Philips SA2105 User manual

For preview purpose only
Your digital music on the move
with MP3, WMA music playback & FM radio
Enjoy your MP3 and WMA music on the move with the Philips SA21XX. With direct
USB for fast and easy music and data transfer.
Your music, your data - on the go, everyday
• Enjoy MP3 and WMA playback
• Make voice recordings
• Fast downloads from your PC via USB 2.0*
• More music with Digital FM Radio with 10 station presets
Ready to wear, Ready to go
• Enjoy up to 10 hours music playback*
• Direct USB – no cables needed
• Simply drag and drop your songs – no software needed
• Plug and play data storage
Easy, intuitive music experience
• Easy-to-read black and white LCD display
• Equalizer for optimized sound to suit your music style
• Folder view to find songs in a simple, fast way
Philips
Flash audio player
512MB*
SA2105

SA2105/37
Specifications Product highlights
Flash audio player
512MB*
Date of issue 2007-06-06
Version: 1.0
12 NC: 8670 000 30631
UPC: 6 09585 13415 7
© 2007 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
Picture/Display
• Backlight
•Lines of text: 2
•Resolution: 32 x 128
•Type: LCD
Sound
•Channel separation: 35 dB
•Equalizer settings: Classic, Jazz, Pop, Rock
•Frequency response: 80 - 18 000 Hz
•Output power (RMS): 2 x 3 mW
•Signal to noise ratio: > 80 dB
Audio Playback
•Compression format: MP3, WAV, Windows
Media™ Audio
•ID3 Tag support: Track title and artist name
•MP3 bit rates: 8-320 kbps and VBR
•MP3 sample rates: 8, 11.025, 16, 22.050, 24,
32, 44.1, 48 kHz
•WMA bit rates: 64-320 kbps
•WMA sample rates: 8, 11.025, 16, 22.050,
32, 44.1, 48 kHz
Audio Capturing
•Audio file format: WAV
•Built-in microphone: mono
•Voice recording: ADPCM
Storage Media
•Built-in memory capacity: 512 MB
•Built-in memory type: NAND Flash
• Mass storage class compliant
•Music memory capacity, WMA: Up to 240
tracks*
Connectivity
•Headphone: 3.5 mm
•USB: High-speed USB 2.0
Convenience
• Firmware upgradeable
•Function: Keypad lock
Accessories
•Batteries: AAA Alkaline
•Headphones: AY3812
•User Guide on CD-ROM
Software
•Device manager: to restore and upgrade
Green Specifications
• Lead-free soldered product
System Requirements
•CD-ROM drive
•Internet connection: Yes (for access to
updated support documents, manuals, future
firmware and PC software upgrades)
•PC OS: Windows 2000, Me, XP
•USB: Free USB port
Dimensions
•Blister dimensions (WxDxH): 135 x 38 x
195 mm
•Packaging type: Clamshell
•Product dimensions (WxDxH): 31.5 X 23 X
77.8 mm
Power
• Batteries included
•Battery type: AAA / LR03 Alkaline
•Playtime on external battery: Up to 10 hours
Tuner/Reception/Transmission
•Tuner Bands: FM
•
