Philips PET717/93 User manual

Register your product and get support at
www.philips.com/welcome
EN User manual
PET717

3EN
English
1 Important 5
Important safety instructions 5
Important Safety Instructions 6
Hearing safety 8
Notice 9
2 Your Portable DVD Player 11
Introduction 11
What’s in the box 12
Overview of the main unit 12
Overview of the remote control 15
3 Get started 18
Charge the built-in battery 18
Install the remote control battery 19
Connect additional equipment 20
Connect a TV 20
Connect an amplier 21
Connect a stereo system 21
Turn on 22
Select an OSD language 23
4 Use your DVD Player 24
Play discs 24
Play options 25
Activate PBC 25
Program 26
Repeat 26
Repeat a section 27
Contents

4EN
Rotate pictures 27
Skip to a title/track/chapter 28
Search 28
Select an audio language 28
Select an audio mode 28
Select a subtitle 28
Select a view angle 29
View disc information 29
Zoom 29
5 Adjust settings 30
Select language options 30
Get the DivX® registration code 30
Select video options 31
Select display ratio 31
Select a view mode 32
Select picture contrast 33
Select audio options 34
Select play preferences 35
Restore original settings 35
Activate screen saver 36
Restrict access 36
Change a password 38
Select JPEG play options 39
6 Troubleshooting 40
7 Product information 42
8 Glossary 43

5EN
English
1 Important
Important safety instructions
Know these safety symbols
This ‘bolt of lightning’ indicates uninsulated material within your unit
may cause an electrical shock. For the safety of everyone in your
household, please do not remove product covering.
The ‘exclamation point’ calls attention to features for which you
should read the enclosed literature closely to prevent operating and
maintenance problems.
WARNING: To reduce the risk of re or electric shock, this
apparatus should not be exposed to rain or moisture and objects
lled with liquids, such as vases, should not be placed on this
apparatus.
CAUTION:To prevent electric shock, match wide blade of plug to
wide slot, fully inse rt.

6EN
Important Safety Instructions
aRead these instructions.
bKeep these instructions.
cHeed all warnings.
dFollow all instructions.
eDo not use this apparatus near water.
fClean only with dry cloth.
gDo not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
hDo not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
iProtect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
j Only use attachments/accessories specied by the
manufacturer.
kUse only with the cart, stand, tripod, bracket, or table
specied by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.

7EN
English
lUnplug this apparatus during lightning storms or when unused
for long periods of time.
m Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
nBattery usage CAUTION – To prevent battery leakage which
may result in bodily injury, property damage, or damage to the
unit:
Install all batteries correctly, + and - as marked on the unit.
Do not mix batteries (old and new or carbon and alkaline,
etc.).
Remove batteries when the unit is not used for a long
time.
oApparatus shall not be exposed to dripping or splashing.
pDo not place any sources of danger on the apparatus (e.g.
liquid lled objects, lighted candles).
qThis product may contain lead and mercury. Disposal of
these materials may be regulated due to environmental
considerations. For disposal or recycling information, please
contact your local authorities or the Electronic Industries
Alliance: www.eiae.org.
•
•
•

8EN
Warning
Never remove the casing of this DVD Player.
Never lubricate any part of this DVD Player.
Never place this DVD Player on other electrical equipment.
Keep this DVD Player away from direct sunlight, naked ames or heat.
Never look into the laser beam inside the DVD Player.
Ensure that you always have easy access to the power cord, plug or adaptor to
disconnect the DVD Player from the power.
•
•
•
•
•
•
Hearing safety
Listen at a moderate volume.
Using headphones at a high volume can impair your hearing.
This product can produce sounds in decibel ranges that may
cause hearing loss for a normal person, even for exposure less
than a minute.The higher decibel ranges are offered for those
that may have already experienced some hearing loss.
Sound can be deceiving. Over time your hearing ‘comfort level’
adapts to higher volumes of sound. So after prolonged listening,
what sounds ‘normal’ can actually be loud and harmful to your
hearing.To guard against this, set your volume to a safe level
before your hearing adapts and leave it there.
To establish a safe volume level:
Set your volume control at a low setting.
Slowly increase the sound until you can hear it comfortably and
clearly, without distortion.
Listen for reasonable periods of time:
Prolonged exposure to sound, even at normally ‘safe’ levels, can
also cause hearing loss.
Be sure to use your equipment reasonably and take appropriate
breaks.
•
•
•
•
•
•

9EN
English
Be sure to observe the following guidelines when using your
headphones.
Listen at reasonable volumes for reasonable periods of time.
Be careful not to adjust the volume as your hearing adapts.
Do not turn up the volume so high that you can’t hear what’s
around you.
You should use caution or temporarily discontinue use in
potentially hazardous situations. Do not use headphones while
operating a motorized vehicle, cycling, skateboarding, etc.; it may
create a trafc hazard and is illegal in many areas.
Caution
Use of controls or adjustments or performance of procedures other than herein
may result in hazardous radiation exposure or other unsafe operation.
•
Notice
Any changes or modications made to this device that are not
expressly approved by Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Environmental information
All unnecessary packaging has been omitted.We have tried to make
the packaging easy to separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags, protective foam
sheet.)
Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials, exhausted
batteries and old equipment.
Always bring your product to a professional to remove/replace the
battery.
•
•
•
•

10 EN
The making of unauthorized copies of copy-protected material,
including computer programs, les, broadcasts and sound recordings,
may be an infringement of copyrights and constitute a criminal
offence.This equipment should not be used for such purposes.
Recording and playback of material might require consent. See
Copyright Act 1956 and The Performer’s Protection Acts 1958 to
1972.
Manufactured under license from Dolby Laboratories.‘Dolby’ and the
double D symbol are trademarks of Dolby Laboratories.
“DivX, DivX” Certied, and associated logos are trademarks of DivX,
Inc. and are used under license.
This DVD Player includes this label:

11EN
English
2 Your Portable DVD Player
Introduction
Your Portable DVD player plays digital video discs conforming to
the universal DVD Video standard.With it, you can play movies with
cinema-like picture and stereo (depending on the disc and your
playback set-up).
You can also select sound track, subtitle languages, and different angle
of view (again depending on DVD disc). Besides, you can set parental
control to prevent your children to see certain discs.
You can play the following discs on the DVD player (including CD-R,
CD-RW, DVD±R, DVD±RW, and DivX):
DVD-Video
Video CD
Super video CD
Audio CD
DivX® CD
MP3 CD
Discs with JPEG les

12 EN
What’s in the box
Check and identify the contents of your package:
Portable DVD Player
Remote control
Battery for remote control
AC power adaptor (ADS-18C-12 1212GPG)
AV cable
User Manual
Quick Start Guide
Overview of the main unit
aSETUP
Access or exit the setup menu
•
•
•
•
•
•
•
•

13EN
English
bMENU
For DVD, access or exit the root menu
For VCD and SVCD, turn PBC (playback control) on or off
in PBC mode
cSTOP
Stop disc play
dPLAY/PAUSE
Start, pause or resume disc play
eNavigation keys
/ / /
Select the up/down/left/right item
/
Press to skip to the previous or next title/chapter/track
Press and hold for fast-backward or fast-forward search
OK
Conrm an entry or selection
fOPEN
Open the disc compartment
gIR/POWER/CHR
Remote sensor, power indicator, or charge indicator
•
•
•
•
•
•
•
•
•
f g
IR/POWER/CHROPEN
f g
IR/POWER/CHROPEN

14 EN
hVOLUME + / -
Adjust volume level
iCOAXIAL
Connect headphones
Socket for coaxial output
jAV OUT
Socket for audio/video output
kPOWER ON / OFF/CHR
Turn on/off the DVD Player
lDC IN 12V
Socket for the AC-DC power adaptor
•
•
•
•
•
•

15EN
English
Overview of the remote control
aREPEAT
Select a repeat mode
bZOOM
Zoom into or out of an image
•
•
m l k j
a b c d
r
q
o
p
s
n
e
f
g
h
i
m l k j
a b c d
r
q
o
p
s
n
e
f
g
h
i

16 EN
cOSD DISPLAY
Display the current play status or disc information
dTITLE
Access or exit the title menu of a disc
eMENU
For DVD, access or exit the root menu
For VCD and SVCD, turn PBC (playback control) on or off
in PBC mode
f/ / /
Select the up/down/left/right item
/
Press to skip to the previous or next title/chapter/track
Press and hold for fast-backward or fast-forward search
OK
Conrm an entry or selection
g
Start, pause or resume disc play
hDVD AV OUT
Switch between [TV Mode (PAL)], [Dual Screen (NTSC)]
and [AV OUT OFF]
iMUTE
Mute or restore the volume
jSUBTITLE
Select a subtitle language
kAUDIO LANGUAGE
Select an audio language or an audio channel
lANGLE
Select a viewing angle of a DVD
•
•
•
•
•
•
•
•
•
•
•
•

17EN
English
mRETURN
(For VCD, PBC on) Return to the previous menu
nNumeric Keypad 0 - 9
Select an item to play
oGO TO
Skip to a chapter/track/title or a play time
p
Stop disc play
qPROGRAM
Access or exit the program menu
rREPEAT A-B
Mark the section for repeat play
sSETUP
Access or exit the setup menu
•
•
•
•
•
•
•

18 EN
3 Get started
Caution
Use the controls only as stated in this user manual.•
Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial
number of your DVD Player.The model number and serial number
are on the bottom of your DVD Player.Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Charge the built-in battery
Caution
Risk of product damage! Ensure that the power supply voltage corresponds to the
voltage printed on the back or the underside of the DVD Player.
Use only the supplied AC adaptor to charge the battery.
•
•
Note
You can only charge the DVD Player when it is in power-off mode.•
1Switch the POWER ON / OFF/CHR slide selector to the OFF/
CHR position.

19EN
English
2Connect the supplied AC adaptor to the DC IN 12V socket on
the DVD Player and to the AC outlet.
The red charge indicator turns on. It takes about 4 hours to
fully charge the battery.
When the battery is fully charged, the red charge indicator
turns off.
Tip
You can only charge the battery when the temperature is between 0°C and 35°C.
When headphones are connected to the DVD Player, the fully charged battery
lasts about 2.5 hours.
To maximize battery life, recharge the battery immediately after the battery is fully
discharged.
When the DVD Player is not in use, turn it off.
•
•
•
•
Install the remote control battery
Caution
Risk of product damage! Risk of explosion! Keep batteries away from heat,
sunshine or re. Never discard batteries in re.
Risk of decreased battery life! Never mix different brands or types of batteries.
Risk of product damage! When the remote control is not used for long periods,
remove the batteries.
Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/
hazardouswaste/perchlorate..
•
•
•
•
»
»
