Philips HQ8160CC User manual

HQ8160CC
ENGLISH 4
INDONESIA 19
한국어 36
BAHASA MELAYU 52
ภาษาไทย 69
TIẾNG VIỆT 82
繁體中文 97
简体中文 111

4
Important
Read these instructions for use carefully before
you use the appliances and save them for future
reference.
Only use the powerplug supplied.
The powerplug transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The powerplug contains a transformer. Do not
cut off the powerplug to replace it with another
plug, as this causes a hazardous situation.
Do not use a damaged powerplug.
If the powerplug is damaged, always have it
replaced by one of the original type in order to
avoid a hazard.
Make sure the powerplug does not get wet.
Charge, use and store the shaver at a
temperature between 5°C and 35°C.
Do not recharge the shaver in a closed pouch.
Always unplug the shaver before you clean it
under the tap.
The shaver complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap.
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands
from getting burnt.
This washable shaver is not suitable for shaving
in the shower.
Do not immerse the shaver in water.
Water may leak from the socket at the bottom
of the shaver when you rinse it.This is normal
and not dangerous because all electronics are
enclosed in a sealed power unit inside the shaver.
Only use the washing machine with the original
HQ200 Cleaning Fluid.
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
ENGLISH

Empty the cleaning chamber and rinse it
thoroughly with hot tap water every 15 days.
The washing machine thoroughly cleans but does
not disinfect your shaver, therefore do not share
the shaver with others.
Never immerse the washing machine in water
nor rinse it under the tap.
Keep the washing machine out of the reach of
children.
Use and store the washing machine at a
temperature between 5°C and 35°C.
Always place the washing machine on a stable,
level and horizontal surface to prevent leakage.
When the washing machine is ready for use, do
not move it to prevent leakage of cleaning fluid.
Charging
Make sure the shaver is switched off before
you charge it.
Charging takes approx. 1 hour.
You can also shave without charging by connecting
the shaver to the mains.
A fully charged shaver has a cordless shaving time of
up to 55 minutes.
1 Charge the shaver when the bottom light
burns or blinks red.
Charge indications
Charging
When you start to charge the empty shaver,
the bottom light blinks red.When the battery
contains enough power for one shave, all lights
blink green sequentially.
,
,
,
,
,
,
,
,
ENGLISH 5

Battery fully charged
When the battery is fully charged, all lights burn
green.
A few hours after charging, all lights go out.
Remaining battery capacity
The number of lights that are on show how
much power is left in the battery.The battery
capacity is only shown when you switch the
shaver on or off.
When all lights burn green, the battery is 100%
charged.
When the bottom light burns green, 20% of the
battery capacity is left.
Battery running low
When the battery is running low, the bottom
light turns red.
When you switch off the shaver, this light blinks a
few times.
Charging with the powerplug
Do not recharge the shaver in a closed pouch.
1 Put the appliance plug in the shaver.
2 Put the powerplug in the wall socket.
3 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver
when the battery is fully charged.
,
,
-
-
,
ENGLISH6

Charging in the washing machine
1 Place the shaver in the holder and push the
lever down completely to lock the shaver into
place.
The charging light on the washing machine blinks to
indicate that the shaver is charging.
When the charging light starts to burn
continuously (after approx. 1 hour), the shaver is
fully charged.
2 Move the lever upwards until it does not go
any further (1) and remove the shaver from the
washing machine (2).
The charging light goes out.
Using the appliance
Shaving
1 Press the on/off button once to switch on the
shaver.
The blue light ring round the on/off button goes on
to indicate that the motor is running.
Note:When you switch on the shaver, all lights go on
and then the remaining battery capacity is shown for a
few seconds.
,
ENGLISH 7

2 Move the shaving heads quickly over your skin.
Make both straight and circular movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
3 Press the on/off button once to switch off the
shaver.
The blue light ring round the on/off button goes out.
4 Clean the shaver (see chapter ‘Cleaning and
maintenance’).
5 Put the protection cap on the shaver every
time you have used it, to prevent damage.
Trimming
You can use the trimmer to groom your sideburns
and moustache.
1 Push the slide downwards to open the
trimmer.
You can activate the trimmer while the motor is
running.
2 Close the trimmer (‘click’).
Cleaning and maintenance
The best and most hygienic way to clean the
shaver is in the washing machine.You can also
clean the shaver by rinsing it under the tap or
with the brush supplied.
-
-
,
ENGLISH8

Regular cleaning guarantees better shaving
performance.
Cleaning the shaver in the washing machine
supplied
Preparing the washing machine for use
Fill the cleaning chamber before first use and when
the cleaning light blinks to indicate that the fluid
level is too low.When the fluid level drops below
the minimum level, the cleaning light starts to blink
with intervals and the holder returns to its starting
position.
If you use the washing machine to clean the shaver
every day, refill the cleaning chamber approx. every
15 days.
1 Simultaneously press the release buttons on
both sides of the cleaning chamber (1) and lift
the washing machine off the cleaning chamber
(2).
The cleaning chamber remains behind.
2 Unscrew the dosing cap from the bottle with
HQ200 Cleaning Fluid and remove the airtight
seal.
3 Fill the cleaning chamber with cleaning fluid up
to the MAX indication.
4 Place the washing machine back onto the
cleaning chamber.
Make sure the release buttons snap back into place.
5 Put the appliance plug in the washing machine
and put the powerplug in the wall socket.
The holder automatically moves to the highest
position.
ENGLISH 9

The washing machine is now ready for use.
Using the washing machine
1 Place the shaver in the holder and push the
lever down completely to lock the shaver into
place.
The charging light on the washing machine blinks to
indicate that the shaver is being charged.
2 Press the start button to start the cleaning
program.
The cleaning light starts to blink and the shaver is
automatically lowered into the cleaning fluid.
During the cleaning program, which takes
approx. 1 hour, the cleaning light blinks
continuously.
During the first phase of the cleaning program,
the shaver automatically switches on and off
several times and is put in different positions.
During the second phase of the cleaning
program, the shaver is placed in the drying
position. It stays in this position until the
end of the program.The cleaning light burns
continuously.
After the cleaning program, the shaver
automatically returns to its starting position and
the charging program is started.The charging
light blinks.
Note:If you press the start button or open the lever
during cleaning, the cleaning program is aborted and
reset. In this case, the cleaning light stops blinking and
the holder returns to its starting position.
Note:If the powerplug is removed from the wall socket
during cleaning, the cleaning program is aborted.
The holder remains in its current position.When
,
,
,
,
ENGLISH10

the powerplug is put back into the wall socket, the
holder moves to the highest position.
Note:If the fluid volume in the cleaning chamber drops
below the minimum level during the cleaning program,
the program is aborted.The cleaning light blinks with
intervals and the holder returns to its starting position.
Cleaning the washing machine
The cleaning chamber is not dishwasher-proof.
Clean the cleaning chamber every two weeks.
1 Simultaneously press the buttons on both sides
of the washing machine (1) and lift the washing
machine off the cleaning chamber (2).
The cleaning chamber remains behind.
2 Pour any remaining cleaning fluid out of the
cleaning chamber.
You can simply pour the cleaning fluid down the sink.
3 Rinse the cleaning chamber under the tap.
4 Place the washing machine back onto the
cleaning chamber.
Make sure the release buttons snap back into place.
5 Clean the washing machine with a moist cloth.
Cleaning the shaver under the tap
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.
,
,
ENGLISH 11

1 Switch off the shaver, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Press the release button to open the shaving
unit.
3 Rinse the shaving unit and the hair
chamber under a hot tap for some time.
Make sure you clean the inside as well as the
outside of the shaving unit.
4 Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
5 Open the shaving unit again and leave it open
to let the appliance dry completely.
You can also clean the hair chamber without water
with the brush supplied.
Cleaning the shaver with the brush supplied
Shaving heads
1 Open the shaving unit, turn the lock
anticlockwise (1) and remove the retaining
frame (2).
,
ENGLISH12

2 Clean the cutters and guards with the brush
supplied.
Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
may take several weeks before optimal shaving
performance is restored.
3 Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit and turn the lock clockwise.
4 Close the shaving unit.
Trimmer
Clean the trimmer every time you have used it.
1 Switch off the shaver, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Clean the trimmer with the brush supplied.
3 Lubricate the trimmer teeth with a drop of
sewing machine oil every six months.
Storage
Put the protection cap on the shaver to prevent
damage.
,
ENGLISH 13

Store the shaver in the pouch or place it in the
washing machine.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with HQ9
Philips Shaving Heads only.
Note:Do not mix up the cutters and the guards to
guarantee optimal shaving performance.
1 Switch off the shaver, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Press the release button to open the shaving
unit.
3 Turn the lock anticlockwise (1) and remove the
retaining frame (2).
4 Remove the shaving heads and place new ones
in the shaving unit. Put the retaining frame
back into the shaving unit and turn the lock
clockwise.
Make sure that the projections of the shaving
heads fit exactly into the recesses.
5 Close the shaving unit.
,
ENGLISH14

Accessories
The following accessories are available:
HQ8000 Powerplug.
HQ9 Philips Shaving Heads.
HQ110 Philips Shaving Head Cleaning Spray.
HQ8010 Car Cord.
HQ200 Philips Cleaning Fluid.
Environment
Do not throw away the appliances with the
normal household waste at the end of their life,
but hand them in at an official collection point
for recycling. By doing this, you help to preserve
the environment.
The built-in rechargeable shaver battery contains
substances that may pollute the environment.
Always remove the battery before you discard
and hand in the shaver at an official collection
point. Dispose of the battery at an official
collection point for batteries. If you have trouble
removing the battery, you can also take the
shaver to a Philips service centre.The staff of
this centre will remove the battery for you and
will dispose of it in an environmentally safe way.
Disposal of the shaver battery
Only remove the battery if it is completely empty.
1 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver.
2 Let the shaver run until it stops and undo the
two screws in the back of the shaver.
-
-
-
-
-
,
,
ENGLISH 15

3 Undo the two screws in the hair chamber.
4 Undo the three screws in the power unit.
5 Bend the 4 hooks aside (1) to take out the
power unit (2).
Be careful, the hooks are very sharp.
6 Remove the power unit cover with a
screwdriver.
7 Remove the battery.
Be careful, the battery strips are very sharp.
Do not connect the shaver to the mains again after
you have removed the battery.
Guarantee & service
If you need information or if you have a
problem, please visit the Philips website at
www.philips.com or contact the Philips Customer
Care Centre in your country (you find its phone
number in the worldwide guarantee leaflet). If there
is no Customer Care Centre in your country, turn
ENGLISH16

to your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.
Frequently asked questions
1 Why does the shaver not shave as well as it
used to?
The washing machine may not have cleaned the
shaver properly, because the cleaning fluid in the
cleaning chamber is soiled or the cleaning fluid
level is too low. Clean the shaver thoroughly
before you continue shaving. If necessary, clean
and refill the cleaning chamber (see chapter
‘Cleaning and maintenance’).
Long hairs may obstruct the shaving heads. Clean
the cutters and guards with the brush supplied
(see chapter ‘Cleaning and maintenance’).
The shaving heads may be damaged or
worn. Replace the shaving heads (see chapter
‘Replacement’).
2 Why does the shaver not work when I press
the on/off button?
The battery may be empty. Recharge the battery
(see chapter ‘Charging’).
The shaver may not be connected to the mains.
Put the appliance plug in the shaver and put the
powerplug in the wall socket.
3 Why does the shaving unit come off the
shaver?
The shaving unit may not be placed correctly.
Put the shaving unit back onto the shaver by
inserting the hinge into the slot in the rim of the
hair chamber.Then push the shaving unit home
until it locks into place (‘click’).
,
,
,
,
,
,
ENGLISH 17

4 Why is the shaver not entirely clean after I
have cleaned it in the washing machine?
The cleaning fluid in the cleaning chamber may
be soiled. Empty and rinse the cleaning chamber.
The cleaning fluid level may be too low. If
the fluid volume in the cleaning chamber
drops below the minimum level during the
cleaning program, the program is aborted.
The cleaning light blinks with intervals and the
holder returns to its starting position. Refill
the cleaning chamber with cleaning fluid up to
the MAX indication (see chapter ‘Cleaning and
maintenance’).
5 Why does the washing machine not work
when I press the start button?
The washing machine may not be connected to
the mains. Put the appliance plug in the washing
machine and put the powerplug in the wall
socket.
There may not be an electrical connection
between the washing machine and the shaver.
Open the lever and close it again until the
charging light on the washing machine starts to
blink.
,
,
,
,
ENGLISH18

19
Penting
Bacalah petunjuk penggunaan ini dengan saksama
sebelum menggunakan alat dan simpanlah untuk
referensi jika dibutuhkan kelak.
Gunakan hanya steker listrik yang disertakan.
Steker mengubah tegangan 100-240 volt menjadi
tegangan rendah yang aman di bawah 24 volt.
Steker listrik berisi trafo. Jangan memotong
steker listrik dan menggantinya dengan steker
lain, karena ini dapat membahayakan.
Jangan gunakan steker listrik yang rusak.
Jika steker listrik rusak, harus selalu diganti
dengan tipe yang asli agar terhindar dari bahaya.
Pastikan steker listrik tidak basah.
Gunakan dan simpan alat pada suhu antara 5°C
dan 35°C.
Jangan mengisi ulang pencukur di dalam kantong
tertutup.
Selalu mencabut steker dari pencukur sebelum
membersihkannya di bawah keran.
Alat cukur ini memenuhi peraturan keselamatan
IEC yang disepakati secara internasional dan
dapat dengan aman dibersihkan di bawah keran
air.
Hati-hati dengan air panas. Selalu periksa apakah
air tidak terlalu panas untuk mencegah luka
bakar pada tangan Anda.
Pencukur yang dapat dicuci ini tidak sesuai untuk
mencukur di bawah pancuran.
Jangan mencelupkan pencukur ke dalam air.
Air mungkin merembes keluar dari soket di
bagian bawah pencukur saat Anda membilasnya.
Ini normal dan tidak berbahaya karena semua
komponen elektronik tersimpan dalam unit daya
yang tertutup rapat di dalam pencukur.
,
,
,
,
,
,
,
,
,
,
,
,
,
,
INDONESIA

Hanya gunakan alat pencuci dengan HQ200
Cleaning Fluid yang asli.
Kosongkan wadah pencucian dan bersihkan
dengan membilas seluruhnya dengan air keran
panas setiap 15 hari.
Alat pencuci dapat membersihkan tuntas tetapi
tidak dapat menyuci-hamakan alat cukur Anda,
oleh sebab itu jangan berbagi pakai pencukur ini
dengan orang lain.
Jangan merendam alat pencuci di dalam air atau
membilasnya di bawah keran.
Jauhkan alat pencuci dari jangkauan anak-anak.
Gunakan dan simpan alat pencuci pada suhu
antara 5°C dan 35°C.
Selalu letakkan alat pencuci pada permukaan
horisontal yang stabil dan rata untuk mencegah
kebocoran.
Saat alat pencuci siap digunakan, alat ini tidak
boleh dipindahkan untuk mencegah kebocoran
cairan pembersih.
Pengisian daya
Pastikan pencukur dimatikan sebelum Anda mulai
mengisi daya.
Waktu pengisian daya kurang lebih 1 jam.
Anda juga dapat mencukur tanpa mengisi daya
dengan menghubungkan pencukur ke listrik.
Pencukur yang terisi penuh dapat digunakan tanpa
kabel hingga 50 menit.
1 Isi daya pencukur apabila lampu pada alas
menyala atau berkedip merah.
,
,
,
,
,
,
,
,
INDONESIA20

Indikator daya
Pengisian daya
Ketika Anda mulai mengisi pencukur yang
kosong , lampu pada alas berkedip merah.
Apabila baterai terisi cukup daya untuk satu kali
pencukuran, semua lampu menyala hijau secara
berurutan.
Baterai terisi penuh
Apabila baterai terisi penuh, semua lampu
menyala hijau.
Beberapa jam setelah pengisian, semua lampu mati.
Kapasitas baterai yang tersisa
Jumlah lampu yang menyala, menunjukkan
berapa banyak daya yang tersisa dalam baterai.
Kapasitas baterai hanya ditunjukkan saat Anda
menghidupkan atau mematikan pencukur.
Apabila semua lampu menyala hijau, baterai terisi
100%.
Apabila lampu pada alas menyala hijau, kapasitas
baterai tersisa 20%.
Baterai hampir habis
Apabila daya baterai hampir habis, lampu pada
alas menyala merah.
Apabila Anda mematikan pencukur, lampu ini
berkedip beberapa kali.
Mengisi baterai melalui steker listrik
Jangan mengisi ulang pencukur di dalam kantong
tertutup.
,
,
,
-
-
,
INDONESIA 21

1 Pasang steker alat pada pencukur.
2 Masukkan steker listrik ke stopkontak.
3 Setelah baterai terisi penuh, cabut steker listrik
dari stopkontak dan lepaskan steker alat dari
pencukur.
Mengisi daya baterai dalam alat pencuci
1 Taruh pencukur dalam dudukannya lalu tekan
tuas ke bawah seluruhnya untuk mengunci
pencukur di dalam tempatnya.
Lampu pengisian pada alat pencuci berkedip untuk
menandakan, bahwa baterai pencukur sedang diisi.
Apabila lampu pengisian mulai menyala terus-
menerus (setelah sekitar 1 jam), berarti baterai
pencukur terisi penuh.
2 Gerakkan tuas ke atas sampai tidak bisa maju
lagi (1) dan keluarkan pencukur dari alat
pencuci (2).
Lampu pengisian akan padam.
Menggunakan alat
Mencukur
1 Tekan tombol on/off satu kali untuk
menghidupkan pencukur.
Cincin lampu biru di sekitar tombol on/off menyala
untuk menunjukkan bahwa motor bekerja.
,
INDONESIA22
