Philips SNB5600/00 User manual

What’s in the box
What else will you need
1Install
●Insert the installation CD into the
PC’s CDROM (or DVDROM) drive
>The installation program will start
automatically
●Follow instructions on the screen
Choose your language
B
By default, the language of your
operating system will be chosen,
but you have 10 seconds if you
want to select another one.
●Click on the required language
>The next screen will be displayed
automatically
Insert installation CD
A
If for some reason the installation
does not start automatically :
●Click on Windows START and
then RUN
●Type explorer and navigate to the
CDROM (or DVDROM) drive
●Double-click on Setup.exe
Choose your product
C
●Click on the picture of the
SNB5600 Wireless Router
>The next screen will be displayed
automatically
2Connect
Follow instructions on the screen
Connect power adapter
A
●Connect the supplied power
adapter to the 9V DC port on the
router
●Connect the power plug to the
electricity supply socket
>Power light will turn on
Connect the modem to the router
B
Connect the router to the PC
C
●Take the Ethernet cable provided in
the box
●Connect this Ethernet cable to the
LAN 1 port on the SNB5600
●Connect the other side of the
Ethernet cable to your computer
>LAN 1 light will turn on
●Then click on Continue
>A progress bar screen will be displayed
Put your mouse over the red
circles on your screen to enlarge
pictures.
3111 285 40831
Wireless router
Ethernet cable
Quick start guide
1
2
3
Connect
Install
Enjoy
SNB5600
Quick start guide
Installation CDROM
Power adapter
A desktop or a
laptop with free
USB port
W
E
B
B
R
O
W
S
E
R
A modem A web browser An Internet
connection
●If your computer is already
connected via Ethernet, then
disconnect this cable from your
computer
●Connect this Ethernet cable to the
WAN port of the SNB5600
> WAN light will turn on
QSG_SNB5600_EN_Euro1_24.08.07.qxp 24.08.2007 14:55 Seite 1

Connected to Internet
E
Enter Internet Service Provider settings
D
●Fill in the fields using the
information provided by your
Internet Service Provider
●Click on Continue
>A progress bar screen will be
displayed, your settings will be saved
and you will be connected to Internet
> The next screen will be displayed
Once the installation completed,
the following screen will be
displayed.
●Click on Menu if you want to go
back to the menu screen
Secure your network
F
Your WiFi network is running
but not secured.
●Click on Set Encryption
> Your WiFi network will be secured by
generating automatically an Encryption
key and a network name (SSID)
At any time you can retrieve your wireless security settings using your
installation CDROM on the computer where you installed your gateway and by
clicking on the security icon of the menu page.
Open Internet address
B
●Enter Internet address
For example : www.philips.com
●Select GO
3Enjoy
W
E
B
B
R
O
W
S
E
R
AOpen Internet browser
Wireless freedom
Enjoy the freedom of wireless networking.Your computer is
now ready for full use anywhere in your home.
Welcome to Philips!
Register your product and get support at
www.philips.com/welcome
Quick Start Guide
1Install
2Connect
3Enjoy
Depending on your modem settings, you might have the following screen
displayed.
SNB5600
QSG_SNB5600_EN_Euro1_24.08.07.qxp 24.08.2007 14:56 Seite 2
