Philips CED110 User manual

www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
CED110
Question?
Contact
Philips

1EN
Contents
1 Safety 2
2 Your car entertainment system 3
Introduction 3
What's in the box 3
Overview of the main unit 5
Overview of the remote control 7
3 Install the car entertainment system 9
Connect wires 9
Mount into the dashboard 10
Attach the front panel 11
4 Get started 13
Prepare the remote control 13
For the rst time use 13
Set the time format 13
Set the clock 14
Select a source 14
Select a listening zone 14
Set for video playback 14
5 Play from hard media 16
Load a disc 16
Connect a USB storage device 16
Control play 17
Browse recorded les 18
Use the GOTO function 18
6 Listen to radio 19
Select a tuner region 19
Select a tuner sensitivity 19
Search for a radio station 19
Store radio stations in memory 19
7 Listen to an external device 21
8 Adjust sound 22
General 22
Customize your sound equalizer 22
9 Adjust system settings 23
10 Adjust AV output settings 24
11 Others 27
Reset the system 27
Replace the fuse 27
12 Product information 28
General 28
Disc player 28
Radio 28
13 Troubleshooting 29
14 Notice 30
Compliance 30
Care of the environment 30
Trademark notice 30
Copyright 31
Contents

2EN
1 Safety
Read and understand all instructions before you
use the device. If damage is caused by failure to
follow instructions, the warranty does not apply.
• Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
• The device is designed for negative ground
(earth) 12 V DC operation only.
• To reduce the risk of trafc accidents, do
not watch video when driving.
• To ensure safe driving, adjust the volume to
a safe and comfortable level.
• Improper fuses can cause damage or
re. When you need to change the fuse,
consult a professional.
• Use only the supplied mounting hardware
for a safe and secure installation.
• To avoid short circuits, do not expose the
device, remote control or remote control
batteries to rain or water.
• The device shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on
the device (e.g. liquid lled objects, lighted
candles).
• Never insert objects into the ventilation
slots or other openings on the device.
• Never place any objects other than discs
into the disc tray/slot.
• To avoid exposure to laser radiation, do
not disassemble the device.
• Never use solvents such as benzene,
thinner, cleaners available commercially, or
anti-static sprays intended for discs.
• Clean the device with soft, damp cloth.
Never use substances such as alcohol,
chemicals or household cleaners on the
device.
• Risk of swallowing coin battery!
• The product/remote control may
contain a coin/button type battery,
which can be swallowed. Keep the
battery out of reach of children at all
times! If swallowed, the battery can
cause serious injury or death. Severe
internal burns can occur within two
hours of ingestion.
• If you suspect that a battery has been
swallowed or placed inside any part
of the body, seek immediate medical
attention.
• When you change the batteries, always
keep all new and used batteries out
of reach of children. Ensure that the
battery compartment is completely
secure after you replace the battery.
• If the battery compartment cannot be
completely secured, discontinue use
of the product. Keep out of reach of
children and contact the manufacturer.

3EN
2 Your car
entertainment
system
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With the car entertainment system, you can
• listen to music,
• watch videos,
• view .JPEG pictures, and
• listen to FM and AM/MW radio.
Playable media
• Disc
• DVD,Video CD, SVCD, Audio CD,
JPEG Picture CD, MP3-CD,WMA-CD
• DVD-R, DVD-RW, DVD+R, DVD+RW,
CD-R, CD-RW
• USB storage device
• Compatibility: USB 2.0, USB 1.1
• Class support: MSC (Mass Storage
Class)
• Maximum capacity: 32 GB
• Files
• File system: FAT16, FAT32
• Maximum number of folders: 99
• Maximum number of tracks/les: 999
• Maximum level of directory: 8
• Video formats: MPEG1, MPEG2
• Picture format: .jpeg
• .mp3 les
Sampling frequencies: 32 kHz, 44.1 kHz,
48 kHz
Bitrates: 8-320 kbps and variable
bitrates
• .wma les
Versions: V4, V7, V8, V9 (L1 and L2)
Sampling frequencies: 44.1 kHz, 48 kHz
Bitrates: 64-192 kbps and variable
bitrates
• ID3 tag V2.0 or later
• Unsupported les:
AAC, WAV, and PCM les
DRM protected WMA les (.wav, .m4a,
.m4p, .mp4, and .aac)
WMA les in lossless format
What's in the box
Check and identify the contents of the package:
a Main unit (with a sleeve)
b Remote control
c Front panel
d Trim plate
ab
cde
fg h
ij

4EN
e Carrying case for the front panel
f ISO male connectors
g Rubber cushion
h Screw
i Disassembly tools
j User manual

5EN
Overview of the main unit
a /
• Tune to a radio station.
• Press to skip to the previous/next
chapter, title, track, or le.
• Press and hold to rewind a chapter/
title/track or search forward fast.
b BAND
• Press to return to radio mode.
• Press repeatedly to select a tuner band.
o up iw v
gf h a dc
b
yx
n mst r q l jk
e
c
• For recorded les, press to select the
previous folder.
• Press and hold to access the system
menu.
• Press to select a tuner band.
d
• Press to power on the system.
• Press and hold to power off the
system.

6EN
• Press to mute the speakers or release
them from mute status.
• Press to conrm an option.
• Rotate to switch between menu
options.
• Rotate to adjust the volume level.
e
• Return to the previous menu or exit.
f iR sensor
g
• Eject the disc.
h
• Connect to a USB storage device.
i AUDIO IN
• Connect to the audio output socket
(usually the headphone socket) of an
external device.
j /AS
• Press to display the set clock.
• In radio mode, press and hold to
activate the automatic search for radio
stations.
k R/L/
• Press repeatedly to select an available
audio language or audio channel.
• Press and hold to stop play.
l
• In radio mode, press to select the
preset radio station of No. 6.
• In radio mode, press and hold to store
the current radio station at channel
No. 6.
• Enable or disable the shufe play.
m
• In radio mode, press to select the
preset radio station of No. 5.
• In radio mode, press and hold to store
the current radio station at channel
No. 5.
• Press repeatedly to select a repeat
mode.
n
• Start, pause, or resume the play.
• In radio mode, press to select the
preset radio station of No. 4.
• In radio mode, press and hold to store
the current radio station at channel
No. 4.
o
• In radio mode, press to select the
preset radio station of No. 3.
• In radio mode, press and hold to store
the current radio station at channel
No. 3.
• For recorded les, press to access the
list of folders that contain compatible
video les.
p
• In radio mode, press to select the
preset radio station of No. 2.
• In radio mode, press and hold to store
the current radio station at channel
No. 2.
• For recorded les, press to access the
list of folders that contain compatible
picture les.
q
• In radio mode, press to select the
preset radio station of No. 1.
• In radio mode, press and hold to store
the current radio station at channel
No. 1.
• For recorded les, press to access the
list of folders that contain compatible
audio les.
r DISP
• Press repeatedly to display available
information about the current track.
s SOURCE
• Press repeatedly to select a source.
t
• Press repeatedly to select a preset
sound equalizer.
• Press and hold to activate the setup of
customized sound equalizer.

7EN
u
• For recorded les, press to select the
next folder.
• Press and hold to activate the selection
of listening zones.
• Press to select a tuner band.
v
• Unlock the front panel.
w
• Press to enable or disable the MAX
Sound effect.
• Press and hold to enable or disable
the DBB (dynamic bass boost) sound
effect.
x RESET
• Press to reset the system to factory
default settings.
y Disc compartment
Overview of the remote
control
a /
• Skip to the previous or next track,
chapter, or le.
• Navigate through on-screen menus.
b
• Press to power on the system.
• Press and hold to power off the
system.
c MENU
• Access or exit the system menu.
d VOLUME + / -
• Press to increase or decrease the
volume.
e DBB
• Enable or disable the DBB (Dynamic
Bass Boost) sound effect.
f
• Enable or disable the MAX Sound
effect.
a
b
c
d
e
f
g
h
i
jk
l
m
n
o
p
q
r
s
t
u
v
w
x
y
z

8EN
g EQ
• Press repeatedly to select a preset
sound equalizer.
h Numeric buttons
• Enter numbers.
i GOTO
• Skip to a chapter/title/track/le or a
point of a video/audio directly.
j SETUP
• Access or exit the menu for audio and
video output settings.
k ZOOM
• Zoom in or out of the picture.
l ANGLE
• Select an available picture viewing
angle.
m
• Select an available subtitle.
n TOP MENU
• Return to or exit the top menu.
o DVD AUDIO
• Select an audio language or audio
channel.
p DVD MENU
• Access or exit the DVD menu of a
DVD disc.
q
• Press to display the set clock.
r DISP
• Press repeatedly to display available
information about the current track.
s ZONE
• Select a music listening zone.
t BAND
• Press to return to radio mode.
• Press repeatedly to select a tuner band.
u /
• Tune to a radio station.
• Press to skip to the previous/next
track.
• Press and hold to rewind a chapter/
title/track or search forward fast.
v
• Start, pause, or resume the play.
w /
• Skip to the previous or next track,
chapter, or le.
• Navigate through on-screen menus.
x
• Return to the previous menu or exit.
y OK
• Conrm an option.
z
• Press to mute the speakers or release
them from mute status.
{SOURCE
• Press repeatedly to select a source.

9EN
3 Install the car
entertainment
system
Always follow the instructions in this chapter in
sequence.
These instructions are for a typical installation.
However, if your car has different requirements,
make the adjustment accordingly. If you have
any question regarding installation kits, consult
your local retailer.
Note
•This system is designed for negative ground (earth) 12V
DC operation only.
•Always install this system in the car dashboard. Other
locations can be dangerous as the rear of the system
heats up during use.
•To avoid short-circuit: before you connect, make sure
that the ignition is off.
•Make sure that you connect the yellow and red power
supply leads after all other leads are connected.
•Make sure that all loose leads are insulated with
electrical tape.
•Make sure that the leads do not get caught under
screws iron parts that will move (e.g. seat rail).
•Make sure that all ground (earth) leads are run to a
common ground (earth) point.
•Use only the supplied mounting hardware for a safe
and secure installation.
•Improper fuses can cause damage or re. When you
need to change the fuse, consult a professional.
•When you connect other devices to this system, make
sure that the rating of the car circuit is higher than the
total fuse value of all the connected devices.
•Never connect speaker wires to the metal body or
chassis of the car.
•Never connect speaker wires with stripes to one
another.
Connect wires
Note
•To enjoy video on an external screen, make sure that
you have correctly connected the system to the screen
as indicated below in step 2.
•Make sure that all loose leads are insulated with
electrical tape.
•Consult a professional to connect wires as instructed
below.
1 Check the car's wiring carefully and
connect them to the the ISO male
connectors.
ISO male
connectors
Connect to
a Green strip, black-
edged green strip
Rear left speaker
b White strip, black-
edged white strip
Front left speaker
c Gray strip, black-
edged gray strip
Front right speaker
d Purple strip, black-
edged purple strip
Rear right speaker
e Red strip Ignition key +12V
DC when ON/
ACC
f Blue strip Motor/electric
antenna relay
control lead

10 EN
ISO male
connectors
Connect to
g White-edged blue
strip
Amplier relay
control lead
h Black strip Ground
i Yellow strip To the +12V car
battery which is
energized at all
times
2 Connect the ISO male connectors and
other wires to the rear panel of the main
unit if necessary.
Sockets or
connectors on rear
panel
External sockets or
connectors
1SUB-W
(Blue socket)
As indicated above
2REAR L
(White socket)
Rear left speaker
3REAR R
(Red socket)
Rear right speaker
4VIDEO
(Yellow socket)
Video input socket
of external screen
L
ab cd
e
f
g
i
h
j
5 Sockets for ISO
male connectors
As indicated in step
1 above
6 Antenna socket Radio antenna
7OE REMOTE
(Purple strip)
OE remote
8VIDEO IN
(Yellow connector)
Video output socket
of an external video
player
9AUDIO IN L
(White connector)
Left audio channel
output socket of an
external video player
10 AUDIO IN R
(Red connector)
Right audio channel
output socket of an
external video player
Tip
•The pin arrangement for the ISO connectors depends
on the type of your vehicle.To avoid damage to the
unit, connect properly.
Mount into the dashboard
• If the car does not have an on-board drive
or navigation computer, disconnect the
negative terminal of the car battery.
• If the car battery is not disconnected, to
avoid short-circuit, make sure that the bare
wires do not touch each other.
1 Make sure that the car dashboard opening
is within these measurements.
178mm
50 mm
5mm

11EN
2 Remove the mounting sleeve with the
supplied disassembly tools.
3 Install the sleeve into the dashboard and
bend the tabs outward to x the sleeve.
Note
•If the unit is not xed by sleeve but by the supplied
screw, skip this step.
4 Slide the unit into the dashboard until you
hear a "click".
183 mm
53.5 mm
5 Attach the trim plate.
6 Reconnect the negative terminal of the car
battery.
Attach the front panel
1 Insert the notch on the front panel to the
chassis on the main unit.
2 Press the left end of the front panel
inwards until it is securely locked with a
"click".

12 EN
Detach the front panel
Note
•Before you reset the system, detach the front panel.
•Before you detach the front panel, make sure that the
system is powered off.
1 Press to release the front panel.
2 Pull the front panel outwards to remove it.

13EN
4 Get started
Caution
•Risk of car accidents! Never watch video or operate
this system while driving.
Prepare the remote control
For the rst time use
Pull the protective sheet out.
» The remote control is ready for use.
Replace the battery
Caution
•Risk of explosion! Keep batteries away from heat,
sunshine or re. Never discard batteries in re.
Note
•Remove the battery if it is exhausted or if the remote
control is not to be used for a long time.
•Batteries contain chemical substances, they should be
disposed of properly.
•Perchlorate Material - special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
1 Pull out the battery tray.
2 Insert one CR2025 battery with correct
polarity (+/-) as indicated.
3 Insert the battery tray.
For the rst time use
1 Press to power on the system.
» [WELCOME] (Welcome) is displayed
and then [SELECT OPERATING
REGION] (select a radio region)
scrolls.
2 When one of the following options is
displayed, rotate to select a radio
region that matches your location.
• [AREA LAT] (Latin America)
• [AREA USA] (United States)
• [AREA EUR] (Western Europe)
• [AREA RUS] (Russia)
• [AREA EAS] (Middle East)
• [AREA ASI] (Asia Pacic)
• [AREA JAP] (Japan)
• [AREA AUS] (Australia)
3 Press to conrm.
» The system switches to radio mode
automatically.
• To power off the system, press and
hold until the screen backlight
is off.
Set the time format
1 Press and hold to access the system
menu.
2 Press / repeatedly until
[CLK FORMAT] is displayed.
3 Rotate to select [CLK 24H] or
[CLK 12H].
• [CLK 24H]: 24-hour time format
• [CLK 12H]: 12-hour time format

14 EN
Set the clock
1 Press and hold to access the system
menu.
2 Press / repeatedly until [CLK] is
displayed with time digits blinking.
3 Rotate anti-clockwise to set the hour.
4 Rotate clockwise to set the minute.
Display the clock
Press /AS.
» The set clock is displayed.
• To exit the clock display, press /AS
again or rotate .
Select a source
Press SOURCE repeatedly to select a source.
• [RADIO]: Listen to FM/AM radio.
• [AUDIO IN]: Listen to the audio input
through the AUDIO IN socket.
• [AV IN]:The audio and video input that is
transferred from an external video player
• [USB]:When a USB storage device is
connected and recognized, you can select
this source to play compatible les that are
stored on it.
• [DVD]/[DISC]:When a compatible disc is
inserted and recognized, you can select this
source to play the disc.
Select a listening zone
1 Press and hold until one of the
following options is displayed.
• [ALL]: For all passengers
• [FRONT-L]: For the front-left seat only
• [FRONT-R]: For the front-right seat
only
• [FRONT]: For front passengers only
2 Press / repeatedly to select a
listening zone.
Set for video playback
If video image is abnormally displayed on the
connect external screen, check the video
connection and make the following setup.
Note
•Make sure that a compatible video disc is inserted and
the source is selected as [DVD]/[DISC].
•Make sure that the video input channel of the external
screen is set to the one for this system.
Set the color system
1 Press SETUP to access the menus for
audio and video output settings.
2 Press / to select [TV SYSTEM] (TV
system), and then press OK to display the
lower level options.
3 Press / to select an option and then
press OK.
• [NTSC]: For a screen with NTSC
color system.
• [PAL60]: For a screen with PAL60
color system.
• [PAL]: For a screen with PAL color
system.
• [AUTO] (Auto): For a screen that
is compatible with PAL, PAL60, and
NTSC.
4 Press SETUP to exit the menus.
TV S YS TE M
VIDEO
TV T YP E
PASS WORD
RATING
DEFAULT

15EN
Set the languages for on-screen items
1 Press SETUP to access the menus for
audio and video output settings.
2 Press / repeatedly until the following
tab is displayed.
3 Press / to select [OSD
LANGUAGE] (on-screen display
language)/[MENU LANG] (menu
language), and then press OK to display
the lower level options.
• [OSD LANGUAGE] (on-screen
display language): Select a language for
on-screen menus.
• [MENU LANG] (menu language):
Select a language for disc menu.
4 Press / to select an option and then
press OK.
5 Press SETUP to exit the menus.
TV S YS TE M
VIDEO
TV T YP E
PASS WORD
RATING
DEFAULT
OSD LANGUAGE
AUDIO LANG
SUBTITLE LANG
MENU LANG

16 EN
5 Play from hard
media
You can use this system to listen to audio, watch
videos, and view photos that are stored on a
compatible disc or USB storage device.
Note
•Before use, check for compatible media.
Load a disc
Caution
•Never insert any object other than a disc of 12 cm
diameter into the disc slot.
1 Insert the disc into the disc slot with the
label side facing up.
» Play starts automatically.
• If play does not start automatically,
press to start play.
2 To eject the disc, press .
» When the disc is ejected, the system
switches to the previous source or
radio mode.
Region Code
You can play DVD discs marked with the
following region code.
DVD region code Countries
Latin America
Connect a USB storage
device
Note
•Make sure that the USB storage device contains
compatible les.
•NTFS (New Technology File System) le system is not
supported.
1 Push the USB socket cover upwards to
open it.
2 Connect the USB storage device to the
USB socket.
» Play starts automatically.
• If play does not start automatically,
press to start play.
• To remove the USB storage device,
switch the system to another source
rst.

17EN
Control play
Basic control
The following operations are applicable to all
compatible media.
Buttons Functions
/ Start, pause, or resume play.
R/L/ Press and hold it to stop play.You
can press / to resume
the play from the stop point.
• For an audio or video, press and
hold it again to end the play.
/ Press to start the previous or next
chapter, title, track, or le.
Select an available repeat mode.
• [REP ALL]: Repeat all tracks or
les.
• [RPT TRK]: Repeat the current
track or le.
• [RPT FLD]: Repeat all tracks
or les in the current folder or
album.
• [REP CHAPT]: Repeat the cur-
rent chapter of a DVD.
• [REP TITLE]: Repeat the cur-
rent title of a DVD.
• [REP OFF]: Play all chapters or
titles of a DVD in sequence.
• [SHUF ALL]: Play all tracks or
les randomly.
• [SHUF OFF]: Play all tracks or
les in sequence.
Numeric
buttons
on the
remote
control
Enter the number of a chapter,
title, track, or le to start it.
Audios
Buttons Functions
/ Press and hold to rewind a track
or search forward fast.
• To play the track at normal
speed, press or .
Pictures
Buttons Functions
/ Rotate the picture by 180°.
/ Rotate the picture by 90°.
ZOOM Press repeatedly to zoom in or out
of the picture.
• To pan through an enlarged pic-
ture, press / / / .
Videos
Buttons Functions
/ Select a speed to rewind a
track/title/chapter or search
forward fast.
1Press and hold it until
[BACKWARD] (backward)
or [FORWARD] (forward) is
displayed.
2Repeat step 1 to select a
speed (X 2, X 4, X 8, or X
20).
• To play at normal speed,
press or .
ZOOM Press repeatedly to zoom in or
out of the image.
• To pan through an enlarged
image, press / / / .
ANGLE When picture viewing angles
are available, press repeatedly to
select one.
When subtitles are available,
press repeatedly to select one.
DVD
AUDIO
Press repeatedly to select an
audio language for a DVD.

18 EN
Buttons Functions
DVD
MENU/TOP
MENU
Press to access the DVD menu
or top menu of a DVD.
• To toggle through the menu
options, press / / / .
• To conrm an option, press
OK.
Browse recorded les
During playing recorded les, you can access
the le list and select les from the list.
1 Press , , or to access the list
of les or folders.
• : Music les or folders
• : Picture les or folders
• : Video les or folders
» [MUSIC], [IMAGE], or [VIDEO] is
displayed.
2 Press / on the main unit or /
on the remote control to select a folder.
» The folder name is displayed.
3 Press on the main unit or OK to
access the list of les under the folder.
» The name of the rst le scrolls.
4 Press / on the main unit or /
on the remote control to select a le.
5 Press on the main unit or OK/
on the remote control to start play.
On the connected external screen, the
following interface is displayed.
[C:] 000001.MP3
01.C:
02.MP3
03.WMA
01.000001
02.000002
03.000003
04.000004
05.000005
06.000006
1 Press / repeatedly until or is
highlighted.
• : For audio les
• : For picture les
• : For video les
2 Press / to select a category icon, and
then press OK, , or .
» The folders that contain the les of this
category are listed.
3 Perform steps 2 to 5 as described above to
select and play a le.
Use the GOTO function
With the GOTO function, you can skip to a
chapter/title/track/le or a point of a video/
audio directly.
1 Press GOTO.
» [GOTO] is displayed on the LCD
screen of the main unit.
» Fields and numbers are displayed on
the top of the connected external
screen.
For a DVD, [TT] (title), [CH] (chapter)
and (time) are displayed.
For a VCD, SVCD, audio CD, and
audio/video les, [TRK] (track) and
(time) are displayed.
For picture les, [TRK] (le) is
displayed.
2 Press / to select a eld, and then
enter the numbers with numeric buttons.
3 Press OK to conrm.
