Philips SBCRU890/00 User manual

SBC RU890
SBC RU890
• Large touch-screen LCD remote control with backlighting
• Dynamic, intuitive user interface for complete control of all
audio/video products
• 7 hard buttons for easy access to frequently used functions
(Mute,Volume +/-, …)
• Build-in IR commands for the Philips RC5/RC6 products
• Universal learnable for all non-Philips products
• Unlimited macro functionality – multiple IR codes are sent
upon a single button press

© Philips Consumer Electronics N.V.
Data subject to change without notice
Business Accessories
SBC RU890
Standard product information
Mechanical
• Case ABS
• Keys yes
• Text/Symbol indication - printing on the housing
- wide range of colours available
• IRED protective lens yes
• Max. number of keys 7 hard keys
• LCD high resolution (320 mm x 240 mm)
liquid crystal display with contrast
control
• LCD colour green, 4 grey levels
• Serial port 3 – wire (RC232) serial port for
future expandability
• Weight - ca. 177 g (excl. batteries)
- ca. 250 g (incl. batteries)
• Standard packing - foam bag with retail package in
carton box
- minimum quantities: 5 pcs/box
Electrical
• Transmission/Coding system Philips RC 5 (enlarged), RC 6
• IRED 2
• Wavelength 950 nm
• EL backlight output 1.3 Cd/m2
• Operating voltage range 4.2 – 7V
• Standby current 100 mA
• Transmitting power 120 mW/sr typ.
• Operating distance 10 m typ.With a receiver sensitivity
>0.5 mW/ m2
• Learning frequency up to 56 kHz (no DC codes, no toggle
lits, no EOT codes)
• Batteries 4 x types AA, 1.5 batteries or one
4.8V battery pack
• Battery life approx.6 months
• Approvals FCC, CE, UL
Temperature range
• Operating temperature + 5 to +45 °C
• Storage temperature -25 to +55 °C
Drop test
• The complete unit, incl. batteries, is dropped on a PVC covered stone floor
from a height of 70 cm. Once on each side.After this test, the unit should
perform without failures.
Liquid test
• 55 cc of coffee is poured over the top-side of the RC unit.After 5 sec the
coffee is removed as good as possible and dried in an open space at 20 °C
during 48h.After this test, the unit should perform without failures.
Dimensions
Key layout top part overview
