Phoenix Model CESSNA AWAGON User manual

Instruction Manual
Wingspan: 2560mm
Length : 1600mm
Weight : 5500g - 6000g
Radio : 7 servo / 6 channel
Engine : 91 - 120 two stroke
g

MOTOR MOUNT ASSEMBLY
. (1) Engine mount
. (8) 4mm x 30 mm screw
. (8) Block washer
. (8) 8mm flat washer
. (8) Nut
THROTTLE CONTROL SYSTEM
. (1) 1.3mm x 600mm metal pushrod
. (1) 3.5mm x 350mm nylon housing
. (1) Metal connector
FUEL TANK
. (1) Nylon fuel tank
. (1) Metal clunk
. (1) Pre - assembled stopper w / 3 tube
MISCELLANEOUS ITEMS
. (1) 32mm x 455mm aluminum dihedral
. (2) 19mm x 360mm aluminum dihedral
. (1) Spinner
. (12) 2,6mm x 10mm wood screws
. (6) 4mm x 35mm wood screws
. (6) 8mm flat washer
. (4) Wing screws
. (2) 4mm x 30mm nylon screws
. (3) 1.7mm x 900mm metal pushrod
. (2) 600 trim tape (white)
. (1) 400 trim tape (red)
. (2) Gear pant
. (1) Wing tip cover
. (2) Wing strut
. (2) Plastic joiner
. (1) Cowling
. (1) Decal
MAIN GEAR ASSEMBLY
. (2) Main gear
. (2) 100mm diameter wheels
. (2) Set of alxe
. (4) 4mm x 20mm screws
. (4) Block washer
. (4) 8mm flat washer
TAIL GEAR ASSEMBLY
. (1) Tail gear
. (3) Collar
. (1) 35mm diameter wheel
ELEVATOR CONTROL SYSTEM
. (2) Control horn
. (2) 3mm x 45 mm screw
. (2) Nylon horn
. (2) Metal clevis M2
. (2) Silicon tube
. (1) Domino connector
. (1) 1.7mm x 100mm metal pushrod
. (1) Nylon snap keeper

Instruction Manual CESSNA AWAGON
2
1 2
3 4
5 6
7 8
Iron the covering if necessary. Glue the hinges by C.A glue.
Remove the covering.
Remove the covering.
Make the center line onto the joiner. Gluing the wing by Epoxy glue.
Apply the trim tape to the center section. Remove the covering.
1
1Joining the wing:
C.A glue

Instruction Manual CESSNA AWAGON
3
910
11 12
13 14
15 16
Tape the servo lead to the thread. Using the thread as a guide.
Pull the servo lead out. Tape the servo lead onto the wing.
Install the aileron servo. Make the same way for the flat servo.
Tape the servo lead onto the wing. Aileron and flap linkage.

Instruction Manual CESSNA AWAGON
4
17 18
19 20
21 22
23 24
Install the control horn for the aileron. Install the control horn for the flap.
Insert the clevis onto the metal rod. Insert the silicone tube into the clevis.
Attach the clevis into the cotnrol horn. Cut away the metal rod.
Bend “L” the aileron pushrod. Attach the nylon snap keeper to the aileron servo arm.

Instruction Manual CESSNA AWAGON
5
25 26
27 28
29
30 31
Attach the nylon snap keeper to the aileron servo arm. Install the flat linkage as the same installing the aileron linkage.
The wing tip. Remove the covering.
Glue the wing tip to the wing using the Epoxy glue.
Make the center line onto the horizontal. Remove the covering.
1
2Installing the horizontal and the vertical:
Center line

Instruction Manual CESSNA AWAGON
6
32 33
34
35 36
37 38
Glue the elevator hinge by C.A glue. Insert the horizontal to the fuselage and check it.
Check the horizontal.
Mark the shape of the fuselage onto the horizontal.
Remove the covering. Glue the horizontal to the fuselage by Epoxy glue.
Remove the covering from the rear of the vertical. Mark the shape of the vertical onto the fuselage.

Instruction Manual CESSNA AWAGON
7
39 40
41 42
44 45
Mark the shape of the vertical onto the horizontal. Remove the covering from the fuselage.
Remove the covering from the horizontal.
Glue the verticcal to the fuselage by Epoxy glue.
43
Glue the verticcal to the horizontal by Epoxy glue.
Check the rudder.
The tail gear. Install the wheel and the collar into the tail gear.
1
3Installing the tail gear and the rudder:
a1 a2
a1 = a2

Instruction Manual CESSNA AWAGON
8
46 47
48 49
50 51
52 53
Remove the covering. Remove the covering.
Remove the covering.
Insert the rudder into the vertical stabilizer.
Slide the tail gear into the fuselage and the rudder,
and than secure it. Glue the hinge by C.A glue.
The landing gear set. Remove the covering.
1
4Installing the landing gear:

Instruction Manual CESSNA AWAGON
9
54 55
56
57 58
59 60
Install the metal connector into the landing gear. Install the landing gear to the fuselage.
Secure the plastic cover for the landing gear.
Install the elevator control horn same as installing the aileron
linkage. Attach the clevis to the elevator pushrod.
Insert the silicone tube into the clevis. Remove the covering.
1
5Installing the elevator pushrod:

Instruction Manual CESSNA AWAGON
10
61 62
63
64 65
66 67
Insert the elevator pushrod into the fuselage. Attach the clevis to the control horn.
Make the same way for the second elevator pushrod.
Install the rudder control horn same as installing the aileron
linkage. Insert the silicone tube into the clevis.
Attach the clevis to the rudder pushrod. Remove the covering.
1
6Installing the rudder pushrod:

Instruction Manual CESSNA AWAGON
11
70 71
72 73
74 75
Install the elevator servo and secure it.
Prepare the metal connector.
68 69
Insert the rudder pushrod into the fuselage.
Attach the clevis into the control horn.
Secure the elevator pushrod. Attach the nylon snap keeper to the servo arm.
Install the rudder servo and secure it. Cut away the rudder pushrod.
1
7Installing the servo of the elevator and the rudder:

Instruction Manual CESSNA AWAGON
12
76 77
78 79
80 81
82 83
Bend “L” the rudder pushrod. Attach the nylon snap keeper to the servo arm.
The engine mount.
Install the engine mount.
Prepare the stopper for the tank. Install the silicone tube of the tank (not included).
Secure the stopper. Install the silicone tube of the tank (not included).
1
8Installing the fuel tank and the engine mount:

Instruction Manual CESSNA AWAGON
13
84 85
86 87
88 89
90 91
Slide the fuel tank to the fuselage and secure it. Attach the engine to the engine mount and mark four holes.
Drill four holes onto the engine mount.
Attach the throttle rod to the arm of the carburator.
Install the engine and secure it. Secure the muffler.
Install the throttle servo. Install the metal connector to the servo arm.
1
9Installing the throttle servo:

Instruction Manual CESSNA AWAGON
14
92 93
94 95
96 97
98 99
Install the servo arm. Attach the throttle rod into the metal connector and secure
it.
Trim the cowl. Install the cowl.
Install the propeller. Install the spinner.
Install and secure the switch. The switch.
1
10 Installing the cowl, propeller:
1
11 Installing the switch:

Instruction Manual CESSNA AWAGON
15
100 101
102 103
104 105
106 107
Glue the plastic part to the wing joiner. Find the hole on the top of the wing by taking measurements.
Drill through the hole you make with a 2.5mm drill bit
(Note: just through the wing joiner).
Secure the wing joiner using a 4mm x 35mm wood screw.
Secure the wing using the two black nylon screw. Install the receiver and battery.
The wing strut. Secure the wing strut to the wing.
1
12 Installing and secure the wing:
1
13 Installing the wing strut:
138mm
84mm
BOTTOM
OF WING
Screw Receiver Battery

108
Secure the wing strut to the fuselage.
16
BALANCING
1. It is critical that your airplane be balanced correctly.
Improper balance will cause your plane to lose
control and crash.
THE CENTER OF GRAVITY IS LOCATED 175mm
BACK FROM THE LEADING EDGE OF THE WING,
AT THE FUSELAGE.
2. Mount the wing to the fuselage. Using a couple of
pieces of masking tape, place them on the top side of
the wing 175mm back from the leading edge, at the
fuselage sides.
3. Turn the airplane upside down. Place your fingers on
the masking tape and carefully lift the plane .
4. If the nose of the plane falls, the plane is heavy nose.
To correct this first move the battery pack further
back in the fuselage. If this is not possible or does not
correct it, stick small amounts of lead weight on the
fuselage under the horizontal stabilizer. If the tail of
the plane falls, the plane is tail heavy. To correct this,
move the battery and receiver forward or if this is not
possible, stick weight into the firewall. When balanced
correctly, the airplane should sit level or slightly nose
down when you lift it up with your fingers.
LATERAL BALANCE
After you have balanced a plane on the C.G. You
should laterally balance it. Doing this will help the
airplane track straighter
1. Turn the airplane upside down. Attach one loop of
heavy string to the engine crankshaft and one to the
tail wheel wire. With the wings level, carefully lift
the airplane by the string. This may require two
people to make it easier.
2. If one side of the wing fall, that side is heavier than
the opposite. Add small amounts of lead weight to
the bottom side of the lighter wing half's wing tip.
Follow this procedure until the wing stays level
when you lift the airplane.
CONTROL THROWS
1. We highly recommend setting up a plane using the
control throws listed.
2. The control throws should be measured at the widest
point of each control surface.
3. Check to be sure the control surfaces move in the
correct directions.
175mm
