Philips FC8398 - FC8390 User manual

FC8398 - FC8390

2

3
1

4

FC8398-FC8390
ENGLISH 6
简体中文 10

6
General description (Fig. 1)
1 Dust cover
2 Dustbag
3 Motor Protection Filter
4 Hose connection opening
5 Hose connector
6 Cord rewind button
7 Suction power knob
8 On/off button
9 Plug
10 Filter grille
11 AFS Filter
12 Handgrip
13 Storage slot
14 Swivel wheel
15 Type plate
16 Rear wheels
17 Dustbag full indicator
18 Handgrip of hose with suction power slide (FC8392)
19 Accessory clip
20 Handgrip of hose (FC8398/8396)
21 Telescopic tube (FC8398)
22 Tubes (FC8396/8392)
23 Tri-Active nozzle (FC8398)
24 Combi nozzle (FC8396/8392)
25 Twist & Clean nozzle (FC8396)
26 Twist & Clean polishing pads
27 Crevice tool
28 Small nozzle
29 Small brush (FC8398)
Important
Read this user manual carefully before you use use the appliance and save it for future reference.
Check if the voltage indicated on the appliance corresponds to the local mains voltage before
you connect the appliance.
Do not use the appliance if the plug, the cord or the appliance itself is damaged.
If the mains cord of this appliance is damaged, you must have it replaced by Philips, a service
centre authorised by Philips or similarly qualied persons in order to avoid a hazard.
Keep the appliance out of the reach of children.
Never suck up water or any other liquid. Never suck up ammable substances and do not suck
up ashes until they are cold.
Do not point the hose, the tube or any other accessory at the eyes or ears nor put it in your
mouth when it is connected to the vacuum cleaner and the vacuum cleaner is switched on.
When you use the appliance to vacuum ashes, ne sand, lime, cement dust and similar
substances, the pores of the paper dustbag become clogged. As a result, the dustbag-full
indicator will indicate that the dustbag is full. Replace the dustbag, even if it is not full yet.
Never use the appliance without the Motor Protection Filter.This damages the motor and
shortens the life of the appliance.
Only use Philips s-bag `double-layer paper dustbags or the reusable dustbag provided.
-
-
-
-
-
-
-
-
-
ENGLISH

Electromagnetic elds (EMF)
This Philips appliance complies with all standards regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this user manual, the appliance is safe to use based on
scientic evidence available today.
Preparing for use
Hose
1 To connect the hose, push it into the appliance and turn it clockwise (Fig. 2).
To disconnect the hose, turn it anticlockwise and pull it out of the appliance.
2 To connect the tubes to each other and to the handgrip of the hose, insert the narrow
section into the wider section while turning a little.The tube with the clip is the lower
tube (Fig. 3).
You can connect the accessories in the same way.
Disconnect the accessories and tubes by pulling them and turning them a little.
Telescopic tube (specic types only)
1 Adjustthetubetothelengthyoundmostcomfortableduringvacuumcleaning.(Fig.4)
Combination nozzle
The combination nozzle can be used on either carpets (with the brush strips folded in) or hard
oors (with the brush strips folded out):
1 Tocleanhardoors,pushtherockerswitchontopofthecombinationnozzlewithyour
foot.Thebrushstripscomeoutofthenozzlehousing.(Fig.5)
2 Tocleancarpets,pushtherockerswitchontheothersidetomakethebrushstrips
disappear into the housing. (Fig. 6)
Accessory clip
The accessory clip can simply be snapped onto the tube.
The crevice tool and the small nozzle (specic types only) can be snapped onto the clip (Fig. 7).
Using the appliance
Vacuuming
1 Pullthecordoutoftheapplianceandputthemainspluginthewallsocket.
2 Push the on/off button on top of the appliance with your foot to switch on the appliance.
You can carry the vacuum cleaner by the handle at the front of the appliance.
Adjusting suction power
You can adjust the suction power by means of:
the slide on the handgrip, or (Fig. 8)
the suction power knob (specic types only) (Fig. 9).
Storage
1 Switchoffapplianceandremovethemainsplugfromthewallsocket.
2 Pressthecordrewindbuttontorewindthemainscord.
3 Puttheapplianceinuprightpositionandattachthelowertubetotheappliancebymeansof
the clip (Fig. 10).
-
-
-
-
ENGLISH 7

Replacement
Replacing the dustbag
Replace the dustbag as soon as the dustbag-full indicator has changed colour permanently.
Always unplug the appliance before you replace the dustbag.
1 Openthedustbagcompartmentcover(Fig.11).
2 Push the dustbag holder backwards (Fig. 12).
3 Pullthecardboardtagupwardstoremovethefulldustbagfromtheholder.Thedustbagis
sealedautomatically(Fig.13).
4 Slidethecardboardfrontofthenewdustbagintothetwogroovesofthedustbagholder.
Press it down as far as possible (Fig. 14).
5Pullthedustbagholderforwards(‘click’)andclosethedustbagcompartmentcover.(Fig.15)
Note:If you have not inserted a dustbag, you cannot close the dustbag compartment cover.
Philips s-bag `paper dustbags are available under type number FC8021 .
Reusable dustbag
If provided, you can use the reusable dustbag instead of paper dustbags.The reusable dustbag can be
used and emptied repeatedly.
To remove and insert the reusable dustbag, simply follow the instructions for replacing paper
dustbags.
To empty the reusable dustbag:
1 Removetheclipbyslidingitoffthedustbagsideways.
2 Shake out the contents into a dustbin.
3 Closethedustbagbyslidingtheclipbackontothebottomedgeofthedustbag.
Philips reusable dustbags are available under type number 4341 004 92090.
Replacing lters
Alwaysunplugtheappliancebeforeyoureplacethelters.
Motor Protection Filter
Replace the Motor Protection Filter once a year.
1 Openthecoverandremovethelter.
2 Insertanewlterintotheholderwiththewhitesidepointingupwards(Fig.16).
AFS Micro Filter
Replace the AFS Micro Filter every 6 months.
1 Openthegrille(1)atthebackoftheapplianceandremoveit(2)(Fig.17).
2 Removetheoldlter.Placethesidesandthebottomedgeofthenewlterproperlybehind
the 3 ridges of the holder on the inside of the grille (Fig. 18).
3 Reattachthegrilletothevacuumcleaner.Firsthookthebottomedgeofthegrilleintothe
appliance(1)andthenpushthegrilletowardstheapplianceuntilitsnapshome(2)(Fig.19).
Two AFS Micro Filters and one Motor Protection Filter are available under type number FC8032.
ENGLISH8

Environment
Do not throw away the appliance with the normal household waste at the end of its life, but
hand it in at an ofcial collection point for recycling. By doing this, you help to preserve the
environment (Fig. 20).
Guarantee and service
If you need information or if you have a problem, please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre in your country (you nd its phone number in the
worldwide guarantee leaet). If there is no Customer Care Centre in your country, go to your local
Philips dealer or contact the Service Department of Philips Domestic appliances and Personal Care
BV.
Troubleshooting
1 The suction power is insufcient.
Make sure the suction power knob is in maximum position (specic types only).
Make sure the slide on the handgrip is closed.
Perhaps the dustbag is full. Replace the dustbag.
Perhaps the lters are dirty. Replace the lters.
The nozzle, tube or hose may be blocked up.To remove the obstruction, disconnect the
blocked-up item and connect it (as far as possible) the other way around. Switch on the vacuum
cleaner to force the air through the blocked-up item in opposite direction (Fig. 21).
-
-
-
-
-
-
ENGLISH 9

10
一般说明(图1)
1 防尘罩
2 集尘袋
3 马达保护滤网
4 软管连接孔
5 软管接口
6 电源线回卷按钮
7 吸力控制旋钮
8 开/关钮
9 插头
10 过滤器栅格
11 AFS滤网
12 手柄
13 插槽
14 转轮
15 型号牌
16 后轮
17 尘量显示器
18 带吸力控制滑片的软管握把(FC8392)
19 附件夹
20 软管握把(FC8398/8396)
21 伸缩管(FC8398)
22 硬管(FC8396/8392)
23 Tri-Active全方位清洁吸尘嘴(FC8398)
24 组合吸嘴(FC8396/8392)
25 洁旋风吸尘嘴(FC8396)
26 洁旋风吸尘嘴微细纤维软垫
27 缝隙工具
28 小号吸嘴
29 小号毛刷(FC8398)
注意事项
使用产品之前，请仔细阅读本用户手册，并妥善保管以供日后参
考。
在将产品连接电源之前，请先检查产品所标电压与当地的供电电
压是否相符。
如果插头、电源线或产品本身受损，请勿再使用本产品。
如果产品的电源线损坏，为避免危险，必须由制造厂或其维修部
或厂方认可的专职人员来更换。
请将产品放置在儿童接触不到的地方。
切勿吸取水或其它液体。切勿吸取易燃物质，并且不要吸取未冷
却的灰烬。
当连接到真空吸尘器并且真空吸尘器已打开时，请勿将软管、硬
管或任何其它附件指向眼睛或耳朵，也不要放在口中。
-
-
-
-
-
-
简体中文

在使用本产品吸收灰尘、细沙、石灰、水泥灰和类似的物质时，
纸质集尘袋的的袋孔可能发生阻塞。因此，集尘袋已满指示灯将
显示集尘袋已满。这时，请更换集尘袋，即使集尘袋并未装满。
切勿在没有马达保护滤网的情况下使用本产品。这会损坏马达并
缩短产品的使用寿命。
只能使用飞利浦的s-bag`双层纸制集尘袋或循环使用集尘袋。
电磁场(EMF)
这款飞利浦产品符合关于电磁场(EMF)的相关标准。据目前的科学证明，如果正确使用并
按照本用户手册中的说明进行操作，本产品是安全的。
使用准备
软管
1 要将软管连接，将软管推入吸尘器并以顺时针方向旋转即可。 (图 2)
要将软管从吸尘器上拆下，请将管端逆时针方向转动，并拉出软管。
2 要将硬管互相连接起来，并连接到软管的手柄上，可以将较窄的一头插入较宽的一
头，并稍稍旋转。带夹子的硬管应处于较低位置。 (图 3)
其他附件也可以同样连接。
拉出硬管并稍稍旋转，即可断开附件和硬管。
伸缩管（仅限于特定机型）
1 将硬管调整到吸尘过程中感觉最舒适的长度。 (图 4)
组合吸嘴
组合吸嘴既能在地毯上使用（刷条内翻）也能在坚硬的地板上使用（刷条外翻）：
1 要清洁硬地板，请用脚推动组合吸嘴上的刷毛转换块。刷条将从吸嘴外壳中伸出
来。 (图 5)
2 要清洁地毯，请用脚按动转换块的另一面，使刷条缩入吸嘴中。 (图 6)
附件夹
附件夹可简单地扣合在硬管上。
缝隙工具和小号吸嘴（仅限于特定机型）可扣合在附件夹上。(图7)
使用本产品
吸尘
1 将电源线从吸尘器中拉出，并将电源插头插入插座。
2 用脚推动产品上的 on/off（开/关）按钮来开启电源。
您可以手握前方的把手提起吸尘器。
调整吸力
您可以通过以下方式调整吸力：
通过握把上的滑动开关即可调整吸力，或(图8)
通过吸力控制旋钮调整吸力（仅限于特定机型）。(图9)
-
-
-
-
-
-
-
简体中文 11

存放
1 关闭吸尘器的电源，从插座中拔下电源插头。
2 按下电源线回卷按钮将电线回卷到吸尘器中。
3 将吸尘器直立起来并利用夹子将下侧硬管装在吸尘器上。 (图 10)
更换
更换集尘袋
一旦集尘袋已满且指示灯持久改变颜色，应立即更换集尘袋。
更换集尘袋前，切记拔下电器插头。
1 打开集尘袋仓盖。 (图 11)
2 将集尘袋固定架向后推。 (图 12)
3 向上拉起纸板片将装满灰尘的集尘袋取掉。集尘袋会自动封闭。 (图 13)
4 将新的集尘袋的纸板片套入集尘袋固定架上的两个狭槽中。尽量向下按。 (图 14)
5 向前拉动集尘袋固定架（听到咔哒声）并关闭集尘袋仓盖。 (图 15)
注：如果尚未插入集尘袋，将无法关闭集尘袋仓盖。
飞利浦s-bag`纸质集尘袋的供应型号为FC8021。
循环使用集尘袋
如果有随附的循环使用的集尘袋，就可以不用纸制集尘袋。循环使用的集尘袋可于灰尘倒
空后重复使用。
拆下和安装可循环使用集尘袋的方法，仅按照更换纸制集尘袋的方法即可。
要倒空可循环使用集尘袋：
1 将夹子从集尘袋侧面滑下，取下夹子。
2 通过摇动倒出里面的积尘。
3 将夹子安装回集尘袋下端, 封闭集尘袋。
飞利浦可循环使用集尘袋的供应型号为434100492090。
更换过滤网
更换过滤网前，切记拔下电器插头。
马达保护滤网
每年更换一次马达保护滤网。
1 打开盖子并拆下滤网。
2 把一张新滤网插入支架，白色的一边朝上。 (图 16)
AFS微尘过滤网
每6个月更换一次AFS微尘过滤网。
1 在电器的后部打开栅栏 (1)，并拆下 (2)。 (图 17)
2 拆下旧滤网。把新滤网的侧边和底边正确地装入栅栏内侧固定架的 3 个凸缘
上。 (图 18)
3 将滤网格栅重新装入真空吸尘器。首先将滤网格栅的底边钩进产品 (1)，向产品的方向
推动格栅直到其扣合到位 (2)。 (图 19)
两个AFS微尘过滤网和一个马达保护滤网的供应型号FC8032。
简体中文12

环保
弃置产品时，请不要将其与一般生活垃圾堆放在一起；应将其交给官方指定的回收中
心。这样做有利于环保。(图20)
保修和服务
如果您需要详细信息或有任何问题，请浏览飞利浦网站，地址为www.philips.com。您也
可以与贵国的飞利浦顾客服务中心联系（您可以从全球保修卡中找到电话号码）。如果贵
国没有飞利浦顾客服务中心，请与当地的飞利浦经销商或与飞利浦家庭小电器的维修中心
联系。
故障种类和处理方法
1 吸力不足。
确保吸力控制旋钮在最大位置（仅限于特定机型）。
确保手柄上的滑动开关已关闭。
可能集尘袋已满。请更换集尘袋。
可能过滤网脏了。请更换过滤网。
检查吸嘴、硬管、软管是否被阻塞。要清除阻塞物，请将阻塞的部分拆下，并将它反
向连接（尽可能离远一些）。打开吸尘器的电源，强迫气流反方向通过阻塞的部
位。(图21)
-
-
-
-
-
-
简体中文 13

14 简体中文

15简体中文
2006/11/08

16

17

1818
2345
6789
10 11 12 13
14 15 16 17
18 19 20 21

19

4222.003.3069.3
