Philips HTS5520 User manual

TABLE OF CONTENTS
Page
Service Manual
. Mechanical and Dismantling Instructions…………........................3-1
. Software Upgrades ........................................................................4-1
. Trouble Shooting Chart……………………………………………….5-1
. Wiring Diagram………………………………………..………..….….6-1
. Electrical Diagrams and Print-layouts..….…………………....….…7-1
. Set Mechanical Exploded view & Part list.…………………..….….8-1
©Copyright 2011Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
CLASS 1
LASER PRODUCT
PHILIPS
GB
HTS5520/12/51/93/94
. DFU Instruction..............................................................................2-1
. Revision List..................................................................................9-1
Home Theater DVD Player
. Technical Specifications…………....………………………..............1-
3
. Safety Instruction, Warning & Notes….……………………....….....1-
4
. Location of PCB BdsÿVersion Variation and Repair Scenario Matrix..........1-2
Published by RY&WL - 1102 BU AVM Printed in The Netherlands Subject to modification
3139 785 35323
Version 1.3
Service

LOCATION OF PCB BOARDS：
Version Variation：
HTS5520
Type/Versions
Features /12 /51 /93
Output Power-800W X X X
Voltage(220~240v) X X X
Repair Scenario Matrix：
Type/Versions
Board in used /12 /51 /93
Main Board C C C
Front Control Board C C C
Amplifier Board C C C
Power Board C C C
Karaoke+USB Board C C C
Encoder Board C C C
*Bd:Board Level Replacement
*C:Component Level Repair
1-2
/94
X
X
HTS5520
/94
C
C
C
C
C
C
MAIN BOARD
LOADER
FRONT CONTROL
BOARD
POWER BOARD
AMPLIFIER
BOARD
KARAOKE+USB
BOARD
ENCODER
BOARD

Signal-to-noiseratio:>65dB(CCIR)/
(A-weighted)
Input sensitivity:
AUX: 500 mV
MP3 LINK: 500 mV
Video
Signalsystem:PAL/NTSC
HDMI output: 480i/576i, 480p/576p,
720p, 1080i, 1080p
Audio
S/PDIF Digital audio input:
Coaxial: IEC 60958-3
Sampling frequency:
MP3: 32 kHz, 44.1 kHz, 48 kHz
WMA:44.1kHz,48kHz
Constant bit rate:
MP3:112kbps-320kbps
WMA: 48 kbps - 192 kbps
Radio
Tuningrange:FM87.5-108MHz(50kHz)
Signal-to-noiseratio:FM50dB
Frequency response: FM 180 Hz-10 kHz
/ ±6dB
USB
Compatibility: Hi-Speed USB (2.0)
Class support: UMS (USB Mass Storage
Class)
Filesystem:FAT12,FAT16,FAT32
Maximummemorysupport:<160GB.
Main Unit
Power supply: 220-240V; ~50 Hz
Power consumption: 150 W
Standbypowerconsumption:<0.9W
Dimensions(WxHxD):435x58x358
(mm)
Weight: 3.56 kg
Subwoofer
Impedance:8ohm
Speakerdrivers:165mm(6.5”)woofer
Frequency response: 40 Hz-150 kHz
Dimensions (WxHxD):
HTS5520:120x307x369(mm)
HTS5530:196x395x342(mm)
Weight:
HTS5520: 3.84 kg
HTS5530: 6.3 kg
Cable length:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Product specifications
Note
6SHFLÀFDWLRQDQGGHVLJQDUHVXEMHFWWRFKDQJH
without notice.
•
Region code
Playback media
DVD-Video, DVD+R/+RW, DVD-R/-RW,
DVD+R DL, CD-R/CD-RW, Audio CD,Video
CD/SVCD, Picture CD, MP3-CD,WMA-CD,
DivX-CD, USB storage device
File Format
Audio: .mp3, .wma
Video: .divx, .divx ultra, .mpeg, .mpg,
ZPYVLPSOHSURÀOH
Picture: .jpeg, .jpg
$PSOLÀHU
Total output power:
HTS5520:800WRMS(30%THD)
HTS5530: 1000 W RMS (30% THD)
Frequency response: 20 Hz-20 kHz /
±3dB
•
•
•
•
•
•
•
Country DVD
Europe, United Kingdom
Latin America
Australia, New Zealand
Russia, India
China
Asia Pacific, Taiwan, Korea
Country DVD
Europe, United Kingdom
Latin America
Australia, New Zealand
Russia, India
China
Asia Pacific, Taiwan, Korea
HTS5520/12:
1-3

HTS5520: 4.3 m
HTS5530:4m
Speakers
System:fullrangesatellite
Speaker impedance: 3 ohm (center), 4
ohm (Front/Rear)
Speakerdrivers:2x3”fullrange
Frequency response: 150 Hz-20 kHz
Dimensions (WxHxD):
Center:280x95x92(mm)
Front/Rear:100x279x103(mm)
Weight:
Center:0.68kg
Front/Rear:0.66kg/each
Cable length:
Center:2m
Front:4m
Rear:10m
/DVHUVSHFLÀFDWLRQ
Type:SemiconductorlaserGaAIAs(CD)
Wavelength:645-665nm(DVD),770
- 800 nm (CD)
Outputpower:6mW(DVD),7mW
(VCD/CD)
Beam divergence: 60 degrees.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
1-4

Note
Specification and design are subject to change
•
without notice.
Region code
For information about which region this home
theater supports, see the type plate on the back
or bottom.
Playback media
DVD-Video, DVD+R/+RW, DVD-R/-RW, DVD+R
DL, CD-R/CD-RW, Audio CD,Video CD/SVCD,
Picture CD, MP3-CD,WMA-CD, DivX-CD, USB
storage device
File Format
Audio: .mp3, .wma•
Video: .divx, .divx ultra, .mpeg, .mpg, .wmv•
(simple profile)
Picture: .jpeg, .jpg•
Country DVD
Europe, United Kingdom
Latin America
Australia, New Zealand
Russia, India
China
Asia Pacific, Taiwan, Korea
1-5
HTS5520/51:
Product Specifications

Subwoofer
Impedance: 4 ohm•
Speaker drivers: 165 mm (6.5”) woofer•
Frequency response: 50 Hz-1.5 kHz•
Dimensions (WxHxD):•
HTS5520: 122.6 x 307 x 369 (mm)
•
HTS5530: 196 x 392 x 342.2 (mm)
•
Weight:•
HTS5520: 3.76 kg
•
HTS5530: 6.3 kg
•
Cable length: 4.3 m•
Speakers
System: full range satellite•
Speaker impedance: 4 ohm (center), 8 ohm•
(Front/Rear)
Speaker drivers: 2 x 3” full range•
Frequency response: 150 Hz-20 kHz•
Dimensions (WxHxD):•
Center: 280 x 95 x 92 (mm)
•
Front/Rear: 100 x 279.3 x 103 (mm)
•
Weight:•
Center: 1.4 kg
•
Front/Rear: 1 kg/each
•
Cable length:•
Center: 2 m
•
Front: 4 m
•
Rear: 10 m
•
Laser specification
Type: Semiconductor laser GaAIAs (CD)•
Wave length: 645 - 665 nm (DVD), 770 -•
800 nm (CD)
Output power: 6 mW (DVD), 7 mW•
(VCD/CD)
Beam divergence: 60 degrees.•
Amplifier
Total output power:•
HTS5520: 800 W RMS (30% THD)
•
HTS5530: 1000 W RMS (30% THD)
•
Frequency response: 20 Hz-20 kHz / ±3dB•
Signal-to-noise ratio: > 65 dB (CCIR) /•
(A-weighted)
Input sensitivity:•
AUX: 2 V
•
MP3 LINK: 1 V
•
Video
Signal system: PAL / NTSC•
HDMI output: 480i/576i, 480p/576p, 720p,•
1080i, 1080p
Audio
S/PDIF Digital audio input:•
Coaxial: IEC 60958-3
•
Sampling frequency:•
MP3: 32 kHz, 44.1 kHz, 48 kHz
•
WMA: 44.1 kHz, 48 kHz
•
Constant bit rate:•
MP3: 112 kbps - 320 kbps
•
WMA: 48 kbps - 192 kbps
•
Radio
Tuning range: FM 87.5-108 MHz (50/100•
kHz)
Signal-to-noise ratio: FM 50 dB•
Frequency response: FM 180 Hz ~ 10 kHz•
/ ±6dB
USB
Compatibility: Hi-Speed USB (2.0)•
Class support: UMS (USB Mass Storage•
Class)
File system: FAT16, FAT32•
Maximum memory support: < 160GB•
Main Unit
Power supply:•
Latin America/Asia Pacific: 110-
•
127V/220-240V; ~50-60Hz switchable
Russia/China/India: 220-240V, ~50Hz
•
Power consumption: 150 W•
Standby power consumption: < 0.9 W•
Dimensions (WxHxD): 435 x 58 x 358•
(mm)
Weight: 3.56 kg•
1-6

Amplifier
Total output power:•
HTS5520: 800 W RMS (30% THD)
•
HTS5530: 1000 W RMS (30% THD)
•
Frequency response: 20 Hz-20 kHz / ±3dB•
Signal-to-noise ratio: > 65 dB (CCIR) /•
(A-weighted)
Input sensitivity:•
AUX: 2 V
•
MP3 LINK: 1 V
•
Video
Signal system: PAL / NTSC•
HDMI output: 480i/576i, 480p/576p, 720p,•
1080i, 1080p
Audio
S/PDIF Digital audio input:•
Coaxial: IEC 60958-3
•
Sampling frequency:•
MP3: 32 kHz, 44.1 kHz, 48 kHz
•
WMA: 44.1 kHz, 48 kHz
•
Constant bit rate:•
MP3: 112 kbps - 320 kbps
•
WMA: 48 kbps - 192 kbps
•
Radio
Tuning range: FM 87.5-108 MHz (50/100•
kHz)
Signal-to-noise ratio: FM 50 dB•
Frequency response: FM 180 Hz ~ 10 kHz•
/ ±6dB
USB
Compatibility: Hi-Speed USB (2.0)•
Class support: UMS (USB Mass Storage•
Class)
File system: FAT16, FAT32•
Maximum memory support: < 160GB.•
Main Unit
Power supply:•
Latin America/Asia Pacific: 110-
•
127V/220-240V; ~50-60Hz switchable
Russia/China/India: 220-240V, ~50Hz
•
Power consumption: 150 W•
Standby power consumption: < 0.9 W•
Dimensions (WxHxD): 435 x 58 x 358•
(mm)
Weight: 3.56 kg•
Product
specifications
Note
Specification and design are subject to change
•
without notice.
Region code
For information about which region this home
theater supports, see the type plate on the back
or bottom.
Playback media
DVD-Video, DVD+R/+RW, DVD-R/-RW, DVD+R
DL, CD-R/CD-RW, Audio CD,Video CD/SVCD,
Picture CD, MP3-CD,WMA-CD, DivX-CD, USB
storage device
File Format
Audio: .mp3, .wma•
Video: .divx, .divx ultra, .mpeg, .mpg, .wmv•
(simple profile)
Picture: .jpeg, .jpg•
Country DVD
Europe, United Kingdom
Latin America
Australia, New Zealand
Russia, India
China
Asia Pacific, Taiwan, Korea
HTS5520/93:
1-7

Subwoofer
Impedance: 4 ohm•
Speaker drivers: 165 mm (6.5”) woofer•
Frequency response: 50 Hz-1.5 kHz•
Dimensions (WxHxD):•
HTS5520: 122.6 x 307 x 369 (mm)
•
HTS5530: 196 x 392 x 342.2 (mm)
•
Weight:•
HTS5520: 3.76 kg
•
HTS5530: 6.3 kg
•
Cable length: 4.3 m
Speakers
System: full range satellite•
Speaker impedance: 4 ohm (center), 8 ohm•
(Front/Rear)
Speaker drivers: 2 x 3” full range•
Frequency response: 150 Hz-20 kHz•
Dimensions (WxHxD):•
Center: 280 x 95 x 92 (mm)
•
Front/Rear: 100 x 279.3 x 103 (mm)
•
Weight:•
Center: 1.4 kg
•
Front/Rear: 1 kg/each
•
Cable length:•
Center: 2 m
•
Front: 4 m
•
Rear: 10 m
•
Laser specification
Type: Semiconductor laser GaAIAs (CD)•
Wave length: 645 - 665 nm (DVD), 770 -•
800 nm (CD)
Output power: 6 mW (DVD), 7 mW•
(VCD/CD)
Beam divergence: 60 degrees.•
1-8

16
•Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)
•Input sensitivity:
•AUX: 2 V
•MP3 LINK: 1 V
Video
•Signal system: PAL / NTSC
•HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p
Audio
•S/PDIF Digital audio input:
•Coaxial: IEC 60958-3
•Sampling frequency:
•MP3: 32 kHz, 44.1 kHz, 48 kHz
•WMA: 44.1 kHz, 48 kHz
•Constant bit rate:
•MP3: 112 kbps - 320 kbps
•WMA: 64 kbps - 192 kbps
Radio
•Tuning range: FM 87.5-108 MHz (50/100
kHz)
•Signal-to-noise ratio: FM 50 dB
•Frequency response: FM 180 Hz ~ 10 kHz
USB
•Compatibility: Hi-Speed USB (2.0)
•Class support: UMS (USB Mass Storage
Class)
•File system: FAT16, FAT32
•Maximum memory support: < 160GB
Main Unit
•Power supply:
•Latin America/Asia Pacific:
110-127V/220-240V; ~50-60Hz
switchable
•Russia/China/India: 220-240V, ~50Hz
•Power consumption:
•HTS5520: 150 W
•HTS5530: 200 W
•Standby power consumption: 0.9 W
•Dimensions (WxHxD): 435 x 50 x 340
(mm)
•Weight: 3.56 kg
8 Product
specifications
Note
•Specification and design are subject to change
without notice.
Region code
The type plate on the back or bottom of the
home theater shows which regions it supports
Playback media
DVD-Video, DVD+R/+RW, DVD-R/-RW, DVD+R
DL, CD-R/CD-RW, Audio CD,Video CD/SVCD,
Picture CD, MP3-CD,WMA-CD, DivX-CD, USB
storage device
File Format
•Audio: .mp3, .wma
•Video: .divx, .divx ultra, .mpeg, .mpg, .wmv
(simple profile)
•Picture: .jpeg, .jpg
Amplifier
•Total output power:
•HTS5520: 800 W RMS (30% THD)
•HTS5530: 1000 W RMS (30% THD)
•Frequency response: 20 Hz-20 kHz
Country DVD
Europe, United Kingdom
Latin America
Australia, New Zealand
Russia, India
China
Asia Pacific, Taiwan, Korea
1-9
HTS5520/94

Subwoofer
•Impedance: 4 ohm
•Speaker drivers: 203 mm (8”) woofer
•Frequency response: 20 Hz-150 Hz
•Dimensions (WxHxD): 196 x 392 x 342.2
(mm)
•Weight: 6.3 kg
•Cable length: 3 m
Speakers
•System: full range satellite
•Speaker impedance: 4 ohm (center), 8 ohm
(Front/Rear)
•Speaker drivers: 2 x 3” full range
•Frequency response: 150 Hz-20 kHz
•Dimensions (WxHxD):
•Center: 280 x 95 x 92 (mm)
•Front/Rear: 100 x 280 x 115 (mm)
•Weight:
•Center: 1.4 kg
•Front/Rear: 1 kg/each
•Cable length:
•Center: 2 m
•Front: 3 m
•Rear: 10 m
Laser specification
•Type: Semiconductor laser GaAIAs (CD)
•Wave length: 645 - 665 nm (DVD), 770 -
800 nm (CD)
•Output power: 6 mW (DVD), 7 mW
(VCD/CD)
•Beam divergence: 60 degrees.
1-10
