio*
to wake up to.
*HF3653 does not feature a radio.
General description
1 Lamp housing
2 Display
3 USB charging port
4 Reset button
5 Radio antenna*
6 Adapter DC-inlet
6English

7 Auxiliary (AUX) input
8 Speaker
9 Snooze/Midnight Light button
10 Adapter
11 Small plug
*HF3653 does not feature a radio.
Intended use
The Philips Sleep & Wake-up Light is intended to give you a more natural
and refreshed wake up and a relaxed feeling before falling asleep.
This is not a general illumination product.
The effects of the Sleep & Wake-Up Light
The Philips Sleep & Wake-Up Light gently prepares your body for waking up
during the last 5 to 60 minutes or last period of sleep, depending on the
Sunrise Simulation time you set. In the early morning hours our eyes are
more sensitive to light than when we are awake. During that period the
relatively low light levels of a simulated natural sunrise prepare our body for
waking up and getting alert.
People who use the Sleep & Wake-Up Light wake up more easily, have a
better overall mood in the morning and feel more energetic. Because the
sensitivity to light differs per person, you can set the light intensity of your
Sleep & Wake-Up Light to a level that matches your light sensitivity for an
optimal start of the day. For more information about the Sleep & Wake-Up
Light, see www.philips.com.
Important safety information
Read this important information carefully before you use the appliance and
save it for future reference.
Danger
-Water and electricity are a dangerous combination. Do not use this
appliance in wet surroundings (e.g. in the bathroom or near a shower or
swimming pool).
-Keep the adapter dry.
-Do not let water run into the appliance or spill water onto the appliance.
-Do not immerse the appliance in water or rinse under the tap.
-Do not place anything close to the appliance that could cause water or
any other liquid to drip or splash onto the appliance.
-This appliance is for indoor use only.
-The adapter contains a transformer, which converts an unsafe
100-240Vac mains voltage to a safe 24Vdc low voltage. Do not cut off the
adapter to replace it with another plug, as this causes a hazardous
situation.
7
English

Warning
-Never use the appliance if the lamp housing is damaged, broken or
missing.
-If the adapter, cord or appliance has been damaged in any way, liquid
has spilled or objects have fallen into and/or onto the appliance, the
appliance has been exposed to rain or moisture, does not operate
normally or has been dropped or damaged, it should not be operated.
-If you feel uncomfortable at any point while using RelaxBreathe in the
breathing exercise, just go back to breathing normally.
-Only use the appliance in combination with the adapter supplied.
-If the adapter (cord) is damaged, always have it replaced with one of the
original type in order to avoid a hazard.
-This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
-Consult your doctor before you start using the appliance if you have
suffered from or are suffering from depression.
-Do not use this appliance as a means to reduce your hours of sleep. The
purpose of this appliance is to help you wake up more easily. It does not
diminish your need for sleep.
Caution
-Check if the voltage indicated on the appliance corresponds to the local
voltage before you connect the appliance.
-Protect the power cord from being walked on or pinched, particularly at
plugs, wall sockets and points where it exits from the lamp.
-Do not use the adapter in or near wall sockets that contain an electric air
freshener to prevent irreparable damage to the adapter.
-Do not drop the appliance on the floor, hit it hard or expose it to other
heavy shocks.
-Place the appliance on a stable, level and non-slippery surface.
-Do not impair the cooling of the appliance by covering the appliance with
items such as blankets, curtains, clothes, papers, etc.
-Do not use the appliance at room temperatures lower than 10°C or higher
than 35°C.
-The appliance has no on/off switch. To disconnect the appliance, remove
the adapter from the wall socket. The adapter must remain easily
accessible at all times.
-This appliance is only intended for household use, including similar use
for instance in hotels.
-No naked flame sources, such as lighted candles, should be placed on
the appliance.
General
-If you often wake up too early or with a headache, reduce the set light
intensity level and/or the set Sunrise Simulation time.
8English

-If you often wake up by the alarm sound, increase the set light intensity
level or the set Sunrise Simulation time.
-If you share a bedroom with someone else, this person may
unintentionally wake up from the light of the appliance, even though this
person is further removed from the appliance. This phenomenon is the
result of differences in light sensitivity between people.
-The power consumption of the appliance is lowest if no device is
connected to the USB port and the lamp, radio and display are turned
off.
Safety and compliance
This appliance meets the safety requirements in the EU for:
-IEC 60598: Luminaires.
-IEC 60065: Audio, Video and Similar Electronic Apparatus.
-IEC 60950: Information technology equipment.
-IEC 62471: Photobiological safety of lamps and lamp systems.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
Display icons
Wake-up profile Display off
Audio feedback Wind-down program
Clock time Sunset simulation
Light intensity and light on/off RelaxBreathe
Select your language Radio*
Settings Natural sounds
AUX socket Sound off
9
English

Radio presets* Alarm
Snooze/Midnight Light Breathing rhythms
Display
*HF3653 does not feature a radio.
Navigating the menu
On the display you can select and set the wake-up profile, bedside light,
settings, sound (source) or the unwind program.
Note: All your personalized settings and profiles will be permanently stored
in the memory, they will not be erased by removing the adapter from the
electrical outlet. You can change all settings at any time, the last setting will
be stored.
Note: If the display is blank, move your hand towards the lower part of the
Sleep & Wake-up Light to show the display menu. You will see the menu
buttons.
Setting wake-up profiles
In your wake-up profile you can set the alarm time, the maximum light
intensity and type of wake-up sound you prefer.
Note: Press and hold the alarm button for 1 second to deactivate all set
alarms at once. Activate a deactivated alarm by pressing the icon .
Set wake-up profile
You can set two different wake-up profiles. For each profile you can set the
time, light intensity, wake-up curve duration, the type of sound and volume.
Duration of the wake-up profile
The default duration of the wake-up curve (brightness increase to the set
maximum light intensity) is 30 minutes. The duration can be changed to your
preference.
10 English

Light intensity of the wake-up profile
The lamp of the appliance simulates a sunrise. Like a sunrise, the brightness
of the lamp increases gradually. During this wake-up curve, the color of the
light changes from soft red to warm orange to bright yellow. You can choose
one of the 25 light intensity levels.
Note: The main display of the appliance shows if the alarm has been set.
Type of sound
You can choose between three options. Select one of the natural sounds, no
sound or the FM radio.*
*HF3653 does not feature a radio.
PowerBackUp+
In the event of a power failure, all functions of the appliance, including the
display, do not work. However, the internal clock and a back-up alarm
remain active for at least 8 more hours.
If during the power failure the set alarm time is due, a back-up alarm goes
off generating a beeping sound for approximately 1 minute.
Snoozing
When the wake-up curve has ended (when the set maximum light intensity
has been reached) and the alarm sound is playing, you can tap the top of
the appliance to snooze.
The lamp stays on, but the sound is muted. After 9 minutes, the alarm sound
starts playing again.
Note: The light and sound automatically turn off 60 minutes after the alarm
has gone off or 60 minutes after the last snooze action.
Turning the alarm off
When the alarm goes off, you can turn it off by pressing this button. If you
turn off the alarm, the alarm profile is deactivated for that day.
Using the Sleep & Wake-Up Light as a bedside
lamp
You can use the Sleep & Wake-Up Light as a bedside lamp.
11
English

Press the bedside lamp button on the display to switch on the bedside
lamp.
Note: You can increase and decrease the brightness intensity. You can select
a brightness between 1 (low) to 25 (high). The default brightness setting is 18.
To switch it off press the cross button in the menu.
Tip: When the light is on, you can also turn off the light with a single tap on
top of the Sleep & Wake-Up Light. All active programs will stop. Set alarms
are still active.
Midnight light
If you wake up during the night, you can tap the top of the appliance to
activate a dim light. This dim, subtle orange light provides you with just
enough light to find your way in the dark. Switch off the Midnight light by
tapping the top of the appliance again.
Note: The Midnight light cannot be activated directly when the main light is
already on. In that case, first tap the top of the appliance to deactivate the
main light. Then tap again to activate the Midnight light.
Settings
In this menu, you can adjust the clock time, the audio feedback and the
display brightness of the appliance.
Note: Press and hold the settings button for 5 seconds to open a new menu,
in which you can select DEMO mode (accelerated wake-up curve) or
VERSION (firmware version of the appliance).
Time
You can change the time and switch between a 12-hour clock (AM/PM) and
a 24-hour clock by pressing on the toggle button (12/24).
12 English

Audio feedback
If you do not want to hear clicks when you press an icon, press the audio
feedback icon to turn off the audio feedback. You hear one click as a
confirmation. To reactivate the audio feedback, press this icon again.
Display
Display brightness
You can adjust the display brightness from level 1 to level 6. Choose a level
that is optimal for you to see the display at night. The appliance
automatically adjusts the display brightness when the light in your bedroom
changes.
Display on/off
If you do not want the appliance to produce any light (including time
indication), you can turn off the display completely by pressing the display
button.
Normally, if you do not touch the display for some time in any menu, the
display reverts to time and status indication only. When the display is off, no
time indication is shown.
Press the crossed-out button to turn on the display again.
Tip: If you want to check the time or select a function while the display is off,
just place your hand near the display to turn it on for a few seconds.
Listening to radio* or your own music
Tip: When the radio or music is on, you can turn off the sound with a single
tap on top of the Sleep & Wake-Up light. All active programs will stop. Set
alarms are still active.
13
English

Radio*
You can listen to the FM radio with the Sleep & Wake-Up Light. If you have
set the radio function in the setup wizard, it shows the selected radio
station. You can manually change the radio station by selecting the FM
frequency of another radio station.
Tip: Make sure to unwind the antenna fully and move it around until you
receive the best reception.
You can preset 5 radio stations. First, select a radio station by setting the the
FM frequency. Press and hold the double arrow button to automatically
search for the next radio station.
After setting a radio station, you can easily add another preset radio station
by selecting the toggle button. With this process, you can preset 5 radio
stations.
Set the preferred volume. To save the radio frequency, select the check
mark button.
*HF3653 does not feature a radio.
Music via Auxiliary (AUX) inlet
You can use the Sleep & Wake-Up Light as a speaker for music by
connecting a music playing device (for instance your mobile phone) to the
AUX inlet.
Note: You cannot wake up to music from a device connected to the AUX
inlet.
If the sound is not loud enough if you have set the Sleep & Wake-Up Light to
maximum volume, increase the volume of your music playing device.
If the sound is too loud or distorted if you have set the Sleep & Wake-Up
Light to low volume settings, decrease the volume of your music playing
device.
Note: Deactivate the sound by tapping the top of the appliance or by
pressing the music note button in the menu for 1 second.
Note: You need an AUX cable to connect the Sleep & Wake-Up Light to a
music playing device.
Wind-down programs
The appliance features two wind-down programs to help you relax before
you fall asleep.
14 English

Note: You can deactivate the active wind-down program by tapping the top
of the appliance.
Sunset Simulation
During the Sunset Simulation, the brightness of the light decreases gradually
with colors changing from bright yellow to warm orange to soft red. You can
set the duration and light intensity to start with.
During the Sunset Simulation you also can select a sound to fade away,
accompanying the Sunset Simulation. You can set the source and the
volume to start with. You can either choose a natural sound, radio* or no
sound. You can also play your own music by connecting a music playing
device to the AUX socket.
Note: If you have set your Sunset Simulation in the setup wizard, it will start
immediately. If you have not set the wake-up profile the Sleep & Wake-Up
Light starts with a default Sunset Simulation.
*HF3653 does not feature a radio.
RelaxBreathe
RelaxBreathe uses the belly breathing technique as a basis for the breathing
program. You can choose one of the breathing programs, guided by light or
sound. The combination of the belly breathing exercise and the guidance of
the Sleep & Wake-Up Light helps you slow down and feel relaxed.
Belly breathing for relaxation
Belly breathing is the most recognized breathing exercise technique to help
people relax. When you breathe from your belly, your diaphragm pulls down
automatically. This pulls down your lungs and allows you to inhale fully and
deeply.
Caution: If you feel uncomfortable at any point during this breathing
exercise, just go back to breathing normally.
How to do belly breathing
1Lie down comfortably on your back.
2Inhale through your nose, exhale through your nose or mouth.
15
English

3Place one hand on your stomach and your other hand on your chest.
You should see your hand on your stomach move up with each inhale
and move down with each exhale. The hand on your chest should only
move slightly.
4Your breath should only come from your belly. Try to make your exhale
longer than your inhale as this will quickly make you feel more relaxed.
Note: The RelaxBreathe function of the appliance can guide you during
belly breathing.
You can select one of seven relaxation programs with preset breathing
rhythms. Each relaxation program has a different breathing rhythm. The
program '4 breaths' is preset to 4 breaths per minute. Program '5 breaths' is
preset to 5 breaths per minute. Each next program has one additional
breath per minute. The last program (10 breaths) is preset to 10 breaths per
minute.
You can select light or sound to guide you during the selected relaxation
program. Follow the light or sound when you inhale and exhale.
-For guidance with light, inhale when the light intensity increases. In
between the two subtle light flashes, hold your breath. Exhale slowly
when the light intensity decreases.
-For guidance with sound, inhale when the intensity of the sound of the
waves increases. When the intensity of the sound pauses, hold your
breath. Slowly exhale when the intensity of the sound of the waves
decreases.
Follow your preferred rhythm with the help of light or sound for a more
relaxed feeling. You can even do this with your eyes closed.
Charging your mobile phone
You can use the USB port (see 'General description') to charge your
smartphone (max 1000 mA).
Cleaning and storage
-Clean the appliance with a soft cloth.
-Do not use abrasive cleaning agents, pads or cleaning solvents like
alcohol, acetone, etc., as this may damage the surface of the appliance.
-If you are not going to use the appliance for an extended period of time,
remove the adapter from the wall socket and store the appliance in a
safe, dry location where it will not be crushed, banged, or subject to
damage.
-Do not wrap the power cord around the appliance when storing it.
16 English

Recycling
-This symbol means that this product shall not be disposed of with normal
household waste (2012/19/EU).
-Follow your country's rules for the separate collection of electrical and
electronic products. Correct disposal helps prevent negative
consequences for the environment and human health.
Accessories and spare parts
-This appliance has no user-serviceable parts inside.
-The light source of this luminaire is not replaceable; when the light source
reaches its end of life the whole luminaire shall be replaced.
-To buy accessories or spare parts, visit www.philips.com/parts-and-
accessories or go to your Philips dealer. You can also contact the Philips
Consumer Care Center in your country (see the international warranty
leaflet for contact details).
The following accessories are available:
-Adapter HF20 EU-version: service code 4222 039 6746 1
-Adapter HF20 UK-version: service code 4222 039 6748 1
Warranty and support
If you need information or support, please visit www.philips.com/support or
read the international warranty leaflet.
Troubleshooting
This chapter summarizes the most common problems you could encounter
with the appliance. If you are unable to solve the problem with the
information below, visit www.philips.com/support for a list of frequently
asked questions or contact the Consumer Care Center in your country.
Problem Solution
The appliance does not
work at all.
Perhaps the adapter is not inserted properly in the wall socket. Insert the
adapter properly in the wall socket.
Perhaps the plug is not inserted properly in the appliance. Insert the plug
properly in the appliance.
Perhaps there is a power failure. Check if the power supply works by
connecting another appliance.
The appliance functions
properly, but the lamp
does not work anymore.
The appliance uses durable LED technology. The lamp should last a long
time. However, if the lamp stops working, go to www.philips.com/support
or contact the consumer care center.
17
English

Problem Solution
The appliance does not
respond when I try to
set different functions.
If you want to go back to factory settings, press the reset button on the
back of the appliance (see 'General description'). If you press the reset
button, the setup wizard needs to be set again.
The lamp does not go
on when the alarm goes
off.
Perhaps you set a light intensity level that is too low. Increase the light
intensity level in your wake-up profile (see 'Light intensity of the wake-up
profile').
Perhaps you turned off the alarm function. The alarm icon is visible on the
display when the alarm function is active (see 'Set wake-up profile').
The lamp does not go
on right away when I
switch it on.
It may take between 1 to 5 seconds for the lamp to switch on, depending on
the set light intensity level.
I do not hear the alarm
sound when the alarm
goes off.
Perhaps you set a sound level that is too low. To set a higher sound level,
increase the volume level of the wake-up sound in your wake-up profile
(see 'Setting wake-up profiles').
When you have set an alarm, you will first see the light of the wake up curve.
The alarm sound only starts playing when the set alarm time is reached. You
can change the duration of the wake up light curve (see 'Duration of the
wake-up profile').
Perhaps you turned off the alarm function. The alarm icon is visible on the
display when the alarm function is active.
If you selected the FM radio* as the alarm sound, turn on the FM radio*
after you turn off the alarm to check if the FM radio* works.
Check if your FM radio* is correctly tuned to a radio station. If necessary,
adjust the frequency. If it does not work, call 1-866-832-4361 for assistance.
The FM radio* does not
work.
Perhaps you set the volume too low. Increase the volume level.
Check if your FM radio* is correctly tuned to a radio station. If necessary,
adjust the frequency.
Change the position of the antenna by moving it around. Make sure you
have unwound the antenna completely.
Contact the consumer care center in your country.
The FM radio* produces
a crackling sound.
Perhaps the broadcast signal is weak. Adjust the frequency and/or change
the position of the antenna by moving it around. Make sure you have
unwound the antenna completely.
The alarm went off
yesterday, but it did not
go off today.
Perhaps you turned off the alarm function. The alarm icon is visible on the
display when the alarm function is active.
Perhaps you set a volume level and/or light intensity level that is too low.
Set a higher volume and/or light intensity level in your wake-up profile (see
'Setting wake-up profiles').
18 English

Problem Solution
When there has been a power failure, the clock time will keep on running up
to 8 hours. Perhaps the power failure lasted longer. In this case, you have to
set the clock time again.
I wanted to snooze, but
the alarm did not go off
again after 9 minutes.
Tap on the top of the Sleep and Wake-up light to snooze. If you press the
button to dismiss the alarm (see 'Set wake-up profile'), the alarm profile is
deactivated for that day.
The light wakes me too
early.
Perhaps the light intensity level you have set is not appropriate for you. Try
a lower light intensity level if you wake up too early. You can also change
the duration of the wake-up curve (see 'Setting wake-up profiles'). If light
intensity 1 is not low enough, move the appliance further away from the
bed.
The light wakes me too
late.
Perhaps the light intensity you have set is too low. Select a higher light
intensity (see 'Light intensity of the wake-up profile'). Perhaps the appliance
is positioned at a lower level than your head. Make sure the appliance is
located at a height at which the light is not blocked by your bed, comforter,
blanket or pillow. Also make sure the appliance is not placed too far away.
I am unable to turn the
Midnight Light function
on/ off.
Make sure you tap on the correct position (top/back) of the appliance.
I am unable to stream
music via USB.
The USB connection is only for charging your mobile phone. You are not
able to stream music to the Sleep & Wake-up light.
The aux inlet doesn't
work properly.
Try to set the volume on your mobile phone either higher or lower. If
necessary, adjust the volume level on the appliance as well.
The aux inlet doesn't
work properly.
Try to set the volume on your mobile phone either higher or lower. If
necessary, adjust the volume level on the appliance as well.
Suddenly the device
makes a beeping sound.
The backup alarm went off. This can happen up to 12 hours after you have
removed the power (adapter) and a set alarm time is due. The alarm sound
stops automatically after approximately 1 minute. You also can stop the
alarm sound immediately if you power up the device for a brief moment.
To prevent the back-up alarm to go off when the power is removed (e.g.
storage) just have the alarms disabled prior to powering down.
*HF3653 does not feature a radio.
Specifications
Model HF3650, HF3651, HF3653, HF3654
Rated input voltage adapter 100-240Vac
Rated input frequency adapter 50/60Hz
No-load power adapter <0.1W
Rated output voltage adapter 24Vdc
Rated output power adapter 18W
19
English

Average Standby Power appliance
Condition: (All functions suspended, ambient light
scenario; day 12h, 500 lux and night 12h, 0 lux)
display at maximum brightness setting / display
off
<0.5W / <0.25W
USB charging port 5V, 1000mA
AUX sensitivity 280mV
Nominal light output (level 1 - 25) 1 - 350 lux at 45cm (1 -350* lux at 17.7 in.)
depending on model
Nominal light color (level 1 - 25) 1500-2800K
Physical characteristics
Dimensions (height x width x Depth) 22.5 x 22.0 x 12.0cm (8.8 x 8.7 x 4.7in.)
Weight main unit / adapter Approx 0.77kg (27.2oz) / 0.14kg (4.9oz)
Cord length adapter 150cm (4.9ft)
Classification
Main unit Luminaires
Adapter Class 2 power supply
Mode of operation Continuous
Operating conditions
Temperature +5°C to +35°C (41°F to 95°F)
Relative humidity 15% to 90% (no condensation)
FM
Operating frequency 87.5 MHz - 108.0 MHz
Storage conditions
Temperature -20°C to +50°C (-4°F to +122°F)
Relative humidity 15% to 90% (no condensation)
20 English
