Philips VisaPure Men User manual

© 2016 Koninklijke Philips Electronics N.V.
All rights reserved.
Document order number: 4222.002.5588.3 10/2016
Quick start guide
VisaPureMen

1
6 7 8
9
11
10
2
3
4
5
1

English
Introduction
Thank you for choosing to buy Philips VisaPure Men. Before you get started, we hope you will register your
product at www.philips.com/welcome in order to enjoy dedicated product support and offers designed
especially for you. So what is VisaPure Men and how can it help your skin? Cleansing is an essential part of
the daily skincare routine, but traditional methods do not always leave your skin as clean and radiant as it
could be. That is why we have developed VisaPure Men - our exciting new approach to facial cleansing for
men. The DualMotion technology of VisaPure Men combines rotating and vibrating movements allowing the
bristles to cleanse deeply seated oil, dirt and dead skin cells from your face. You will notice the cleansing
effect immediately - experiencing smoother, more radiant skin. It also helps enhance your grooming routine,
whatever your style is (clean-shaven or bearded). Designed to complement your current routine, use the
appliance with your own daily cleansing product. VisaPure Men comes ready to use with two brush heads:
Normal brush head for daily cleansing of normal, combination or oily skin and exfoliation brush head for
weekly removal of dead skin cells. Additional brush head types are available separately. Ready to get
started? Enjoy making VisaPure Men part of your daily grooming routine and have a well-cleansed, smooth
and radiant skin every day.
3
English

General description
1 Handle
2 Charging light and battery low indication
3 On/off button
4 Connection pin
5 Charging pins
6 Brush head
7 Protection cap
8 Appliance socket
9 Charging stand
10 Small plug
11 Adapter
Important safety information
Read this important information carefully before you use the appliance and save it for future reference.
4

Danger
Keep the adapter dry.
Warning
- Only use the appliance in combination with the adapter supplied.
- Do not use the appliance, a brush head or the adapter if it is damaged
or broken to avoid injuries.
- If the adapter is damaged, always have it replaced with one of the
original type in order to avoid a hazard.
- The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this causes a hazardous situation.
5
English

- Fully charge the appliance at least every 3 months to sustain battery
lifetime.
- This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and if they
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
- This appliance is NOT a toy. Keep the appliance out of the reach of
children.
6

- Do not insert metal-containing material into the socket for the
appliance plug to avoid short circuiting.
Caution
- This appliance is developed and intended for cleansing facial skin on
cheeks, forehead and chin (including the area between eyes and ears
and the area between nose and upper lip, excluding the area around
the eyes) and on the neck. Do not use the appliance for any other
purpose.
7
English

- Do not use the appliance more than twice a day when the normal
brush head is on. When the exfoliation brush is on, do not use the
device more than once per week.
- For hygienic reasons, we advise you to not share the appliance with
other people.
- Do not clean the appliance with water that is hotter than shower
temperature (max. 40°C/104°F).
- Do not put the appliance or any part in the dishwasher.
- Charge, use and store the appliance at a temperature between
10°C/50°F and 40°C/104°F.
8

- Do not use the appliance on chapped skin, open wounds, or when
you suffer from skin diseases or skin irritations, such as severe acne,
sunburn, skin infection, etc.
- Do not use the appliance if you are taking steroids.
- Do not use the appliance with self-made cleansers or cleansers
containing harsh chemicals or rough particles.
General
- Please note that the condition of the skin varies throughout the year. Facial skin can get dryer during the
winter season. In that case you may reduce the treatment time or frequency, depending on the needs of
your skin.
9
English

- If you have sensitive skin, select speed 1 the first few times you use the appliance. If you do not
experience any skin reactions, you can start using the appliance at speed 2. If you still have a sensitive
skin, we advise you to switch to the sensitive brush head (MS591, available separately).
- Regular cleaning of the appliance ensures optimal results and a longer life.
- The appliance complies with the internationally approved IEC safety regulations and can be safely used
in the bath or shower and cleaned under the tap.
- The appliance is equipped with an automatic voltage selector and is suitable for mains voltages ranging
from 100 to 240 volts.
Electromagnetic fields (EMF)
This Philips device complies with all applicable standards and regulations regarding exposure to
electromagnetic fields.
10

Preparing for use
Charging the appliance
Charging the appliance takes approximately 6 hours. A fully charged appliance has a cordless operating time
of up to 30 minutes.
1 Make sure the appliance is switched off.
2 Insert the small plug in the socket of the charging stand (1) and put the adapter in the wall socket (2).
Remove the protection cap and place the appliance in the charging stand (Fig. 2).
3 The charging light flashes white to indicate that the appliance is charging. When the battery is fully
charged, the charging light lights up white continuously (Fig. 3).
Battery-low indication
When the battery is almost empty, the charging light flashes orange for 15 seconds (Fig. 4). The battery still
contains enough energy for a complete treatment.
11
English

Using the appliance
Make sure the appliance is fully charged before you use it for the first time.
Note: You can either use the appliance in front of the sink, in the shower or in the bathtub.
Tip: Using the brush daily to cleanse your face will improve your grooming routine and help you have a
more comfortable shave or a soft beard.
Facial cleansing with VisaPure Men
Speed settings
You can choose between two different speed settings depending on your personal preference.
- Speed 1, ‘gentle cleansing’, for a mild and soft cleansing.
- Speed 2, ‘deep cleansing’, for a comfortable and more intensive cleansing.
Auto shut-off
The appliance automatically switches off after one minute to prevent overtreatment.
12

Cleansing procedure
Note: Do not use the appliance more than twice a day when the normal brush head is on. Use the
appliance only once per week when the exfoliation brush head is on.
1 Push the brush head onto the connection pin until it locks into position with a click (Fig. 5).
2 Apply some water to your skin (Fig. 6).
3 Moisten the brush head with water and/or liquid cleanser or apply the cleanser directly on your skin
before you use the appliance. Do not use the appliance with a dry brush head, as this can irritate the skin
(Fig. 7).
4 Place the brush head on your skin (Fig. 8).
5 Press the on/off button once to switch on the appliance. The appliance starts to operate at speed 1. Press
twice for speed 2. Press three times to switch off the appliance or wait until it stops automatically (Fig. 9).
6 Gently move the brush head across your skin from the nose towards the ear . Do not push the brush head
too hard onto the skin to make sure the treatment remains comfortable (Fig. 10).
13
English

Cleaning and maintenance
Note: The accessories supplied may vary for different products. The box shows the accessories that have
been supplied with your appliance.
Never use scouring pads, abrasive cleaning agents or aggressive liquids such as petrol or acetone to clean
the appliance.
Cleaning the appliance and the brush head
Clean the appliance and the brush head thoroughly with water after each use, to ensure optimum
performance. Make sure the appliance is switched off before you start cleaning it.
1 Remove the brush head from the appliance and rinse it under the tap with warm water (max. 40ºC /
104ºF (Fig. 11)).
2 Clean the back of the brush head and the connection pin of the appliance under the tap at least once a
week.
3 Dry these parts with a towel (Fig. 12).
14

Cleaning the adapter and the charging stand
Danger: Always keep the adapter dry. Never rinse it under the tap or immerse it in water.
1 Make sure the adapter is unplugged when you clean it. Only wipe it with a dry cloth.
2 Always detach the charging stand from the adapter before you clean it (Fig. 13).
3 You can clean the charging stand with a moist cloth (Fig. 14). Dry the charging stand before you reconnect
it to the adapter
Storage
Store the appliance with the brush head attached in the charging stand without the protection cap (Fig. 15).
Note: Never put the protection cap on the brush head if the brush head is still wet.
- For traveling: put the protection cap on the dry brush head to protect the brush head bristles when you
take the appliance with you (Fig. 16).
15
English

Brush head replacement
Worn bristles could lead to skin irritation. Therefore, and for a hygienic cleanse, the normal brush head
(MS590) should be replaced every 3 months or earlier if the bristles are deformed or damaged. The weekly
exfoliation brush head (MS592) can be replaced every 6 months as the usage frequency is lower.
Replacement brush heads and additional brush head types are available from our website
www.shop.philips.com/service or from the shop where you purchased your Philips appliance. If you have
any difficulties obtaining replacement brush heads, please contact the Philips Consumer Care Centre in your
country. You find its contact details in the worldwide guarantee leaflet. You can also visit
www.philips.com/support.
Recycling
- This symbol means that this product shall not be disposed of with normal household waste (2012/19/EU).
16

- This symbol means that this product contains a built-in rechargeable battery which shall not be disposed
of with normal household waste (2006/66/EC). We strongly advise you to take your product to an official
collection point or a Philips service centre to have a professional remove the rechargeable battery.
- Follow your country’s rules for the separate collection of electrical and electronic products and
rechargeable batteries. Correct disposal helps prevent negative consequences for the environment and
human health.
Removing the rechargeable battery before discarding the appliance
1 Remove the appliance from the charging stand, switch on the appliance and let it operate until it switches
off after one minute. Repeat this action until the rechargeable battery is empty.
2 Insert a small flathead screwdriver between the silver- colored ring and the anti-roll ridge and pry loose
the top part of the appliance. Carefully pull the top part with the battery holder out of the housing.
3 Remove the rechargeable battery from the battery holder (Fig. 18).
Warning: Do not attempt to replace the rechargeable battery.
17
English

Warning: Do not reconnect the appliance to the mains after you have removed the
rechargeable battery.
Warranty and support
If you need information or support, please visit www.philips.com/support or read the international warranty
leaflet.
Troubleshooting
This chapter summarises the most common problems you could encounter with the appliance. If you are
unable to solve the problem with the information below, visit www.philips.com/support for a list of
frequently asked questions or contact the Consumer Care Centre in your country.
18

Problem Solution
I do not know if the
appliance is suitable for use
on my skin.
The appliance is suitable for all skin types. Do not use the appliance on dry,
chapped skin, open wounds, or when you suffer from skin diseases or skin
irritation, such as severe acne, sunburn, skin infection, etc. Do not use the
appliance if you are taking steroids.
The appliance does not
charge. Make sure the socket to which you connect the appliance is live. Check whether the voltage indicated on the appliance corresponds to the local
mains voltage. Check whether the charging pins on the appliance are in
proper contact with the contact points in the stand. If you use a socket in a
bathroom cabinet, you may need to switch on the light to activate the socket.
When the light on the appliance still does not light up or when the appliance
still does not charge, take it to your Philips dealer or the nearest Philips
service center.
19
English

Problem Solution
The appliance does not
work anymore. Make sure that you have pressed the on/off button properly. Charge the appliance according to the instructions in this user manual. Verify whether
there is a power failure and if the wall socket is live. Check if the charging light
on the appliance lights up to make sure the appliance is charging. If it does
not light up or if the appliance still does not work, take it to your Philips
dealer or the nearest Philips service center.
