1. General description
The CBT3384 provides ten bits of high-speed TTL-compatible bus switching. The low
ON resistance of the switch allows connections to be made with minimal propagation
delay.
The CBT3384 device is organized as two 5-bit bus switches with two separate output
enable (1OE, 2OE) inputs. When nOE is LOW, the switch is on and port A is connected to
the B port. When nOE is HIGH, each switch is disabled.
The CBT3384 is characterized for operation from −40 °C to +85 °C.
2. Features
n5Ωswitch connection between two ports
nTTL-compatible control input levels
nMultiple package options
nSee CBTD3384 for CBT3384 with level shifting diodes
nLatch-up protection exceeds 100 mA per JESD78
nESD protection:
uHBM JESD22-A114E exceeds 2000 V
uCDM JESD22-C101C exceeds 1000 V
3. Ordering information
[1] Also known as QSOP24 package
CBT3384
10-bit bus switch with 5-bit output enables
Rev. 06 — 2 November 2009 Product data sheet
Table 1. Ordering information
Type
number Package
Temperature range Name Description Version
CBT3384D −40 °C to +85 °C SO24 plastic small outline package; 24 leads; body width 7.5 mm SOT137-1
CBT3384DB −40 °C to +85 °C SSOP24 plastic shrink small outline package; 24 leads;
body width 5.3 mm SOT340-1
CBT3384DK −40 °C to +85 °C SSOP24[1] plastic shrink small outline package; 24 leads; body
width 3.9 mm; lead pitch 0.635 mm SOT556-1
CBT3384PW −40 °C to +85 °C TSSOP24 plastic thin shrink small outline package; 24 leads;
body width 4.4 mm SOT355-1

CBT3384_6 © NXP B.V. 2009. All rights reserved.
Product data sheet Rev. 06 — 2 November 2009 2 of 14
NXP Semiconductors CBT3384
10-bit bus switch with 5-bit output enables
4. Functional diagram
5. Pinning information
5.1 Pinning
Fig 1. Logic diagram
001aak877
1A1
1A5
1B1
1B5
1OE
3
11
1
10
2
2A1
2A5
2B1
2B5
2OE
14
22
13
23
15
Fig 2. Pin configuration for SO24 (SOT137-1) Fig 3. Pin configuration for SSOP24 (SOT340-1) and
TSSOP24 (SOT355-1)
CBT3384
1OE VCC
1B1 2B5
1A1 2A5
1A2 2A4
1B2 2B4
1B3 2B3
1A3 2A3
1A4 2A2
1B4 2B2
1B5 2B1
1A5 2A1
GND 2OE
001aak878
1
2
3
4
5
6
7
8
9
10
11
12
14
13
16
15
18
17
20
19
22
21
24
23
CBT3384
1OE VCC
1B1 2B5
1A1 2A5
1A2 2A4
1B2 2B4
1B3 2B3
1A3 2A3
1A4 2A2
1B4 2B2
1B5 2B1
1A5 2A1
GND 2OE
001aak879
1
2
3
4
5
6
7
8
9
10
11
12
14
13
16
15
18
17
20
19
22
21
24
23

CBT3384_6 © NXP B.V. 2009. All rights reserved.
Product data sheet Rev. 06 — 2 November 2009 3 of 14
NXP Semiconductors CBT3384
10-bit bus switch with 5-bit output enables
5.2 Pin description
6. Functional description
[1] H = HIGH voltage level; L = LOW voltage level; Z = high-impedance OFF-state.
Fig 4. Pin configuration for SSOP24 (SOT556-1)
CBT3384
1OE VCC
1B1 2B5
1A1 2A5
1A2 2A4
1B2 2B4
1B3 2B3
1A3 2A3
1A4 2A2
1B4 2B2
1B5 2B1
1A5 2A1
GND 2OE
001aak880
1
2
3
4
5
6
7
8
9
10
11
12
14
13
16
15
18
17
20
19
22
21
24
23
Table 2. Pin description
Symbol Pin Description
1OE, 2OE 1, 13 output enable input (active LOW)
1A1 to 1A5 3, 4, 7, 8, 11 data input/output (A port)
2A1 to 2A5 14, 17, 18, 21, 22 data input/output (A port)
1B1 to 1B5 2, 5, 6, 9, 10 data input/output (B port)
2B1 to 2B5 15, 16, 19, 20, 23 data input/output (B port)
GND 12 ground (0 V)
VCC 24 positive supply voltage
Table 3. Function selection[1]
Input Input/output
1OE 2OE 1An, 1Bn 2An, 2Bn
L L 1An = 1Bn 2An = 2Bn
L H 1An = 1Bn Z
H L Z 2An = 2Bn
HHZZ

CBT3384_6 © NXP B.V. 2009. All rights reserved.
Product data sheet Rev. 06 — 2 November 2009 4 of 14
NXP Semiconductors CBT3384
10-bit bus switch with 5-bit output enables
7. Limiting values
[1] Stresses beyond those listed may cause permanent damage to the device. These are stress ratings only and functional operation of the
device at these or any other conditions beyond those indicated under Section 8. is not implied. Exposure to absolute-maximum-rated
conditions for extended periods may affect device reliability.
[2] The input and output negative-voltage ratings may be exceeded if the input and output clamp-current ratings are observed.
8. Recommended operating conditions
9. Static characteristics
Table 4. Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134).
[1]
T
amb
= − 40 ° C to +85 ° C, unless otherwise specified.
Symbol Parameter Conditions Min Max Unit
VCC supply voltage −0.5 +7.0 V
VIinput voltage [2] −0.5 +7.0 V
IOoutput current VO<0V - ±128 mA
IIK input clamping current VI/O =0V −50 - mA
Tstg storage temperature −65 +150 °C
Table 5. Operating conditions
All unused control inputs of the device must be held at V
CC
or GND to ensure proper device operation.
Symbol Parameter Conditions Min Typ Max Unit
VCC supply voltage 4.5 - 5.5 V
VIH HIGH-state input voltage 2.0 - - V
VIL LOW-state input voltage - - 0.8 V
Tamb ambient temperature operating in free air −40 - +85 °C
Table 6. Static characteristics
Voltages are referenced to GND (ground = 0 V).
Symbol Parameter Conditions Tamb = −40 °C to +85 °C Unit
Min Typ[1] Max
VIK input clamping voltage VCC = 4.5 V; II=−18 mA - - −1.2 V
IIinput leakage current VCC = 5.5 V; VI= GND or 5.5 V - - ±1µA
ICC supply current VCC = 5.5 V; IO= 0 mA;
VI=V
CC or GND --3µA
∆ICC additional supply current per input pin; VCC = 5.5 V; one input at
3.4 V, other inputs at VCC or GND [2] - - 2.5 mA
Vpass pass voltage output HIGH; VI=V
CC = 5.0 V;
IO=−100 µA3.6 3.9 4.2 V
CIinput capacitance control pins; VI= 3 V or 0 V - 4.0 - pF
Cio(off) off-state input/output
capacitance port off; VI= 3 V or 0 V; nOE = VCC - 10.0 - pF

CBT3384_6 © NXP B.V. 2009. All rights reserved.
Product data sheet Rev. 06 — 2 November 2009 5 of 14
NXP Semiconductors CBT3384
10-bit bus switch with 5-bit output enables
[1] All typical values are at VCC =5V,T
amb =25°C.
[2] This is the increase in supply current for each input that is at the specified TTL voltage level rather than VCC or GND.
[3] Measured by the voltage drop between the nAn and the nBn terminals at the indicated current through the switch. ON resistance is
determined by the lowest voltage of the two (nAn or nBn) terminals.
10. Dynamic characteristics
[1] The propagation delay is the calculated RC time constant of the typical ON resistance of the switch and the specified load capacitance,
when driven by an ideal voltage source (zero output impedance).
[2] tpd is the same as tPLH and tPHL.
RON ON resistance VCC = 4.5 V; VI=0V;I
I=64mA [3] -57Ω
VCC = 4.5 V; VI=0V;I
I=30mA [3] -57Ω
VCC = 4.5 V; VI= 2.4 V; II=−15 mA [3] -1015Ω
Table 6. Static characteristics
…continued
Voltages are referenced to GND (ground = 0 V).
Symbol Parameter Conditions Tamb = −40 °C to +85 °C Unit
Min Typ[1] Max
Table 7. Dynamic characteristics
Voltages are referenced to GND (ground = 0 V). For test circuit see Figure 7.
Symbol Parameter Conditions Tamb = 25 °C Tamb =−40 °C to +85 °C Unit
Min Typ Max Min Max
tpd propagation delay nAn, nBn to nBn, nAn;
see Figure 5 [1][2]
VCC = 5.0 V ±0.5 V - - 0.25 - 0.25 ns
tPZH OFF-state to HIGH
propagation delay nOE to nAn or nBn; see Figure 6
VCC = 5.0 V ±0.5 V 1.2 2.3 5.7 1.2 5.6 ns
tPZL OFF-state to LOW
propagation delay nOE to nAn or nBn; see Figure 6
VCC = 5.0 V ±0.5 V 1.2 2.3 5.7 1.2 6.0 ns
tPHZ HIGH to OFF-state
propagation delay nOE to nAn or nBn; see Figure 6
VCC = 5.0 V ±0.5 V 1.7 3.6 5.2 1.7 5.5 ns
tPLZ LOW to OFF-state
propagation delay nOE to nAn or nBn; see Figure 6
VCC = 5.0 V ±0.5 V 1.7 2.7 5.2 1.7 6.6 ns

CBT3384_6 © NXP B.V. 2009. All rights reserved.
Product data sheet Rev. 06 — 2 November 2009 6 of 14
NXP Semiconductors CBT3384
10-bit bus switch with 5-bit output enables
11. Waveforms
Measurement points are given in Table 8.
Logic levels: VOL and VOH are typical output voltage levels that occur with the output load.
Fig 5. The data input (nAn, nBn) to output (nBn, nAn) propagation delay times
001aak881
VMVM
VMVM
VI
nAn, nBn input
GND
VOH
nBn, nAn output
VOL
tPHL tPLH
Measurement points are given in Table 8.
Logic levels: VOL and VOH are typical output voltage levels that occur with the output load.
Fig 6. Enable and disable times
001aak298
tPLZ
tPHZ
outputs
disabled outputs enabled
VY
VX
outputs
enabled
output
LOW to OFF
OFF to LOW
output
HIGH to OFF
OFF to HIGH
nOE input
VI
3.5 V
VMVM
VOL
VOH
GND
GND
tPZL
tPZH
VM
VM
Table 8. Measurement points
Supply voltage Input Output
VCC VIVMVMVXVY
VCC = 5.0 V ±0.5 V GND to 3.0 V 1.5 V 1.5 V VOL + 0.3 V VOH −0.3 V

CBT3384_6 © NXP B.V. 2009. All rights reserved.
Product data sheet Rev. 06 — 2 November 2009 7 of 14
NXP Semiconductors CBT3384
10-bit bus switch with 5-bit output enables
12. Test information
Test data is given in Table 9.
All input pulses are supplied by generators having the following characteristics: PRR ≤10 MHz; Zo=50Ω.
The outputs are measured one at a time with one transition per measurement.
Definitions for test circuit:
RL= Load resistance.
CL= Load capacitance including jig and probe capacitance.
RT= Termination resistance should be equal to output impedance Zoof the pulse generator.
VEXT = External voltage for measuring switching times.
Fig 7. Test circuit for measuring switching times
VMVM
tW
tW
10 %
90 %
0 V
VI
VI
negative
pulse
positive
pulse
0 V
VMVM
90 %
10 %
tf
tr
tr
tf
001aae331
VEXT
VCC
VIVO
DUT
CL RT
RL
RL
G
Table 9. Test data
Supply voltage Input Load VEXT
VItr, tfCLRLtPLH, tPHL tPLZ, tPZL tPHZ, tPZH
VCC = 5.0 V ±0.5 V GND to 3.0 V ≤2.5 ns 50 pF 500 Ωopen 7.0 V open

CBT3384_6 © NXP B.V. 2009. All rights reserved.
Product data sheet Rev. 06 — 2 November 2009 8 of 14
NXP Semiconductors CBT3384
10-bit bus switch with 5-bit output enables
13. Package outline
Fig 8. Package outline SOT137-1 (SO24)
UNIT A
max. A1A2A3bpcD
(1) E(1) (1)
eH
ELL pQZ
ywv θ
REFERENCES
OUTLINE
VERSION EUROPEAN PROJECTION ISSUE DATE
IEC JEDEC JEITA
mm
inches
2.65 0.3
0.1 2.45 2.25 0.49 0.36 0.32 0.23 15.6 15.2 7.6 7.4 1.27 10.65 10.00 1.1 1.0 0.9 0.4 8
0
o
o
0.25 0.1
DIMENSIONS (inch dimensions are derived from the original mm dimensions)
Note
1. Plastic or metal protrusions of 0.15 mm (0.006 inch) maximum per side are not included.
1.1
0.4
SOT137-1
X
12
24
wM
θ
A
A1
A2
bp
D
HE
Lp
Q
detail X
E
Z
c
L
vMA
13
(A )
3
A
y
0.25
075E05 MS-013
pin 1 index
0.1 0.012
0.004 0.096 0.089 0.019 0.014 0.013 0.009 0.61 0.60 0.30 0.29 0.05
1.4
0.055
0.419
0.394 0.043 0.039 0.035 0.016
0.01
0.25
0.01 0.004
0.043
0.016
0.01
e
1
0 5 10 mm
scale
SO24: plastic small outline package; 24 leads; body width 7.5 mm SOT137-1
99-12-27
03-02-19

CBT3384_6 © NXP B.V. 2009. All rights reserved.
Product data sheet Rev. 06 — 2 November 2009 9 of 14
NXP Semiconductors CBT3384
10-bit bus switch with 5-bit output enables
Fig 9. Package outline SOT340-1 (SSOP24)
UNIT A1A2A3bpcD
(1) E(1) (1)
eH
ELL pQZywv θ
REFERENCES
OUTLINE
VERSION EUROPEAN PROJECTION ISSUE DATE
IEC JEDEC JEITA
mm 0.21
0.05 1.80 1.65 0.38 0.25 0.20 0.09 8.4 8.0 5.4 5.2 0.65 1.25
7.9
7.6 0.9 0.7 0.8 0.4 8
0
o
o
0.13 0.10.2
DIMENSIONS (mm are the original dimensions)
Note
1. Plastic or metal protrusions of 0.2 mm maximum per side are not included.
1.03
0.63
SOT340-1 MO-150 99-12-27
03-02-19
X
wM
θ
A
A1
A2
bp
D
HE
Lp
Q
detail X
E
Z
e
c
L
vMA
(A )
3
A
112
24 13
0.25
y
pin 1 index
0 2.5 5 mm
scale
SSOP24: plastic shrink small outline package; 24 leads; body width 5.3 mm SOT340-1
A
max.
2

CBT3384_6 © NXP B.V. 2009. All rights reserved.
Product data sheet Rev. 06 — 2 November 2009 10 of 14
NXP Semiconductors CBT3384
10-bit bus switch with 5-bit output enables
Fig 10. Package outline SOT556-1 (SSOP24)
UNIT A1A2A3HELp bpcD
(1) E(1) Z(1)
eL ywv θ
REFERENCES
OUTLINE
VERSION EUROPEAN PROJECTION ISSUE DATE
IEC JEDEC JEITA
mm 0.25
0.10 1.55 1.40 0.25 0.31 0.20 0.25 0.18 8.8 8.6 4.0 3.8 0.635 1
6.2
5.8 0.89 0.41 1.05 0.66 8
0
o
o
8
0
o
o
0.180.25 0.1
DIMENSIONS (millimetre dimensions are derived from the original inch dimensions)
Note
1. Plastic or metal protrusions of 0.2 mm (0.008 inch) maximum per side are not included.
SOT556-1 99-12-27
03-02-18
wM
bp
D
HE
E
Z
e
c
vMA
X
A
y
112
24 13
θ
A
A1
A2
Lp
detail X
L
(A )
3
MO-137
0 2.5 5 mm
scale
SSOP24: plastic shrink small outline package; 24 leads; body width 3.9 mm; lead pitch 0.635 mm SOT556-1
A
max.
1.73
inches 0.0098
0.0040 0.061 0.055 0.01 0.012 0.008 0.0098 0.0075 0.344 0.337 0.157 0.150 0.025 0.041
0.244
0.228 0.035 0.016 0.040 0.026
0.0070.01 0.004
0.068
