Philips DVD-Video Player DVD 870
DesignLine (ivory)
• DVD/Video CD/Audio CD/CD-R/CD-RW/MP3-CD Playback
• Dual Laser Drive for optimum read-out of DVD and CD-discs
• Perfect Still picture with multiple zoom factors
• Enhanced Parental Control with Disc Lock
• 5 Disc Resume
• Digital Audio output (PCM / MPEG 2 / Dolby Digital / DTS)
• NTSC/PAL Conversion
• 3D Sound for analog out
• New enhanced graphical user interface
• Audio and video bit rate indicator
• Independent subwoofer audio output
DVD870
DVD870
8239 300 15421

DVD870
DVD870
Playback system
• DVD-Video
• Video CD
• CD (CDR and CD-RW)
• DVD+RW
• MP3-CD
Optical read-out system
• Laser type SemiconductorAlGaAs
• NumericalAperture 0.60 (DVD)
0.45 (VCD/CD)
• Wavelength 650 nm (DVD)
780 nm (VCD/CD)
DVD disc format
• Medium Optical disc
• Diameter 12 cm (8 cm)
• Playing time One layer 2.15
h1
(12cm) Dual layer 4 h1
Two side, 4.30
single layer h1
Two side, 8 h1
dual layer
TV standard PAL NTSC
50 Hz 60Hz
• Number of lines 625 525
• Playback Multi standard (PAL/NTSC)
Video format
• D/A converter 10 bits
• Signal handling Components
• Digital compression MPEG 2 for DVD
MPEG 1 for VCD
DVD 50H 60Hz
Horiz.resolution 720 720
pixels pixels
Vertical resolution 576 lines 480 lines
VCD 50Hz 60Hz
Horiz.resolution 352 pixels 352 pixels
Vertical resolution 288 lines 240 lines
Video performance
• Video output 1 Vpp into 75 ohm
• S-Video Output Y: 1Vpp into 75 ohm
C: 0.3Vpp into 75 ohm
• RGB output 0.7 Vpp into 75 ohm
• Black Level Shift On/off
• Video Shift Left/right
Audio format
• Digital Mpeg/AC-3/ DTS Compressed Digital,
PCM 16,20 bits
fs,44.1,48,96 kHz
• Analog sound stereo
• Dolby Pro Logic downmix from Dolby Digital
multi-channel sound
• 3D sound for virtual 5.1 channel sound on 2
speakers
DVD-Video player
Dolby Prologic is trademark of Dolby Laboratories Licensing Inc. , and the symbol are trademarks of SRS Labs, Inc. *** Only available in certain countries. DRAFT - specifications subject to change without prior notice. 870-EU
General functionality
• Stop/ play/ pause
• Fast forward/ backward
• Time search
• Step forward/ backward
• Slow motion
• Title/ chapter/ track select
• Skip next/ skip previous
• Repeat (Chapter/ title/ all) or (Track/ all)
• A-B repeat
• Shuffle
• Scan
• New enhanced user graphical interface
• Perfect still with digital multi-tap filter
• Zoom (x1.33,x2,x4) with picture enhancement
• Screen saver (dim 75% after 15 min.)
• Cinemalink interconnection for plug & play
• 3D sound
• Virtual Jog Shuttle
• Audio and video bit rate indicator
• Smart Picture
DVD functionality
• Multi-angle selection
• Audio selection (1 out of max.8 languages)
• Subtitles selection (1 out of max.32 languages)
• Aspect ratio conversion
(16:9,4:3 letterbox,4:3 Pan Scan)
• Parental control and disc lock
• Disc Menu support (title menu and root menu)
• Resume (5 discs) after stop/ standby
• Programming titles/ chapters with favorite
selection
Video CD functionality
• Playback control forVCD 2.0 discs
• Disc lock
• Resume (5 discs) after stop/ standby
• Programming tracks with favorite selection
Audio CD functionality
• Time display (total/ track/ remaining track time)
• Full audio functionality with remote control
• Programming with favorite track selection
MP3 functionality
• Time Display (Track)
• Album andTrack Selection
• Repeat (Disc/Album/Track)
1 Typical playing time for movie with 2 spoken
languages and 3 subtitle languages.
Audio performance (typical)
• D/A converter 24 bits
DVD: Fs 96 kHz 4 Hz- 44 kHz
Fs 48 kHz 4 Hz- 22 kHz
Video CD: Fs 44.1 kHz 4 Hz- 20 kHz
CD: Fs 44.1 kHz 4 Hz- 20 kHz
SVCD: Fs 44.1 kHz 4 Hz- 20 kHz
Fs 48.1 kHz 4 Hz- 22 kHz
• Signal-noise (1kHz) 100 dB
• Dynamic Range (1kHz) 97 dB
• Crosstalk (1kHz) 110 dB
• Distortion/noise (1kHz) 88 dB
• MPEG MP3 MPEGAudio L3
Connection
• Scart Euroconnector
• S-Video output Mini DIN,4-pins
• Video output Cinch (yellow)
• Audio L+R Output Cinch (white/ red)
• Audio Centre Cinch (blue)
• Audio Subwoofer Cinch (black)
• Digital Output 1 coaxial,1 optical
IEC958 for CDDA/
LPCM
IEC1937 for MPEG 1/2,
AC-3,DTS
• Cinemalink on SCART
Power supply
• Power inlet 230V,50 Hz
• Power usage 20 watt
• Power usage standby less than 5 watt
Cabinet
• Dimension 435 x 92 x 320 mm
(w x h x d)
• Weight Approx.4 kg
Package contents
• DVD-video player
• Remote control with batteries
• User manual
• Audio cable
• Video cable
• SCART cable (euroconnector)
Technical specifications DVD 870
8239 300 15421
