Philips FC8972 User manual

FC8972, FC8776,
FC8774, FC8772

1
2
3
4
5
6
7
8
9 10
12
13
14
15
18
19
20
21
2223O
17
11
16
1

English 6
Dansk 16
Deutsch 26
Español 37
Français 48
Italiano 59
Nederlands 70
Norsk 81
Português 91
Suomi 102
Svenska 112

English
Introduction
Congratulations on your purchase and welcome to Philips! To fully benefit from the support that
Philips offers, register your product at www.philips.com/welcome.
General description (Fig. 1)
1 Top cover
2 Handle of dust container lid
3 Dust container lid
4 Filter
5 Dust container
6 Fan
7 Bumper
8 Docking station sensor
9 Start/stop button (to start or stop the robot)
10 Display
11 TriActive XL nozzle
12 Front wheel
13 Side brush shafts
14 Drop-off sensors
15 Battery compartment
16 Wheels
17 Suction opening
18 Side brushes
19 Battery holder
20 Remote control
21 Small plug
22 Adapter
23 Docking station
Display and remote control
Display (Fig. 2):
1 Warning indicator
2 Dust container full indicator
Remote control (Fig. 3):
1 Navigation buttons and start/stop
2 Docking button
3 Cleaning time button
4 Cleaning mode buttons
How your robot works
What your robot cleans
This robot is equipped with features that make it a suitable cleaner to help you clean the floors in your
home.
The robot is especially suitable for cleaning hard floors, such as wooden, tiled or linoleum floors. It
may experience problems cleaning soft floors, such as carpet or rugs. If you use the robot on a carpet
or rug, please stay close by the first time to see if the robot can deal with this type of floor. The robot
also needs supervision when you use it on very dark or shiny hard floors.
6English

How your robot cleans
Cleaning system
The robot has a 2-stage cleaning system to clean your floors efficiently.
-The two side brushes help the robot clean in corners and along walls. They also help to remove dirt
from the floor and move it towards the suction opening (Fig. 4).
-The suction power of the robot picks up loose dirt and transports it through the suction opening
into the dust container (Fig. 5).
Cleaning patterns
In its auto cleaning mode, the robot uses an automatic sequence of cleaning patterns to clean each
area of the room optimally. The cleaning patterns it uses are:
1 Z-pattern or zigzag pattern (Fig. 6)
2 Random pattern (Fig. 7)
3 Wall-following pattern (Fig. 8)
4 Spot-cleaning pattern (Fig. 9)
In its auto cleaning mode, the robot uses these patterns in a fixed sequence:z-pattern, random
pattern, wall-following pattern, and spot-cleaning pattern.
When the robot has completed this sequence of patterns, it starts moving in Z-pattern again. The
robot continues to use this sequence of patterns to clean the room until the rechargeable battery runs
low, or until it is switched off manually.
Note: You can also select each mode individually by pressing the appropriate button on the remote
control. For more details, see chapter 'Using your robot', section 'Cleaning modes'.
How your robot avoids height differences
The robot has three drop-off sensors in its bottom. It uses these drop-off sensors to detect and avoid
height differences such as staircases.
Note: It is normal for the robot to move slightly over the edge of a height difference, as its front drop-
off sensor is located behind the bumper.
Caution: In some cases, the drop-off sensors may not detect a staircase or other height difference
in time. Therefore monitor the robot carefully the first few times you use it, and when you operate it
near a staircase or another height difference. It is important that you clean the drop-off sensors
regularly to ensure the robot continues to detect height differences properly (see chapter ' Cleaning
and maintenance' for instructions).
Before first use
Mounting the side brushes
1Unpack the side brushes and place the robot upside down on a table or on the floor.
2Push the side brushes onto the shafts on the bottom of the robot (Fig. 10).
Note: Make sure you attach the side brushes properly. Press them onto the shaft until you hear
them lock into position with a click.
Removing the protection tag from the remote control
The remote control works on a CR2025 coin-shaped battery. This battery is protected with a
protection tag that has to be removed before use.
7
English

1Pull the battery protection tag out of the battery compartment of the remote control (Fig. 11).
Now the remote control is ready for use.
Preparing for use
Installing the docking station
1Insert the small plug of the adapter into the socket on the docking station (1) and insert the adapter
into the wall socket (2) (Fig. 12).
2Place the docking station on a horizontal, level floor against a wall.
Note: Make sure that there are no obstacles or height differences 80 cm in front, 30 cm to the right
and 100 cm to the left of the docking station (Fig. 13).
Important note: deep sleep mode
In deep sleep mode, the robot does not respond at all when you press a button. To reactivate the
robot when it is in deep sleep mode:
1Press the start/stop button on the robot to bring the robot from deep sleep mode to standby
mode.
2Press the start/stop button on the robot (Fig. 19) or on the remote control to start the robot.
3If the robot does not start cleaning, place it on the plugged-in docking station to recharge its
rechargeable battery.
The robot enters deep sleep mode when you press the start/stop button for 3 seconds. It may also
enter the deep sleep mode when its battery is empty. The battery may, for instance, run empty if the
robot is unable to find its docking station.
Note: You cannot get the robot out of its deep sleep mode with the start/stop button on the remote
control. You need to press the on/off button on the robot.
Charging
-When charging for the first time and when the rechargeable battery of the robot is empty, the
charging time is four hours.
-When the rechargeable battery is fully charged, your robot can clean for up to 120 minutes.
-Your robot can only be charged on the docking station.
Charging on the docking station
1Press the start/stop button on the robot.
2Place the robot on the plugged-in docking station (Fig. 14).
3The start/stop button starts flashing slowly (Fig. 15).
4When the rechargeable battery is fully charged, the start/stop button lights up continuously (Fig.
16).
Charging automatically during use
1When the robot has finished cleaning or when only 15% of the battery power remains, it
automatically searches for the docking station to recharge. When the robot searches for the
docking station, the start/stop button flashes quickly (Fig. 17).
2When the rechargeable battery is fully charged, the start/stop button lights up continuously.
8English

Note: The robot only searches for the docking station automatically when it started cleaning from the
docking station.
Preparing the room for a cleaning run
Before you start the robot on its cleaning run, make sure that you remove all loose and fragile objects
from the floor (Fig. 18).
Also remove all cables, wires and cords from the floor.
Using your robot
Starting and stopping
1Press the start/stop button.
-You can press the start/stop button on the robot (Fig. 19).
-You can also press the start/stop button on the remote control (Fig. 20).
2The start/stop button is continuously on and the robot starts cleaning (Fig. 21).
3The robot cleans in the auto-cleaning mode until its battery runs low. In the auto-cleaning mode, it
follows repeated sequences of Z-pattern, random, wall-following and spot-cleaning patterns (Fig.
22).
Note: To select an individual mode, press one of the mode buttons on the remote control. See
section 'Cleaning mode selection' for more details.
4When the battery runs low, the start/stop button starts flashing and the robot searches for the
docking station to recharge (Fig. 17).
5You can also press the start/stop button to interrupt or stop the cleaning run. If you press the
start/stop button again and there is still enough energy in the rechargeable battery, the robot
continues cleaning in the auto-cleaning mode.
6To make the robot return to the docking station before the rechargeable battery runs low, press
the docking button on the remote control (Fig. 23).
The start/stop button starts flashing and the robot searches for the docking station (Fig. 24).
Note: If you did not start the robot from the docking station, it does not search for the docking
station automatically when the rechargeable battery runs low. If there is still enough energy in the
rechargeable battery, you can press the docking button on the remote control to make the robot
return to the docking station. If the rechargeable battery is completely empty, you have to place
the robot on the docking station manually.
Operating the docking station
The docking station has two controls that can be used to operate the robot.
Battery full and go button
If you press the battery full and go button on the docking station while the robot is charging, the robot
starts cleaning as soon as the rechargeable battery is full (Fig. 25).
24h button
If you press the 24h button on the docking station, the docking station starts to count down the 24
hours until the next cleaning run. When the countdown is finished, the robot starts cleaning until its
battery runs low and then returns to the docking station automatically to recharge (Fig. 26).
9
English

Cleaning mode selection
Next to the auto-cleaning mode, this robot has four individual cleaning modes that can each be
activated by pressing the appropriate button on the remote control.
Z-pattern mode
In Z-pattern mode, the robot cleans by making Z-shaped loops through the room to clean large areas
(Fig. 27).
Random mode
In this mode, the robot cleans the room in a mixed pattern of straight and crisscross movements (Fig.
28).
Wall-following mode
In this mode, the robot follows the walls of the room to give the area alongside the walls an extra
clean (Fig. 29).
Spot-cleaning mode
In this mode, the robot moves randomly on a small area to clean this area thoroughly (Fig. 30).
Note: The manually selected modes are only active for a couple of minutes. After that, the robot
switches to auto-cleaning mode.
Manual driving
1Use the arrow buttons above and below and to the left and right of the start/stop button on the
remote control to navigate the robot through the room. (Fig. 31)
Note: Be careful when you drive the robot manually close to height differences and staircases.
Note: The vacuuming function and the side brushes only work when the robot is driven forward.
The left, right or back buttons are only for maneuvering the robot.
Using the cleaning time button
Press the cleaning time button on the remote control to make the robot clean for 35 minutes. When
the cleaning time is finished, the robot returns to the docking station to recharge (Fig. 32).
Signals and their meaning
The robot has a display with two indicators: a warning indicator and the dust container full indicator.
The start/stop button gives light signals. The table below explains the meaning of the signals.
Signal Meaning
The start/stop button is on continuously. The robot is ready to clean.
The start/stop button flashes slowly. The robot is charging.
The start/stop button flashes quickly. The robot is is searching for the docking station.
The rechargeable battery of the robot is low.
The dust container full indicator lights up. The dust container is full.
The warning indicator lights up. The robot was lifted while it was cleaning.
10 English

Signal Meaning
The bumper of the robot is stuck.
A wheel or side brush is stuck.
The top cover is not present or is not closed
properly.
The robot cannot find the docking station.
Clap response
The clap response is enabled when the robot enters sleep mode in the following situations:
-when it stops cleaning due to an error
-when it cannot find its docking station in 20 minutes
If you do not see the robot, you can locate it by clapping your hands once. The robot will respond by
beeping and by lighting up all icons on its display.
Cleaning and maintenance
Emptying and cleaning the dust container
Empty and clean the dust container when the dust container full indicator lights up continuously.
1Remove the cover (Fig. 33).
2Pull up the handle of the dust container lid and lift the dust container out of the dust container
compartment (Fig. 34).
Note: When you remove or reinsert the dust container, take care not to damage the blades of the
motor fan.
3Carefully lift the lid off the dust container (1) and take out the filter (2) (Fig. 35).
4Shake the dust container over a dustbin to empty it. Clean the filter and the inside of the dust
container with a cloth or a toothbrush with soft bristles. Also clean the suction opening in the
bottom of the dust container (Fig. 36).
Caution: Do not clean the dust container and the filter with water or in the dishwasher.
5Put the filter back into the dust container (1). Then place the lid on the dust container(2) (Fig. 37).
6Put the dust container back into the dust container compartment and put the top cover back on
the robot (Fig. 38).
Caution: Always make sure the filter is present inside the dust container. If you use the robot
without the filter inside the dust container, the motor will be damaged.
Cleaning the robot
To maintain good cleaning performance, you have to clean the drop-off sensors, the wheels, the side
brushes and the suction opening from time to time.
1Place the robot upside down on a flat surface.
2Use a brush with soft bristles (e.g. a toothbrush) to remove dust or fluff from the drop-off sensors.
(Fig. 39)
Note: It is important that you clean the drop-off sensors regularly. If the drop-off sensors are dirty,
the robot may fail to detect height differences or staircases.
11
English

3Use a brush with soft bristles (e.g. a toothbrush) to remove dust or fluff from the front wheel and
side wheels (Fig. 40).
4To clean the side brushes, grab them by the bristles and pull them off their shafts (Fig. 41).
5Remove fluff, hairs and threads from the shaft and from the side brush with a soft brush (e.g. a
toothbrush) or a cloth (Fig. 42).
6Check the side brushes and the bottom of the robot for any sharp objects that could damage your
floor.
7After you have removed the side brushes from their shafts, undo the snap connections of the
TriActive XL nozzle by inserting your fingers at the places marked with arrows and pull the TriActive
nozzle off the robot (Fig. 43).
8Clean the suction opening with a soft brush (e.g. a toothbrush) (Fig. 44).
9Remove all visible dirt from the TriActive nozzle (Fig. 45).
10 Insert the snap hooks of the TriActive nozzle into the holes in the bottom of the robot (Fig. 46).
Push the TriActive nozzle back into position. Check if the nozzle can move a few millimeters up and
down freely.
Replacement
Ordering accessories
To buy accessories or spare parts, visit www.shop.philips.com/service or go to your Philips dealer.
You can also contact the Philips Consumer Care Center in your country (see the international warranty
leaflet for contact details).
Replacing the filter
Replace the filter if it is very dirty or damaged. You can order a new filter under order number FC8012.
See 'Emptying and cleaning the dust container' in chapter 'Cleaning and maintenance' for instructions
on how to remove the filter from the dust container and how to place it in the dust container.
Replacing the side brushes
Replace the side brushes after some time to ensure proper cleaning results.
Note: Always replace the side brushes when you notice signs of wear or damage. We also recommend
that you replace both side brushes at the same time. You can order spare side brushes as a set under
order number FC8013.
1To replace the side brushes, grab the old side brushes by the bristles and pull them off their shafts
(Fig. 41).
2Push the new side brushes onto the shafts (Fig. 10).
Replacing the rechargeable battery
The rechargeable battery of the robot may only be replaced by qualified service engineers. Take the
robot to an authorized Philips service center to have the battery replaced when you can no longer
recharge it or when it runs out of power quickly. You can find the contact details of the Philips
Consumer Care Center in your country in the international warranty leaflet or go to
www.philips.com/support.
12 English

Replacing the battery of the remote control
The remote control works on a CR2025 coin-shaped battery. Replace the battery when the robot no
longer responds when you press the buttons on the remote control.
1Hold the remote control upside down. Push the release button on the battery holder and at the
same time slide the battery holder out of the remote control (Fig. 47).
2Remove the empty battery from the battery holder and place a new battery in the battery holder.
Then slide the battery holder back into the remote control (Fig. 48).
Storage
When you are not going to use the robot for more than one month, press the start/stop button on the
robot for 3 seconds to make the robot enter deep sleep mode to protect its rechargeable battery.
Unplug the docking station to save energy.
Removing the rechargeable battery
Warning: Only remove the rechargeable battery when you discard the appliance. Make
sure the battery is completely empty when you remove it.
To remove the rechargeable battery, follow the instructions below. You can also take the robot to a
Philips service center to have the rechargeable battery removed. Contact the Philips Consumer Care
Center in your country for the address of a service center near you.
1Start the robot from a place somewhere in the room and not from the docking station.
2Let the robot run until the rechargeable battery is empty to make sure that the rechargeable
battery is completely discharged before you remove it and dispose of it.
3Undo the screws of the battery compartment lid and remove the lid (Fig. 49).
4Lift out the rechargeable battery and disconnect it (Fig. 50).
5Take the robot and the rechargeable battery to a collection point for electrical and electronic
waste.
Troubleshooting
This chapter summarizes the most common problems you could encounter with the appliance. If you
are unable to solve the problem with the information below, visit www.philips.com/support for a list
of frequently asked questions or contact the Consumer Care Center in your country.
Problem Possible cause Solution
The robot does not start
cleaning when I press the
start/stop button.
The rechargeable battery is
empty.
Charge the rechargeable battery (see
chapter 'Preparing for use').
The robot is in deep sleep
mode.
Press the start/stop button once to
reactivate the robot.When you press the
start/stop button again the robot starts
cleaning. If the rechargeable battery is
empty,place the robot on the plugged-in
docking station.
13
English

Problem Possible cause Solution
The robot does not
respond when I press
one of the buttons.
The robot's rechargeable
battery is empty'.
Place the robot on the plugged-in
docking station. After a few seconds, the
robot beeps and the display lights up.
The warning indicator
flashes quickly.
One or both wheels are
stuck.
Remove the fluff, hair, thread or wire that
is caught around the wheel suspension.
One or both side brushes are
stuck.
Clean the side brushes (see chapter
'Cleaning and maintenance').
The top cover is not present
or is not closed properly.
When the top cover is not present or is
not closed properly, the robot does not
work. Place the top cover on the robot
properly.
The bumper is stuck. Lift the robot so that its bumper comes
free. Place the robot at some distance
from the obstacle and press the
start/stop button to make it resume
cleaning.
The robot was lifted while it
was cleaning.
Place the robot on the floor. Then press
the start/stop button to make the robot
resume cleaning.
The robot does not clean
properly.
The bristles of one or both
side brushes are crooked or
bent.
Soak the brush or brushes in warm water
for a while. If this does not restore the
bristles to their proper shape, replace the
side brushes (see chapter 'Replacement').
The filter in the dust
container is dirty.
Clean the filter in the dust container with
a cloth or a toothbrush with soft bristles.
You can also clean the filter and dust
container with a regular vacuum cleaner
at a low suction power setting.
If brushing or vacuuming does not help to
clean the filter, replace the filter with a
new one. We advise you to replace the
filter at least once a year.
The suction opening in the
bottom of the dust container
is clogged.
Clean the suction opening (see chapter
'Cleaning and maintenance').
The front wheel is jammed
with hair or other dirt.
Clean the front wheel (see chapter
'Cleaning and maintenance').
The robot is cleaning a very
dark or shiny surface, which
triggers the drop-off sensors.
This causes the robot to
move in an unusual pattern.
Press the start/stop button and then
move the robot to a lighter colored piece
of the floor. If the problem continues to
occur on lighter colored floors, please go
to www.philips.com/support or contact
the Consumer Care Center in your
country.
14 English

Problem Possible cause Solution
The robot is cleaning a floor
that reflects sunlight quite
strongly. This triggers the
drop-off sensors and causes
the robot to move in an
unusual pattern.
Close the curtains to block sunlight from
entering the room. You can also start
cleaning when the sunlight is less bright.
The rechargeable battery
can no longer be charged
or runs empty very fast.
The rechargeable battery has
reached the end of its life.
Have the rechargeable battery replaced
by a Philips service center (see chapter
'Replacement').
The battery of the
remote control runs
empty too fast.
Perhaps you did not insert
the correct type of battery.
For the remote control, you need a
CR2025 coin-shaped battery. If the
problem persists, go to
www.philips.com/support or contact the
Consumer Care Center in your country.
The robot is moving in
circles.
The robot is in spot-cleaning
mode.
This is normal behavior. The spot-cleaning
mode can be activated when a lot of dirt
is detected on the floor for a thorough
clean. It is also part of the auto cleaning
mode. After approximately one minute
the robot resumes its normal cleaning
pattern. You can also stop the spot-
cleaning mode by selecting a different
cleaning mode on the remote control.
The robot cannot find the
docking station.
There is not enough room for
the robot to navigate
towards the docking station.
Try to find another place for the docking
station. See 'Installing the docking station'
in chapter 'Preparing for use'.
The robot is still actively
searching.
Give the robot around 20 minutes to
return to the docking station.
The robot was not started
from the docking station.
If you want the robot to return to the
docking station after a cleaning run, start
it from the docking station.
15
English

Dansk
Introduktion
Tillykke med dit køb, og velkommen til Philips! For at få fuldt udbytte af den support, Philips tilbyder,
skal du registrere dit produkt på www.philips.com/welcome.
Generel beskrivelse (fig. 1)
1 Topdæksel
2 Håndtag på låg til støvbeholder
3 Låg til støvbeholder
4 Filter
5 Støvbeholder
6 Ventilator
7 Stødfanger
8 Sensor til dockingstationen
9 Start/stop-knap (til start eller stop af robotten)
10 Display
11 TriActive XL mundstykke
12 Forhjul
13 Sidebørsteaksler
14 Sensorer
15 Batterirum
16 Hjul
17 Sugeåbning
18 Sidebørster
19 Batteriholder
20 Fjernbetjening
21 Lille stik
22 Adapter
23 Dockingstation
Display og fjernbetjening
Display (fig. 2):
1 Advarselsindikator
2 Indikator for fuld støvbeholder
Fjernbetjening (fig. 3):
1 Navigationsknapper og start/stop
2 Dockingknap
3 Knap til rengøringstid
4 Knapper til rengøringstilstand
Sådan fungerer din robot
Det kan din robot rengøre
Robotten er udstyret med funktioner, som gør den til et nyttigt rengøringsredskab, der hjælper med at
rengøre gulvene i dit hjem.
Robotten er især velegnet til rengøring af hårde gulve, som f.eks. trægulve, flisegulve eller
linoleumsgulve. Den kan have svært ved at rengøre bløde gulve, som f.eks. tæpper. Hvis robotten skal
bruges på et tæppe, skal man holde øje med den i starten for at se, om robotten kan klare den
16 Dansk

pågældende type gulvbelægning. Hold også øje med robotten, når den skal bruges på meget mørke
eller blanke og hårde gulve.
Sådan udfører din robot rengøring
Rengøringssystem
Robotten har et 2-trins rengøringssystem til effektiv rengøring af dine gulve.
-De to sidebørster hjælper robotten med at gøre rent i hjørnerne og langs vægge. De hjælper også
med at fjerne urenheder fra gulvet og flytte støvet hen mod sugeåbningen (fig. 4).
-Sugekraften i robotten opsamler løst snavs og transporterer det gennem sugeåbningen ind i
støvbeholderen (fig. 5).
Rengøringsmønstre
I auto-rengøringstilstanden anvender robotten en automatisk rækkefølge i sine rengøringsmønstre,
således at alle områder i rummet rengøres bedst muligt. De anvendte rengøringsmønstre er:
1 Z-mønster eller zigzag-mønster (fig. 6)
2 Tilfældigt mønster (fig. 7)
3 Væg-følgende mønster (fig. 8)
4 Spotmønster (fig. 9)
I auto-rengøringstilstand benytter robotten disse mønstre i en fast sekvens: z-mønster, tilfældigt
mønster, væg-følgende mønster og spotmønster.
Når robotten har gennemført denne sekvens af mønstre, vil den begynde at bevæge sig i Z-mønster
igen. Robotten fortsætter med at benytte denne sekvens af mønstre til rengøring af gulvet, indtil det
genopladelige batteri er næsten opbrugt, eller indtil den slukkes manuelt.
Bemærk: Du kan også vælge hver tilstand individuelt, ved at trykke på den relevante knap på
fjernbetjeningen. Der er flere oplysninger i kapitlet "Sådan bruges din robot" i afsnittet
"Rengøringstilstande".
Sådan undgår din robot højdeforskelle
Robotten har tre sensorer i bunden. Disse drop-off-sensorer bruges til at registrere og undgå
højdeforskelle, som f.eks. trapper.
Bemærk: Det er normalt, at robotten bevæger sig lidt ud over kanten på en højdeforskel, da den
forreste sensor er placeret bag stødfangeren.
Forsigtig: I visse tilfælde kan sensorerne ikke registrere en trappe eller en anden højdeforskel i tide.
Du skal derfor nøje holde øje med robotten de første par gange, den anvendes, samt når den
betjenes i nærheden af en trappe eller en anden højdeforskel. Det er vigtigt at rengøre sensorerne
regelmæssigt for at sikre, at robotten fortsat kan registrere højdeforskelle korrekt (se anvisninger i
kapitlet "Rengøring og vedligeholdelse").
Før apparatet tages i brug
Montering af sidebørsterne
1Pak sidebørsterne ud, og anbring robotten med bunden opad på et bord eller på gulvet.
2Skub sidebørsterne på akslerne på robottens bund (fig. 10).
17
Dansk

Bemærk: Sørg for at få sat sidebørsterne korrekt på robotten. Skub dem ind på akslen, indtil de
"klikker" hørbart på plads.
Sådan fjernes beskyttelsesmærket fra fjernbetjeningen
Til fjernbetjeningen skal bruges et CR2025 knapbatteri. Dette batteri er beskyttet med en
beskyttelsesstrimmel, der skal fjernes før brug.
1Træk batteriets beskyttelsesmærke ud af fjernbetjeningens (fig. 11) batterirum.
Nu er fjernbetjeningen klar til brug.
Klargøring
Installation af dockingstationen
1Sæt det lille stik på adapteren i tilslutningsstikket på dockingstationen (1).Sæt adapteren i en
stikkontakt (2) (fig. 12).
2Placer dockingstationen op mod væggen på et vandret, plant gulv.
Bemærk: Sørg for, at der ikke er forhindringer eller højdeforskelle 80 cm foran, 30 cm til højre for og
100 cm til venstre for dockingstationen (fig. 13).
Vigtigt meddelelse: Dyb dvaletilstand
I dyb dvaletilstand reagerer robotten slet ikke, når du trykker på en knap. Sådan genaktiverer du
robotten, når den er i dyb dvaletilstand:
1Tryk på start/stop-knappen på robotten for at vække robotten fra dyb dvaletilstand til
standbytilstand.
2Tryk på start/stop-knappen på robotten (fig. 19) eller på fjernbetjeningen for at starte robotten.
3Hvis robotten ikke starter rengøringen, anbringes den i dockingstationen, der er sluttet til en
stikkontakt, så det genopladelige batteri oplades.
Robotten går i dyb dvaletilstand, når du trykker på start/stop-knappen i tre sekunder. Den kan også
gå i dyb dvaletilstand, når batteriet er afladet. Batteriet kan f.eks. blive tømt, hvis robotten ikke kan
finde dockingstationen.
Bemærk: Du kan ikke få robotten ud af dvaletilstanden ved hjælp af start/stop-knappen på
fjernbetjeningen. Du skal trykke på on/off-knappen på robotten.
Opladning
-Når apparatet oplades første gang, og når robottens genopladelige batteri er brugt op, er
opladningstiden fire timer.
-Når det genopladelige batteri er fuldt opladet, kan robotten gøre rent i op til 120 minutter.
-Opladning af robotten kan kun ske i dockingstationen.
Opladning i dockingstationen
1Tryk på start/stop-knappen på robotten.
2Anbring robotten i den tilsluttede dockingstation (fig. 14).
3Start/stop-knappen begynder at blinke langsomt (fig. 15).
4Når det genopladelige batteri er fuldt opladet, lyser start/stop-knappen konstant (fig. 16).
18 Dansk

Automatisk opladning under brug
1Når robotten er færdig med rengøringen, eller når der kun er 15 % tilbage af batteriet, vil den
automatisk søge tilbage til dockingstationen for at blive opladet. Når robotten søger tilbage til
dockingstationen, blinker start/stop-knappen hurtigt (fig. 17).
2Når det genopladelige batteri er fuldt opladet, lyser start/stop-knappen konstant.
Bemærk: Robotten søger kun automatisk tilbage til dockingstationen, hvis den startede rengøringen
fra dockingstationen.
Rummet gøres klar til rengøring
Inden du sætter robotten til at rengøre, skal du sikre dig, at alle løse og skrøbelige genstande er fjernet
fra gulvet (fig. 18).
Fjern ligeledes alle kabler og snore fra gulvet.
Sådan bruges din robot
Start og stop
1Tryk på start/stop-knappen.
-Du kan trykke på start/stop-knappen på robotten (fig. 19).
-Du kan også trykke på start-/stopknappen på fjernbetjeningen (fig. 20).
2Start/stop-knappen er konstant på "on", og robotten begynder på rengøring (fig. 21).
3Robotten rengør i auto-rengøringstilstand, indtil batteriets kapacitet bliver lav. I auto-
rengøringstilstand følger den gentagne sekvenser med Z-mønster og tilfældige mønstre, væg-
følgende mønstre og spotmønstre (fig. 22).
Bemærk: For at vælge en individuel tilstand skal du trykke på en af tilstandsknapperne på
fjernbetjeningen. Se afsnittet "Valg af rengøringstilstand" for at få flere oplysninger.
4Når batteriet begynder at blive afladet, begynder start/stop-knappen at blinke, og robotten søger
tilbage til dockingstationen for at blive ladet op (fig. 17).
5Du kan også trykke på start/stop-knappen for at afbryde eller stoppe rengøringsarbejdet. Hvis du
trykker på start/stop-knappen igen, og der stadig er batterikapacitet nok på det genopladelige
batteri, fortsætter robotten med at gøre rent i auto-rengøringstilstand.
6For at få robotten til at vende tilbage til dockingstationen, inden det genopladelige batteri bliver for
lavt, skal du trykke på dockingknappen på fjernbetjeningen (fig. 23).
Start/stop-knappen begynder at blinke, og robotten søger tilbage til dockingstationen (fig. 24).
Bemærk: Hvis robotten ikke blev startet fra dockingstationen, vil den ikke automatisk søge tilbage
til dockingstationen, når det genopladelige batteri trænger til opladning. Hvis der stadigvæk er
strøm nok på det genopladelige batteri, kan du trykke på dockingknappen på fjernbetjeningen for
at få robotten til at vende tilbage til dockingstationen. Hvis det genopladelige batteri er
fuldstændigt afladet, skal du sætte robotten hen i dockingstationen manuelt.
Betjening af dockingstationen
Dockingstationen er forsynet med to knapper, der bruges til styring af robotten.
Knapperne Batteri opladet og Go
Hvis du trykker på knappen Batteri opladet og Go på dockingstationen, mens robotten oplades,
begynder robotten at gøre rent, så snart det genopladelige batteri er fuldt opladet (fig. 25).
19
Dansk

24h-knappen
Hvis du trykker på 24h-knappen på dockingstationen, begynder dockingstation at tælle ned fra 24
timer, indtil næste rengøring. Når nedtællingen er slut, begynder robotten at støvsuge, indtil batteriet
skal oplades. Derefter vender den tilbage automatisk tilbage til dockingstationen for at genoplade (fig.
26).
Valg af rengøringstilstand
Ud over auto-rengøringstilstanden har robotten fire individuelle rengøringstilstande, som hver kan
aktiveres ved at trykke på den pågældende knap på fjernbetjeningen.
Tilstanden Z-mønster
I tilstanden Z-mønster rengør robotten ved at lave Z-formede mønstre i rummet for derved at rengøre
store arealer (fig. 27).
Tilstanden tilfældige bevægelser
I denne tilstand rengør robotten rummet i et kombineret mønster af lige og krydsgående bevægelser
(fig. 28).
Væg-følgende tilstand
I denne tilstand følger robotten rummets vægge for ekstra rengøring (fig. 29) af arealerne langs
væggene.
Tilstanden Spot-rengøring
I denne tilstand bevæger robotten sig i et tilfældigt mønster på et begrænset areal for at foretage en
grundig (fig. 30) rengøring af dette område.
Bemærk: De manuelt valgte tilstande er kun aktive i et par minutter. Derefter skifter robotten til auto-
rengøringstilstand.
Manuel kørsel
1Brug piletasterne over, under og til højre og venstre for start/stop-knappen på fjernbetjeningen for
at navigere robotten gennem rummet (fig. 31).
Bemærk: Vær forsigtig, når du kører robotten manuelt i nærheden af højdeforskelle og trapper.
Bemærk: Støvsugningsfunktionen og sidebørsterne fungerer kun, når robotten kører fremad.
Knapperne venstre, højre eller tilbage bruges kun til at manøvrere robotten.
Brug af knappen til rengøringstid
Tryk på knappen til rengøringstid på fjernbetjeningen for at få robotten til at støvsuge i 35 minutter.
Når rengøringstiden er afsluttet, vender robotten automatisk tilbage til dockingstationen for at lade op
(fig. 32).
Signaler og deres betydning
Robotten er forsynet med et display med to indikatorer: en advarselsindikator og en indikator for fuld
støvbeholder. Start/stop-knappen afgiver lyssignaler. I tabellen nedenfor er signalernes betydning
forklaret.
20 Dansk
