Philips Slimline T 12 User manual

Ideal for applications where longer
relamp cycles would be beneficial
◗Long Life
–60 has 18,000 hours rated average life1
which is 50% longer than standard
Slimline Econ-O- att
–75 has 15,000 hours rated average life1
which is 25% longer than standard Slimline
◗Sustainable Lighting Solution
Reduces the impact on the environment
–Low mercury
–Energy efficient
–Long life
◗Philips Slimline T12 Warranty Perio :
18 Months
1) Average life under specified test conditions with lamps turned off and restarted no
more frequently than once every 3 operating hours. Lamp life is appreciably longer if
lamps are started less frequently.
Philips Slimline T12 Long Life 8' Lamps
featuring ALTO®Lamp Technology
Environmentally Responsible Lamps:
Long Life and Low Mercury
0 5,000 10,000 15,000 20,0000 5,000 10,000 15,000 20,000
Philips Slimline T12 Long Life 60W
Econ-O-Watt Lamps
Rated Average Life
Philips Slimline T12 Long Life 60W
Econ-O-Watt Lamps
Rated Average Life
12,000
Standard Slimline T12
Rated Average Life in HoursRated Average Life in Hours
18,000
Philips Slimline T12 Long Life 60W Econ-o-Watt
BASED ON 3 HOURS PER START1
0 5,000 10,000 15,000 20,0000 5,000 10,000 15,000 20,000
Philips Slimline T12 Long Life 75W Lamps
Rated Average Life
Philips Slimline T12 Long Life 75W Lamps
Rated Average Life
12,000
Standard Slimline T12
Rated Average Life in HoursRated Average Life in Hours
15,000
Philips Slimline T12 Long Life 75W
BASED ON 3 HOURS PER START1
Photography by Mark Delsasso of Visus, Ltd.

E
Color Nominal Rated Approx. Color
Product Ordering Package Nominal Temp. Length Average Life Initial Design Rendering
Number Code Qty. atts (Kelvin) (in) (hrs)1Lumens2Lumens3(CRI)
14747-0 F96T12/CW/EW/LL/ALTO 15 60 4100K 96 18,000 5400 4750 62
14748-8 F96T12/841/EW/LL/ALTO 15 60 4100K 96 18,000 5900 5550 85
14749-6 F96T12/841/LL/ALTO 15 75 4100K 96 15,000 6600 6225 85
1) Average life under engineering data with lamps turned off and restarted once every 12 operating hours.
2) Approximate initial lumens.The lamp lumen output is based upon lamp performance after 100 hours of operating life, when the output is measured during operation on a reference ballast under standard laboratory conditions.
For expected lamp lumen output, commercial ballast manufacturers can advise the appropriate ballast factor for each of their ballasts when they are informed of the designated lamp.The ballast factor is a multiplier applied to the
designated lamp lumen output.
3) Design lumens are the approximate lamp lumen output at 40%of the lamp’s rated average life.This output is based upon measurements obtained during lamp operation on a reference ballast under standard laboratory conditions.
Lamp meets U Federal Minimum Efficiency tandards.
Philips Slimline T12 Long Life 8' Lamps featuring ALTO®Lamp Technology
Electrical,Technical and Ordering Data ( ubject to change without notice)
E
E
E
Philips Lighting Company
200 Franklin Square Drive
P.O. Box 6800
Somerset, NJ 08875-6800
1-800-555-0050
ADivision of Philips Electronics North America Corporation
Printed in USA 1/07 P-5821
Philips Lighting
281 Hillmount Roa
Markham, Ontario
Cana a L6C 2S3
1-800-555-0050
A Division of Philips Electronics Ltd.
www.philips.com
†This lamp is better for the environment because of its reduced
mercury content. All Philips ALTO®lamps give you end-of-life options
which can simplify and reduce your lamp disposal costs depending on
your state and local regulations.
