H.I.D. lamps MASTER Colour CDM-R
CDM-R lamps have to be used in
combination with a ballast and an
ignitor or a suitable fully
electronic ballast, like the Philips
PrimaVision range.
For a satisfactory operation of the
lamp on conventional gear, the
mains supply should not fluctuate
more than 5% from the rated
voltage of the ballast. If there is a
constant deviation of more than
3 % of the rated voltage, another
ballast rating is recommended.
Burning position: universal.
Note
CDM-R is equipped with an
E27 lamp base, E27 lampholders
used must be suitable for
ignition peaks up to 5 kV.
Applications
- Accent/decorative lighting:
sparkling, theatrical effects in
display lighting, even in
surroundings with a high
luminance level like shop
windows.
- General lighting: in downlighters,
a warm, comfortable
atmosphere can be created.
The CDM-R comprises a range of
reflector metal halide lamps with
a warm colour impression
(3000 K) and excellent colour
rendering.
High beam intensities can be
created thanks to the small axial
discharge arc, optimally positioned
in the internal reflector.
Low operating costs result from
the high lamp efficacy, combined
with long lamp life compared to
incandescent and halogen lamps.
The CDM-R's unique "effect/lamp
volume" ratio increases flexibility
in application and allows powerful
lighting accents from
inconspicuous luminaires.
Ease of luminaire design is
provided since the CDM-R lamps
can be used in open luminaires.
In indoor applications comfort is
enhanced because of the
relatively low heat output of the
lamps.
The lamps contain a UV-Block
burner capsule for reduced fading
risks.
35 W PAR 20L 30º
35 W PAR 20L 10 degrees
35 W PAR 30L 10º 35 W PAR 30L 30º 70 W PAR 30L 10º
Dimensions in mm
Burning position
70 W PAR 30L 40º
∅97 max.
125 max.
∅65 max.
95 max.
Universal
PAR 30PAR 20
2
H.I.D. lamps MASTER Colour CDM-R
300 400 500 600 700 800
50
100
150
200
250
300 CDM
Wavelength in nm
mW per 5 nm
per lumen
12345
200
160
120
40
0
CDM
Time in min.
%
lamp current
lamp wattage
luminous flux
lamp voltage
80
92 96 100 104 108
125
115
105
95
85
75
CDM
Relative supply voltage in %
%
lamp current
lamp wattage
luminous flux
lamp voltage
Spectral power distribution
Effects of mains voltage variations
Lamp performance during run-up
Commercial Type Cap/ Lamp Lamp Correlated Lumen Colour Max Lamp
name base wattage voltage colour output rendering luminous current
temperature reflector index intensity
WV Klm cdA
CDM-R
MASTER Colour CDM-R CDM-R 35W/830 PAR20L10DG E27 38 88 3000 2000 81 23000 0.5
MASTER Colour CDM-R CDM-R 35W/830 PAR20L30DG E27 38 88 3000 2000 81 5000 0.5
MASTER Colour CDM-R CDM-R 35W/830 PAR30L10DG E27 38 88 3000 2200 81 44000 0.5
MASTER Colour CDM-R CDM-R 35W/830 PAR30L30DG E27 38 88 3000 2200 81 7400 0.5
MASTER Colour CDM-R CDM-R 70W/830 PAR30L10DG E27 73 90 3000 4850 83 68000 1.0
MASTER Colour CDM-R CDM-R 70W/830 PAR30L40DG E27 73 90 3000 4850 83 10000 1.0
Commercial Type Maximum Maximum Chromaticity Chromaticity Minimum Nett EOC
name permissible permissible coordinate coordinate ignition weight
base/pinch bulb supply
temperature temperature voltage
°C °C x y V g
CDM-R
MASTER Colour CDM-R CDM-R 35W/830 PAR20L10DG 200 300 433 402 198 120 198082
MASTER Colour CDM-R CDM-R 35W/838 PAR20L30DG 200 300 433 402 198 120 198105
MASTER Colour CDM-R CDM-R 35W/830 PAR30L10DG 200 300 431 400 198 225 197016
MASTER Colour CDM-R CDM-R 35W/830 PAR30L30DG 200 300 431 400 198 225 197030
MASTER Colour CDM-R CDM-R 70W/830 PAR30L10DG 200 300 427 397 198 225 197054
MASTER Colour CDM-R CDM-R 70W/830 PAR30L40DG 200 300 427 397 198 225 197078
3
H.I.D. lamps MASTER Colour CDM-R
PAR 20/035 10D 1 x CDM-R20-35W / 830
LVE021920C
Polar intensity diagram
(cd) 0o
180o
30oo
30
60oo
60
90oo
90
120oo
120
5000
10000
15000
20000
25000
30000
γ
Visual impact diagram
Accent
factor
2
5
10
15
30
50
100
Eh(lx)25 50 100 250 500 1000
2.00m
1.50m
1.00m
0.50m
Beam diagram
h
h(m) (m) (lx) VBA 1/2Imax
E0d(m)
K4
0.50
1.00
1.50
2.00
2.501.5 1.0 0.5 0.0 0.5 1.0 1.5 (m)
0.50 92001 0.09 0.11
0.75 40889 0.13 0.16
1.00 23000 0.17 0.21
1.25 14720 0.22 0.26
1.50 10222 0.26 0.32
1.75 7510 0.31 0.37
2.00 5750 0.35 0.42
2.25 4543 0.39 0.47
o
2 x 6
max
I
2
/
1
VBA 2 x 5o
PAR 20/035 30D 1 x CDM-R20-35W / 830
LVE021910C
Polar intensity diagram
(cd) 0o
180o
30oo
30
60oo
60
90oo
90
120oo
120
1000
2000
3000
4000
5000
γ
Visual impact diagram
Accent
factor
2
5
10
15
30
50
100
Eh(lx)25 50 100 250 500 1000
2.00m
1.50m
1.00m
0.50m
Beam diagram
h
h(m) (m) (lx) VBA 1/2Imax
E0d(m)
K4
0.50
1.00
1.50
2.00
2.501.5 1.0 0.5 0.0 0.5 1.0 1.5 (m)
0.50 20000 0.31 0.29
0.75 8889 0.46 0.43
1.00 5000 0.61 0.57
1.25 3200 0.76 0.72
1.50 2222 0.92 0.86
1.75 1633 1.07 1.00
2.00 1250 1.22 1.15
2.25 988 1.38 1.29
o
2 x 16
max
I
2
/
1
VBA 2 x 17o
PAR 30L/035 10D 1 x CDM-R30-35W / 830
LVE019360C
Polar intensity diagram
(cd) 0o
180o
30oo
30
60oo
60
90oo
90
120oo
120
10000
20000
30000
40000
50000
γ
Visual impact diagram
Accent
factor
2
5
10
15
30
50
100
Eh(lx)25 50 100 250 500 1000
2.00m
1.50m
1.00m
0.50m
Beam diagram
h
h(m) (m) (lx) VBA 1/2Imax
E0d(m)
K4
0.50
1.00
1.50
2.00
2.501.5 1.0 0.5 0.0 0.5 1.0 1.5 (m)
0.50 --- 0.09 0.09
0.75 78222 0.13 0.13
1.00 44000 0.17 0.17
1.25 28160 0.22 0.22
1.50 19556 0.26 0.26
1.75 14367 0.31 0.31
2.00 11000 0.35 0.35
2.25 8691 0.39 0.39
o
2 x 5
max
I
2
/
1
VBA 2 x 5o
4
PAR 30L/035 30D 1 x CDM-R30-35W / 830
LVE019380C
Polar intensity diagram
(cd) 0o
180o
30oo
30
60oo
60
90oo
90
120oo
120
1500
3000
4500
6000
7500
γ
Visual impact diagram
Accent
factor
2
5
10
15
30
50
100
Eh(lx)25 50 100 250 500 1000
2.00m
1.50m
1.00m
0.50m
Beam diagram
h
h(m) (m) (lx) VBA 1/2Imax
E0d(m)
K5
0.50
1.00
1.50
2.00
2.501.5 1.0 0.5 0.0 0.5 1.0 1.5 (m)
0.50 29600 0.27
0.75 13155 0.40
1.00 7400 0.54
1.25 4736 0.67
1.50 3289 0.80
1.75 2416 0.94
2.00 1850 1.07
2.25 1462 1.21
o
2 x 15
max
I
2
/
1
NO VISIBLE SPOT
H.I.D. lamps MASTER Colour CDM-R
PAR 30L/070 10D 1 x CDM-R30-70W / 830
LVE019330C
Polar intensity diagram
(cd) 0o
180o
30oo
30
60oo
60
90oo
90
120oo
120
15000
30000
45000
60000
75000
γ
Visual impact diagram
Accent
factor
2
5
10
15
30
50
100
Eh(lx)25 50 100 250 500 1000
2.00m
1.50m
1.00m
0.50m
Beam diagram
h
h(m) (m) (lx) VBA 1/2Imax
E0d(m)
K4
0.50
1.00
1.50
2.00
2.501.5 1.0 0.5 0.0 0.5 1.0 1.5 (m)
0.50 --- 0.09 0.09
0.75 --- 0.13 0.13
1.00 67997 0.17 0.17
1.25 43518 0.22 0.22
1.50 30221 0.26 0.26
1.75 22203 0.31 0.31
2.00 16999 0.35 0.35
2.25 13432 0.39 0.39
o
2 x 5
max
I
2
/
1
VBA 2 x 5o
PAR 30L/070 40D 1 x CDM-R30-70W / 830
LVE019350C
Polar intensity diagram
(cd) 0o
180o
30oo
30
60oo
60
90oo
90
120oo
120
2000
4000
6000
8000
10000
γ
Visual impact diagram
Accent
factor
2
5
10
15
30
50
100
Eh(lx)25 50 100 250 500 1000
2.00m
1.50m
1.00m
0.50m
Beam diagram
h
h(m) (m) (lx) VBA 1/2Imax
E0d(m)
K5
0.50
1.00
1.50
2.00
2.501.5 1.0 0.5 0.0 0.5 1.0 1.5 (m)
0.50 39999 0.34
0.75 17777 0.52
1.00 10000 0.69
1.25 6400 0.86
1.50 4444 1.03
1.75 3265 1.21
2.00 2500 1.38
2.25 1975 1.55
o
2 x 19
max
I
2
/
1
NO VISIBLE SPOT
