Lensed Recessed CFL Downlighting 1050SQ_3D
5" Square, 1 Lt., CFL, Low-Profile IC Airseal® Energy Star® FIK
Complete Fixture consists of Frame-In Kit and Reflector Trim. Select each separately.
Xceed Compact Fluorescent Lensed Square Reflector Trims
*All frames come standard with preset mounting screws and
a 2700K lamp. Models are available with preset nails and/or a
3500K lamp. (13ES = 2700K only). Simply add an N and/or 35 to
the end of the model number for those options.
Compatible Xceed Frame-In Kits
(See Individual Frame-In Kit Specification Sheets)
Catalog No. Installation Type Lamping
1050SQ13ES* IC Airseal®120v 13w Triple
1050SQ18ES* IC Airseal®120v 18w Triple
1050SQ26ES* IC Airseal®120v 26w Triple
Downlight Slope/Wall Washer
Adobe Reader 7.0 or above is required to fully utilize Lightolier’s 3D PDF le. You can download the latest free Adobe Reader at www.adobe.com.
3 Dimensional Supplement
For complete details please see specication sheet
Click on the image below to launch the Acrobat 3D toolbar. Once the toolbar
appears make a selection and begin exploring the three-dimensional model.
1050SQDLWB 1050SQSLWWB
White Baffle with White Flange
1050SQDLCDW 1050SQSLWCDW
Clear Diffuse with White Flange
1050SQDLCDP 1050SQSLWCDP
Clear Diffuse with Clear Diffuse Flange
1050SQDLWDW 1050SQSLWWDW
Warm Diffuse with White Flange
1050SQDLWDP 1050SQSLWWDP
Warm Diffuse with Warm Diffuse Flange
