Philips PET101 User manual

© 2008 Koninklijke Philips Electronics N.V.
All rights reserved.
Document order number:
Register your product and get support at
000000000000
418176_indesign.xml.indd Sec4:136-Sec3:1418176_indesign.xml.indd Sec4:136-Sec3:1 2008-07-24 10:21:41 AM2008-07-24 10:21:41 AM

2 135
418176_indesign.xml.indd Sec3:2-Sec2:135418176_indesign.xml.indd Sec3:2-Sec2:135 2008-07-24 10:21:58 AM2008-07-24 10:21:58 AM

EN User manual 4
ES Manual del usuario 46
FR Mode d’emploi 90
DE Benutzerhandbuch 134
418176_indesign.xml.indd Sec1:3418176_indesign.xml.indd Sec1:3 2008-07-24 10:21:59 AM2008-07-24 10:21:59 AM

4EN 5EN
English
Contents
1 Important 6
Important safety instructions 6
Notice 10
2 Your portable DVD player 14
Introduction 14
What’s in the box 15
Overview of the main unit 16
Overview of the remote control 18
3 Get started 21
Connect toTV 22
Connect power 23
Install remote control battery 24
Select display language 25
4 Use your player 27
Turn on 27
Play discs 27
Play options 28
5 Adjust settings 32
Playback control options 32
DivXVideo-on-Demand code 33
Restrict access 34
Return to default settings 36
SelectTV display aspect ratio 37
Select video output format 38
Select MPEG-4 video subtitle 39
Select audio output 39
6 Troubleshooting 41
7 Product information 44
418176_indesign.xml.indd Sec1:4-Sec1:5418176_indesign.xml.indd Sec1:4-Sec1:5 2008-07-24 10:21:59 AM2008-07-24 10:21:59 AM

6EN 7EN
English
1 Important
Important safety instructions
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
h Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
i For countries with a polarized mains, do not
defeat the safety purpose of the polarized
or grounding-type plug.A polarized plug has
two blades with one wider than the other.
A grounding type plug has two blades and
a third grounding prong.The wide blade
or the third prong are provided for your
safety. If the provided plug does not fit
into your outlet, consult an electrician for
replacement of the obsolete outlet.
Caution:To prevent electric shock, match
the wide blade of the plug to the wide slot,
fully insert.
j Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
k Only use attachments/accessories specified
by the manufacturer.
l Use only with the cart, stand, tripod,
bracket, or table specified by the
418176_indesign.xml.indd Sec1:6-Sec1:7418176_indesign.xml.indd Sec1:6-Sec1:7 2008-07-24 10:22:00 AM2008-07-24 10:22:00 AM

8EN 9EN
English
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
m Unplug this apparatus during lightning
storms or when unused for long periods of
time.
n Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
o Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
unit:
Install all batteries correctly, + and - as
marked on the unit.
Do not mix batteries (old and new or
carbon and alkaline, etc.).
Remove batteries when the unit is not
used for a long time.
p Apparatus shall not be exposed to dripping
or splashing.
q Do not place any sources of danger on the
apparatus (e.g. liquid filled objects, lighted
candles).
r This product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.
•
•
•
418176_indesign.xml.indd Sec1:8-Sec1:9418176_indesign.xml.indd Sec1:8-Sec1:9 2008-07-24 10:22:01 AM2008-07-24 10:22:01 AM

10 EN 11EN
English
Warning
Never remove the casing of this player.
Never lubricate any part of this player.
Never place this player on other electrical equipment.
Keep this player away from direct sunlight, naked flames
or heat.
Never look into the laser beam inside the player.
Ensure that you always have easy access to the power
cord, plug or adaptor to disconnect the player from the
power.
•
•
•
•
•
•
Norge
Typeskilt finnes på apparatens bakside.
Observer: Nettbryteren er sekundert innkoplet.
Den innebygde netdelen er derfor ikke
fraktoplet nettet så lenge apparatet er tilsluttet
nettkontakten.
For å redusere faren for brann eller elektrisk støt,
skal apparatet, ikke utsettes for regn eller fuktighet.
Notice
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Electronics may void the user’s
authority to operate the equipment.
Disposal of old equipment and Used
batteries
Information for Users on Collection and
Disposal of Old Equipment and Used Batteries
These symbols on the products, batteries,
packaging, and/or accompanying documents
mean that used electrical and electronic products
and batteries should not be mixed with general
household waste. For proper treatment, recovery
and recycling of old products and used batteries,
please take them to applicable collection points, in
accordance with your national legislation and the
Directives 2002/96/EC and 2006/66/EC.
By disposing of these products and batteries
correctly, you will help to save valuable resources
and prevent any potential negative effects on
418176_indesign.xml.indd Sec1:10-Sec1:11418176_indesign.xml.indd Sec1:10-Sec1:11 2008-07-24 10:22:02 AM2008-07-24 10:22:02 AM

12 EN 13EN
English
human health and the environment which could
otherwise arise from inappropriate waste handling.
For more information about collection and
recycling of old products and batteries, please
contact your local municipality, your waste disposal
service or the point of sale where you purchased
the items.
Information on Disposal in other Countries
outside the European Union
These symbols are only valid in the European
Union. If you wish to discard these items, please
contact your local authorities or dealer and ask for
the correct method of disposal.
Note for the battery symbol
This symbol might be used in combination with a
chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical
involved.
Environmental information
All redundant packing material has been omitted.
We have done our utmost to make the packaging
easily separable into mono materials.
Please observe the local regulations regarding the
disposal of packing materials.
The making of unauthorized copies of copy-
protected material, including computer programs,
files, broadcasts and sound recordings, may be
an infringement of copyrights and constitute a
criminal offence.This equipment should not be
used for such purposes.
Recording and playback of material may require
consent. See Copyright Act 1956 andThe
Performer’s Protection Acts 1958 to 1972.
This player includes this label:
418176_indesign.xml.indd Sec1:12-Sec1:13418176_indesign.xml.indd Sec1:12-Sec1:13 2008-07-24 10:22:03 AM2008-07-24 10:22:03 AM

14 EN 15EN
English
2 Your portable
DVD player
Congratulations on your purchase, and welcome
to Philips!To fully benefit from the support that
Philips offers, register your product at www.Philips.
com/welcome.
Introduction
Your portable DVD player plays digital video
discs that conform to the universal DVD Video
standard.With it, you can play movies with true
cinema picture quality and stereo or multi-channel
sound (depending on disc and playback set-up).
You can also select sound track, subtitle languages,
and different angle of view (again depending on
DVD disc). Besides, you can restrict the play of
discs that are not suitable for children.
You can play the following discs on the DVD
player:
DVD video disc
Video CDs
MP3s
Audio CDs
CD with JPEG files
What’s in the box
Check and identify the contents of your package:
Portable DVD player
Remote control
AC power adaptor (AY4195)
AV cable
SCART converter
•
•
•
•
•
418176_indesign.xml.indd Sec1:14-Sec1:15418176_indesign.xml.indd Sec1:14-Sec1:15 2008-07-24 10:22:04 AM2008-07-24 10:22:04 AM

16 EN 17EN
English
Overview of the main unit
a AV OUT
Audio/Video output jack
b
Move cursor up / down
c /
Skip to previous/next chapter, track or
title
Move cursor to left/right
d
Stop play
•
•
•
•
•
e SETUP
Enter or exit system setup menu
f OPEN
Open disc door to insert or remove
disc
g IR/POWER
Remote sensor/Power indicator
h POWER
Turn DVD player on/off
i MENU
Enter or exit DVD menu
j
Start or interrupt play
k DC IN
Power supply socket
•
•
•
•
•
•
•
418176_indesign.xml.indd Sec1:16-Sec1:17418176_indesign.xml.indd Sec1:16-Sec1:17 2008-07-24 10:22:05 AM2008-07-24 10:22:05 AM

18 EN 19EN
English
Overview of the remote
control
a SETUP
Enter or exit system menu
b , OK
Move cursor up / down / left / right.
Confirms selection.
c OSD
Access available functions
d
Skip to previous chapter, track or title.
•
•
•
•
•
2
5
3
4
1
6
7
8
9
10
11
12
13
14
15
16
DVD ME NU
OSD
MUTE
TITLE
2
5
3
4
1
6
7
8
9
10
11
12
13
14
15
16
DVD ME NU
OSD
MUTE
TITLE
e
Start / pause / resume play
f MUTE
Turn off sound
g Numeric Keypad 0 - 9
Input numbers.
h SUBTITLE
Select a subtitle language for DVD disc.
i RETURN
Return to the PBC (playback control)
menu ofVCD disc
j A-B
Setup repeated play of a specific section
k DVD MENU
Return to main menu of DVD disc
l TITLE
Return to title menu of DVD disc
m
Skip to the next chapter, track or title
n
•
•
•
•
•
•
•
•
•
418176_indesign.xml.indd Sec1:18-Sec1:19418176_indesign.xml.indd Sec1:18-Sec1:19 2008-07-24 10:22:08 AM2008-07-24 10:22:08 AM

20 EN 21EN
English
Stop play
o AUDIO
Select an audio language when playing
a DVD disc or select an audio mode
(Stereo, Mono-Left or Mono-Right)
when playing aVCD/CD disc
p ZOOM
Enlarge or reduce picture or active
image size
•
•
•
3 Get started
Caution
Use the controls only as stated in this user manual.•
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial numbers. Find the model
number and serial number of this player at the
back or the bottom of your player.Write these
numbers here:
Model No. __________________________
Serial No. ___________________________
418176_indesign.xml.indd Sec1:20-Sec1:21418176_indesign.xml.indd Sec1:20-Sec1:21 2008-07-24 10:22:09 AM2008-07-24 10:22:09 AM

22 EN 23EN
English
Connect to TV
Note
Match the color of the AV cable with the jacks: the yellow
cable is for the yellow video jack, the red/white cable is for
the red/white audio jacks.
•
1 Connect AV cable to the player and to the
TV.
If there are no matching AUDIO IN
jacks on theTV, plug the supplied
SCART converter onto the TV first,
then connect the AV cable to the
SCART converter.
•
Connect power
Caution
Risk of product damage! Ensure that the power supply
voltage corresponds to the voltage printed on the back or
the underside of the player.
Risk of electric shock! When you unplug the AC adaptor,
always pull the plug from the socket. Never pull the cord.
•
•
1 Connect the AC adaptor to the DC IN jack
of the player and to the power outlet.
418176_indesign.xml.indd Sec1:22-Sec1:23418176_indesign.xml.indd Sec1:22-Sec1:23 2008-07-24 10:22:10 AM2008-07-24 10:22:10 AM

24 EN 25EN
English
Install remote control battery
Caution
Risk of explosion! Keep batteries away from heat, sunshine
or fire. Never discard batteries in fire.
Risk of decreased battery life! Never mix different brands
or types of batteries.
Risk of product damage! When the remote control is not
used for long periods, remove the batteries.
Perchlorate Material - special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
•
•
•
•
For first-time use:
1 Remove the protective tab to activate the
remote control battery.
To replace the remote control battery:
1 Open the battery compartment.
2 Insert 1 CR2025 battery with correct
polarity (+/-) as indicated.
3 Close the battery compartment.
Select display language
English is the default language for screen display.
You can change the display language.
1 Slide the POWER switch to turn on the
DVD player.
2 Turnr on theTV.
418176_indesign.xml.indd Sec1:24-Sec1:25418176_indesign.xml.indd Sec1:24-Sec1:25 2008-07-24 10:22:12 AM2008-07-24 10:22:12 AM

26 EN 27EN
English
3 Press SETUP.
4 Select [General] > [Language].
5 Select the language, then press OK.
Setup menu - General
Language
PBC settings
Divx VOD
Parental
Sot password
Factory settings
OK SETUP
Browse Seoect Exit
On
PGR
English
Francals
Doutsch
Spanlsh
Italian
Setup menu - General
Language
PBC settings
Divx VOD
Parental
Sot password
Factory settings
OK SETUP
Browse Seoect Exit
On
PGR
English
Francals
Doutsch
Spanlsh
Italian
4 Use your player
Turn on
1 Slide the POWER switch to turn on the
DVD player.
2 Turn on theTV.
Play discs
1 Slide OPEN on the DVD player and lift up
the CD compartment.
2 Insert the disc with label side facing up.
3 Push down to close the CD compartment.
Play starts automatically.
If a menu appears, select an item, then
press OK to start play.
To stop play, press .
To pause, press . Press again to
resume play.
»
•
•
•
418176_indesign.xml.indd Sec1:26-Sec1:27418176_indesign.xml.indd Sec1:26-Sec1:27 2008-07-24 10:22:14 AM2008-07-24 10:22:14 AM

28 EN 29EN
English
To select the previous/next item, press
or .
To start search within video/audio, press
and hold or . Briefly press or
during search to adjust search speed.
ForVideo CDs or Super Video CDs:
Press RETURN to return to the
previous menu.
Play options
Select audio language
For DVDs that contain two or more audio
languages.
1 During play, press AUDIO repeatedly until
the language is selected.
Select subtitle language
For DVDs that contain two or more subtitle
languages.
•
•
•
1 During play, press SUBTITLE repeatedly until
the language is selected.
Select audio mode
When you playVCDs/CDs, you can select an
audio mode.
1 Press AUDIO repeatedly until the audio
mode is selected.
Zoom
For DVDs,VCDs and picture CDs, you can zoom
in and out for video images or pictures.
1 Press ZOOM repeatedly to zoom in and out.
2 When the video image or picture is enlarged,
press to pan through it.
Repeat a section
You can repeat a specific section of audio/video
within a title/chapter/track (repeat A-B).
1 During play, press A-B to mark the start of
the section to repeat.
418176_indesign.xml.indd Sec1:28-Sec1:29418176_indesign.xml.indd Sec1:28-Sec1:29 2008-07-24 10:22:15 AM2008-07-24 10:22:15 AM

30 EN 31EN
English
2 Press and hold or to search for the
end of the section.
3 Press A-B to mark the end of the section.
The selected section plays repeatedly.
4 Press A-B to cancel.
Repeat one/all
1 During play, press OSD.
2 Select [Repeat], then press OK.
3 Select [Repeat 1] or [Repeat all], then press
OKto confirm.
Random play
For audio CDs and MP3 CDs only.
1 Press OSD.
2 Select [Shuffle].
3 Select [On] or [Off], then press OK to
confirm.
»
Rotate pictures
For picture CDs only.
1 When you view the picture, press OSD.
2 Select [Rotate], then press OK.
3 Press to rotate counter-clockwise.
4 Press to rotate clockwise.
5 Press OSD again to exit.
418176_indesign.xml.indd Sec1:30-Sec1:31418176_indesign.xml.indd Sec1:30-Sec1:31 2008-07-24 10:22:16 AM2008-07-24 10:22:16 AM

32 EN 33EN
English
5 Adjust settings
Playback control options
ForVCDs (version 2.0 only) and SVCDs.
1 Press SETUP.
2 Select [General] > [PBC settings].
3 Select [On] or [Off], then press OK to
confirm.
4 Press SETUP to exit.
Setup menu - General
General
Video
Audio
Language
PBC settings
DivX VOD
Parental
Sot password
Factory settlngs
OK SETUP
Browse Seoect Exit
Setup menu - General
General
Video
Audio
Language
PBC settings
DivX VOD
Parental
Sot password
Factory settlngs
OK SETUP
Browse Seoect Exit
DivXVideo-on-Demand code
DivX is a popular media technology created
by DivX, Inc. DivX media files contain highly
compressed video with high visual quality that
maintains a relatively small file size. DivX files can
also include advanced media features like menus,
subtitles, and alternate audio tracks. Many DivX
media files are available for download online, and
you can rent and purchase DivX videos with the
DivXVOD (Video on Demand) service.To use
this service, you need the DivX VOD registration
code of this player. For more information and
instructions, visit www.divx.com/vod.
1 Press SETUP.
2 Select [General] > [DivX (VOD)].
The DivX registration code appears
3 Write down the number for future reference.
4 Press SETUP to exit.
»
418176_indesign.xml.indd Sec1:32-Sec1:33418176_indesign.xml.indd Sec1:32-Sec1:33 2008-07-24 10:22:17 AM2008-07-24 10:22:17 AM

34 EN 35EN
English
“DivX, DivX” Certified, and associated logos
are trademarks of DivX, Inc. and are used under
license.
Offical DivX® Certified product. Plays all versions
of DivX® video (including DivX® 6) with
standard playback of DivX® media files.
Restrict access
You can restrict the play of discs that are not
suitable for children, or have certain discs played
with alternative scenes. Once you selected an
access level, discs with higher levels cannot be
played.
1 Press SETUP.
2 Select [General] > [Parental].
A list of disc rating is displayed.
[1 kid safe]: acceptable for children.
[2 G]: acceptable for general viewers.
[3 PG]: parental guidance suggested.
[4 PG 13]: unsuitable for children under
age 13.
»
»
»
»
»
[5 PGR]: recommend parents to restrict
children under 17 to view.
[6 R]: restricted. Recommend parent to
guide children under 17 to view.
[7 NC 17]: unsuitable for children under
age 17.
[8 Adult]: acceptable for adults only.
3 Select a setting, then press OK to confirm.
4 Enter the password.
If this is the first time you restrict access,
enter 9999 as the password.
5 Press SETUP to exit.
Set password
1 Press SETUP.
2 Select [General] > [Set password].
3 Enter the current password.
If this is the first time you restrict access,
enter 9999 as the password.
4 Enter the new 4-digit password, then press
OK to confirm.
»
»
»
»
•
•
418176_indesign.xml.indd Sec1:34-Sec1:35418176_indesign.xml.indd Sec1:34-Sec1:35 2008-07-24 10:22:19 AM2008-07-24 10:22:19 AM

36 EN 37EN
English
5 Enter the new password again, then press
OK to confirm.
6 Press SETUP to exit.
Return to default settings
Note
When you return to default settings, the access restriction
password will not be reset.
•
1 Press SETUP.
2 Select [General] > [Factory settings], then
press OK.
The settings return to their default
setting.
3 Press SETUP to exit.
»
Select TV display aspect ratio
Set the screen format according to how you want
the picture to appear on yourTV:
1 Press SETUP.
2 Select [Video] > [TV display], then select an
option:
[16:9]: For widescreen TVs
[4:3 LB]: For normalTVs.While playing
a wide-screen picture, black bars may
appear on the top and the bottom of
the screen.
[4:3 PS]: For normalTVs.While playing
a full-height picture, the sides of the
picture may be trimmed.
3 Press OK to confirm.
4 Press SETUP to exit.
•
•
•
Setup menu - Video
General
Video
Audio
TV Display
TV Standard
MPEG - 4 subtitles
OK SETUP
Browse Seoect Exit
Setup menu - Video
General
Video
Audio
TV Display
TV Standard
MPEG - 4 subtitles
OK SETUP
Browse Seoect Exit
418176_indesign.xml.indd Sec1:36-Sec1:37418176_indesign.xml.indd Sec1:36-Sec1:37 2008-07-24 10:22:20 AM2008-07-24 10:22:20 AM
