Philips ADD4952 User manual

ADD4952
Dispenser
User Manual

Main technical specication
1 1
Product overview
2 2
Instruction
3 3
4 3
Precautions
5 5Cleaning and maintenance
6 5Trouble shooting
6
6
Guarantee and Service
7
Packing list
8
Content

1
1 Main technical specication
≥90℃, 4L/h
≤10℃，2L/h
S T/ T
R134a, 38g
≤90%
I
Model
Rated voltage
Rated frequency
Heating power
Cooling power
ADD4952
220V-240V~
50Hz/60Hz
420W
85W
Hot water
Cold water
Environmental temp.
Coolant
Relative humidity
Protection of anti-electric shock

2
2 Product overview
5
7
8
6
Hot water button
1
Cold water button
2
Water faucet
3
Lower cabinet
4
Power switch
5
Power cord
6
Drain Plug
7
Condenser
8
Indicator
9
Bottle seat
10
1
10
2
9
3
4

3 Instruction
· Unpack the water dispenser. Place the dispenser indoors, on a at surface and at a distance
no less than 15 cm from the back wall.
· Insert the bottle vertically on the seat
· Press the hot water button until water ows out from the faucet.
· Insert the power plug to the wall socket.
· Turn on the power switch on the back of the unit to heat or cool the water. The indicator light
will be on when heating or cooling is working. To get optimal temperature, do not turn o the
power switch until heating or cooling is done.
· Enjoy the hot or cold water you need.
· If you do not need hot or cold water, turn o the power switch to conserve energy.
· The drain plug on the back of the unit may become loose during shipping. Fasten the drain
plug tightly before you start to operate the unit. If the drain plug is loose, the unit may leak
and cause oor damage.
· Make sure to have poured water from the water faucet before plugging and switching the
appliance ON to heat. If the dispenser is turned ON with an empty water tank, it can be
damaged.
· When you are ready to move the water dispenser, do not tilt more than 45º to avoid damage
to the compressor.
· Keep this appliance away from high temperatures and in a dry and ventilated place.
Never install it in the open air or under rain or direct sunlight.
4 Precautions
3
At the back of the dispenser there is a red switch which controls the heating power, and a
green switch controlling the cooling power.
You can turn it on when you need hot or cold water.
When you rst turn on the switch, for optimal temperature, the dispenser will need around 20
minutes for hot water and around an hour for cold water.
Heating switchCooling switch
Power Switch

· Children should not use the red hot water tap.
· If the appliance is not going to be used for a long period of time, unplug it and drain all water
in its interior.
· Before the rst use and after a long period of not using it, the water tank and water pipes
should be cleaned well. If possible, they should be disinfected, and the rst heated water
must be discarded (turn o the heating switch while draining the system).
· Wash and disinfect the system every 3-6 months with a suitable cleaner and according to its
instructions for use.
· Do not pull out the cable to unplug. Do not turn on and o the appliance by connecting it
and disconnecting it from the source of electricity.
· Do not clean the outside of the appliance with water to avoid of electric shock. Clean it with a
soft cloth.
· If you are not using the appliance for a long period of time or during the night, you can turn it
o to save energy.
· Do not attempt to change the power cord by yourself if it has any damage. Contact the
aftersales personnel for support.
· If the power cable suers any damage, contact the aftersales personnel for support.
· Use only properly grounded outlets.
· WARNING – to avoid the risks of an unstable installation, the equipment must be installed
following its instruction.
· WARNING - keep the ventilation openings at the back of the appliance uncovered and
unobstructed.
· NOTICE - do not damage the refrigerant circuit.
· The environmental temperature for this appliance should be between 18° C and 38 ° C.
· The appliance is not to be used by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction.
· Children being supervised should not play with the appliance.
· Do not store explosive substances such as aerosol cans with a ammable propellant in this
appliance.
· This appliance is intended to be used in household and similar applications
such as: IEC 60335-2-15.
- sta kitchen areas in shops, oces and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
· WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
· WARNING: Do not locate multiple portable socket outlets or portable power supplies at the
rear of the appliance.
4

5 Cleaning and maintenance
6 Trouble shooting
· To avoid accidents, turn o and unplug the water dispenser from the outlet before cleaning.
· A soft damp cloth may be used to clean the surface of the water dispenser. When necessary,
a mild detergent may be used. DO NOT use corrosive chemical solvents to clean the unit, as
this may damage the surface of the water dispenser.
· DO NOT pour water on the exterior of the unit to avoid getting the internal electrical system
wet . DO NOT immerse the unit in water when cleaning.
· The water bottle cap, hose, and drip tray may be washed in a dishwasher (top rack only).
· Keep the water dispenser 6 inches (15cm) away from the wall so it can work properly. Make
certain all ventilation openings are clear of obstruction.
· Do not damage the heating or cooling system, paying particular attention to the black
condenser or heating radiator on the back of the water dispenser.
· If you will not use the water dispenser for a long period of time, please unplug the power
cord and drain the water dispenser. Drain the water from all faucets, then remove the drain
plug on back and allow it to drain. Make certain the drain plug is fastened tightly when
nished.
Trouble Possible causes Solutions
1.Appliance is not connected to the
electrical system
2.The switch is not on
1.The water tank is broken
2.The water pipe is broken
3.The faucet is damaged
1.Heating switch is damaged or
not connected well
2.The heating tank is broken
3.The electrical connection is loose
1.Cooling switch is damaged or
makes no contact
2.The electrical connection is loose
1.Make sure that the switch is ON
and the plug is connected
2.Turn the switch into on
Lights do
not lit
Leaking
Not heating
Not cooling
Contact aftersales personnel for
support
Contact aftersales personnel for
support
Contact aftersales personnel for
support
5

7 Guarantee and Service
8 Packing list
This product includes a two-year warranty for the dispenser and three-year warranty for
compressor from the date of purchase. If you need more information, please
visit: www.Philips.com.
Within the warranty period, you will receive free warranty service for any damage caused
by the manufacturing process or components under normal operation conrmed by our
maintenance service.
The warranty service does not include frequent replaced consumable components (water
purier lter, pitcher lter, granular activated carbon, ion exchange resin, hollow ber
membrane, etc.)，auxiliary devices, transportation fee and door-to-door service.
Please show the proof of purchase to the service personnel during maintenance.
You cannot receive free warranty service under the following conditions:
1. Damage by improper operation, such as improper components connection, improper
installation, deprived of manual use, misoperation.
2. Negligence and damage because of transportation or other accident.
3. Maintenance and modication without approval.
4. Other damage caused by force majeure (such as natural disaster, abnormal voltage, etc.).
5. Damage caused by general use outside home (e.g. industrial and commercial use).
6. Aging, wear and tear caused by normal operation of the product without aecting normal
operation of the product.
This statement serves as a publicity for free maintenance within the specied time limit and
conditions, and does not limit the legal rights of consumers.
Water dispenser
User Manual
Supporting bracket kit
1x
1x
1x
6

Please keep this user manual for future reference.

© 2019 AquaShield
All rights reserved.
The Philips trademark and the Philips Shield Emblem are registered trademarks
of Koninklijke Philips N.V. used under license.
This product has been manufactured by and is sold under the responsibility of Hong Kong AquaShield Health
Technology Company Limited and Hong Kong AquaShield Health Technology Company Limited is the warrantor in
relation to this product.
Rev A Sep 19
Specications are subject to change without notice
