◗Ordering Information
Ordering Code C1000S52/ALTO NC HPS
ANSI Designation S52
Product Number 157263
Description High Pressure Sodium
TCLP*Compliant
Non-Cycling
Package Quantity 6
◗Physical Characteristics
Bulb Size ED-25
Bulb Finish Clear
Base ogul Screw
ax. Overall Length ( OL) 15.08" (383mm)
Light Center Length (LCL) 8.74" (222mm)
Arc Length 8.5" (215mm)
Arc Tube Length 9.6" (243mm)
Arc Tube aterial Aluminum Oxide
Operating Position Universal
aximum Permissible Bulb Temperature 400ºC (752°F)
aximum Permissible Base Temperature 210ºC (410°F)
aximum Bulb to Base Eccentricity 3°
aximum Arc Tube to Base Eccentricity 3°
◗Operating Characteristics (Photometric)
Approximate Initial Lumens1130,000
Approximate ean Lumen2117,000
Rated Average Life, Hours330,000
Correlated Color Temperature (CCT) 2100 K
CIE Chromaticity Approximate x-.515, y-.420
Color Rendering Index (CRI) 20
Efficacy (LPW) 130
◗Operating Position
Universal
◗TCLP*Characteristics
Toxicity Characteristic Leaching Procedure (Federal TCLP) Results
Hg Pb
EPA Limit (mg/l) ax 0.200 5.00
C1000S52/ALTO NC HPS 0.062 <0.31
ercury (mg/lamps) ax 11
Ceramalux®High Pressure Sodium Non-Cycling
1000 Watt ED-25 (Clear) Lamp
featuring ALTO®Lamp Technology

Ceramalux®High Pressure Sodium Non-Cycling 1000 Watt ED-25 (Clear) Lamp featuring ALTO®Lamp Technology
Electrical Data (Subject to change without notice)
LampWatts(Nominal)..................................1000
Lamp Operating Voltage (rms) (Nominal). . . . . . . . . . . . . . . . . . 275V
Initial Lamp Voltage Range (rms) . . . . . . . . . . . . . . . . . . . . . . . . . . 250–300V
Lamp Operating Current (Amps) (rms) (Nominal). . . . . . . . . . 4.7
aximum Lamp Starting Current (Amps)(rms) . . . . . . . . . . . . . 8.0
Lamp Current Crest Factor ( aximum) . . . . . . . . . . . . . . . . . . . 1.8
Warm-up Time to 80% of Output . . . . . . . . . . . . . . . . . . . . . . . . 7 inutes
Re-strike Time for Hot Lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 inutes
BallastType............................................ANSIS52
Ballast Open Circuit Voltage ( inimum): . . . . . . . . . . . . . . . . . . 456 Vrms
PulsePeakVolts .......................................2675
Pulse Width @ 90% Peak. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 µs inimum at 2700 Volts
Pulse Frequency ( inimum)
LagBallast .........................................1perCycle
LeadCircuitBallast..................................1perCycle
inimum Operating Temperature. . . . . . . . . . . . . . . . . . . . . . . . . -30°C
Reference Ballast Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77Ω(ohms) minimum at 480V
aximumLampWatts..................................1200
inimumLampWatts ..................................750
aximum Voltage Increase by Fixture . . . . . . . . . . . . . . . . . . . . . 25V
Footnotes:
1) easured at 100 hours of life in vertical and horizontal positions.
2) Approximate mean lumen output at 40% of lamp rated average life. easured in vertical and horizontal operating positions.
3) Rated average life is the life obtained, on the average, from large representative groups of lamps in laboratory tests under controlled conditions at 10 or more operating hours per start.
It is based on survival of at least 65% of the lamps and allows for individual lamps or groups of lamps to vary considerably from the average.
*The TCLP is the US EPA’s Toxicity Characteristic Leaching Procedure.
Philips Lighting Company
200 Franklin Square Drive
P.O. Box 6800
Somerset, NJ 08875-6800
1-800-555-0050
ADivision of Philips Electronics North America Corporation
Updated 1/07 TDS-157263
Philips Lighting
281 Hillmount oad
Markham, Ontario
Canada L6C 2S3
1-800-555-0050
A Division of Philips Electronics Ltd.
www.philips.com
WA NINGS, CAUTIONS AND OPE ATING INST UCTIONS
for Ceramalux High Pressure Sodium Lamps
“WA NING: These lamps must be operated in fixtures designed for use with
High Pressure Sodium lamps.The fixture wattage rating must match the wattage
indicated on the outer glass bulb. Do not scratch the outer bulb or subject it to pressure
as this could cause the outer bulb to crack or shatter. A partial vacuum in the outer bulb
may cause glass to fly if the glass is struck. Operating the lamp improperly may result in
PE SONAL INJU Y, P OPE TY DAMAGE, BU NS AND FI E.
1) If the outer glass bulb is broken, shut off power immediately and remove the lamp
after it has cooled.
2) Use only auxiliary equipment meeting Philips and/or ANSI standards. Use within
voltage limits recommended by ballast manufacturer.
A. Operate lamp only within specified limits of operation.
B. For total supply load refer to ballast manufacturers electrical data.
3) Protect lamp base, socket and wiring against moisture, corrosive atmospheres and
excessive heat.
4) Replace the lamp if the outer glass bulb has been scratched, cracked or damaged
in any way.
5) If a lamp bulb support is used, be sure to insulate the support electrically so as to
avoid possible decomposition of the bulb glass.
6) Do not use this lamp in a fixture which redirects a substantial portion of the
energy toward the arc tube and its immediate vicinity, as this may lead to very
early lamp failure.
7) Take care in handling and disposing of lamps. If arc tube is broken, avoid skin
contact with any of the contents or fragments.
8) The arc tube of this lamp contains sodium and mercury. Dispose of in accordance
with federal, state and local requirements.
