Service Manual
DVD Portable PD709/05/12

1.0 TECHNICAL SPECIFICATION
VIDEO/ AUDIO Characteristic Testing discs
Test discs˖DOLBY: Dolby Test disc
ABEX: TDV-540A
VIDEO FORMAT
AUDIO FORMAT
CD / MP3(32 - 320 kbps)
Video (PAL / NTSC)
White bar : 714mV +10%/-20%
Sync. Amplitude: 286mV ±40mV
Burst/chroma ratio: ± 15%
S/N luminance: >42 dB
POWER CONSUMPTION
Power-Supply(AC-DC Adaptor):
Supply voltage: AC 100~240V ±10%
Supply Power consumption(AC adaptor 100/240V): 9V 0.8A
+10%
DC Power supply(Operate voltage range): 6V-15.49V±10%
Standby Power (AC adaptor, no load),264VAC: <0.75W
GENERAL DESCRIPTION
Optical Pickup: ASA PM2381-D(870PH)
Chip set/ Solution:
Disc Size:8cm/12cm
1-1
DVD / SVCD / JPEG / MPEG4 / DIVX3, 4,5,6(Home theater)
Sunplus SPHE8202PS-A

1.1 PCBs Location
VERSION VARIATIONS
Type/Versions:
Service policy
Board in used:
PD709
KEY BOARD M
TFT BOARD M
*TIPS: C -- Component Lever Repair.
M -- Module Lever Repair
X -- OCX
1-2
MAIN BOARD M
12

1.2 System, Region Code, etc. Setting Procedure
Procedure to change region code of your DVD Portable
1. Power ON the DVD player and do not insert DISC inside player
2. Setup Prefer
9Æ6Æ5Æ3
The LCD display showed the existing region Code
3. PressŸ(navigation up)orź(navigation down)
repeatedly to select the number from 1 to 6.
4. Then press OK to confirm your region code.
5. Refer below table for your region code setting
Procedure for SW upgrade
1. The upgrade will provide a document re-named: PHILIPS.BIN
2. “PHILIPS.BIN” copy to CD-ROM into the data;
3. Reading the CD-ROMˈin accordance with promptˈpress ”OK” key to upgrade
Warning: Do not unplug the AC adapter during firmware upgrade to prevent flash corrupt of the set!!
Procedure to check SW version of your DVD Portable
1. OPEN
2. Press SETUP MENU
3. Select Preferences
4. Select Version Info
5. Press “OK” key
1-3

2.0 SAFTETY INSTRUCTIONS
GB
WARNING
All ICs and many other semi-conductors are
susceptible to electrostatic discharges (ESD).
Careless handling during repair can reduce life
drastically.
When repairing, make sure that you are
connected with the same potential as the mass
of the set via a wrist wrap with resistance.
Keep components and tools also at this
potential.
F
ATTENTION
Tous les IC et beaucoup d’autres
semi-conducteurs sont sensibles aux
décharges statiques (ESD).
Leur longévité pourrait être considérablement
écourtée par le fait qu’aucune précaution n’est
prise à leur manipulation.
Lors de réparations, s’assurer de bien être relié
au même potentiel que la masse de l’appareil et
enfiler le bracelet serti d’une résistance de
sécurité.
Veiller à ce que les composants ainsi que les
outils que l’on utilise soient également à ce
potentiel.
ESD
D
WARNUNG
Alle ICs und viele andere Halbleiter sind
empfindlich gegenüber elektrostatischen
Entladungen (ESD).
Unsorgfältige Behandlung im Reparaturfall kan
die Lebensdauer drastisch reduzieren.
Veranlassen Sie, dass Sie im Reparaturfall über
ein Pulsarmband mit Widerstand verbunden
sind mit dem gleichen Potential wie die Masse
des Gerätes.
Bauteile und Hilfsmittel auch auf dieses gleiche
Potential halten.
NL WAARSCHUWING
Alle IC’s en vele andere halfgeleiders zijn
gevoelig voor electrostatische ontladingen
(ESD).
Onzorgvuldig behandelen tijdens reparatie kan
de levensduur drastisch doen verminderen.
Zorg ervoor dat u tijdens reparatie via een
polsband met weerstand verbonden bent met
hetzelfde potentiaal als de massa van het
apparaat.
Houd componenten en hulpmiddelen ook op
ditzelfde potentiaal.
I
AVVERTIMENTO
Tutti IC e parecchi semi-conduttori sono
sensibili alle scariche statiche (ESD).
La loro longevità potrebbe essere fortemente
ridatta in caso di non osservazione della più
grande cauzione alla loro manipolazione.
Durante le riparazioni occorre quindi essere
collegato allo stesso potenziale che quello della
massa dell’apparecchio tramite un braccialetto
a resistenza.
Assicurarsi che i componenti e anche gli utensili
con quali si lavora siano anche a questo
potenziale.
“Pour votre sécurité, ces documents
doivent être utilisés par des spécia-
listes agréés, seuls habilités à réparer
votre appareil en panne”.
GB
Safety regulations require that the set be restored to its original
condition and that parts which are identical with those specified,
be used.
NL
Veiligheidsbepalingen vereisen, dat het apparaat bij reparatie in
zijn oorspronkelijke toestand wordt teruggebracht en dat onderdelen,
identiek aan de gespecificeerde, worden toegepast.
F
Les normes de sécurité exigent que l’appareil soit remis à l’état
d’origine et que soient utiliséés les piéces de rechange identiques
à celles spécifiées.
D
Bei jeder Reparatur sind die geltenden Sicherheitsvorschriften zu
beachten. Der Original zustand des Geräts darf nicht verändert werden;
für Reparaturen sind Original-Ersatzteile zu verwenden.
I
Le norme di sicurezza esigono che l’apparecchio venga rimesso
nelle condizioni originali e che siano utilizzati i pezzi di ricambio
identici a quelli specificati.
"After servicing and before returning set to customer perform a
leakage current measurement test from all exposed metal parts to
earth ground to assure no shock hazard exist. The leakage current
must not exceed 0.5mA."
CLASS 1
LASER PRODUCT
3122 110 03420
GB
Warning !
Invisible laser radiation when open.
Avoid direct exposure to beam.
S
Varning !
Osynlig laserstrålning när apparaten är öppnad och spärren
är urkopplad. Betrakta ej strålen.
SF
Varoitus !
Avatussa laitteessa ja suojalukituksen ohitettaessa olet alttiina
näkymättömälle laserisäteilylle. Älä katso säteeseen!
DK Advarse !
Usynlig laserstråling ved åbning når sikkerhedsafbrydere er
ude af funktion. Undgå udsaettelse for stråling.
2-1

Whenthepowersupplyisbeingturnedon,youmaynotremovethislasercautionslabel.Ifitremoves,radiationoflaser
maybereceived.
2.1 ESD PROTECTION
PREPARATIONOFSERVICING
PickupHeadconsistsofalaserdiodethatisverysusceptibletoexternalstaticelectrocity.
Althoughitoperatesproperlyafterreplacement,ifitwassubjecttoelectrostaticdischargeduringreplacement,
itslifemightbeshortened.Whenreplacing,useaconductivemat,solderingironwithgroundwire,etc.to
protectthelaserdiodeformdamagebystaticelectricity.
Andalso,theLSIandICaresameasabove.
Solderingiron
withgroundwire
orceramictype
Groundconductive
wriststrapforbody.
Conductivemat
Thegroundresistance
betweenthegroundline
andthegroundislessthan10
1M
2-2

SAFTY NOTICE
Plug the AC line cord directly into a 120V AC outlet (do
not use an isolation transformer for this check). Use an
AC voltmeter, having 5000 per volt or more sensitivity.
Connect a 1500 10W resistor,paralleled by a 0.15uF
150V AC capacitor between a knomn good earth ground
(water pipe, conduit, etc.) and all exposed metal parts of
cabinet (antennas, handle bracket, metal cabinet
screwheads, metal overlays, control shafts, etc.).
SAFTY PRECAUTIONS
LEAKAGE CURRENT CHECK
Measure the AC voltage across the 1500 resistor.
The test must be conducted with the AC switch on and
then repeated with the AC switch off. The AC voltage
indicated by the meter may not exceed 0.3V.A reading
exceeding 0.3V indicates that a dangerous potential
exists, the fault must be located and corrected.
Repeat the above test with the DVD VIDEO PLAYER
power plug reversed.
NEVER RETURN A DVD VIDEO PLAYER TO THE
CUSTOMER WITHOUT TAKING NECESSARY
CORRECTIVE ACTION.
READING SHOULD NOT EXCEED 0.3V
DVD VIDEO PLAYER
AC OUTLET
AC VOLTMETER
Test all exposed metal.
Voltmeter Hook-up for Leakage Current Check
0.15uF 150V AC
1500
10W
(5000 per volt
or more sensitivity)
Good earth ground
such as a water pipe,
conduit, etc.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
2-3

2.2 SAFETY INSTRUCTIONS
Battery Handling Guideline
Since the battery is packed in soft package, to ensure its better performance, it’s very important to carefully handle
the battery
2.2.1 Soft Aluminium foil
The soft aluminum packing foil is very easily damaged by sharp edge parts such as Ni-tabs, pins and needles.
x Don’t strike battery with any sharp edge parts
x Trim your nail or wear glove before taking battery
x Clean worktable to make sure no any sharp particle
2.2.2 Sealed edge
Sealing edge is very flimsy
x Don’t bend or fold sealing edge
2.2.3 Folding edge
The folding edge is form in battery process and passed all hermetic test.
x Don’t open or deform folding edge
2.2.4 Tabs
The battery tabs are not so stubborn especially for aluminum tab.
x Don’t bend tab
2.2.5 Mechanical shock
x Don’t Fall, hit, bend battery body
2.2.6 Short
Short terminals of battery is strictly prohibited, it may damage battery.
2-4

3.0 Instruction for Use
You can download this information from the following websites:
http://www.philips.com/support
http://www.p4c.philips.com
3-1

4.0 MECHANICAL INSTRUCTION
4-1
1Remove screws on back cabinet to separate
top cabinet and back cabinet.
2 Generally open the middle cabinet.
3Remove screws on main board.
Disassemble hous and connecter.
4Remove screws on KEY board.
Disassemble hous and connecter.
5Remove screws on front cabinet.
Open the top cabinet

5.0 TROUBLESHOOTING
SYMPTOM: NO IMAGE / NO SOUND
SYMPTOM: NO IMAGE OUTPUT ( THE PANEL SHOW BLUE PICTURE)
Start
Check the external AV
Cable TYPEnote and
connection is OK?
Replace DVD DriveCheck DVD Drive work?
Replace Main Board
Exchange AV cable
NOTE: AV Cable TYPE from outside to
Inside L-Audio, R-Audio, Video, Ground
no
yes
no
yes
SYMPTOM: NO SOUND COMES FROM SPEAKER
Start
Check the Connection OK? Reinsertion
Check speaker OK?
Replace Main Board
Change the speaker
no
yes
no
yes
5-1

5.0 TROUBLESHOOTING
SYMPTOM: THE DVD DRIVE DOES NOT WORK
SYMPTOM: THE DVD DRIVE DOESNϗT WORK
Start
Replace DVD-
Loader
Check the DVD-Loader
OK?
Replace main board
NO
Yes
Yes
Cable ReinsertionNO
Check DVD-Loader
connection OK?
5-2

5.0 TROUBLESHOOTING
SYMPTOM: ADAPTOR CANNOT POWER ON
Start
Check Adaptor OK?
Adaptor can not Power ON
Change adaptor SET OK?
Return set to
Customer
NO
Check the Power-ON
button and cable OK? Replace Main Board
Replace Button or
Cable
Yes
NO
Yes
No
YES
OK
5-3

5.0 TROUBLESHOOTING
SYMPTOM: KEY & BOTTON FAILURE
SYMPTOM: Key & Botton Fail
Start
Check KEY board OK?
Replace main board
NO
Yes
Yes
Cable ReinsertionNO
Check CABLE form board to
board connection OK?
Return to custormerOK
Replace KEY board
OK
5-4

6-1
OVERALL BLOCK DIAGRAM
TFT PANNEL LG J2
SDRAM 4X16
9~15V
L/R AND CVBS
SW5888
LOADER(SANYO SP850)
PolymerBattery
SPHE8202
AV OUT JACK
Power input
MOTOR DRIVER
DC-DC REMOTE CONTROL
EARPHONE
BACK LIGHT
SPI FLASH 16M
AMPLIFIER
MPEG DECODER
KEY CONTROL
SPEAKER 0.2W X2

CIRCUIT DIAGRAM-MAIN BOARD
7-1
Close to 8202P-A
RF +3.3V
AUDIO DAC +3.3V
Servo MOTOR +5V Video buffer +5V Servo analog +5V SDRAM +3.3V
SPI Flash +3.3V
VIDEO DAC +3.3V
+5V POWER
USB +3.3V
+1.25V POWER
݇ ᓔ
POWER Switch
VDS=30V
DC INPUT 6~15V
⬉⑤ᣛ⼎JUHHQ
+3.3V POWER
POWER ON POWER OFF
Current=8A VGS=20V
CHARGE_STAR CHARGE_STOP
DC9V_IN
BAT_OUT
ON/OFF
PS
PS
N18343289
B-CHARG
B-CHARG
ON/OFF
N20648632
$$$25
CHARGE_IN BAT_OUT P+5V
$$$28
VGH VGL
$$$27
$$$27
N18343237
ADAPTER_DET
$$$7
X00242
ADAPTER_DET
VGH
VGL
BAT_OUT 5 CHARGE_IN 5 P+5V 3,5 ADAPTER_DET 3 VGH 3 VGL 3
RFGND
A+5V
RFGND
M+5V
RF3.3V
RFGND
VVCC3
SD_VCC3 SPI_VCC3
AVCC3
P+5V
USB_AVDD3V3
GND
VCC1.2
PLL_VDD1.2
PGND
PGND
GND
GND GND GND
VGND GNDAGND MGND
P+5V
7*1'
DGND PGND
GND
PGND
CARDGNDSGND ADGND
DC_IN P+5V
PGND
DVCC3
DC_IN
PGND
RFGND
DVCC3
DVCC3
PGND
PGND PGNDPGND
DC_IN
BAT_OUT
PGND
CHARGE_INDC9V_IN
DC_IN
PGND
PGND
PGND
PGND
VGL
VGH
DC9V_IN
9V_IN
PGND
DVCC3
ADGND
GND
PGND
DC9V_IN DVCC3
AGND
GND
C123
1uF/50V
12
C6 0.1uF/25V
D4
C120
1uF/50V
12
C3 0.1uF/25V
EC2 100uF_10V
C2 0.1uF/25V
R1 2.2_0805
R12
10K
Q12 2N3904
1
2 3
C12 1000pF
1 2
D7 SS24
U3
UTC1117-ADJ
2
1
3OUT
GND
IN
MARK2
L8 3.3uH_0805
L3 L-851
1 3
2 4
C8 100nF
R249 NC
C1 100nF
P
F1 PolyFuse/8v/0.75A
G
D
S
Q21
SI2307
3
1
2
R240 4.7K
12
Q2
2N3904
1
2 3
L12
22uH
Q22
2N3904
1
2 3
+
EC5
100uF/16V
MARK3
R132
47K
ZD7 16V
1 2
R253 1K
Q7 2N3904
1
23
EC48
10uF_16V
R6
10
EC14 100uF_10V
L7 2.2R
MARK4
L2 FB120R
D3 SS14
C15
1uF/25V
C11 100nF
R4 100K
L5 FB120R
Q5 SI2307
1
2 3
R130 47K
R242 1K
12
Q4 SI2307
1
2 3
+
EC6
100uF/25V
C21 1uF/25V
L20 FB600R
D1 SS14
R16 2.7K
L1 FB120R
D8 SS24
R2 100K
R241 1k
C20 1000P
1 2
R18 1K
R7 3.3uH_0805
R8 18K
C100.1uF/25V
CN1 DC/JACK
1 2 3
C118 100nF/25V
1 2
C5 100nF
R15 22K
R17 10K
C117 1uF/50V
12
EC7 100uF_10V ZD6 6.8V
12
100nF C25
C19
0.1uF/25V
D5 SS14
C22
0.1uF/25V
C9
100nF
C18
100nF
R11 1K
L9
22uH
Q8
2N3906
2
13
1000pF C24
U1
SS7701
1
2
3
4
5
CE
GND
VFB
EXT
VIN
C119 1uF/50V
12
R65 10K
MARK1
+
EC11
100uF/16V
Q3
2N3904
1
2 3
C95 1uF/50V
12
R10 2.7K
C4 100nF
C122
1uF/50V
12
C116 100nF/25V
1 2
+
EC10100uF/25V
R14 560R
D2 15V
R3 10K R5 10K
R133 47K
Q13 BAT54S
1
3
2
100nF C23
EC3 100uF_10V
Q14 BAT54S
1
3
2
U2
SS7701
1
2
3
4
5
CE
GND
VFB
EXT
VIN
Q15 BAT54S 1
3
2
R9 22K
R134
27R
R131 1K
C7 100nF
+
EC45 220uF/16V
SW1
POWER_SWITCH_SK-22D13-V4
1 2 3 4
5 6
78
1 2 34
5 6
GG
D14 15V
Q23
2N3904
1
2 3
G
D
S
Q1 SI2307
3
1
2
EC13 47uF_16V
C121 100nF/25V
1 2
EC4 220uF_10V
R25 47K
BAT-DISCHARGE1
12
R13 10

CIRCUIT DIAGRAM-MAIN BOARD
7-2
RESET
The Cover Limit Switch
UART/I2C
close to connector
CLOSE TO 8202
M_BA1 M_WE M_BA0 M_RAS M_CAS M_CLK M_A11 SPI_CE SPI_CLK SPI_D0 SPI_D1 CVBS AOUT_R AOUT_L
SP- FCO FOC+ FOC- SPDCO
DMEA SLED+ SLED- RAD+ VREF2 RAD- TCO SCO
XOPVIN
SLED-
PUH_CDLD PUH_DVDLD
FCO TCO
SPDCO SCO
G/Y R/V B/U
M_D6
B/U
STHL
M_A3
XOPVIP
M_CAS
DAC_VREF
COVER_SW
M_D13
M_D8
M_A7SPI_CLK
VREF1
M_D12
G/Y
M_A1
XOPVIN
OEVM_D5
AOUT_L
R/V
M_CLK M_A9
SC_OUT
DVDLDO
M_D14
M_D10
M_RAS
KEY0
M_D9
M_A6 M_DQM0
DA_FEO
RESET_B
VREF1
M_D0
M_A11
CDLDO
M_D4
M_BA0 M_A2
SPDC_OUT
CKV
CLKIN
M_D3
M_D11
M_D15
M_BA1
AOUT_R
SPI_CE M_A5
M_A4
DA_TEO OTP
DC_COM
RESET_B
M_A8 M_A0
CDLDO
V_COMP
V_FSADJ
M_D1
DA_VDD
CLKOUT
M_D7
CVBS
M_A10
SPI_D1 DVDMDI
M_WE
XOPVIP
M_DQM1
PWM2
VREF_2
KEY3
AC_COM
SPI_D0
OEH
M_D2
KEY1
DVDLDO
D
COMP
KEY2
PUHRF
IR_IN
P_CPH1CPH1
STVU
SP+
DVDVR CDVR
FOC- D RAD- RAD+ FOC+
PUH_CDLD PUH_DVDLD
DVDMDI CDVR# B PUH_CDLD# PUH_DVDLD# C /LDSW PUHRF A F E VREF1
CD_VR CDVR DVD_VR DVDVR
CD_VR DVD_VR
VREF2
SP+
RESET_DEMOD
RESET_DEMOD
UA_TX UA_RX
SP- SLED+
A_+5V
KEY3
IR_IN
R/V B/U P_STVU
P_CPH1
P_CKV P_OEV AC_COM DC_COM P_STHL P_OEH G/Y
VREF_2
DA_VDD
BACKL_EN
DVDVR#
P_PWM2
B/U G/Y R/V P_CPH1 P_OEH P_OEV P_STHL P_CKV GND DC_COM P_STVU AC_COM
KOUT2 KOUT1
FOC- FOC+ RAD+ RAD- C D /LDSW PUHRF A B F VREF1 E CDVR# DVDVR# PUH_CDLD# DVDMDI PUH_DVDLD# A+5V RFGND A_+5V
P_PWM2
VGH
B/U G/Y R/V P_STHL P_OEH P_OEV P_CKV P_STVU DC_COM AC_COM
STVU CKV OEV STHL OEH
VGL
SP- SP+ RFGND SLED- SLED+
UA_TX UA_RXCOVER_SW
PWM2
KOUT3
P_+5V
DMEA
BATSDA SCL UA_TX UA_RX
KEY2 KEY1 KEY0
SCL BATSDA P+5V
$$$20 HOME
HOME
BACKL_EN
SCL
BATSDA
BATSDA SCL
F
GND
GND
HOME
ADAPTER_DET
HOME
C
B
A
E
$$$8ADAPTER_DET
/LDSW
/LDSW$$$6
$$$17
VGH VGL
M_A[0..11] 4 M_D[0..15] 4 M_DQM[0..1] 4 M_CAS 4 M_RAS 4 M_WE 4 M_BA0 4 M_BA1 4 SPI_CE 4 SPI_CLK 4 M_CLK 4 M_A11 4 SPI_D0 4 SPI_D1 4 CVBS 6 AOUT_R 6 AOUT_L 6
SCL 5 BATSDA 5
P+5V 2,5
ADAPTER_DET 2 VGH 2
VGL 2
GND
GND
VVCC3
GND
GND
VCC1.2
VVCC3
RF3.3V
RF3.3V
M+5V M+5V
M+5V
RFGND
RFGND
RFGND
RFGND
RFGND
RFGND
RF3.3VRF3.3V
RFGND
RFGND RFGND
RF3.3V
RST3.3V GND RST3.3V
DVCC3
GND
VCC1.2
USB_AVDD3V3
DVCC3
PLL_VDD1.2
AVCC3
DA_VDD
DVCC3
DVCC3
GND GND GND
PLL_VDD1.2 RF3.3VDVCC3 VCC1.2
GNDGND RFGND
RFGND
A+5V
A+5V
RFGND
RFGND RFGND A+5V
RFGND
RFGND
RFGND
P+5V
GND
GND GND
GND
RFGND
DVCC3
A+5V
DVCC3
GND
P+5V
RST3.3V
GND
GND GND
GND
RF3.3V
DVCC3
RFGND
P+5V
DVCC3
VGH VGL
RFGND
GND
GND
GND
GND
GND
GND
RFGND RFGND
GND
GND
P+5V
GND
GND
GND
GND
GND
GND
DVCC3 RST3.3V
GND
GND
R175 10K
0.1uFC28
J6
CON14/1.25mm/DIP
1 2 3 4 5 6 7 8 9
10 12 11 13 14
FB9 FB600R
10pFC29
TP37
NC/100pFC135
TP63
TP55
NC/1000pF C129
C30 33pF
R50 10K
TP23
D23 NC/1N4148
0.1uF C41
EC19
10uF_16V
1000pFC140
TP71
0.1uF C42
C53 0.1uF
EC22 100uF_16V
TP64
D24 NC/1N4148
TP10 Reset
NC/1000pF
C150
NC/100pFC136
TP56
EC15 100uF_10V
EC18
10uF_16V
TP50
TP30
FB3 FB600R
10pFC33
TP38
FB1
FB600R
R49 100
TP65
TP34
0.1uF
C146
TP9
FGIN
CN5
NC/CON4/1.25MM/DIP
1 2 3 4
1 2 3 4
TWR1
1000PC72
U16 IR(NC)
1
2
3
DET
GND
VCC
TP57
D16 1N4148
1000pFC38
J5 8PIN/1.25L
1 2 3 4 5 6 7 8
100pFC130
L13 10uH
R245 FB600R
L28 FB120R
C48 0.1uF
TP26
TP72
0.1uF C44
C55 0.1uF
TP24
R32 4.7K
TP66
R174 FB600
R47 10K
1000pF
C145
10uF_16V EC47
R129 200R
TP58
NC/1000pFC148
R19 10K
CN2
26 25
17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 18 19 20 21 22 23 24
Q10 S8550
2
3 1
EC16
10uF_16V
D17 1N4148
R244 470R
D15 1N4148
CN4 2P/2.0
1 2
EC21 47uF_16V
L14 10uH
C114
100nF
0.1uFC36
TP67
FB18 FB600R
R34 150
680pFC37
TP31
1000pFC141
R30FB600R
TP59
R28 150
SW3
DISC_SWITCH_TC-0030
3 4 2 1
TP41
NC/1000pF C126
FB15 FB600R
CN3 4P/2.0
1 2 3 4
C58 0.1uF
FB4 FB600R
0.1uF C26
0.1uF C43
C56 0.1uF
TP73
NC/100pFC137
NC/1000pFC149
FB13 FB600R
R29 4.7K
TP68
TP27
1000pF C125
0.1uFC40
TP25
FB11 FB600R
TP69
1000pF
C69
TP60
FB2 FB600R
TP42
R37 91K
TP49 TWR4
TP61
100pFC131
R36 0
D6 1N4148
0.1uF C47
L6
FB600R
100pFC138
XT1 27MHz
TP39
C31 33pF
R40 2.2K
C50 0.1uF
TP43
1000pF C14
C57 0.1uF
TP48
R31 150
R48 10K
FB5 FB600R
R46
FB1000R
TP74
R41 5.1
R179 10K
R38 20K
TP32
100pFC132
R26 0
100pFC139
R44 1
TP44
TP20 TP28
U4
SPHE8202P-A
102
101
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
78
75
76
77
103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128
64 63 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39
1
2
3
4
5
6
7
8
9
10
11
13
15
12
14
29
33
34
35
36
37
38
16
17
18
19
20
21
22
23
24
65
79
80
81
82
74
73
72
71
70
69
68
67
66
62
25
26
27
28
30
31
32
129 130 131
132
133
134
135
136
137
138
139
140
141
142 143
CDE
CDF
DVDA
DVDB
DVDC
DVDD
RFIS
AD_AVDD
LDSW
HOME/CARD_RST
CLKOUT
CLKIN
PLL_VDD12
USB_DM
USB_DP
USB_AVDD
COMP
FB
DCDC_PWM
DCDC_VCC3
VDD12
TCON_STVU
TCON_CKV
TCON_OEV
OPVIP OPVIN DVDLDO CDLDO MDI SRV_AVDD V21 V165 VDDQ DA_TEO DA_FEO DA_AVDD SPDC_OUT SC_OUT DMEA FGIN DVDVR/SCL/GPIO74 CDVR/SDA/GPIO75 CARD_SENSE/GPIO80 SPI_CE SPI_D0 SPI_CLK SPI_D1 SD_D0/MS_D0 SD_CLK/MS_CLK SD_CMD/MS_BS
TCON_AC_VCOM
AOUT_R
ADAC_AVDD
VREF
AUDIO_MUTE/GPIO54/HSYNC(3)
SPDIF_OUT/GPIO53/VSYNC(3)
M_A3 M_A2 M_A1 M_A0
M_A10
M_BA1 M_BA0
M_RAS M_CAS
M_WE
M_DQM0
M_A4 M_A5 M_A6 M_A7 M_A8 M_A9
M_A11
M_CLK
RESET_DEMOD
TS_ERR
VDD_33
RESET_B
TS_SYNC
TS_DATA
TS_DEN
TS_CLK
VDD12
GPIO7/HSYNC(1)
GPIO8/VSYNC(1)
GPIO10
GPIO12
GPIO9
GPIO11
M_D15
M_D11
M_D10
M_D9
M_D8
M_DQM1
VDD_33
GPIO13
GPIO14
GPIO15
GPIO16
IR/GPIO17
M_D0
M_D1
M_D2
M_D3
TCON_DC_VCOM
TCON_OEH
TCON_STHL
TCON_CPH1
TCON_PWM
VDD_33
TV_DAC3
TV_DAC2
TV_DAC1
TV_AVDD
TV_AVDD
TV_DAC0
V_FSADJ
VCOMP
AOUT_L
M_D4
M_D5
M_D6
M_D7
M_D14
M_D13
M_D12
GND7 GND8 GND9
GND10
GND11
GND12
GND13
GND14
GND15
MARK1
MARK2
GND3
GND4
GND5 GND6
2200pFC32
TP51
J7 8pin/1.25w
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
R33 1K
TP21 TP35
FB6 FB600R
R176 10K
FB8 FB600R
Q9 S8550
2
3 1
FB19 FB600R
U5 AM5888 HSOP28
17 18
12 11
16 20 15 23
8
10 19
22 28
14 13
4 5
25 27 26
1
24 21 2930
7 6 9 3 2
VOSL+
VOSL-
VOSP+ VOSP-
VOTK-
VNFTK
VOTK+
VINSL
Vcc1 VOLD+ Vcc2
PreGND
STBY
VOFC+ VOFC- VINSP VNFFC
CTKerr1
BIAS
VINTK
VINFC
CTKerr2
VCTL
GND1GND2
REV FWD VOLD- CFCerr2 CFCerr1
EC23
10uF_16V
Q11 2N3904
R66
560R
R35 10K
1000pFC142
R42 5.1
C51
0.1uF
C54 0.1uF
1uFC35
TP45
TP19
NC/100pFC133
FB10 FB600R
TP52
FB7 FB600R
0.1uFC39
TP47
CN6
NC/CON4/1.25MM/DIP
1 2 3 4
1 2 3 4
FB20 FB600R
R27 0
NC/1000pF C127
0.1uF C46
0.1uFC45
0.1uF
C147
R177 10K
TP36
TP46
0.1uFC27
TP53
TP22
NC/100pFC134
FB12 FB600R
FB17 FB600R
TP29
R39 2.2K
TP33
FB14 FB600R
R43 10K
C52 0.1uF
TP62
NC/1000pF C128
TP70
R243 91K
EC20 47uF_16V
TP40
0.1uF C124
0.1uF C34
R178 10K
EC17 10uF_16V
TP54

CIRCUIT DIAGRAM-MAIN BOARD
7-3
For 1bit SPI Flash
DQ0 DQ1
SPI_D0 SPI_D1
SPI_WP DQ0SPI_D0 SPI_HOLD DQ1SPI_D1
M_A5 M_A2 M_A6 M_A1 M_A8 M_A10 M_A3 M_A7 M_A9 M_A4 M_A11 M_DQM1 M_DQM0 M_WE M_A0 M_CAS M_RAS
M_D9
M_BA0 M_BA1 RAM_CLK
M_D4 M_D8 M_D2 M_D10 M_D7 M_D6 M_D5 M_D3 M_D14 M_D1 M_D0 M_D13 M_D12 M_D15 M_D11
RAM_CLKM_CLK
M_BA1 M_WE M_BA0 M_RAS M_CAS M_CLK SPI_CE SPI_CLK
DQ0 SPI_WP SPI_CE
SPI_CLK_1 DQ1 SPI_HOLD
SPI_CLK_1SPI_CLK SPI_D0 3
SPI_D1 3 M_A[0..11] 3 M_D[0..15] 3 M_DQM[0..1] 3 M_CAS 3 M_RAS 3 M_WE 3 M_BA0 3 M_BA1 3 SPI_CE 3 SPI_CLK 3 M_CLK 3SPI_VCC3
SPI_VCC3
GND
SD_VCC3
GND
GND
SD_VCC3
GND
GND
SD_VCC3
GND
SPI_VCC3
GND
GND
AGNDGND
R55 10K
100nF C63
10pF C67
U6
EON25T16/MX25L1605
1 2 3 4
8 7 6 5
/CS DO /WP VSS
VCC
/HOLD
CLK
DIO
R56 10K
EC24 10uF_16V 100nF
C64
100nF C60
R51 NC
100nF C65
R52 0R
100nF C61
R57 0R
+
EC25
100uF/16V
R53 33R
NC
C68
100nF C59
R54 0R
100nF C62
100nF C66
U8 SDRAM_1Mx16x4
23 24 25 26 29 30 31 32 33 34 17 18 15 16 19 37 38 39
2 4 5 7 8 10 11 13 42 44 45 47 48 50 51 53 36
20
1 27 28 41
22
40 3 9 43 49
6
12 46 52 35 21
54 14
A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 CAS
RAS LDQM WE CS CKE CLK UDQM
D0 D1 D2 D3 D4 D5 D6 D7 D8 D9
D10 D11 D12 D13 D14 D15
NC
BA0
VDD VDD
VSS VSS
A10/AP
NC/RFU
VDDq VDDq VDDq VDDq
VSSq VSSq VSSq VSSq A11 BA1
VSS
VDD
100nF
C49

CIRCUIT DIAGRAM-MAIN BOARD
7-4
C0603
8/5
BAT_OUT
N17530607
N18018963
N20881055
N17529525
CHARGE_IN
N20876270
BATSDA
N17854794
SCL
N17529751
N20875627
N20876921
N20875945
N17529659
$$$44
$$$21
N17529623
N17530369 $$$46
N20260395
$$$47
N17529617
N20876956
N20875929
$$$40
N17836826
N17529509
$$$22
N17529601
N20881025
CHARGE_IN BAT_OUT BATSDA SCL
P+5V
P+5V
N17529643
N20879818
N20879373
$$$1
CHARGE_IN 2 BAT_OUT 2 BATSDA 3 SCL 3 P+5V 2,3
P+5V
DQ13
9926
1
2
3
45
6
7
8
B+
1
DL1
33uH
LED3 DIP-LDE-HP
DC7 104
C0402
2 1
DR1 1K
DR35
10k
21
DR5 NC
21
TSC1
1
DR9
680R(0805)
21
DC12 104
12
DR31
NC
2 1
TWR2
TBM1
1
DC5
1000P
DR19 100
21
DR12
NC
21
DC9 104
DC13
104
12
B-
1
DC11
0.01UF
12
DR3 1K
DIC2A
TL431
2
3
1
2
3
1
DR8
680R(0805)
21
DD4
5.6V
1 2
TB+1
1
DC8 104
DR4 150k 1%
21
DC15 1000P C0603
12
BM1
1
DR24
68K
21
DQ3
9013
DR10 1K
DC3
104
C0402
2 1
DD3 1N4148
DR18
4.7K
TSD
1
DC6 104
TWR3
1
DQ4
2N3904
1
2 3
TB-1
1
DIC21
HT46R52A
1 2 3 4 5 6 7 8 13
14 15 16 17 18 19 20
9
10
12 11
PD2 PD3/PWM1 PC2/PWM0 PC3 RST/VCC GND PA0/AN0 PA1/AN1 PB2/AN6
PB3/AN7
VDD
OSC1/SCK
OSCO/PC0
PC1/VREF
PD0 PD1
PA2/AN2 PA2/AN3
PA2/AN5 PA2/AN4
+
DC2 220uF/16V
DR16 2K
21
DC1
47uF/6.3V ECAP-5X5
2 1
TSC2
1
DQ1 HT772J Q
3
2 1
DR30 0.1
1 2
DQ2
2N3904
1
2 3
DR17
470
21
DR15 3.3K
21
DC16 0.47uF
TPC3
1
DR29 0.15
1 2
DD1
4148
1N4148/SMD
12
DR20
100K
2 1
DIC3
8242AAY
8242
2
1
4
5
3
6
CO
DO
VC
VCC
VM
VSS
DD2
4148
1N4148/SMD
12
DD5
SS14
DC23 0.1UF
DR2 10R
21
TSC
1
TPW1
1
DR32
NC
2 1
DR13
1K
21
DR6 100R(0805)
21
TPWM1
DR14 4.7M
21
DR11
51K 1%
21
DR21 10k 1%
21
DR7 1K
21

CIRCUIT DIAGRAM-MAIN BOARD
7-5
2
B
1
BAV99
EB
2
1
E
C
2N3904
3
1
2
3
2N3906
3
2
1
3
C
volume
C
3
B
2
E
1
2
13
2N3906
C
B
2N3904
E
AOUT_L CVBS AOUT_R
$$$3 $$$5
AV_OUT_R AV_OUT_L
$$$13CVBS $$$10
$$$12
$$$11
N16885211
OUT-L
$$$23 $$$24
R_HP_IN
HP_R
L_HP_IN
N16885147
OUT-R
$$$16
N16885376N16885376
$$$18
L_HP_IN
N17993446
$$$15
N16885333
HP_L
N16885345
R_HP_IN
$$$2
N16885823
AC
N16885798
N16885819
N16885821
AU_OP
VREF3
N16886088
OUT-R
N16885495
AV_OUT_L AV_OUT_R
N16885851
AC
N16885833
N16885796
AU_OP
DC_IN
N16885849
N17993041
N17993529
SPL
SPK_L SPK_R
SPR
AOUT_R
AOUT_L
N16885337
$$$19
HP_L
$$$4 N16885329 OUT-L
CVBS 3
AOUT_L 3 AOUT_R 3
GND VGNDAGND
VGND VGND VGND
AGND
DC_IN
VREF5
VREF5
VR1 C10K R1001G 16/2
5 4 3 2 6 1 7
C82
820p
R128
100K R_0402
12
R63 680K
C89 100pF
C70 100pF
C16
0.1uF
L15 FB2K2(0603)
U12
APA2822
1
2
3
4
5 6 7 8
R93 5.1K
+
EC26
10uF/16V
J3AV/OUT-JACK
1
2
3
45
TP76
1
+
EC32 10uF/16V
L17 FB2K2(0603)
C94
0.1uF
L10 1.8uH
C93
0.1uF
R24
NC
C74
820p
+
EC8
22uF/25V
R60 10k
L18 FB600R(0805) L-0805
1 2
R125
75R 1%
+
EC12
10uF/16V
Q6 SI2307
1
2 3
R118
10K
C73
1000pF
C17
0.1uF
R88 27K
+
EC39 100uF/16V
L11
FB2K2(0603)
L16 FB2K2(0603)
C77
0.1uF
R94 360R
L25 OR(0603)
C86
150P
R110 360R
R107 5.1K
D20 IN4148
+
EC42 220uF/16V
+
EC35 10uF/16V
R58
30K
1 2
+
EC33
22uF/25V
C76 100pF
R117
4.7R
R61
2R(0805)
C85 150P
R92 10K
R115 56K
C79
1000pF
R126 180R
R248 100K
TP78
1
C91
0.1uF
+
EC41 100uF/16V
C71 0.1uF
R108
30K
1 2
TP75
1
R62 2R(0805)
C88 100pF
R101 27K
J8
speaker
3 2 1 4
3 2 1 4
+ -
U11A
NJM4558-SOP-8
3 2
1
8 4
+
EC31 10uF/16V
+
EC9
100uF/16V
R119 10K
C13
0.1uF
+ -
U11B
NJM4558-SOP-8
5 6
7
8 4
R102 39K
R114
4.7R
R127
100K
R45
NC
R106 10K
R124 180R
R59 5.1R R_0402
2 1
+
EC36 47uF/16V
RL
J4
Earphone
5
3
14
2
8
6
7
10
9
11
L19 FB2K2(0603)
R23 100K
+
EC40
100uF/16V
+
EC38 100uF/16V
R109 43K
R116
56K
+
EC37 10uF/16V
C92 0.1uF
TP77
1
