Philips HR7771/50 User manual

ServiceManual
Philips Consumer Lifestyle
Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
Foodprocessor
HR7771/50
11/02
PRODUCT INFORMATION
Features
- Extra Large feeding tube The XL feeding tube takes whole fruits and vegetables so you don’t need to pre-cut them
anymore.
- Large 3.4L bowl The large 3.4 L bowl allows for maximum volumes to be processed in 1 go: capacity for 2 L
soup, 1.7 kg dough, 7 egg whites.
- 31 functions 7 tools for 31 different functions. They are: a SS blade for chopping, crumbling, cutting,
mashing, mincing; a reversible slicing disk; a shredding disk for medium or fine shredding
or grating; an emulsifying disk for emulsifying; a kneading tool for heavy mixing, kneading,
folding in; a blender for blending, crushing, foaming, grinding, (heavy) pureeing,
homogenizing, liquidizing, milling, shaking, stirring, measuring; a citrus press for pressing
citrus fruits.
- 700 W motor + 2 speed With the powerful 700 W motor plus 2 speed button you can adjust speed precisely to get
desired results.
- Sturdy base The sturdy base comes with suction feet to ensure it does not move, even when you use it for
heavy applications like kneading dough.
Accessories
- Chopping knife Chopping, beating, creaming, crumbling, cutting, folding in, mashing, mincing
- Kneading tool For kneading, heavy kneading, mixing dough, batter
- Emulsifying disk For emulsifying
- Reversible shredding disk For medium and fine shredding
- Reversible slicing disk For medium and fine slicing
- Break resistant blender For blending, crushing, foaming, grinding, pureeing, homogenizing, liquidizing, milling,
shaking, stirring

HR7771/50
2-6
Safety
- Automatic resettable thermal cut off Protecting the motor against overheating.
- Built-in safety lock Detects whether lid & bowl are assembled.
- Brake system Stops the accessories within 1,5 seconds.
SPECIFICATIONS
General specifications Integrated cord storage, Non-slip feet
Technical Specifications
- Cord length 1,20 m
- Voltage 220 - 240 V
- Frequency 50 - 60 Hz
- Bowl volume capacity dry 3,4 l
- Bowl working capacity liquid 2 l
- Bowl working capacity dough 1700 g
- Bowl working capacity flour 1000 g
- Blender working capacity 1,5 l
- Safety Lid & bowl detection, mechanical 1,5 sec brake
- Speeds 2 speed
- Function buttons Pulse, rotary
Design specifications
- Housing, bottom, speed knob, pusher ABS
- Toolholder PA + 30 %
- Disks, chopping blade Stainless steel
- Kneading tool PP
- Colours Bright white, citrus yellow, paprika red, capoeira grey
- Bowl + lid, blender, inner pusher SAN
- Knife protection PET
Product size:
Length : 230 mm
Width : 230 mm
Height : 170/400 mm (with food pusher)
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- No specific issues.
REPAIR INSTRUCTION
- No specific issues.
TECHNICAL INFORMATION

HR7771/50
3-6
PARTS LIST
Pos Service code Description
1
2
3
4
5
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
4203 035 95991
4203 035 87720
4203 035 87730
4203 035 87740
4203 035 96001
4203 035 87770
4203 035 87780
4203 035 87790
4203 035 87800
4203 035 87810
4203 035 87820
4203 035 87830
4203 035 87840
4203 035 87850
4203 035 82650
4203 035 87860
4203 035 87870
4203 035 87880
4203 035 87890
4203 035 87900
4203 035 87910
4203 035 87920
4203 035 87930
4203 035 87940
4203 035 87950
4203 035 87960
4203 035 94991
Housing
Bottom + Airtunnel
Sucker Foot (1 pcs)
Motor - incl. Wires + Gearing + Driving coupling
2 speed Switch knob assembly
Holder safety switch I
Safety switch
Cordset (white) WEu
Storage for Cordset
Holder safety switch II
Safety switch lever
Stopper
Lid of Blender Jar
Jar
Sealing ring
Blade unit for Jar
Inner Pusher
Outer Pusher
Bowl Lid
Tool holder
Bowl
Fine/ Medium Slicing disc (yellow)
Fine/ Medium Shredding disc (yellow)
Kneading accessory
Chopping knife + Protection
Emulsifying disc
Blade coupling + Screw + Discs

HR7771/50
4-6
EXPLODED VIEW
1
10
2
9
8
5 12
11
4
7
3

HR7771/50
5-6
EXPLODED VIEW
14
15
16
17
28
13
19
20
21
22
18

HR7771/50
6-6
EXPLODED VIEW
23
25
27
24
26
