Before you start
Thank you for buying Philips GoPure
Car air purier. Before you install
GoPure in your car, take time to read
this guide.
The GoPure Car air purier will
help you protect your health by
improving the quality of the air you
breathe in your car. It is known that
air pollution levels inside cars are
often much higher than outside.
The GoPure Car air purier removes
harmful gases and ne particles
such as particulate matter, cigarette
tar, pet hairs, and microorganisms. It
also reduces bad odors to make the
time in your car more pleasant
and healthier.
Warranty and service
The Lumileds warranty applies, provided:
• The product is handled properly
for its intended use only.
• The product is used in accordance
with its operating instructions.
• You present the original invoice
with the product.
The Lumileds warranty does not
apply if the product is damaged due
to accident, error, or misuse.
For more information and
assistance, or if you have a problem
with the product, you can visit the
Philips website at
www.philips.com/automotive,
or contact the retail outlet where
you purchased the product.
Or for the users in China, please call the
customer service hotline:
400 690 8826
Lumileds (Shanghai) Management
Co., Ltd
No. 19-20, Lane 299, Wenshui Road,
JiangAn District, Shanghai
English

3
1 mImportant information
Environment
m Warning
Philips GoPure car air
purier device contains
high-precision technology.
Handle with care.
Do not drop or tamper!
m Important
Help to preserve the
environment. Do not
discard the device with
household waste. Bring
it to the ocial waste
recycling service near
by you. Filters may
be disposed of with
household waste.
c Danger
Do not clean or spill any
liquids such as water,
detergents, or ammable
solvents on the device.
m Warning
Keep Philips GoPure
car air purier free of any
obstruction. Do not cover!
m EN Important
To clean the GoPure car
air purier:
• Disconnect GoPure car
air purier
• Use soft cloth only.
m Warning
Philips GoPure car air
purier is not a toy!
Do not let children
play with it.
m Warning
For your safety, do not
manually operate the
device while driving.
Always stop your car rst!
Cautions:
• this appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved
• children shall not play with
the appliance
• cleaning and user
maintenance shall not be
done by the children
without supervision
• the appliance is only to be
used with the detachable
power supply provided
• must only be supplied at
SELV

4
Car air purier
Ӟᄟఛ࣮߈చ
GP9301
English 3
ࡩ฼ᇓ໗ 11
User Manual
䄡ᬻΓ
下ݖ⊓↪䒓⩌≨
Ⴥ󰪇ᓛԎڙф
Belt Power
adaptor
Quick
start guide
2 Product Introduction
2.1 Discover the content of Philips GoPure package
m Note
Make sure the device is
installed according
to the instructions in
this guide.
For your safety, please use the items
delivered in this package only
to install the device. In case of incorrect
installation, Lumileds declines
all responsibility for any harm or accident.
Air inlet
Air outlet
Power
cable port
Select Filter Plus x2
(Remove lter from
plastic wrapping)
Air quality
indicator
Open cover button
Control
button/display
interface
USB
charging port
Auto mode
Boost
Silent
Gas
level display
PM2.5
numerical
display

5
3Installing the GoPure car air purier
m Note
• For your safety, do not
attempt to operate the
purier manually while
driving.
• Please don’t put
device on car
dashboard or airbag.
• The belt may not be
suitable to all car
models.
Place the belt over the
device as shown, with
the furry surface facing
the device.
Recommended
installation location is
on the rear headrest
or rear window sill.
3.1
Press the “OPEN”
button, lift the top cover
and remove the lter’s
plastic wrapping.
3.2 Installing and
connecting the console
It is recommended to
hide the wiring in the car
by following the route
illustrated in the above
diagram - through the
carpet - seat edge - rear
headrest.
Connect the power
cable to the
device as shown.
Connect the power
adapter to a 12V outlet
in your car.
m Important
When using Phillips GoPure
car purier,
• Keep using car ventilation at
low speed.
• Keep car windows closed.
0
m Note
Please note the following
troubleshooting
instructions:
E1: The device is not
connected to
power cable.
E2: The top cover of the
device is not
properly closed.









6
4 Bluetooth connection
mWarning
• These instructions
apply only when the
GoPure car air purier is
connected the rst time
or the Bluetooth on the
smartphone has been
reset to factory settings.
• You cannot set up two
air puriers at the same
time. The only way to set
up multiple air puriers is
to repeat the procedure
for each machine.
• Please ensure a
distance of less than
5 meters without any
obstacle between the
smartphone and GoPure
car air purier. It is
recommended to set up
pairing in the car.
• “Air Matters” app
support above Andorid
5.0 and IOS 10.0 system,
older version system
may cause app function
failure. "Siri" function
support IOS12.0 and
above system.
1. Connect GoPure car
air purier to a power
source and turn on the
machine.
2. Turn on Bluetooth on
the mobile phone. For
an Android device, open
Settings app and turn
on Bluetooth. Look for
“GoPure” in the list of
devices. Click to initiate
pairing.
3. Scan the QR code
below to download and
install “Air Matters” app.
4. Open app. Click on
Connect an air purier
on the main page to
access a list of Philips
models. Refer to the app
instructions to add the
car air purier
“GoPure 9301”.
5. Return to the main
page and see “Philips
GoPure” has been
added. The app interface
will show “GoPure 9301”
and real-time PM1,
PM2.5, PM10 and Gas
concentration.
6. If you encounter
any problem, please
refer to Help or the
troubleshooting
information page for a
wide range of updated
troubleshooting tips.

7
5Using the GoPure car air purier
1. Press the control button to switch between the three modes:
Silent, Auto and Boost.
3. When turned o, power on the purier and it will start
running in Automatic mode.
The purier will turn on automatically once the car engine is started. The
default mode is the one used before the last shutdown.
2. When turned on, press and hold the control button for
2 seconds to shut down the purier.
Reminders:
1. The main unit’s AQI (Air Quality Indicator) shows a combination of PM2.5 and Gas
contamination levels. Air matters APP displays additional pollutants, PM1 and PM10.
2. Gas sensor can detect formaldehyde, toluene, VOC, cigarette smoke, ammonia etc.
3. Gas sensor initialization duration will be dierent according to dierent environment,
It may take 30 seconds to 3 minutes to display Gas level. Please do not turn o while waiting.
Understanding the GoPure Healthy Air Indicator
The Healthy Air Indicator will display your car’s air quality in real time.
Red
Red
>150 ug/m3
76-150 ug/m3
0-75 ug/m3
L3
L2
L1
Severe pollution
Moderate pollution
High concentration level
Medium concentration level
Low concentration level
Yellow
Yellow
Blue
Blue
Excellent
2S

8
6Filter replacement and reset
Philips GoPure car air
purication system is
a multi-layer ltration
system that guarantees
the most eective air-
purication. All lter
layers are integrated in
one simple-to-replace
lter.
6.1 Filter replacement
reminder
1. Philips GoPure car
air purier reminds you
automatically when lter
need to be replaced.
3. Remove the old lter
as shown.
4. Insert new original
GoPure lter. According
to the directions shown
above.
m Important
The lter slides in only
one way, do not force it in.
6.2 How to reset
GoPure car air
purier after a lter
replacement
m Important
You must reset the
Philips GoPure device
after every lter
replacement.
1. Open top cover, press
& hold the cigarette
lighter’s control button
for 5s until “ding ding”
sound. The lter reset is
completed.
2. Car air purier operates
in normal mode once
top cover is locked.
3. Repeat the above steps
if the lter reset fails.
m Important
For you safety, GoPure
car air purier will shut
down automatically
whenever you open
the top cover.
6.2 How to replace lter
1. Disconnect from
power source.
2. Push OPEN button,
take o top cover.
2. When the lter
need to be replaced,
the cigarette lighter
will display “FLt” and
device's AQI will alert in
yellow blinking light.
3. You can also enable
APP notication for
lter status monitoring.

9
Problem 1:
Philips GoPure car air
purier does not start.
Solution 1:
•Verify that the 12V pow-
er supply is on.
•Check the power con-
nection and make sure
the socket is properly
inserted.
•Make sure the top cover
is pushed down to lock
properly.
•Check whether there
is any error indicate on
cigar lighter’s UI. (E1: the
device is not connected
to power cable. E2: The
top cover of the device is
not properly closed.
Problem 2:
After lter replacement,
Philips GoPure displays
"FLt" or "E2".
Solution 2:
•Repeat the reset steps
section 6.3.
• Close top cover, the device
has been reset properly.
Problem 3:
Philips GoPure PM2.5 and
Gas value does not change
for a very long time.
Solution 3:
It may simply indicate
stable air quality. It may
also indicate that the air
intake slots are obstruct-
ed or polluted.
•Make sure the air circu-
lation around the device
is free.
•Restart the device. If
the problem remains,
please contact your retailer.
Problem 4:
Philips GoPure PM2.5
and Gas value changes
frequently.
Solution 4:
This is normal and the
device is working prop-
erly. When the air quality
is poor, the device per-
forms its cleaning pro-
cess. However, the PM2.5
and Gas value reects
the air quality near the
device. A times, this may
bring a frequent PM2.5
or Gas value change. Let
the GoPure car air purier
perform its cleaning
process. When the air
reaches good quality, the
PM2.5 and Gas will turn
normal as described.
Problem 5:
Philips GoPure Air
Quality Indicator shows a
blue light, but some odor
remains in the car.
Solution 5:
There are multi-factors
impact odor in the car,
GoPure car air purier
applies HESA technology,
highly ecient in elim-
inating harmful gases,
including formaldehyde,
Toluene, TVOC, vehicle
exhausts, ammonia, etc.
Philips GoPure car air pu-
rier continuously purify
the air, however, some
odor in cars may emit
continuously. Suggest
remove pollution source
or select boost mode to
accelerate purify speed.
Problem 6:
App on smartphone fails
to connect the GoPure
car air purier.
Solution 6:
Make sure GoPure car air
purier is connected to
power source, and the dis-
tance between the device
and the smart phone must
be less than 5m.
Problem 7:
Which gas can be de-
tected by Philips GoPure
car air purier.
Solution 7:
Philips GoPure car air
purier could detect
VOCs like ammonia,
hydrogen, alcohol, meth-
ane, propane, gansu
alkanes, propanediol,
phenol, toluene, pheny-
lethane, xylol, formal-
dehyde etc. And smoke
from cigarette burning
from wood, paper, etc.
Problem 8:
Philips Go Pure car air
purier Gas value does
not display after device
power on.
Solution 8:
Gas sensor initialization
duration will be dierent
according to dierent
environment, It may take
30 seconds to 3 minutes
to display Gas level.
Please do not turn o
while waiting.
Problem 9:
Philips GoPure car air
purier is noisy.
Solution 9:
Philips GoPure car air
purier has 3 speed
settings: boost, auto and
silent mode. At boost
mode, the motor will
be set to high speed to
accelerate purication.
You can set speed to
auto mode, GoPure car
air purier will adjust mo-
tor speed automatically
according to pollution
level, motor speed and
sound will be reduced
automatically when the
air quality is good.
7Philips GoPure car air purier troubleshooting

10
简体中文
开始使用前
感谢您购买飞利浦怡动车载空气净化
器。在车内安装怡动净化器之前，请花
一点时间阅读本使用说明。
众所周知，车内空气污染程度往往高
于外界空气。透过飞利浦怡动车载空
气净化器改善车内空气质量，保护您
的健康。
怡动车载空气净化器可以去除诸如粉尘，
烟灰，毛发及有害气体。同时减少异味，
伴您更愉快健康地度过车内时光。
保修和服务
亮锐保修适用范围：
• 产品严格按照指定用途操作；
• 产品依照使用说明使用；
• 出示产品原始发票。
亮锐保修不适用于事故、失误或使用不
当引起的产品损坏。
欲知详情和指导，或对产品有疑问，
请访问飞利浦网站：
www.philips.com/automotive，
亦可联系向您出售产品的零售商。
或致电客户服务热线：
400 690 8826
亮锐（上海）管理有限公司
上海市静安区汶水路299弄19-20号
邮编: 200072

11
1 m 重要事项
环保
m 小心跌落
飞利浦怡动车载空气净化
器使用了精密零部件，
跌落可能导致损坏!
m 重要事项
为环保尽一份力。切勿将
净化器同生活垃圾一起丢
弃。将净化器带到附近的
官方垃圾回收中心。过滤
网则属于生活垃圾一类。
c 危险
切勿用液体清洗或泼洒净
化器，如水、洗涤剂或易
燃溶剂。
m 注意
保持飞利浦怡动车载空气
净化器周围畅通无阻。
切勿覆盖！
m 重要事项
清洁飞利浦怡动车载空气
净化器：
•将怡动车载空气净
化器同电源断开。
•仅使用柔软抹布擦拭。
m 注意
飞利浦怡动车载空气净化
器不是玩具！
切勿给儿童把玩。
m 注意
为了您的安全，切勿在驾
车时调节净化器以及使用
智能手机应用程式查看与
控制净化器。
请先停车！

Car air purier
Ӟᄟఛ࣮߈చ
GP9301
English 3
ࡩ฼ᇓ໗ 11
User Manual
䄡ᬻΓ
下ݖ⊓↪䒓⩌≨
Ⴥ󰪇ᓛԎڙф
安全
系带 点烟器
电源线
快速说明书
12
2 产品简介
m 注意
为了您的安全，请依照使用说明安装
净化器。
2.1 熟悉飞利浦怡动车载空气净化器盒内配件
进 风 口
出风口
电源线口
高效过滤网x2
(使用前需拆封)
空 气 质 量 指 示 灯
开盖按键
控制按键/
显示界面
USB
充电口
自动模式
劲速
静音
Gas
等级显示
PM2.5
数值显示
为了您的安全，请只使用本包装盒内的
配件安装净化器。
亮锐不承担任何因安装不当而引起的损
害或事故责任。

13
m 注意
• 为了您的安全，行车时
切勿试图手动操作净
化器。
• 请勿将净化器放在汽车
仪表盘和安全气囊上。
• 安装绑带不一 定适合所
有车型。
3 安装GoPure车载空气净化器
使用安装绑带，绒毛面朝
向净化器。
建议安装在后排头枕或后
窗台 。
3.1
按开盖按键，打开上
盖，拆除滤网塑料包装。
3.2
安装和连接控制端
建议车内隐藏走线方式,
建议按照上图方式经地毯-
座椅边沿-后排头枕走线 。
将净化器连上电源线。
在车内将点烟器插头连
上12伏电源插座。
m 重要事项
使用飞利浦怡动净化器时：
• 保持车内低风速水平
• 保持车窗关闭。
0
m 注意
故障提示参考如下解决：
E1: 净化器主机未连接
电源。
E2: 净化器上盖未盖好。









14
m 注意
• 仅在首次设置空气净化
器时或智能手机蓝牙设置
已执行出厂重置后，此说
明才有效。
• 您不能同时设置两个空
气净化器。
• 确保智能手机与空气净
化器之间的距离小于 5
米，且中间没有任何障
碍物。建议在车内进行
配置。
• “在意空气”应用程
序支持Android 5.0及以
上，IOS 10.0 及以上系
统版本，过旧版本系统
可能无法完整使用其所
有功能。“Siri”功能支
持IOS12.0及以上系统
版本。
1. 将空气净化器通
电，并
启动使其工作。
2. 打开手机蓝牙连接
功能。
3 扫描下图中的二维码下
载并安装“在意空气”
应用程序。
4. 启动该应用程序，在
主页面点击连接净化器进
入飞利浦品牌菜单，参照
应用程序说明添加型号
为“GoPure 9301”的车载
空气净化器 。
5. 返回应用程式主页面，
可见“Philips GoPure”已
添加。卡片显示
“GoPure 9301”型号和实
时PM1、PM2.5、PM10和
Gas浓度数值。
6. 如果情况并非如此，
请参阅疑难解答页或应用
程序中的帮助部分，以获
得广泛和最新的故障排除
技巧。
4 首次设置手机应用程序(APP)

15
5 使用GoPure车载空气净化器
1. 按控制按键， 切换净化三种模式，静音，自动和劲速。
3.
关机状态下 ， 可手动按键开机 ， 默认运行在上次关机前模式。
启动汽车引擎，净化器将自动开机，默认运行在上次关机前模式。
2. 开机状态下，长按控制按键2秒，净化器将关机。
提示:
1. 主机AQI空气指示灯综合显示PM2.5和Gas气体污染程度，“在意空气”APP中还可以显示
PM1和PM10浓度。
2. 气体传感器可探测以下气体：甲醛、甲苯、有机挥发气体、香烟、氨气等。
3.
气体传感器初始化根据环境不同，需要不同时长，可能需要等待 30 秒至 3 分钟显示 Gas 浓度等级。
2S
理解怡动健康空气指示灯
点烟器显示界面空气指示灯将实时显示您车内的空气质量 。
红色
红色
>150 ug/m3
76-150 ug/m3
0-75 ug/m3
L3
L2
L1
PM2.5严重污染
PM2.5中度污染
Gas浓度等级高
Gas浓度等级中
Gas浓度等级低
黄色
黄色
蓝色
蓝色
PM2.5优

16
6 过滤网的更换及重置
3.
如图示取下过滤网。
4. 对齐前端的沟槽，插入
新的替换过滤网。
m 重要事项
过滤网只能单向滑入，切
勿强行安装。参见上图
6.3 如何在更换过滤网
后重置净化器
m 重要事项
每次更换过滤网之后，您
必须重置飞利浦怡动车载
净化器。
1. 顶盖打开状态下，长按
点烟器显示屏5秒直到听
到“叮叮”两声松开按
键，滤网清零重置成功。
2. 扣上顶盖，车载空气
净化器即恢复正常工作状
态。
3. 若滤网重置失败，请重
复以上操作。
m 重要事项
为了安全起见，当打开顶
盖时，怡动净化器将自动
关闭。
飞利浦怡动车载空气净化
系统由多层过滤网组成，
确保最佳空气净化质量。
所有过滤网均装配在同
一个可简便更换的过滤
器内。
1. 飞利浦怡动车载空气净
化器自动提醒您更换过
滤网。
m 重要事项
请务必使用正品飞利浦怡
动净化器过滤网做及时更
换，这将维持您的怡动车
载空气净化器的最佳性
能，确保车内空气最大纯
净度。
6.2 如何更换过滤网
6.1 过滤网更换提醒
1. 将飞利浦怡动车载空气
净化器设备同电源断开。
2. 如图示按压开盖按键，
取下顶盖。
2. 当需要更换滤网时，每
次开机时，点烟器显示屏
会显示“FLt”，同时主
机黄灯会闪烁。
3. 在意空气APP显示“
滤网寿命已耗尽，请立刻
更换”。

17
问题 1
无法启动飞利浦怡动车载
净化器。
解答 1
•确认已连接12V电源
•检 查 电 源 线 ，确 保 插 座 已
插紧。
•确保已正常关闭顶盖。
•确认点烟器显示屏上是
否有故障显示。
（E1: 净化器主机未连接
电源。E2:净化器上盖未
盖 好）
•再次按点烟器显示屏，
如果仍然不能启动机器，
请联系零售商。
问题 2
更 换 过 滤 网 后 ，点 烟 器
显示屏仍然显示“FLt”
或 “ E 2 ”。
解答 2
•重复章节6.3上的重置
步骤。
•盖上顶盖，净化器成功重
置并正常运行。
问题 3
飞利浦怡动净化器点烟
器 AQI 显示PM2.5和Gas
没有变化。
解答 3
可能表示空气质量稳定。
可能表示空气通风口堵塞
或遭污染。
•确保空气净化器周围空
气畅通。
•重启净化器，观察问题是
否 仍 然 存 在 ，如 果 AQI
数字仍然长时间没有变
化，请联系零售商。
问题 4
飞利浦怡动净化器点烟器
AQI 显示PM2.5和Gas频
繁变化。
解答 4
正 常 现 象 ，净 化 器 运 转 正
常 。当 空 气 质 量 不 佳 时 ，
净化器会循序渐进的完成
其 净 化 功 能 。尽 管 如 此 ，
如果空气中的粉尘或Gas
气 体 分 布 不 均 ，这 可 能 会
引起点烟器显示PM2.5和
Gas频 繁 变 化 。这 意 味 着
净化器运转正常，请让它
完成其净化功能。
问题 5
飞利浦怡动车载净化器
已运转了较长一段时间，
但我的车内仍然有异味。
解答 5
车内的异味归咎于多种
因 素 。怡 动 净 化 器 采 用
HESA技术高效选择性吸
附有害气体和气味，如甲
醛 、甲 苯 、TVOC、汽 车 尾
气、氨气等。车内也可能
有不断产生异味的污染
源，建议清除污染源或启
动劲速模式加快净化。
问题 6
智能手机应用程式无法连
接净化器。
解答 6
确保净化器电源已连接
并 正 常 供 电 ，设 备 与 智 能
手机距离小于5米。
问题 7
飞利浦怡动车载净化器
Gas可以检测哪些气体。
解答 7
飞利浦怡动车载净化器
Gas传感器能检测氨气、
氢 气 、酒 精 、一 氧 化 碳 、甲
烷、丙烷、甘烷、丙二醇、
酚、甲苯、乙苯、二甲苯、甲
醛 等 有 机 挥 发 气 体 、香 烟 、
木材、纸张燃烧烟雾等。
问题 8
开机后，飞利浦怡动净化
器的Gas数值一直没有
显示。
解答 8
气体传感器初始化根据车
内环境不同，需要不同时
长，为能更准确的检测空
气质量，可能需要等待30
秒至3分钟显示Gas浓度
等 级 ，请 耐 心 等 待 。
问题 9
为什么怡动净化器声音
很大。
解答 9
怡动车载净化器有劲速，
自动和静音模式。在劲速
模式下，风机转速最大以
提供最快净化速度， 此
时，产品运行声音略高。
自动净化模式会根据环
境污染浓度自动调整风
速，当空气良好时净化速
度和噪音会自动降低。
7 飞利浦怡动车载空气净化器疑难解答

3211 008 23491
Lumileds is the warrantor of this product.
Philips and the Philips Shield Emblem are regis-
tered trademarks of Koninklijke Philips N.V. and
are used under license.
2019 © Lumileds Holding B.V. All rights reserved.
亮锐(Lumileds)为此产品提供质保。
飞利浦(Philips)以及飞利浦盾牌为皇家飞利浦有限公司
(Koninklijke Philips N.V.)的注册商标，
皇家飞利浦有限公司许可亮锐使用。
2019 © 亮锐公司(Lumileds Holding B.V.)版权所有。
保留所有权利。
