Philips DVP 7400S User manual

S-VIDEO
YPbPr
MIXED 2CH MAIN
CENTER
SUB WOOFER
6CH DISCRETE SURROUND
LL
R
L
R
COMPONENT
SCAN MODE
INTERLACE
PROGRESSIVE
VIDEO
VIDEO OUT
HDMI
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AUDIO OUT
~ AC
MAINS
VIDEO IN
(CVBS)
VIDEO IN
(CVBS)
S-VIDEO
YPbPr
COMPONENT
SCAN MODE
INTERLACE
PROGRESSIVE
VIDEO
VIDEO OUT
MIXED 2CH
MAIN
LL
R
OPTICAL
R
VIDEO IN
(CVBS)
1Connect
AUse the supplied composite video cable (yellow plug)
to connect the DVD player’s Video Out (CVBS)
socket to the Video In socket (or labeled as A/V In,
Video In, Composite or Baseband) on the TV.
BTo hear the sound of this DVD player from the TV,
use the supplied audio cables (red and white plugs)
to connect {AUDIO OUT L/R} sockets of the DVD
player to the corresponding Audio In sockets on the
TV.
CPlug in the power cable from the DVD player to an
AC power outlet.
Note See the accompanying user manual for other
possible connections (e.g. S-Video, Component Video).
Basic Connection
A
Audio/Video connection to TV
To Video In
socket on the TV To Audio In
socket on the TV
From Video Out
socket on the
DVD Player
From Audio Out
sockets on the
DVD player
DVP 7400S
DVD Video Player
Quick Start Guide
What’s in the box?
DVD Video Player
Remote Control
and 2 AA batteries
User Manual
Quick Start Guide
Power cable Audio (red & white plugs) and
Video (yellow plugs) cables
1_dvp7400_qsg_98_eng_24061.indd 11_dvp7400_qsg_98_eng_24061.indd 1 2006-08-01 2:42:13 PM2006-08-01 2:42:13 PM

3Enjoy
Need help?
User Manual
For more product information refer to the user manual of the DVD player
Online
Go to www.philips.com/support
2005 CKoninklijke Philips N.V.
All rights reserved.
12 NC 3139 246 24061
www.philips.com
SL/0631/98/93_06/02
2Set up
A
Finding the viewing channel
APress 2on the DVD player’s remote control.
BPress SELECT button until [DVD] is lighted on the
remote control display panel.
CSwitch on the TV.
DPress SYSTEM MENU on the DVD player’s remote
control.
GENERAL SETUP PAGE
DISC LOCK
PROGRAM
OSD LANGUAGE
SCREEN SAVER
SLEEP
DIVX(R) VOD CODE
EPress ‘0’ on the TV’s remote control, then repeatedly
press the Channel Down button until you see the
DVD background screen. This is the correct viewing
channel for the DVD player.
Note For some TVs, to nd the correct viewing
channel, you can keep pressing the AV or SELECT
buttons, If still unable to nd the correct viewing
channel, check the connections again or check your
TV’s user manual.
B
Language preference setup
Use the DVD player’s remote control to select the
desired On-screen language, Audio language, Subtitle
language and Menu language you preferred.
Selecting On-screen language
APress
Xto select {General Setup Page}.
BPress STto highlight {OSD Language}, then press X.
GENERAL SETUP PAGE
DISC LOCK
PROGRAM
OSD LANGUAGE ENGLISH
SCREEN SAVER
SLEEP
DIVX(R) VOD CODE
CPress STto select a language and press OK.
Note The On-screen language for the setup menu
will remain once you set it, regardless of various disc
languages.
A
Start playback
APlayback may start automatically when a disc has
been loaded in the disc tray.
Note If a disc menu appears on the TV:
1) Press STWXto scroll through the options
available in the DVD menu.
2) Press PLAY Xon the option
you want to start playback
BPress PLAY Xto start
playback.
CTo stop playback, press
STOP Ç.
DPress DISC MENU to
go back to the disc
menu anytime.
STOP
PLAY
OK
MENU
DISC
Troubleshooting
For more troubleshooting tips, see the user
manual.
No power
• Check if the AC power cord is properly connected.
• Press the STANDBY-ON on the front of the DVD
player to turn on the power.
No picture
• Check connection to TV and ensure the plugs are
rmly in place.
No sound or distorted sound
• Adjust the volume
• Check audio connections are in the correct input
source.
Remote control does not work
• Check the batteries are loaded correctly or replace the
batteries with new ones.
• Reduce the distance between the remote control and
the DVD player.
• Point the remote control directly toward the IR
sensor.
