Fluorescent lamps
Fluorescent lighting is efficient
and economical.The efficacy
(lumen/watt) of all fluorescent
lamps is high compared to most
other light sources.
Different luminaires are available
for various purposes.
TL-D lamps are low-pressure
mercury discharge lamps with a
clear tubular 26 mm envelope.
The tube wall is internally
covered with a mixture of
fluorescent powders.
TL-D Standard colours have a
moderate colour rendering index
(C.R.I. 50 - 75). Especially the red
part of the spectral power
distribution is moderately
covered by standard colours.
TL-D Standard colours are
mostly used in applications
where colour rendering is not an
important parameter.
The efficacy of TL-D Standard
colours is lower than TL-D /80
colours.
The colour designation of TL-D
lamps creates a certain
atmosphere. It varies from warm-
white to cool daylight.The colour
designation is determined by the
colour temperature of the lamp.
Dimensions in mm
TL-D Standard colours
A
Ø 28 max.
B
C
Type A B B C
max. min. max. max.
TL-D 14W 361.2 365.9 368.3 375.4
TL-D 15W 437.4 442.1 444.5 451.6
TL-D 16W 720.0 724.7 727.1 734.2
TL-D 18W 589.8 594.5 596.9 604.0
TL-D 23W/36W-1 970.0 974.7 977.1 984.2
TL-D 30W 894.6 899.3 901.7 908.8
TL-D 36W 1199.4 1204.1 1206.5 1213.6
TL-D 38W 1047.0 1051.7 1054.1 1061.2
TL-D 58W 1500.0 1504.7 1507.1 1514.2
TL-D 70W 1763.8 1768.5 1770.9 1778.0
Commercial Type Cap/ Lamp Lamp Colour Correlated Lumen Average Nett EOC
name base voltage*) current*) designation colour output*) luminance*) weight
temperature
VA Klmcd/cm2g
/25
TL-D TL-D 15W /25 G13 51 0.34 COOL WHITE 4000 900 0.90 76 702760
TL-D TL-D 16W /25 G13 95 0.20 COOL WHITE 4000 1000 0.65 125 614193
TL-D TL-D 18W /25 G13 59 0.36 COOL WHITE 4000 1100 0.80 100 702647
TL-D TL-D 30W /25 G13 98 0.36 COOL WHITE 4000 1900 0.90 145 702814
TL-D TL-D 36W /25 G13 103 0.44 COOL WHITE 4000 2600 0.95 186 702685
TL-D TL-D 36W-1 /25 G13 80 0.56 COOL WHITE 4000 2600 1.10 161 702869
TL-D TL-D 38W /25 G13 104 0.43 COOL WHITE 4000 2550 1.10 162 726667
TL-D TL-D 58W /25 G13 111 0.67 COOL WHITE 4000 4125 1.20 233 702722
/29
TL-D TL-D 15W /29 G13 51 0.34 WARM WHITE 2900 1000 1.00 76 946683
TL-D TL-D 16W /29 G13 95 0.20 WARM WHITE 2900 1100 0.70 125 614223
TL-D TL-D 18W /29 G13 59 0.36 WARM WHITE 2900 1250 0.85 100 702654
TL-D TL-D 30W /29 G13 98 0.36 WARM WHITE 2900 2175 1.05 145 728920
TL-D TL-D 36W /29 G13 103 0.44 WARM WHITE 2900 2975 1.05 186 702692
TL-D TL-D 36W-1 /29 G13 80 0.56 WARM WHITE 2900 2700 1.15 161 702876
TL-D TL-D 58W /29 G13 111 0.67 WARM WHITE 2900 4700 1.35 233 702739
TL-D TL-D 70W /29 G13 132 0.69 WARM WHITE 2900 5450 1.35 272 618344
*) conventional gear

400 500 600 700
100
0
200
300
500
400
TL /25 Ra= 70
Wavelength in nm
µW per 5 nm per lumen
400 500 600 700
100
0
200
300
500
400
TL /33 Ra= 63
Wavelength in nm
µW per 5 nm per lumen
400 500 600 700
100
0
200
300
500
400
TL /29 Ra= 51
Wavelength in nm
µW per 5 nm per lumen
400 500 600 700
100
0
200
300
500
400
TL /35 Ra= 55
Wavelength in nm
µW per 5 nm per lumen
400 500 600 700
100
0
200
300
500
400
TL /54 Ra= 72
Wavelength in nm
µW per 5 nm per lumen
Spectral power distributions
Fluorescent lamps TL-D Standard colours
Commercial Type Cap/ Lamp Lamp Colour Correlated Lumen Average Nett EOC
name base voltage*) current*) designation colour output*) luminance*) weight
temperature
VA Klmcd/cm2g
/33
TL-D TL-D 14W /33 G13 45 0.38 COOL WHITE 4100 730 0.95 66 721754
TL-D TL-D 15W /33 G13 51 0.34 COOL WHITE 4100 960 0.95 76 702777
TL-D TL-D 18W /33 G13 59 0.36 COOL WHITE 4100 1200 0.85 100 702661
TL-D TL-D 23W /33 G13 95 0.30 COOL WHITE 4100 1900 0.90 161 726384
TL-D TL-D 30W /33 G13 98 0.36 COOL WHITE 4100 2100 1.05 145 702821
TL-D TL-D 36W /33 G13 103 0.44 COOL WHITE 4100 2850 1.05 186 702708
TL-D TL-D 36W-1 /33 G13 80 0.56 COOL WHITE 4100 2800 1.20 161 702883
TL-D TL-D 38W /33 G13 104 0.43 COOL WHITE 4100 3100 1.20 162 726698
TL-D TL-D 58W /33 G13 111 0.67 COOL WHITE 4100 4600 1.35 233 702746
TL-D TL-D 70W /33 G13 132 0.69 COOL WHITE 4100 5250 1.30 272 618375
/35
TL-D TL-D 15W /35 G13 51 0.34 WHITE 3500 960 0.95 76 618634
TL-D TL-D 18W /35 G13 59 0.36 WHITE 3500 1150 0.85 100 729002
TL-D TL-D 30W /35 G13 98 0.36 WHITE 3500 2300 1.05 145 618603
TL-D TL-D 36W /35 G13 103 0.44 WHITE 3500 3000 1.10 186 704580
TL-D TL-D 58W /35 G13 111 0.67 WHITE 3500 4600 1.35 233 700704
TL-D TL-D 70W /35 G13 132 0.69 WHITE 3500 5400 1.35 272 615862
/54
TL-D TL-D 14W /54 G13 45 0.38 COOL DAYLIGHT 6200 660 0.85 66 721785
TL-D TL-D 15W /54 G13 51 0.34 COOL DAYLIGHT 6200 830 0.85 76 722218
TL-D TL-D 18W /54 G13 59 0.36 COOL DAYLIGHT 6200 1050 0.75 100 702678
TL-D TL-D 23W /54 G13 95 0.30 COOL DAYLIGHT 6200 1550 0.70 161 726414
TL-D TL-D 30W /54 G13 98 0.36 COOL DAYLIGHT 6200 1825 0.90 145 722638
TL-D TL-D 36W /54 G13 103 0.44 COOL DAYLIGHT 6200 2500 0.95 186 702715
TL-D TL-D 36W-1 /54 G13 80 0.56 COOL DAYLIGHT 6200 2350 1.00 161 726599
TL-D TL-D 58W /54 G13 111 0.67 COOL DAYLIGHT 6200 4000 1.15 233 702753
*) conventional gear

3
Fluorescent lamps TL-D Standard colours
Life expectancy
Life expectancy
Life expectancy
Lumen maintenance
capacitive
inductive
50
60
70
80
90
100
Survivals in %
Operating hours
05000 10000 15000 20000
TL-D Standard colours on conventional gear
(inductive/capacitive)
50
60
70
80
90
100
05000 10000 15000 20000
Lumen in %
Operating hours
Typical values:
5.000 hrs:85%
10.000 hrs:80%
15.000 hrs:75%
TL-D 36W Standard colours on conventional gear
capacitive
50% inductive
50% capacitive
inductive
50
60
70
80
90
100
Survivals in %
Operating hours
05000 10000 15000 20000
Typical values:
5.000 hrs:98%
10.000 hrs:84%
15.000 hrs:n.a.
(50% inductive/50% capacitive)
TL-D Standard colours on conventional gear
50
60
70
80
90
100
Survivals in %
Operating hours
05000 10000 15000 20000
Typical values:
5.000 hrs:99%
10.000 hrs:97%
15.000 hrs:50%
TL-D Standard colours on conventional gear (inductive)
