BENEFIT OF UPGRADINGCURRENT LA P PHILIPS ENERGY SAVING
UPGRADE PRODUCT
ENERGY
SAVINGS
(PER LA P)
WATTS
SAVED
(PER LA P)
$28.00†7W††
$21.00†7W††
Philips Energy Advantage T8 25W 4ft
featuring ALTO II™Technology
• Only 1.7 mg of mercury • 36 month warranty period
• 97% lumen maintenance
• Fully dimmable without burn-in
$16.80†7W††
Philips Energy Advantage T8 U-Bent 25W
featuring ALTO®Lamp Technology
• Sustainable lighting solution—reduces the impact on
the environment with only 3 mg of mercury per lamp
• 36 month warranty period
$10.00†5W††,2
Philips Energy Advantage PL-T 27W
featuring ALTO®Lamp Technology
• 88% lumen maintenance
• 15.6% Energy Savings vs. the Standard 32W PL-T2
• Only 1.4 mg of mercury
$8.00†5W††,3
Philips Energy Advantage PL-C 21W
featuring ALTO®Lamp Technology
• 88% lumen maintenance
• 19% Energy Savings vs. the Standard 36W PL-C3
• Only 1.4 mg of mercury
RATED
AVERAGE
LIFE§
40,000 hrs.
@ 12 hr.
Instant Start
30,000 hrs.
@ 12 hr.
Instant Start
24,000 hrs.
@ 12 hr.
Instant Start
20,000 hrs.
@ 12 hr. Start
16,000 hrs.
@ 12 hr. Start
§ Rated average life is the length of operation (in hours) at which point an average of 50% of a large sample of lamps will still be operational and 50% will not.
† Based on (wattage saved) multiplied by (upgrade product rated average life) divided by (1000 x kWh rate (.10)) = Amount saved in dollars.
†† Current lamp watts - Upgrade watts.
1. On Instant Star t ballast, a standard 40W PL-L only draws 32W, so the actual savings is 7W (32W-25W=7W). his is an energy savings of 18% over the standard 40W PL-L (7W/40W=18%).
2. he actual savings when switching from a standard 32W PL- to a Philips Energy Advantage 27W PL- is 5W (32W-27W=5W and 5W/32W=15.6%).
3. he actual savings when switching from a standard 26W PL-C to a Philips Energy Advantage 21W PL-C is 5W (26W-21W=5W and 5W/26W=19%).
Philips Energy Advantage T8 XLL 25W 4ft
featuring ALTO II™Technology
• Only 1.7 mg of mercury • 48 month warranty period
• 97% lumen maintenance
• Fully dimmable without burn-in
Retrofit Solutions—Upgrade your system by simply upgrading the lamps
ADDED BENEFITS
Standard 40W PL-L $16.80†7W††,1
Philips Energy Advantage PL-L 25W
featuring ALTO®Lamp Technology
• 18% Energy Savings vs. the Standard 40W PL-L1
• Only 1.4 mg of mercury • 95% lumen maintenance
24,000 hrs.
@ 12 hr. Start
See reverse side for System Upgrade Solutions.
Healthcare Lighting
Energy Saving Upgrade Guide
Sustainable solutions help create a positive atmosphere and control operational costs
DESIRED
BENEFITS KEY Energy savings Long life Quality of light Low ercury Reduced
aintenance Costs

BENEFIT OF UPGRADING
CURRENT
LA P
CURRENT
BALLAST ADDED BENEFITS
PHILIPS ENERGY SAVING
UPGRADE PRODUCT
PHILIPS ADVANCE
ELECTRONIC
BALLAST UPGRADE
ENERGY
SAVINGS
SYSTE
WATTS
SAVED
34 W††
Philips Energy Advantage
T8 XLL 25W 4ft featuring
ALTO II™Technology
Optanium®High
Efficiency Ballast
IOP-2P32-LW-SC
Philips T8 PLUS 32W
4ft featuring ALTO II™
Technology
Optanium®High
Efficiency Ballast
IOP-2P32-LW-SC
• 36 month warranty period
• 95% lumen maintenance
• Only 1.7 mg of mercury
• Only 1.7 mg of mercury
• Longest life for increased savings on
maintenance and recycling costs
Standard 34W 4ft T12 Electromagnetic Ballast
Standard 34W 4ft T12 Electromagnetic Ballast
$86† 24 W††
$136†
System Upgrade Solutions—Replace lamps and ballasts to meet lighting requirements
RATED
AVERAGE
LIFE§
36,000 hrs.
@ 12 hr.
Instant Start
40,000 hrs.
@ 12 hr.
Instant Start
Philips 800 Series
T8 32W 4ft featuring
ALTO II™Technology
Optanium®High
Efficiency Ballast
IOP-2P32-LW-SC
• 30 month warranty period
• 95% lumen maintenance
• Only 1.7 mg of mercury
• 82 CRI—Excellent color rendering
Standard 34W 4ft T12 Electromagnetic Ballast $72†
24 W††
30,000 hrs.
@ 12 hr.
Instant Start
§ Rated average life is the length of operation (in hours) at which point an average of 50% of a large sample of lamps will still be operational and 50% will not.
† wo lamp system. Based on (wattage saved) multiplied by (upgrade product rated average life) divided by (1000 x kWh rate (.10)) = Amount saved in dollars.
†† Current lamp watts - Upgrade watts. Based on a two lamp system.
See reverse side for Retrofit Solutions.
