Philips HD965X User manual

User manual 5
Bedienungsanleitung 27
Mode d’emploi 53
Gebruiksaanwijzing 79
HD965X
HD976X

3
ENGLISH
TABLE OF CONTENTS
Important 4
Introduction 9
General description 9
Before rst use 10
Preparing for use 10
Placing the removable mesh bottom and fat
reducer 10
Food table 11
Using the appliance 14
Airfrying 14
Changing to another preset during cooking 18
Using the manual mode 19
Changing the cooking temperature or time
at any time 20
Choosing the keep warm mode 21
Making home-made fries 21
Cleaning 22
Storage 24
Recycling 24
Guarantee and support 24
Troubleshooting 24

4
ENGLISH
Important
Read this important information carefully before you use the
appliance and save it for future reference.
Danger
-Always put the ingredients to be fried in the
basket, to prevent them from coming into
contact with the heating elements.
-Do not cover the air inlet and the air outlet
openings while the appliance is operating.
-Do not ll the pan with oil as this may cause
a re hazard.
-Never immerse the appliance in water or
any other liquid, nor rinse it under the tap.
-Do not let any water or other liquid enter
the appliance to prevent electric shock.
-Never put any amount of food that exceeds
the maximum level indicated in the basket.
-Never touch the inside of the appliance
while it is operating.
Warning
-Check if the voltage indicated on the
appliance corresponds to the local mains
voltage before you connect the appliance.
-Do not use the appliance if the plug,
the mains cord or the appliance itself is
damaged.
-If the mains cord is damaged, you must
have it replaced by Philips, a service centre
authorised by Philips or similarly qualied
persons in order to avoid a hazard.
-This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of

5
ENGLISH
the appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
unless they are older than 8 years and
supervised.
-Keep the appliance and its cord out of
reach of children less than 8 years.
-Keep the mains cord away from hot
surfaces.
-Only connect the appliance to an earthed
wall socket. Always make sure that the plug
is inserted into the wall socket properly.
-This appliance is not intended to be
operated by means of an external timer or a
separate remote-control system.
-Do not place the appliance against a wall
or against other appliances. Leave at least
10cm free space on the back and sides and
10cm free space above the appliance. Do
not place anything on top of the appliance.
-Do not use the appliance for any other
purpose than described in the user manual.
-During hot air frying, hot steam is released
through the air outlet openings. Keep
your hands and face at a safe distance
from the steam and from the air outlet
openings. Also be careful of hot steam
and air when you remove the pan from the
appliance.
-The accessible surfaces may become hot
during use.
-The pan, basket and accessories inside the
Airfryer become hot during use. Be careful
when you handle them.

6
ENGLISH
-Do not place the appliance on or near a hot
gas stove or all kinds of electric stove and
electric cooking plates, or in a heated oven.
-Never use light ingredients or baking paper
in the appliance.
-Do not place the appliance on or near
combustible materials such as a tablecloth
or curtain.
-Do not let the appliance operate
unattended.
-Immediately unplug the appliance if
you see dark smoke coming out of the
appliance. Wait for the smoke emission
to stop before you pull the pan out of the
appliance.
-Storage of potatoes: The temperature shall
be appropriate to the potato variety stored
and it shall be above 6°C to minimize the
risk of acrylamide exposure in the prepared
foodstu.
-Do not plug in the appliance or operate the
control panel with wet hands.
Caution
-This appliance is intended for normal
household use only. It is not intended
for use in environments such as sta
kitchens of shops, oces, farms or other
work environments. Nor is it intended
to be used by clients in hotels, motels,
bed and breakfasts and other residential
environments.
-Always return the appliance to a
service centre authorised by Philips for
examination or repair. Do not attempt to
repair the appliance yourself, otherwise the
guarantee becomes invalid.

7
ENGLISH
-If the appliance is used improperly or
for professional or semi-professional
purposes or if it is not used according to
the instructions in the user manual, the
guarantee becomes invalid and Philips
refuses any liability for damage caused.
-Always place and use the appliance on a
dry, stable, level and horizontal surface.
-Always unplug the appliance after use.
-Let the appliance cool down for approx.
30 minutes before you handle or clean it.
-Make sure the ingredients prepared in this
appliance come out golden-yellow instead
of dark or brown. Remove burnt remnants.
Do not fry fresh potatoes at a temperature
above 180°C (to minimise the production of
acrylamide).
-Be careful when cleaning the upper area of
the cooking chamber: Hot heating element,
edge of Metal parts.
Electromagnetic elds (EMF)
This Philips appliance complies with all applicable standards
and regulations regarding electromagnetic elds.
Automatic shut-o
This appliance is equipped with an automatic shut-o
function. When the time of the timer has elapsed, the device
will shut o automatically. To switch o the appliance manually
turn the timer to the “0” position.

8
ENGLISH
1
B
A HI
C
D
F
G
E
2
3
4
5 6
7
9
8
10
11

9
ENGLISH
Introduction
Congratulations on your purchase and welcome to Philips!
To fully benet from the support that Philips oers, register
your product at www.philips.com/welcome.
Philips Airfryer XXL uses hot air to fry your favorite food with
little or no added oil. It is built to fry as crispy as deep fried with
minimum amount of fat. By combining a powerful heater and
motor with new Twin TurboStar technology, the hot air in the
Airfryer XXL swirls fast, like a tornado – throughout the entire
cooking basket. This extracts fat from food, and captures it all
in the fat reducer at the bottom of the Airfryer.
Fat released from the food is captured in one place at the
bottom of the pan for easy disposal and cleaning.
You can now enjoy perfectly cooked fried food – crispy on
the outside tender on the inside – Fry, grill, roast and bake to
prepare a variety of tasty dishes in a healthy, fast and easy way.
For more inspiration, recipes and information about the
Airfryer, visit www.philips.com/kitchen or download the free
Airfryer App for IOS®or Android™.
General description
1 Drawer
2 Basket with removable mesh bottom
3 Removable mesh bottom
4 Fat reducer
5 Pan
6 Cord storage compartment
7 Air outlets
8 MAX indication
9 Power cord
10 Air inlet
11 Control panel
A. Temperature indication
B. Temperature button
C. Keep warm button
D. QuickControl dial
E. Power On/O button
F. Preset button
G. Timer button
H. Time indication
I. Presets: French fries/frozen snacks, chicken, meat, sh,
baking and manual

10
ENGLISH
Before rst use
1 Remove all packing material.
2 Remove any stickers or labels from the appliance.
3 Thoroughly clean the appliance before rst use, as
indicated in the cleaning table.
Preparing for use
Placing the removable mesh bottom and fat reducer
1 Open the drawer by pulling the handle.
2 Remove the basket by lifting the handle.
3 Place the fat reducer into the pan.
4 Insert the removable mesh bottom into the slot on the
right bottom side of the basket. Push the mesh bottom
down until it locks into position (“click” on both sides).
1
2

11
ENGLISH
5 Put the basket in the pan.
6 Slide the drawer back into the Airfryer by the handle.
Note
•Never use the pan without the fat reducer or the basket in it.
Food table
The table below helps you select the basic settings for the
types of food you want to prepare.
Note
•Keep in mind that these settings are suggestions. As ingredients
dier in origin, size, shape as well as brand, we cannot guarantee
the best setting for your ingredients.
•When preparing larger amount of food (e.g. fries, prawns,
drumsticks, frozen snacks), shake, turn, or stir the ingredients in
the basket 2 to 3 times in order to achieve a consistent result.
Ingredients Min.- max.
amount
Time
(min) Temperature
Shake,
turn,
or stir
halfway
Note
Thin frozen fries (7x7 mm) 200-1400 g 13-32 180°C Yes
Thick frozen fries (10x10
mm) 200-1400 g 13-33 180°C Yes
Home-made fries (10x10
mm) 200-1400 g 18-35 180°C Yes
Soak 30
minutes in
water, dry
then add
1/4 to 1 tbsp of
oil.

12
ENGLISH
Ingredients Min.- max.
amount
Time
(min) Temperature
Shake,
turn,
or stir
halfway
Note
Homemade potato
wedges 200-1400 g 20-42 180°C Yes
Soak 30
minutes in
water, dry
then add
1/4 to 1 tbsp of
oil.
Frozen snacks
(chicken nuggets)
80-1300 g
(6-50 pieces) 7-18 180°C Yes
Ready when
golden yellow
and crispy
outside.
Frozen snacks
(small spring rolls around
20 g)
100-600 g
(5-30 pieces) 14-16 180°C Yes
Ready when
golden yellow
and crispy
outside.
Whole chicken 1200-1500 g 50-55 180°C
Avoid that
legs touch
the heating
element.
Chicken breast
Around 160 g 1-5 pieces 18-22 180°C
Drumsticks 200-1800 g 18-35 180°C Yes
Chicken ngers bread
crumbed
3-12 pieces
(1 layer) 10-15 180°C
Add oil to the
breadcrumbs.
Ready when
golden yellow.
Chicken wings
Around 100 g
2-8 pieces
(1 layer) 14-18 180°C Yes
Meat chops without bone
Around 150 g 1-5 chops 10-13 200°C
Hamburger
Around 150 g (diameter
10 cm)
1-4 patties 10-15 200°C
Thick sausages
Around 100 g (diameter
4 cm)
1-6 pieces
(1 layer) 12-15 200°C
Thin sausages
Around 70g (diameter 2
cm)
1-7 pieces 9-12 200°C

13
ENGLISH
Ingredients Min.- max.
amount
Time
(min) Temperature
Shake,
turn,
or stir
halfway
Note
Pork roast 500-1000 g 40-60 180°C
Let it rest for 5
minutes before
cutting.
Whole sh
Around 300-400 g 1-2 18-22 200°C
Cut o the tail
if it does not t
into the basket.
Fish lets
Around 120 g
1-3
(1 layer) 9-12 200°C
In order to
avoid sticking,
place the skin
side to the
bottom and
add some oil.
Shellsh
Around 25-30 g 200-1500 g 10-25 200°C Yes
Cake 500g
18 oz 28 180°C Use a cake pan.
Muns
Around 50 g 1-9 12-14 180°C
Use heat-proof
silicone mun
cups.
Quiche (diameter 21 cm) 1 15 180°C
Use a baking
tray or oven
dish.
Pre-baked toast / bread
rolls 1-6 6-7 180°C
Fresh bread 700 g 38 160°C
The shape
should be
as at as
possible to
avoid that the
bread touches
the heating
element when
rising.
Fresh rolls
Around 80 g 1-6 pieces 18-20 160°C
Chestnuts 200-2000 g 15-30 200°C Yes
Mixed vegetable (roughly
chopped) 300-800g 10-20 200°C Yes
Set the cooking
time according
to your own
taste.

14
ENGLISH
Using the appliance
Airfrying
Caution
•This is an Airfryer that works on hot air. Do not ll the pan with
oil, frying fat or any other liquid.
•Do not touch hot surfaces. Use handles or knobs. Handle the hot
pan and fat reducer with oven-safe gloves.
•This appliance is for household use only.
•This appliance may produce some smoke when you use it for the
rst time. This is normal.
•Preheating of the appliance is not necessary.
1 Place the appliance on a stable, horizontal, level and heat-
resistant surface. Make sure the drawer can be opened
completely.
Note
•Do not put anything on top or on the sides of the appliance. This
could disrupt the airow and aect the frying result.
2 Pull the power cord out of the cord storage compartment
at the back of the appliance.
3 Put the plug in the wall outlet.
4 Open the drawer by pulling the handle.

15
ENGLISH
5 Put the ingredients in the basket.
Note
•The Airfryer can prepare a large range of ingredients. Consult the
‘Food table’ for the right quantities and approximate cooking
times.
•Do not exceed the amount indicated in the ‘Food table’ section or
overll the basket beyond the ‘MAX’ indication as this could aect
the quality of the end result.
•If you want to prepare dierent ingredients at the same time,
make sure you check the suggested cooking time required for the
dierent ingredients before you start to cook them simultaneously.
6 Slide the drawer back into the Airfryer by the handle.
Caution
•Never use the pan without the fat reducer or basket in it. If you
heat up the appliance without basket, use oven gloves to open
the drawer. The edges and inside of the drawer become very hot.
•Do not touch the pan, fat reducer or basket during and for some
time after use, as they get very hot.
7 Press the Power On/O ( ) button to switch on the
appliance.
8 To change the preset, turn the QuickControl dial to the
desired setting.
»To conrm the selected preset, push the QuickControl
dial. The cooking time indication blinks on the screen.
1
2

16
ENGLISH
9 To change the cooking time, turn the QuickControl dial to
the desired setting.
»To conrm the selected cooking time, push the
QuickControl dial.
Note
•Refer to the food table with basic cooking settings for dierent
types of food.
10 The appliance starts cooking after the cooking time has
been conrmed.
Tip
•To pause the cooking process, push the QuickControl dial. To
resume the cooking process, push the QuickControl dial again.
Note
•If you do not set the required cooking time within 30 minutes, the
appliance automatically shuts o for safety reasons.
•If “- -” is selected as the time indication, the appliance goes into
preheating mode.
•Some ingredients require shaking or turning halfway through the
cooking time (see ‘Food table’). To shake the ingredients, press
the QuickControl dial to pause cooking, open the drawer and lift
the basket out of the pan and shake it over the sink. Then slide
the pan with the basket back into the appliance, and press the
QuickControl dial to resume cooking.
•If you set the timer to half the cooking time, when you hear the
timer bell it is time to shake or turn the ingredients. Be sure to
reset the timer to the remaining cooking time.
11 When you hear the timer bell, the set preparation time has
elapsed.
12 Open the drawer by pulling the handle and check if the
ingredients are ready.
1
2

17
ENGLISH
Note
•If the ingredients are not ready yet, simply slide the drawer back
into the Airfryer by the handle and add a few extra minutes to the
set time.
13 To remove small ingredients (e.g. fries), lift the basket out
of the pan by the handle.
Caution
•After the cooking process, the pan, the fat reducer, the basket,
interior housing and the ingredients are hot. Depending on the
type of ingredients in the Airfryer, steam may escape from the
pan.
14 Empty the basket contents into a bowl or onto a plate.
Always remove the basket from the pan to empty contents
as hot oil may be in bottom of the pan.
Note
•To remove large or fragile ingredients, use a pair of tongs to lift out
ingredients.
•Excess oil or rendered fat from the ingredients is collected on the
bottom of the pan below the fat reducer.
•Depending on the type of ingredients cooking, you may want to
carefully pour o any excess oil or rendered fat from the pan after
each batch or before shaking or replacing the basket in the pan.
Place the basket on a heat-resistant surface. Wearing oven-safe
gloves, lift the pan o tracks and place on heat-resistant surface.
Carefully remove the fat separator from the pan using rubber
tipped tongs. Pour o excess oil or rendered fat. Return the fat
separator to the pan, the pan to the drawer and the basket to the
pan.
When a batch of ingredients is ready, the Airfryer is instantly
ready for preparing another batch.
Note
•Repeat steps 1 to 14 if you want to prepare another batch.

18
ENGLISH
Changing to another preset during cooking
1 Press the preset ( ) button.
2 Turn the QuickControl dial to select another preset.
3 To conrm the selected preset, push the QuickControl dial.
The cooking time indication blinks on the screen.
4 To change the cooking time, turn the QuickControl dial.
»To conrm the selected cooking time, push the
QuickControl dial.
1
1
1

19
ENGLISH
Using the manual mode
1 Press the preset ( ) button.
2 Turn the QuickControl dial to select the manual mode ( ).
3 Push the QuickControl dial to enter the manual mode.
»The default temperature is 180°C.
4 To change the temperature, turn the QuickControl dial.
»To conrm the temperature, push the QuickControl dial.
5 After the temperature is conrmed, the time indication
“- -” starts blinking.
6 To change the cooking time, turn the QuickControl dial.
»To conrm the cooking time, push the QuickControl dial.
1
2
1
2

20
ENGLISH
Changing the cooking temperature or time at any time
1 Press the temperature ( ) or timer ( ) button.
2 To change the cooking temperature or time, turn the
QuickControl dial.
»To conrm the cooking temperature or time, push the
QuickControl dial or the temperature/timer button
again.
Note
•If you do not press the QuickControl dial or the temperaure/
timer button to conrm the changes, they will be automatically
conrmed after 10 seconds.
1
2
1
2
