Philips HDD100/00 User manual

All my music on the go
Direct MP3 recording
Want all your music and data with you? The hdd100 promises the ultimate music
experience of 10 hours of WMA and MP3 music playback, generous 15GB capacity
and direct MP3 recording - all encased in a stylishly sleek and slim design.
Easy, intuitive music experience on the go
• Simple and easy-to-use interface menus
• SuperScroll™ navigation finds songs in a simple, fast way
Capture all your favorite music
• Make voice memos in MP3
• Record directly to MP3 via analog or digital line-inputs
• Fast downloads from your PC via USB2.0
All your music, your data - on the go, everyday
• 10 hours battery life
• 15GB* capacity for music and data on the go.
• USB mass storage to store and carry your data files
• Super-slim design fits perfectly in your pocket
Philips
Jukebox
15GB*
HDD100

HDD100/00
Specifications Product highlights
Jukebox
15GB*
Date of issue 2007-01-15
Version: 1.0
12 NC: 9073 101 00709
EAN: 87 10895 76772 9
© 2007 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
Picture/Display
• Backlight
•Backlight color: White
•Indications: Battery status, DBB
•Lines of text: 6
•Resolution: 160 x 128
•Type: LCD
Sound
•Bass enhancement: Digital Bass Boost
•Equalizer: 5-bands
• Equalizer customizable
•Equalizer settings: Classic, Jazz, Pop, Rock
•Frequency response: 20 - 20 000 Hz
•Output Power: 2x5mW (16 Ohm)
•Sensitivity: < 100dB
•THD: 0.01-0.1%
•Volume Control: digital, Volume Control up/
down
Audio Playback
•Buffer memory: 32 MB
•Compression format: MP3, Windows Media™
Audio
•ID3 Tag support: Album indication, Album title
and artist name, Genre title, Track title and artist
name
• ID3-tag support
•MP3 bit rates: 8-320 kbps and VBR
•WMA bit rates: 32-192 kbps
•WMA sample rates:
8,11.025,16,22.050,32,44.1,48
Audio Recording
•Audio Jukebox: MP3 recording on HDD
•Bit rate: 64,128,192 kbps
•Line in: analogue, digital
•Recording formats: MPEG1 layer 3 (MP3)
•Recording Media: HDD
Audio Capturing
•Audio file format: MP3
•Built-in microphone: mono
• Voice recording
Storage Media
•Built-in memory type: Hard disk
•Hard Disk Capacity: 15 GB
• Mass storage class compliant
•Music memory capacity: Up to 10,000 songs
Connectivity
•Computer support: PC
•Connector: 3.5 mm stereo
•DC in: 5V
•Front / Side connections: DC-in, Headphone
out, USB type B port
•Headphone: 3.5 mm
•Internet connection options: Upgradeable
•USB: USB 2.0
Convenience
•Backlight: White superbright LED
• Battery charging indication
• Battery full indication
• Battery low indication
•Comfort: Album title and artist name
•Function: Keypad lock
• Headphone jack
•Language support:
Eng,Fr,Spa,NL,Ge,Port,Swe+more
•Lines of text: 6
• Superscroll
•Volume control
Accessories
•AC/DC Adaptor/Charger: Multi-voltage AY3192
•CD-ROM: with installer, PC SW, manuals
•Headphones: SBC HE570/77P
•Included Accessories: CD-ROM with software +
manual, Hi-quality in-ear headphones, Multi
voltage adapter/charger
•Pouch: AY3274
•Printed User Guide
•USB cable: AY3911
•User Guide on CD-ROM:
Eng,Fr,Spa,NL,Ge,Port,Swe
• Warranty Card
Software
•DMM: for PC
Green Specifications
• Lead-free soldered product
System Requirements
•CD-ROM drive
•Hard disk space: 100 MB
•PC OS: Windows 98, 2000, ME, XP
•Processor: Pentium II or better
•RAM memory: 64 MB
•Sound card
•Video card
Dimensions
•Box dimensions (W x H x D):
63 x 153 x 252 mm
•Master carton dimensions: 163 x 89 x 262 mm
•Master carton quantity: 1
•Product dimensions (W x H x D):
64.4 x 106.5 x 19.9 mm
•Product weight: 0.167 kg
Power
•Adaptor type: 100 - 240 V
•Battery capacity: 1200
•Battery Type: LI-Polymer
•Charging time: 4 hrs full, 2 hrs fast charge hr
• Rechargeable
• Removable/ replaceable
•
Easy-to-use interface menus
SuperScroll™ navigation
Double action search keys allow easy speed control
when scrolling through large libraries. You can choose
to move through your playlist one song at a time or just
press and hold down a little harder to SuperScroll™
swiftly to your desired track.
Direct MP3 voice memos
Sing, dictate, record notes directly to MP3 via the built-
in microphone.
Direct MP3 recording
Record directly to MP3 via digital or analog line-in
connections for real-time MP3 encoded files (No PC
required).
Downloads via USB2.0
10 hrs battery life
15GB* capacity
USB mass storage device
USB mass storage devices offer a convenient way to
save, backup and move your files around. The devices
connect to your computer using a USB connection and
do not require any special software to be installed (only
Windows 98 and Me need drivers). The device
automatically shows up as a removable drive in
Windows Explorer allowing you to simply drag and drop
files to and from the device.
Fits perfectly in your pocket
