Philips Affinium LFM 200 User manual

Lighting food.
Brightening faces.
Affinium™ LED modules LFM 200
for refrigerated display cases
Affinium LED LFM 200 modules offer the following
key benefits:
An excellent total cost of ownership with attractive•
payback times.
A dramatic improvement in visibility of both the•
merchandise on display as well as the entire display case.
Significant reduction in energy consumption and waste, as•
well as the elimination of hazardous substances such as
mercury and lead.
Affinium LED modules represent the latest in solid
state lighting for refrigerated displays. Designed
to replace traditional fluorescent lamps inside
vertical glass-door refrigerated cases, our LFM200
modules feature specialized optics that provide
bright, consistent illumination without the glare
or hotspots associated with older fluorescent
technology.With a slim, streamlined design, the
Affinium LED lighting system provides the perfect
solution for retrofit or new installations in the
refrigerated aisle .

2
Color temperature
Cool White (CW) Affinium LED modules have a correlated color temperature (CCT) of 5600 ± 300K.
Neutral White (NW) Affinium LED modules have a correlated color temperature (CCT) of 4200 ± 300K.
The optical design of Affinium LED modules ensures that the adjacent LEDs in one module are optimally mixed in order to minimize
color differences.
Lighting levels and energy savings
Our products deliver best-in-class light uniformity and are available in two different lighting levels:
•Standardsystem:Deliversin-storelevelsofupto1000luxatthecenterofashelfwitha5inchshelfdistance.
•High-levelsystem:Deliversin-storelevelsofupto1300luxatthecenterofashelfwitha5inchshelfdistance.
The standard lighting level offers energy savings up to 75% with improved illumination compared to fluorescent lighting systems.The high
lighting level offers maximum aesthetics for the presentation of merchandise, while reducing the energy consumption by up to 55%. Both levels
offer superior uniformity, enabling a much better visual impression of the merchandise on display and the entire cooler and freezer sections.
Side1
Side 2
Side 2
Side 1
Connections at the top of the freezer
If the electrical wires are fed through the top of the case,
installtheside1moduleontheleftsideandtheside2
module on the right side of the case.
Connections at the bottom of the freezer
If the electrical wires are fed through the bottom of the
case, install the side 2 module on the left side and the side
1moduleontherightsideofthecase.
The Affinium LED lighting system for refrigerated display cases includes:
LFM 200 modules, 24VDC Xitanium™ LED power drivers, and mounting extrusions.
About Affinium LED modules LFM 200
The LFM 200 module is suitable for full-height glass door refrigerated display cases and is available in 59” and 67” lengths.
Both lengths are available in three versions:
Center module•
Side1module•
Side 2 module•
Theside1or2modulecanbeplacedoneithersideofthecase,dependingonthewiringschemefollowed.
Affinium LED lighting
C1
A3
A1 B1 B1
B1
SideCenterSide
C1
A3
A1 B1 B1
B1
Affinium LED modules
LFM 200 59” center module
LFM20059”side1module
LFM 200 59” side 2 module
LFM 200 67” center module
LFM20067”side1module
LFM 200 67” side 2 module
Dimensions (in)
A1 A3 B1
59.06 59.45 2.20
59.06 59.45 1.93
59.06 59.45 1.93
66.93 67.32 2.20
66.93 67.32 1.93
66.93 67.32 1.93

3
Type Power nominal
W
Color temperature
K
Color rendering index
CRI
Standard lighting level 1000 lux
LFM 200 59” center CW 25 5300-5900 ≥ 72
LFM20059”side1CW 15 5300-5900 ≥ 72
LFM 200 59” side 2 CW 15 5300-5900 ≥ 72
LFM 200 59” center NW 25 3900-4500 ≥72
LFM20059”side1NW 15 3900-4500 ≥72
LFM 200 59” side 2 NW 15 3900-4500 ≥72
High lighting level 1300 lux
LFM 200 59” center NW 35 3900-4500 ≥72
LFM20059”side1NW 22 3900-4500 ≥72
LFM 200 59” side 2 NW 22 3900-4500 ≥72
Affinium LED modules, 59” length
Lifetime
The lifetime of Affinium LED modules is rated at 50,000 hours (70% lumen maintenance).
Temperature
Operating temperature (performances): T
operating min-13°F / max +50°F
Safety temperature (operating, no defects) Tsafety min -22°F / max +86°F
Storage temperature Tstorage min -22°F/max+140°F
Enhanced safety
In the event of unit damage, when used with a Safety Extra LowVoltage (SELV), energy-limited, class-2 Xitanium™ driver,
the Affinium LED system provides a safer operating environment than that of a fluorescent system.
Compliances and approvals
Affinium LED modules comply with all applicable regulations including:
ENEC   •CE•
Productsafety,classIII •RoHScompliant•
WEEE   •EUdirective2002/95/EC•
UL   •NSF•
Type Power nominal
W
Color temperature
K
Color rendering index
CRI
Standard lighting level 1000 lux
LFM 200 67” center CW 31 5300-5900 ≥72
LFM20067”side1CW 20 5300-5900 ≥ 72
LFM 200 67”side 2 CW 20 5300-5900 ≥72
LFM 200 67” center NW 31 3900-4500 ≥ 72
LFM20067”side1NW 20 3900-4500 ≥ 72
LFM 200 67”side 2 NW 20 3900-4500 ≥ 72
High lighting level 1300 lux
LFM 200 67” center NW 44 3900-4500 ≥72
LFM20067”side1NW 28 3900-4500 ≥72
LFM 200 67” side 2 NW 28 3900-4500 ≥ 72
* Notes on lighting levels and energy savings:
Lighting levels are measured by a CCD camera at the center of the shelf at the center-most door of the case with a 5 inch distance between the
back of the module and the front of the merchandise.These measurements were taken at in-store lighting level conditions.Values for nominal
power and lighting levels can deviate by 20%, measured at -4°F (-20°C). Due to insufficient data points the values are best estimations.
Affinium LED modules, 67” length

Ordering details
Type Quantity
per pack
Ordering
code
Standard lighting level 1000 lux
LFM 200 1500mm (59”) center 25W CW 1 9290 001 37113
LFM 200 1500mm (59”) side 1 15W CW 1 9290 001 37213
LFM 200 1500mm (59”) side 2 15W CW 1 9290 001 37313
LFM 200 1500mm (59”) center 25W NW 1 9290 001 37413
LFM 200 1500mm (59”) side 1 15W NW 1 9290 001 37513
LFM 200 1500mm (59”) side 2 15W NW 1 9290 001 37613
High lighting level 1300 lux
LFM 200 1500mm (59”) center 35W NW 1 9290 004 55813
LFM 200 1500mm (59”) side 1 22W NW 1 9290 004 55913
LFM 200 1500mm (59”) side 2 22W NW 1 9290 004 56013
Affinium LED modules, 59” length
Type Part Number
LFM200 60” Center Mounting Extrusion LFM200EXT60INCRM
LFM200 72” Center Mounting Extrusion LFM200EXT72INCRM
LFM200 60” Side Mounting Extrusion (both sides) LFM200EXT60INSDM
LFM200 72” Side Mounting Extrusion (both sides) LFM200EXT72INSDM
Retrofit Mounting Extrusions
©2008 Philips Lighting Electronics N.A.
All rights reserved.
FormNo.PA-7020-R0110/08
Philips Lighting Electronics N.A.
10275W.HigginsRoad
RosemontIL60018
Tel:800-322-2086Fax:888-423-1882
CustomerSupport/TechnicalService:800-372-3331
OEMSupport:866-915-5886
www.philips.com/advance
Type Quantity
per pack
Ordering
code
Standard lighting level 1000 lux
LFM 200 1700mm (67”) center 31W CW 1 9290 001 38313
LFM 200 1700mm (67”) side 1 20W CW 1 9290 001 38413
LFM 200 1700mm (67”) side 2 20W CW 1 9290 001 38513
LFM 200 1700mm (67”) center 31W NW 1 9290 001 38613
LFM 200 1700mm (67”) side 1 20W NW 1 9290 001 38713
LFM 200 1700mm (67”) side 2 20W NW 1 9290 001 38813
High lighting level 1300 lux
LFM 200 1700mm (67”) center 44W NW 1 9290 004 56413
LFM 200 1700mm (67”) side 1 28W NW 1 9290 004 56513
LFM 200 1700mm (67”) side 2 28W NW 1 9290 004 56613
Affinium LED modules, 67” length
